Vetta c-500 User manual

CYCLE COMPUTER OWNER'S MANUAL
ENGLISH FRANÇAIS ESPANOL DEUTSCH ITALIANO
˜
Congratulations on your purchase of the Vetta C-500 wireless cycle computer. The C-500’s advanced wireless
design has been engineered to significantly reduce false readings caused by outside interference. Its large
buttons and unique universal transmitter also make the C-500 an ideal unit for installation on suspension
mountain bikes.
INTRODUCTION
WARNINGS AND CAUTIONS
!
!
!
CAUTION Vetta Sports encourages you to ride safely. Wear a helmet every time you ride, use a front
and rear light at night, and always keep your eyes on the road ahead of you.
CAUTION Vetta cycle computers are sophisticated electronic instruments. Vetta recommends that this
product be installed only by a qualified bicycle retailer. Failure to read these instructions and improper
installation of this device may void the warranty. If you are in doubt about any aspect of the installation or
operation of this product, consult your local bicycle retailer for clarification.

DRAWINGS OF PARTS
Head Unit
Flat Rubber Block Angled Rubber Block Head Unit Battery Transmitter Battery Magnet
Rubber ShimsTransmitter Bracket
MAGNET
UP
SPEEDOMETER ( ) ( or
)
Tells you your instantaneous speed. Accurate to 0.5 mph or kmph
AUTOMATIC RIDE TIME STOPWATCH ( )
Stopwatch activated by wheel movement, turning on when you ride and off when
you stop. Records true ride time, time spent actually riding, up to 9:59:59.
SPEED COMPARATOR ( or )
Compares current speed to average speed. As you are riding a ( ) or a ( ) will
appear in the upper right hand corner of the display. This will indicate whether
your current speed is faster ( ) or slower ( ) than your current average speed.
This function is automatic, requiring no programming and cannot be disabled.
TRIP ODOMETER ( )
Tells you the distance for your current ride from 0 to 999.9 mi. or km.
AVERAGE SPEED ( )
Your average speed calculated using your true ride time and trip distance.
LISTING OF FUNCTIONS

CUMULATIVE ODOMETER ( )
Tells you your cumulative distance for the year from 0 to 99999 mi. or km.
MAXIMUM SPEED ( )
Displays the fastest speed that you have traveled.
DIGITAL 12 HOUR CLOCK
Gives you the time of day in a 12 hour format.
AUTO SHUT DOWN
As a battery saving device, Vetta computers will automatically shut down after
5-10 minutes of non-use. Because it is wireless, once the C-500 has entered the
sleep mode, you must press one of the two buttons to reactivate the unit.
FREEZE FRAME MEMORY (FLASHING DISPLAY)
This feature allows you to store a snapshot of the display for an extended period
of time. This feature is useful at the end of a race, allowing you to hold a record
of your time, distance, average speed and maximum speed while you are cooling
down. While the display is frozen, the computer will continue to update and store
ride information. All information is updated and displayed as soon as the freeze
frame memory is turned off.
ACTIVATE FREEZE FRAME MEMORY
In any mode, press the upper computer key (B) for approximately 1 second. The entire display will flash
indicating that the feature is active. You may now cycle through the functions by pressing the lower key (A).
DEACTIVATE FREEZE FRAME MEMORY
Press the upper computer key (B) to update the display and return to normal operation.
RESET CYCLING FUNCTIONS
In the / mode, press both keys for 2 seconds to clear the , , and displays.

BATTERY INSTALLATION
The head of the C-500 uses a common 3032 3v lithium button cell battery, and
the transmitter uses a common 23A 12v battery. Replacement batteries are
available at most camera shops and from your Vetta retailer. Under normal usage
a battery should last approximately one year.
NOTE: Most problems that occur
with cycle computers are caused by dead or weak batteries. If you are having
problems with your computer's operation, check and replace the battery first.
INSTALLATION OF HEAD UNIT BATTERY
STEP 1
Remove the battery cover from the bottom of the computer using a small flat
blade screwdriver.
STEP 2
Install the battery into the battery compartment with the positive (+) side of the
battery facing the compartment door. Be careful when you are installing the
battery not to bend any of the battery contacts.
3032 3v Lithium Battery
AUTO CLEAR BUTTON
Press for total reset of unit.
All stored data will be erased.
!CAUTION
!
STEP 3
Press the battery cap firmly into place making sure that the rubber o-ring seal
does not get pinched or distorted as this will compromise the waterproofing of
the unit.
INSTALLATION OF TRANSMITTER BATTERY
The transmitter should come from the factory with the 23A 12v battery installed.
STEP 1
To replace the battery, first remove the battery cap on the top of the transmitter
with a coin. Remove the old battery and dispose of properly.
NOTE: Check
the inside of the transmitter for corrosion. If corrosion is visible replace the
transmitter with a new unit.
STEP 2
Install a new battery in the transmitter battery compartment with the positive
(+) side facing the opening and reinstall the battery cap.
CAUTION Make sure that the battery cap is tight to prevent moisture from
entering the transmitter unit. An improperly installed battery can damage the
23A 12v Battery
MAGNET
UP

“A” BUTTON (BOTTOM)
Controls progressing through functions and settings, and advances the screen
while programming the computer.
“B” BUTTON (TOP)
Controls advancing through the digits while programming the computer and
activating the Freeze Frame memory function.
BUTTON FUNCTIONS
Now that you are familiar with the features of your Vetta cycle computer, you are ready to begin programming
the unit specifically for your bike. Take a few minutes to familiarize yourself with the buttons and keystroke
sequences before you proceed to the programming of the unit.
PROGRAMMING THE HEAD OF THE COMPUTER
“A”
“B”
All Vetta cycle computers are capable of being programmed to read out in either
miles or kilometers. It is also possible to change back and forth between miles
and kilometers by simply reentering the setting program and changing your
choice of measurements.
STEP 1
With the computer in the / mode, press the lower key (A) for over 2 seconds.
STEP 2
The screen will clear and the icon will flash along with the Default Wheel
Size Setting of 2074mm (700 x 20c). Press the upper key (B) to select either miles
( ) or kilometers ( ).
STEP 3
Set your choice and advance to the wheel size setting mode by pressing the lower
key (A) again.
SETTING MILES/HOUR OR KILOMETERS/HOUR

DETERMINING YOUR PROPER WHEEL SIZE
Vetta cycle computers are programmed using the circumference of the wheel measured in millimeters. Note
that while your computer can be programmed to +/- 1mm for total accuracy, discrepancies of as much as
50mm or more will not have a significant effect on the accuracy of the unit for most normal rides.
The following chart lists the programming sizes for some of the most popular wheel sizes currently in use.
These numbers are estimations and may vary slightly from the size of your actual wheel depending on the
manufacturer of the tire that you are using.
26 x 1.7
26 x 1.9
27 x 1.0 700c Tubular
26 x 2.1 700 x 38c
26 x 2.0
700 x 25c
700 x 28c
700 x 32c
27 x 1-1/4
650 x 20c
700 x 23c
700 x 20c
650 x 23c
2035
2055
2075
2095
2140
2180
1945
1990
2124
2140
2155
2074 2170
2114 2130
TIRE SIZE TIRE SIZE TIRE SIZE
CIRC. CIRC. CIRC.
WHEEL SIZE CALCULATION
If the wheel size of your bike is not listed in the chart, follow these simple steps to calculate the calibration
number for your bike.
STEP 1
Measure the distance from the center of the front axle to the ground in millimeters. If you are measuring in
inches, multiply the number of inches by 25.4 to get millimeters. If you want total accuracy make this
measurement while you are sitting on the bike.
STEP 2
Multiply the above number by 6.2832 (2π).
STEP 3
Enter the resulting number into the computer.
PRESET VALUE
The C-500 has a factory preset wheel size value of 2074 (700 x 20c).

PROGRAMMING YOUR WHEEL SIZE
STEP 1
Once you select miles ( ) or kilometers ( ) and press the lower key
(A), the C-500 will automatically advance into the wheel size setting mode. (See
SETTING MILES/HOUR OR KILOMETERS/HOUR)
STEP 2
The right hand digit (4) will begin flashing. Use the upper key (B) to advance to the
number that you want.
NOTE: Hold the upper key (B) to fast advance through the digits.
STEP 3
Press the lower key (A) to set the number and advance to the next flashing digit (7).
STEP 4
Repeat this sequence until all digits are at the appropriate settings.
STEP 5
Press the lower key (A) one final time to enter the wheel size setting into memory
and advance the unit back to the /screen.
The Vetta C-500 cycle computer is equipped with a digital clock that displays time
in a 12 hour format.
STEP 1
With the display in the mode, press the lower key (A) for 2 seconds.
STEP 2
The screen will clear and the hour digits will begin to flash. Advance the digits
using the upper key (B).
NOTE: Hold this key to fast advance through the digits.
STEP 3
When you have selected the correct digit, press the lower key (A) to enter the digit
and advance to set the minutes using the same procedure as above.
STEP 4
Press the lower key (A) to set the minutes and return to the screen.
SETTING THE CLOCK

MAGNET, SENSOR AND BRACKET INSTALLATION
Because your C-500 is wireless, the mounting of the unit is simple and straight
forward. Begin by mounting the head unit and bracket to the handlebars.
STEP 1
Clamp the bracket around the handlebars and tighten in place. All Vetta cycle
computer brackets are designed to work with 26.0 - 26.4mm standard
diameter road handlebars. Shims are provide to fit smaller 25.4mm mountain
and road bars. Make sure not to over tighten the bracket as this may result in
breakage. The bracket only needs to be tightened enough to keep it from
spinning on the handlebar during normal riding.
STEP 2
Loosely, mount the C-500 transmitter to the leading edge of your left fork
blade using the flat rubber block and the 2 zip-ties provided. The arrow
printed on the side of the transmitter should be facing the spokes and pointing
toward the bracket on the handlebars.
Installation Diagram
!
On some bikes it may be necessary to use the angled spacer that is provided
in place of the flat spacer, in order to get the transmitter to line up correctly
with the head unit.
STEP 3
Attach the spoke magnet to the wheel, and adjust the alignment of the magnet
and transmitter so that the magnet passes the transmitter within 1-2mm of
the small line molded into the lower part of the transmitter and the word
MAGNET
printed on the side of the transmitter.
CAUTION The C-500 uses an offset bracket design. It is designed to be
supported by the handlebar stem when it is installed. It is NOT necessarily
designed to fit directly over the center of the handlebar stem. Especially if this
causes the bracket to be bent or deformed. Install the C-500 bracket so that
the stem provides support and a firm platform for the computer.
Transmitter
Fork Leg
Alignment
Arrow
1-2mm
Wheel
Magnet
Correct
Incorrect

HEAD UNIT INSTALLATION
!
The heads of all Vetta computers are designed to lock into their brackets.
When installing your computer head into the bracket you should hear an
audible “SNAP” indicating that the unit is locked firmly in place. The head of
the C-500 will slide into the bracket from the back to the front, this feature
keeps the unit from inadvertently being pushed out of the bracket during
normal use.
CAUTION Because the C-500 is a wireless cycle computer, it will operate
without being fully secured in the bracket. BE SURE THAT THE HEAD IS
FULLY LOCKED IN PLACE IN THE BRACKET BEFORE USING THE UNIT.
Once you have finished with the installation procedure, you are ready to test the unit to make sure that it works.
STEP 1
Advance the computer to the speedometer mode.
STEP 2
Pick up the front of the bicycle and spin the front wheel. The computer should register speed within 1-2 seconds.
If you do not get a speed reading, check to be sure that the magnet and sensor alignment is correct and that
the space between the magnet and sensor is 1-2mm or less. If this does not solve the problem, call the Vetta
customer service hotline at 1.800.GO.VETTA.
TEST OF INSTALLATION

Vetta Sports warrants all Vetta products, to the original purchaser, to be free of defects in materials or
workmanship for a period of one year from the original date of purchase. Vetta Sports will, at its sole
discretion, repair or replace any product deemed defective. This express warranty is in lieu of all other
warranties, either expressed or implied. Any warranties of merchantability of fitness for a particular purpose
are limited to the one year duration of the above express warranty. Vetta Sports will not be held liable for any
incidental or consequential damages.
If you ever experience a problem with the function of your Vetta C-500 cycle computer, please visit your local
Authorized Vetta Dealer for assistance.
Should you experience a problem with your Vetta C-500 cycle computer that can not be solved by your local
Authorized Vetta Dealer, please ask them to comply with the following simple steps to assure quick and
efficient processing of your claim.
WARRANTY
WARRANTY RETURN AND REPAIR PROCEDURE
STEP 1
Fill out the warranty information card within this manual.
STEP 2
Call the appropriate Vetta Customer Service number listed below for help or to obtain a Return Authorization
Number (RA Number).
STEP 3
Send the unit back to the appropriate Vetta Customer Service Center along with the original copy of your
purchase receipt and a detailed explanation of the problem you are experiencing.
Vetta Customer Service USA Vetta Customer Service Europe
1500 Kearns Boulevard Suite A-200 Via E. Fermi 4
Park City, UT 84060 USA Casella d'Asolo (TV) 31010 Italy
Phone: 1.800.GO.VETTA or 1.801.647.2929 Phone: 39.423.524094
Fax: 1.801.647.2947 Fax: 39.423.524199
Serving: US, Canada, South America, Australia, Serving: Europe and the Middle East
New Zealand, and Asia

WARRANTY INFORMATION CARD
Name
Address
Phone/Fax Number
Place of Purchase
RA Number Date of Purchase
Problem
Table of contents
Other Vetta Bicycle Accessories manuals

Vetta
Vetta V100HR User manual

Vetta
Vetta VL110A User manual

Vetta
Vetta V50 User manual

Vetta
Vetta Solar Flare500-111 User manual

Vetta
Vetta VL110 User manual

Vetta
Vetta C-25 User manual

Vetta
Vetta RT55 User manual

Vetta
Vetta VL110 User manual

Vetta
Vetta RT255L Instruction manual

Vetta
Vetta PathFinder II Wireless Instruction manual
