PORTABLE UTILITY PUMP
USR MANUAL
Applicable model: Q1CZ-800C1
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and doses not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.

1
SET UP AND OPERATING INSTRUCTIONS
Have product questions? Need technical support? Please feel free to
contact us:
[e-mail]
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
PORTABLE
UTILITY PUMP

2
Read this material before using this product. Failure to do so can
result in serious injury. SAVE THIS MANUAL.
SAVE THIS MANUAL
Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance, and cleaning procedures. Write the
product s serial number on the back of the manual near the assembly
diagram (or the month and year of purchase if the product has no number).
Keep this manual and the receipt in a safe and dry place for future
reference.
IMPORTANT SAFETY
In this manual, on the labeling and all other information provided with
this product:
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messages that follow this symbol
to avoid possible injury or death.
DANGER indicates a hazardous situation that, if not avoided,
will result in death or serious injury.
WARNING indicates a hazardous situation that, if not avoided,
could result in death or serious injury.
CAUTION, used with the safety alert symbol, indicates a
hazardous situation that, if not avoided, could result in minor or moderate
injury.

3
NOTICE
NOTICE is used to address practices not related to personal
injury.
CAUTION
CAUTION, without the safety alert symbol, is used to address
practices not related to personal injury.
GENERAL POWER TOOL SAFETY
WARNING Read all safety warnings and instructions.
Failure to follow the warnings and instructions may result in electric shock,
fire, and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-operated
(corded) power tool or battery-operated (cordless) power tool.
1.Work area safety
a.Keep the work area clean and well-lit. Cluttered or dark areas invite
accidents.
b.Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases, or dust. Power tools create sparks
that may ignite dust or fumes.
a. Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
2.Electrical safety
a.Power tool plugs must match the outlet- Never modify the plug in any way.
Do not use any adapter plugs with grounded power tools. Unmodified
plugs and matching outlets will reduce the risk of electric shock.
b. Avoid body contact with grounded surfaces such as pipes, radiators,
ranges, and refrigerators. There is an increased risk of electric shock if
your body is grounded.
c.Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.

4
Do not abuse the cord. Never use the cord for carrying, pulling, or
unplugging the power tool. Keep the cord away from heat, oil, sharp edges,
or moving parts. Damaged or entangled cords increase the risk of electric
shock.
e.When operating a power tool outdoors, use an extension cord suitable
for outdoor use. The use of a cord suitable for outdoor use reduces the risk
of electric shock
f.If operating a power tool in a damp location is unavoidable, use a Ground
Fault Circuit Interrupter (GFCI) protected supply. Use of
a GFCI reduces the risk of electric shock.
3.Personal safety
a. Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired or
under the influence of drugs, alcohol, or medication. A moment of
inattention while operating power tools may result in serious personal injury
b. Use personal protective equipment. Always wear eye protection.
Safety equipment such as dust masks, non-skid safety shoes, hard hats, or
hearing protection used for appropriate conditions will reduce personal
injuries.
c.Prevent unintentional starting.
Ensure the switch is in the off-position before connecting to the power
source and/or battery pack, picking up or carrying the tool. Carrying power
tools with your finger on the switch or energizing power tools that have the
switch on invites accidents.
d.Remove any adjusting key or wrench before turning the power tool on. A
wrench or a key left attached to a rotating part of the power tool may result
in personal injury.
e.Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
f.Dress properly. Do not wear loose clothing or jewelry. Keep your hair,
clothing, and gloves away from moving parts. Loose clothes, jewelry, or
long hair can be caught in moving parts.
g.If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used. The

5
use of these devices can reduce dust-related hazards
h. Only use safety equipment that has been approved by an appropriate
standards agency. Unapproved safety equipment may not provide
adequate protection. Eye protection must be ANSI-approved, and
breathing protection must be NIOSH-ap- proved for the specific hazards in
the work area.
4.Power tool use and care
a. Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the
rate for which it was designed
b.Do not use the power tool if the switch does not turn on and off. Any
power tool that cannot be controlled with the switch is dangerous and must
be repaired.
c.Disconnect the plug from the power source and/or the battery pack from
the power tool before making any adjustments, changing accessories, or
storing power tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts,
breakage of parts, and any other condition that may affect the power tools'
operation. If damaged, have the power tool repaired before use. Many
accidents are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools
with sharp cutting edges are less likely to bind and are easier to control.
g.Use the power tool, accessories and tool bits, etc. in accordance with
these instructions, taking into account the working conditions and the work
to be performed. Use of the power tool for operations different from those
intended could result in a hazardous situation.
5.Service
a. Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power
tool is maintained.

6
PORTABLE PUMP SAFETY WARNINGS
1.Maintain labels and nameplates on the tool. These carry important safety
information. If unreadable or missing, contact Harbor Freight Tools for a
replacement.
2.Avoid unintentional starting. Prepare to begin work before turning on the
tool.
3.Do not leave the tool unattended when it i$ plugged into an electrical
outlet. Turn off the tool, and unplug it from its electrical outlet before
leaving.
4.This product is not a toy. Keep it out of reach of children.
5.People with pacemakers should consult their physician(s) before use.
Electromagnetic fields in close proximity to the heart pacemaker could
cause pacemaker interference or pacemaker failure. In addition, people
with pacemakers should: Avoid operating alone.
·Do not use the power switch locked on.
·Properly maintain and inspect to avoid electrical shock.
·Any power cord must be properly grounded. Ground Fault Circuit
Interrupter (GFC1) should also be implemented-it prevents sustained
electrical shock.
6.WARNING: Handling the cord on this product will expose you to lead, a
chemical known to the State of California to cause cancer, birth defects, or
other reproductive harm. Wash hands after handling (California Health &
Safety Code §25249.5, et seq.)
7.WARNING: The brass components of this product contain lead, a
chemical known to the State of California to cause birth defects (or other
reproductive harm). (California Health & Safety code §25249 5t et seq.)
8.The warnings, precautions, and instructions discussed in this instruction
manual cannot cover all possible conditions and situations that may occur.
It must be understood by the operator that common sense and caution are
factors that cannot be built into this product but must be supplied by the
operator.

7
SAVE THESE INSTRUCTIONS.
GROUNDING
TO PREVENT ELECTRIC SHOCK AND DEATH FROM
INCORRECT GROUNDING WIRE CONNECTION ：
Check with a qualified electrician if you are in doubt as to whether
the outlet is properly grounded. Do not modify the power cord plug
provided with the tool. Never remove the grounding prong from the plug.
Do not use the tool if the power cord or plug is damaged. If damaged, have
it repaired by a service facility before use. If the plug does not fit the outlet,
have a proper outlet installed by a qualified electrician.
GROUNDED TOOLS: TOOLS WITH THREE PRONG PLUGS
3-Prong Plug and Outfet

8
1. Tools marked with "Grounding Required" have a three-wire cord and
three-prong grounding plug. The plug must be connected to a properly
grounded outlet. If the tool should electrically malfunction or break down,
grounding provides a low resistance path to carry electricity away from the
user, reducing the risk of electric shock. (See 3-Prong Plug 2. and Outlet.)
2. The grounding prong in the plug is connected through the green wire
inside the cord to the grounding system in the tool. The green wire in the
cord must be the only wire connected to 1. the tool's grounding system and
must never be attached to an electrically "live" terminal. (See 3-Prong Plug
and Outlet.)
3.The tool must be plugged into an appropriate outlet, properly installed,
and grounded in accordance with all codes and ordinances. The plug and
outlet should look like those in the preceding illustration. (See 3-Prong Plug
and Outlet.)
DOUBLE INSULATED TOOLS: TOOLS WITH TWO PRONG PIUGS
Outlets for 2-Prong Plug
1.Tools marked ' Double Insulated” do not require grounding. They have a
special double insulation system that satisfies OSHA requirements and

9
complies with the applicable standards of Underwriters Laboratories, Inc.,
the Canadian Standard Association, and the National Electrical Code. (See
Outlets for 2-Prong Plug.)
Double-insulated tools may be used in either of the 115-volt outlets shown
in the preceding illustration. (See Outlets for 2-Prong Plug.)
EXTENSION CORDS
1.Grounded tools require a three-wire extension cord. Double Insulated
tools can use either a two or three-wire extension cord.
2.As the distance from the supply outlet increases, you must use a heavier
gauge extension cord. Using extension cords with inadequately sized wire
causes a serious drop in voltage, resulting in loss of power and possible
tool damage.
(See Table A.)
3.The smaller the gauge number of the wire, the greater the capacity of the
cord. For example, a 14 gauge cord can carry a higher current than a 16
gauge cord. (See Table A.)
4.When using more than one extension cord to make up the total length,
make sure each cord contains at least the minimum wire size required
(See Table A.)
5.If you are using an extension cord for more than one tool, add the
nameplate amperes and use the sum to determine the required minimum
cord size. (See Table A.)
6.If you are using an extension cord outdoors, make sure it is marked with
the suffix "W-A" (W in Canada) to indicate it is acceptable for outdoor use.
7.Make sure the extension cord is properly wired and in good electrical

10
condition. Always replace a damaged extension cord or have it repaired by
a qualified electrician before using it.
8. Protect the extension cords from sharp objects, excessive heat, and
damp or wet areas.
RECOMMENDED MINIMUM WIRE
GAUGE FOR EXTENSION CORDS*
(115 VOLT)
NAMEPLATE
AMPERES
(At Full Load)
25’
50’
75’
100’
150’
0-2.0
18
18
18
18
16
2.1-3.4
18
18
18
16
14
3.5-50
18
18
16
14
12
5.1-7.0
18
16
14
12
12
7.1-12.0
18
14
12
10
*
12.1-16 0
14
12
10
-
16.1-20.0
12
10
-
TABLE A *Based on limiting the line,
voltage drop to five volts at
150% of the rated amperes.

11
SPECIFICATIONS
UNPACKING
When unpacking, check to make sure that the item is intact and
undamaged. If any parts are missing or broken, please call Harbor Freight
Tools at the number shown on the cover of this manual as soon as
possible.
Electrical Requirements
115V/60 Hz
Current
7.5A
Power
1/2 HP
Pumping Capacity
1600 GPH Max.
Inlet & Outlet Size
GHT3/4
Pump Lift Capacity
120 Feet Max.

12
LIST OF CONTENTS
INSTRUCTIONS FOR PUTTING INTO USE
Read the ENTIRE IMPORTANT SAFETY INFORMATION
section at the beginning of this manual, including all text under
subheadings therein before set up or use of this product.
TO PREVENT SERIOUS INJURY
FROM ACCIDENTAL OPERATION: Turn the Power Switch of the tool to its
"OFF" position and unplug the tool from its electrical outlet before
assembling or making any adjustments to the tool.
Note ： For additional information regarding the parts listed in the following
pages, refer to the Assembly Diagram near the end of this manual.
Description
Qty
Portable Utility Pump
1
Filter
1
Carbon Brush
1
Brass Adapter
1
Instruction Manual
1

13
ASSEMBLY
1.Inlet and outlet hoses (not included) must be attached to the pump prior
to use.
2.Attach inlet and outlet hoses to Hose Fittings (3) on Pup Facing (2).
Standard garden hose fitting will work.
3 Attach the Accessory Basket Filter included with the pump to the inlet end
of the inlet hose. The strainer will prevent foreign material from entering the
pump and damaging or jamming it.
MOUNTING
1.Pump should be firmly mounted on a stable base prior to use,
2.The pump and its electrical connections should be mounted so that they
remain dry. Water may damage the pump if it enters any electrical
component.
FUNCTIONS
This pump is useful for pumping clean water. Do not use it for dirty water
containing large particulates.
OPERATING INSTRUCTIONS
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at
the beginning of this manual, including all text under subheadings therein,
before setting up or use of this product.

14
TOOL SET UP
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL
OPERATION:
Turn the Power Switch of the tool to its "OFF" position and unplug the tool
from its electrical outlet before
performing any inspection, maintenance, or cleaning procedures-
1.This pump operates immediately when plugged in. Do not plug in this
pump when dry. Always prime the pump before plugging it in.
WORK PIECE AND WORK AREA SET UD
1 Designate a work area that is clean and well-lit. The work area must not
allow access by children or pets to prevent injury and distraction.
2 Route the power cord along a safe route to reach the work area without
creating a tripping hazard or exposing the power cord to possible damage.
The power cord must reach the work area with enough extra length to
allow free movement while working.
3.There must not be hazardous objects, such as utility lines or foreign
objects, nearby that will present a hazard while working.
4.Protect yourself and others from the risk of electrical shock. Always wear
insulated boots and gloves. Stay out of water or wet surfaces. Protect the
pump and its power cord from moisture
Never operate this tool in explosive atmospheres.
GENERAL OPERATING INSTRUCTIONS
1.Attach inlet and outlet hoses (not included) to the pump. Standard
garden hoses will work
2.Attach the accessory Basket Filter to the inlet end of the inlet hose.

15
3 Place the basket filter end of the inlet hose in the water to be pumped.
4.Rout the outlet hose so that pumped water will run off appropriately.
5.Remove Priming Plug (4) by turning counterclockwise. Fill the pump with
clean water. Replace Priming Plug by turning it clockwise.
6.Plug in Power Cord (22). The pump will operate immediately. It will take a
few minutes for the pump to prime and remove air from the inlet hose.
Water will then flow through the hoses and pump.
7.Do not allow the Basket Filter to become clogged. Check it periodically to
be sure that clear water can enter the inlet hose.
8. Do not allow the pump to run dry. Running dry, the pump will overheat,
and the impeller and seals will be damaged.
9.To prevent accidents, turn off the tool and disconnect it$ power supply
after use. Clean, then store the tool indoors out of children s reach.
MAINTENANCE AND SERVICING
Procedures not specifically explained in this manual must be
performed only by a qualified technician.
TO PREVENT SERIOUS INJURY
FROM ACCIDENTAL OPERATION: Unplug the tool from its electrical
outlet before performing any inspection, maintenance, or cleaning
procedures.

16
TO PREVENT SERIOUS INJURY FROM TOOL FAILURE:
Do not use damaged equipment. If abnormal noise or vibration occurs,
have the problem corrected before further use.
CLEANING, MAINTENANCE, AND LUBRICATION
1.BEFORE EACH USE. Inspect the general condition of the tool. Check for
loose screws, misalignment or binding of moving parts, cracked or broken
parts, damaged electrical wiring, and any other condition that may affect its
safe operation.
2.AFTER USE, clean the external surfaces of the tool with a clean cloth.
3.CARBON BRUSH MAINTENANCE.
The carbon brushes may require maintenance when the motor
performance of the tool decreases or stops waking completely, lb maintain
the brushes:
a.Remove the brush cap on each side of the motor housing.
b.Remove the carbon brushes from the housing Keep track of which
orientation the old carbon brushes were in to prevent needless wear if they
are reinstalled.
c.If either carbon brush is worn down by more than 1/2, replace both
carbon brushes.
d. To clean old carbon brushes before reusing them, rub the contact areas
with a pencil eraser.
e.Reinsert the old carbon brushes in the same orientation to reduce wear.
f.When installing the carbon brushes, make sure the carbon portions of the
carbon brushes contact the motor armature, and that the springs face
away from the motor. Also, make sure the springs operate freely.
g.Replace the brush caps. Do not over-tighten.

17
Note:
New carbon brushes tend to spark when first used until they wear and
conform to the motor's armature.
If the supply cord of this power tool is damaged, it must be
replaced only by a qualified service technician.
Troubleshooting
Problem
Possible Causes
Likely Solutions
Tool will not start
1.No power at the outlet.
2.Cord is not connected.
3.Worn out or damaged Carbon
Brushes.
1.Check power at outlet.
2.Check that cord is plugged in,
3.Replace Carbon Brushes.
Pump operates
but does not
pump water
1.Pump is not primed
2.Basket Filter is clogged.
3.All water has been pumped out
4.Impeller is worn out or jammed
1.Prime pump. See instructions on page 9.
2.Check and clean the basket filter.
3.Turn off the pump and complete mop up
by hand
4.Repair or replace Impeller as needed.
Follow all safety precautions whenever diagnosing or servicing the
tool. Disconnect the power supply before service.

18
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE
PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A
REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER NOR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF
ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE
ANY REPAIRS TO THE PRODUCT OR THAT HE OR SHE IS QUALIFIED
TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE
MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY STATES THAT
ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE
UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS AND
NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT
OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR
HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Record Products Serial Number Here:
Note: If the product has no serial number, record the month and year of
purchase instead.
Note: Some parts are listed and shown for illustration purposes only and
are not available individually as replacement parts.

19
ASSEMBLY DIAGRAM
List of Explosion Plans
Number
Spare Parts List
Qty
1
foot set
3
2
vortex chamber
1
3
copper joints
2
4
bolt of seal
1
5
O-ring
1
6
impeller
1
7
ceramics seal
1
8
orifice plate
1
9
rubber ring
1
10
bearing
1
