VEVOR RD03-4001 User manual

Technical Support and E-Warranty Certificate
www.vevor.com/support
Hole Saw
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the
major top brands and doses not necessarily mean to cover all categories of tools offered by
us. You are kindly reminded to verify carefully when you are placing an order with us if you
are actually saving half in comparison with the top major brands.

- 1 -
RD03-4001 RD03-4002
Have product questions? Need technical support? Please feel free to
contact us:
CustomerSe[email protected]
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
HOLE SAW

- 2 -
INSTRUCTIONS
Thank you very much for choosing this hole saw. Please read all of the
instructions before using it.The information will help you achieve the best possible
results.
The products in this catalog may be different in color than the actual item.
Warning-To reduce the risk of injury, user must read instructions
manual carefully.
Warning- Be sure to wear eye protectors when using this product.
Caution! Wear a breathing mask. Dust which is injurious to
health can be generated when working on wood and other
materials.
WARNING!
Read and understand all instructions before using this hole saw. The operator
must follow basic precautions to reduce the risk of personal injury and/or damage
to the equipment. Keep this manual for safety warnings, precautions, operating or
inspection and maintenance instructions.
Safety Precautions
Wear working clothes suitable for the operation. In particular, eye protection
equipment must be worn to prevent shavings from getting into your eyes.
Prepare the working environment before starting the job. Be careful to
consider safety when working in high places, being close to inflammable materials,
in dark places, in rain, in wet place, on scaffolding. Consider falling, fires, electric
shock, etc.
Be sure to check if there are any defects in the product before use. Never use
the product if it has any defect.
Be sure to turn off the main switch of the drill and disconnect the power supply
plug from the socket before attaching and detaching the product.

- 3 -
Do not touch the product, the shavings, or the drilled surface by hand because
they may be hot by drilling friction.Never remodel or modify the product.
Do not touch moving parts, especially the drill tip or blades.
When you feel anything unusual in use, stop using the product and inspect it
as well as the electrical drill.
CAUTION
Do not allow any person other than the working staff to enter the working place.
Do not touch the blades by hand because they are very sharp.
Please read handling description well when changing and assembling.
Use spare parts that comply with the product specification.
The product and its size must be appropriate for the specification of the electrical
drill used.
Model and Parameters
Model
RD03-4001
RD03-4002
Hole Saws
Diameters
Included inches
(mm)
3/4, 7/8, 1, 1-1/8, 1-
3/8,
1-1/2, 1-3/4, 2, 2-
1/4,
2-1/2, 3
（19, 22, 25, 29,
35, 38, 44, 51, 57,
64, 76）
3/4, 7/8, 1, 1-1/8, 1-1/4, 1-3/8, 1-
1/2, 1-3/4, 2, 2-1/8, 2-1/4, 2-3/8,
2-1/2, 2-11/16, 3,
3-1/4, 3-3/4, 4-1/2
（19, 22, 25, 29, 32, 35, 38, 44,
51, 54, 57, 60, 64, 68, 76, 83,
95, 114）

- 4 -
Mandrels For Hole Saws
Fits Hole Saws
Mandrels
Hole Saws
inches
mm
RD03-1009M-5
3/4, 7/8 , 1 , 1-1/8
19, 22, 25, 29
RD03-1006M-2
1-1/4, 1-3/8, 1-1/2, 1-3/4, 2,
2-1/8, 2-1/4, 2-3/8, 2-1/2,
2-11/16, 3, 3-1/4, 3-3/4,
4-1/2
32, 35, 38, 44, 51, 54, 57,
60, 64, 68, 76, 83, 95, 114
Assembly and Usage

- 5 -
CAUTION
TO PREVENT INJURY:
Wear heavy-duty work gloves and ANSI-approved safety goggles during setup
and whenever handling the saws.
1. Select the desired size Hole Saw and either the Large or Small Mandrel.
NOTE: Unthread the 2-1/2" and 2-1/8" Hole Saws from one another before use.
2. The correct size Mandrel will fit exactly into the Hole Saw.
3 . Use the Adapter to attach the Small Mandrel to medium size Hole Saws (such
as 1-3/8" and 1-1/2" sizes.) Carefully thread the Adapter into the Hole Saw and
then thread the Small Mandrel through the bottom so that it screws into the
Adapter.
4.To attach Hole Saw to the Large Mandrel, see illustrations and instructions on
facing page.
5.Open Jaws of Drill Chuck (sold separately).
6.Place the Mandrel Shaft completely into the Chuck and securely tighten the
Chuck.
Large Mandrel Setup
A. Unthread the knurled Locking Collarto retract the Locking Pins.
B. Thread Hole Saw onto Collar Thread until the Locking Pins align with the
Holes in the Saw. It just needs to align, it does not need to be tight.

- 6 -
C. Tighten the knurled Locking Collar to extend the Locking Pins through the
holes in the Hole Saw.
D. Tighten the knurled Locking Collar securely to hold the Hole Saw in place.
The shank shape allows for most chuck diameter.
Precautions on use
Securely chuck the shank to prevent swinging or falling.
Do not reduce the rotation speed excessively during drilling. Jamming or tip
cracking may result.
Do not hit the cutting edges against any hard object or allow strong contact
with the work material that may occur when the center drill passes through.
The tip will crack.

- 7 -
Hole Saws Recommended Cutting Speeds
Hole Saw Diameter
Material RPM(Rotation Per Minute)
Ø mm
Ø inch
stainless
steel
steel
aluminium
wood
19
3/4
230
460
690
3000
22
7/8
195
390
580
3000
25
1
175
350
525
2700
29
1-1/8
150
300
450
2400
32
1-1/4
140
275
410
2400
35
1-3/8
125
250
375
2400
38
1-1/2
115
230
345
2400
44
1-3/4
95
195
295
2100
51
2
85
170
255
2000
54
2-1/8
80
160
240
2000
57
2-1/4
75
150
225
2000
60
2-3/8
70
140
220
2000
64
2-1/2
65
135
205
1850
68
2-11/16
65
130
190
1800
76
3
55
115
170
1800
83
3-1/4
50
105
165
1500
95
3-3/4
45
90
135
1200
114
4-1/2
35
75
105
900

- 8 -
Operation
1. Holding the drill at 90° to the workpiece, set the Hole Saw on the workpiece.
2. Press the drill's trigger to turn it on.
3. If the drill is a variable speed type, cut the work piece slowly until a circular
groove is made in the workpiece. Then cut faster.
4. When the hole is cut, release the trigger and wait for Hole Saw to come to a
complete stop before removing it from the workpiece.
5. When finished, remove Hole Saw from drill's chuck.
6. Remove Hole Saw from Mandrel and clean off Hole Saw with a cloth. Place
Hole Saw and Mandrel back in carrying case.
7. Store Hole Saws inside case, out of reach of children.
8. Replace the pilot drill bit if dull or broken. Make sure the bit is securely held in
place after being reinstalled.
Maintenance
9. Always secure the material to be cut. If not, the turning action of the hole saw
will cause the workpiece to spin or slip.
10. Start the hole saw square to the workpiece surface with steady feed pressure.
Unbalanced tooth engagement will result in erratic hole saw action and could
cause tooth scrappage.
11. Follow the recommended standard hole saw operating speeds.
12. Hole saws should be worked in and out to help clear chips when working at
the upper ranges of the hole saws' capacity.
13. Whenever possible, use a cutting oil, except with cast iron (or wood), to help
clear chips and lubricate the blade for longer life.
14. Occasionally check the mandrel's drive pins to prevent them from vibrating out
of the hole saw's drive pin holes.
Address: Baoshanqu Shuangchenglu 803long 11hao 1602A-1609shi Shanghai
Imported to AUS: SIHAO PTY LTD, 1 ROKEVA STREETEASTWOOD NSW 2122
Australia
Imported to USA: Sanven Technology Ltd., Suite 250, 9166 Anaheim Place,
Rancho Cucamonga, CA 91730
MADE IN CHINA
