Vicon V739 User manual

XX049-01

MODEL V739

VICOAX®VIDEO / DATA

TRANSMISSION SYSTEM

VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788

TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116

UK: +44 (0) 1489 566300 WEB www.vicon-cctv.com

24-Hour Technical Support: 800-34-VICON (800-348-4266)

Vicon part number 8009-8049-01-00 Section 10 Rev 703

Dear Valued Customer:

Thank you for selecting Vicon systems and products

for your video needs.

Since Vicon's beginning in 1967, our only business

has been the design, engineering, and production of

the highest quality video systems and equipment for

use in a wide variety of security, safety, control, sur-

veillance, and communication applications.

We stand behind the quality and dependability of every product with an

industry leading Beneficial Use warranty.

If you are not satisfied with a Vicon product or service, I would like to know.

Your complete satisfaction is the mission of every Vicon employee.

Sincerely,

Kenneth M. Darby

President

IMPORTANT SAFEGUARDS

GRAPHIC SYMBOL EXPLANATION

The lightning flash with arrowhead symbol, within an

equilateral triangle, is intended to alert the user to the pres-

ence of uninsulated "dangerous voltage" within the prod-

uct's enclosure that may be of sufficient magnitude to con-

stitute a risk of electric shock.

The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important oper-

ating and maintenance (servicing) instructions in the litera-

ture accompanying the unit.

IMPORTANT

1. Read Instructions - All the safety and operating instruc-

tions should be read before the video product is operated.

2. Retain Instructions - All the safety and operating

instructions should be retained for future reference.

3. Heed Warnings - All warnings on the video product and

in the operating instructions should be adhered to.

4. Follow Instructions - All operating and use instructions

should be followed.

5. Cleaning - Step a applies to equipment that can be dis-

connected from the CCTV system without seriously jeop-

ardizing security. Step b applies to equipment that must

operate continuously such as video switching equipment at

military installations.

a. Disconnect this video product from its power source

before cleaning. Do not use caustic, abrasive, or

aerosol cleaners. Use a damp cloth for cleaning.

b. Use a damp cloth to clean the equipment. Do not allow

moisture or liquids to enter any vents. Do not use caus-

tic, abrasive, or aerosol cleaners.

6. Attachments - Do not use attachments not recommend-

ed by Vicon as they may cause hazards.

7. Water and Moisture - Do not use this video product in

any location where it may be exposed to water or moisture.

This does not apply to outdoor camera housings, outdoor

pan-and-tilt drives, and other equipment designed for direct

exposure to outdoor environments.

8. Accessories - Do not place this video product on any

unstable surface or table. The video product may fall, caus-

ing serious injury to a person and serious damage to the

video product. Use only with a mounting accessory recom-

mended by Vicon, or sold with the video product. Any

mounting of the video product should follow Vicon's instruc-

tions, and a mounting accessory recommended by Vicon

should be used.

9. Ventilation - Slots and openings in the cabinet are pro-

vided for ventilation and to ensure reliable operation of the

video product and to protect it from overheating, and these

openings must not be blocked or covered. The openings

should never be blocked by placing the video product on a

rug or other similar surface. This video product should never

be placed near or over a radiator or heat register. This video

product should not be placed in a built-in installation such as

a bookcase or rack unless proper ventilation is provided or

Vicon's instructions have been adhered to.

10. Power Sources - This video product should be operat-

ed only from the type of power source indicated on the

marking label. If you are not sure of the type of power sup-

plied to your installation site, consult your Vicon dealer or

local power company. For video products intended to oper-

ate from battery power, or other sources, refer to the oper-

ating instructions.

11. Grounding - This applies to video products equipped

with a 3-wire grounding-type plug, a plug having a third

(grounding) pin. This plug only fits into a grounding-type

power outlet. This is a safety feature. If you are unable to

insert the plug into the outlet, contact your electrician to

replace your obsolete outlet. Do not defeat the safety pur-

pose of the grounding-type plug.

12. Power-Cord Protection - Power supply cords should

be routed so that they are not likely to be walked on or

pinched by items placed upon or against them, paying par-

ticular attention to cords at plugs, convenience receptacles,

and the point where they exit from the video product.

13. Outdoor Cable Grounding - If an outside

cable system is connected to the video product, be

sure the cable system is grounded so as to pro-

vide some protection against voltage surges and

built-up static charges. Section 810 of the National

Electrical Code, ANSI/NFPA 70-1984, provides

information with respect to proper grounding of the

lead-in wire to an antenna discharge unit, size of

grounding conductors, location of antenna-dis-

charge unit, connection to grounding electrodes,

and requirements for the grounding electrode.

14. Lightning - For added protection for this

video product when it is not used for long periods

of time, disconnect it from its power source and

from the cable system. This prevents damage to

the video product due to lightning and power-line

surges.

15. Power Lines - An outside cable system

should not be located in the vicinity of overhead

power lines or other electric light or power circuits,

or where it can fall into such power lines or circuits.

When installing an outside cable system, extreme

care should be taken to keep from touching such

power lines or circuits as contact with them might

be fatal.

16. Overloading - Do not overload wall outlets

and extension cords as this can result in a risk of

fire or electric shock.

17. Object and Liquid Entry - Never push

objects of any kind into this video product through

openings as they may touch dangerous voltage

points or short out parts that could result in a fire

or electric shock. Never spill liquid of any kind on

the video product.

18. Servicing - Do not attempt to service this

video product yourself as opening or removing

covers may expose you to dangerous voltage or

other hazards. Refer all servicing to qualified serv-

ice personnel.

19. Damage Requiring Service - Disconnect this

video product from its power source and refer

servicing to qualified service personnel under the

following conditions. Note that step c does not

apply to outdoor camera housings, outdoor pan-

and-tilt drives and other equipment specifically

designed for direct exposure to outdoor environ-

ments.

a. When the power-supply cord or plug is dam-

aged.

b. If liquid has been spilled, or objects have fall-

en into the video product.

c. If the video product has been exposed to rain

or water.

d. If the video product does not operate normally

by following the operating instructions. Adjust

only those controls that are covered by the

operating instructions, as an improper adjust-

ment of other controls may result in damage

and will often require extensive work by a

qualified technician to restore the video prod-

uct to its normal operation.

e. If the video product has been dropped or the

cabinet has been damaged.

f. When the video product exhibits a distinct

change in performance - this indicates a need

for service.

20. Replacement Parts - When replacement

parts are required, be sure the service technician

has used replacement parts specified by Vicon or

that have the same characteristics as the original

part. Unauthorized substitutions may result in fire,

electric shock, or other hazards.

21. Safety Check - Upon completion of any serv-

ice or repairs to this video product, ask the service

technician to perform safety checks to determine

that the video product is in proper operating condi-

tion.

GENERAL

This manual is a guide to the installation and operation of

the V739 series fiber optic video and data transmission

system. Please read the entire manual before installing

the equipment.

NOTE: The series numbers V739T and V739R are used

to describe all models of transmitters and receivers

unless noted otherwise.

The V739 series video and data transmission system

offers transmission of video from a camera to a monitor-

ing station and a data signal back to the camera over one

multimode fiber.

A single coaxial cable at each end of the link is used to

connect the appropriate equipment to the system.

A complete system consists of a transmitter, V739T, and a

receiver, V739R. Units are designed for standalone oper-

ation or for installation in Vicon’s V515R-PS or V517R-PS

Card Cages (V739R-R and V739T-R).

Both the V739T transmitter and V739R receiver have one

video input and one fiber connector.

Unpacking the Unit

In the event that anything is missing from the following

list, contact your authorized Vicon representative.

V739T Transmitter or V739R Receiver

Instruction manual

Save the original packing materials in case it becomes

necessary to return the unit. Refer to the Shipping

Instructions at the end of this manual.

MODULE SETUP

Alarm Jumper

Rack cards are supplied with an alarm function that goes

active if the optical signal input to the card fails. The

alarm is always indicated on the front panel of the card by

a red LEVEL/LOSS LED. The alarm may also be output

to the rack power supply, where a sonalert (audible

alarm) and alarm output contact closure may be

activated.

The alarm is set to ON (Enabled) at the factory. If the

alarm output is not desired, move jumper W1 to the OFF

(Disabled) position. Refer to Figure 2 for both V739T-R

and V739R-R units.

NOTE: Setting the Alarm Jumpers to OFF does not effect

the operation of the LEVEL/LOSS LED. Loss of optical

signal will always be indicated by a red LEVEL/LOSS

LED.

INSTALLATION

Installation Considerations

This fiber-optic link is supplied in two forms, as a stand-

alone module and as a rack card. Units should be

installed in dry locations protected from extremes of tem-

perature and humidity.

Standalone Modules

1. Determine where the module is to be installed and

ensure that there is adequate space at both ends for

making the various cable connections and for reading

the diagnostic LEDs.

2. Standalone modules are provided with mounting

holes for four No. 6 screws (3-mm or 3.5-mm

screws). The type of screw used for installation must

be suitable for the surface on which the module is to

be mounted.

V739 VIDEO / DATA

TRANSMISSION SYSTEM

continued on page 3

FIGURE 1: SYSTEM DIAGRAM

one

optical fiber

V739T

V739R

ONE COAXIAL CABLE

Video & Response

Command & Sync

ONE COAXIAL CABLE

Video & Response

Command & Sync

FIGURE 2: RACK-MOUNT V739R-R AND V739T-R

OPTICAL

ALARM

ON OFF

VIDEO

NOTE: ALARM JUMPER W1 SHOWN IN THE ON (ENABLED) POSITION

V739R-R

OPTICAL

VIDEO

V739T-R

NOTE: ALARM ON (ENABLED) WITH JUMPER W1 INSTALLED

2MODEL V739

Rack Cards

Rack cards are designed to be installed in one of Vicon’s

19-inch (483-mm) EIA standard card-cage racks, either

the V515R-PS or the V517R-PS. Follow these steps after

selecting data format, contact closure and alarm output.

CAUTION: Although a rack card may be installed

without turning off power to the rack (hot-swap-

pable), Vicon recommends that the power switch on

the rack power supply is turned OFF and that the rack

power supply is disconnected from any power source.

1. Make sure that the card is oriented right-side up and

slide it into the card guides in the rack until the edge

connector at the back of the card seats in the corre-

sponding slot in the rack’s connector panel. Seating

may require thumb pressure on the top and bottom of

the card’s front panel.

CAUTION: Take care not to press on any of the

LEDs.

2. Tighten the two thumb screws on the card until the

front panel of the card is seated against the front of

the rack.

CONNECTIONS

Video Cable Connection

Connect the video source cable to the input BNC jack on

the V739T transmitter. Connect monitor equipment to the

output BNC jack on the V739R receiver.

Vicon suggests that Belden number 9259 or equivalent

coaxial cable should be used.

Fiber Optic Cable Connection

Most cable manufacturers identify the individual fibers in

the cable. Select appropriately terminated fiber and mark

both ends with unique identification label (e.g., for cable

no. 03, fiber no. 08) to ensure that the fiber connected to

the near end is the same one that is connected to the far

end. The proper optical connection links the transmitter's

OUT port to the receiver's IN port.

1. Wipe the inside of the port’s sleeve with a lint-free

pipe cleaner moistened with reagent-grade isopropyl

alcohol. Blow dry with dry air.

2. Clean the connector using a lint-free cloth dampened

with alcohol to thoroughly wipe the side and end of

the ferrule. Blow the ferrule dry with dry air. Visually

inspect the ferrule for lint.

3. Fasten the fiber optic cable to the port.

Power Connections

Standalone modules may be powered either by 12 - 16

VAC or by 12 - 16 VDC. Connect input power according

to the label on the module. See Figure 3.

Rack modules’ power connections are made automatical-

ly when the card is installed. To supply power to the rack,

connect the rack power supply to an AC outlet and set the

power switch to ON.

OPERATION

V739 links operate automatically once installed. Refer to

LED OPERATION and Tables 1 and 2 for an explanation

of LED color codes.

LED OPERATION

The V739 has 5 LED indicators that are very useful in

describing the current state of operation, as well as the

current status of data flow and fiber optic signal strength.

These indicators are LEVEL/LOSS, VIDEO IN

(Transmitter) or VIDEO OUT (Receiver), CMND IN

(Transmitter), CMND OUT (Receiver), RESP OUT

(Transmitter), RESP IN (Receiver) and SYNC IN

(Transmitter), SYNC OUT (Receiver). Tables 1 and 2 pro-

vide a summary of LED operation. See Figure 4. They

function as follows:

LEVEL/LOSS Indicator

This LED is useful for indicating the relative optical signal

strength at the fiber optic receiver. When sufficient opti-

cal power is being received, the LED shines green. As

the optical power is decreased, as happens through long

fiber runs, splices, or connections, the intensity of the

LEVEL/LOSS LED will diminish until the limit of the

V739's sensitivity range has been reached. At this point

the LED will be OFF. If any additional optical attenuation

is introduced, the LEVEL/LOSS LED will turn bright RED,

indicating an insufficient amount of optical power is being

received.

VICOAX®VIDEO AND DATA SYSTEM

4MODEL V739

VIDEO IN (or OUT) Indicator

This LED indicates the strength of the video signal.

VIDEO IN on the transmitter remains green as long as

adequate video signal is being input to the transmitter. If

the video input becomes too weak, the LED turns red.

The VIDEO OUT LED on the receiver performs a similar

function, except that it refers to the video that is output

from the receiver.

NOTE: The V739 monitors the sync signals on the video

to determine the strength of the signal. It does not mon-

itor the brightness signal. Thus, if the scene in front of a

camera is totally dark, producing a blank monitor screen,

the VIDEO LEDs can still be green.

CMND IN ( or OUT) Indicator

The CMND IN and CMND OUT LEDs monitor the PTZ

Control Data pulses from the monitoring equipment to the

camera equipment. Green LEDs indicate the signal level

of the PTZ commands is greater than 250 millivolts.

These indicators are off when the signal level drops

below 250 millivolts.

RESP IN ( or OUT) Indicator

The RESP IN and OUT LEDS monitor the response sig-

nals from the camera equipment to the monitoring equip-

ment. Green LEDs indicate the signal level of the

response signals is greater than 250 millivolts. These

indicators are off when the signal level drops below 250

millivolts.

FIGURE 3: STANDALONE MODULE, V739T AND V739R

OPTICAL

CONNECTOR

VIDEO

CONNECTOR

POWER

CONNECTOR

PIN 1

Connection

+12 –16 VDC

12 –16 VAC

12 -16 VAC

Ground

VICOAX®VIDEO AND DATA SYSTEM

SYNC IN ( or OUT) Indicator

The SYNC IN and OUT LEDs monitor the Genlock

Synchronization signals, where applicable. Green LEDS

indicate the level of the Genlock Synchronization signals

is greater than 2 volts. These indicators are off when the

signal level drops below 2 volts.

MAINTENANCE

There is no operator maintenance other than keeping the

units clean.

TECHNICAL SUPPORT

For installation assistance, or in the event that a unit

should fail or if the cause of a problem cannot be deter-

mined, contact Vicon’ technical support at:

TOLL FREE: 800-34-VICON (800-348-4266) or

PHONE: 631-952-CCTV (2288)

SHIPPING INSTRUCTIONS

Use the following procedure when returning a unit to the

factory:

1. Call or write Vicon for a Return Authorization (R.A.) at

one of the locations listed below.

Record the name of the Vicon employee who issued

the R.A.

Vicon Industries Inc.

89 Arkay Drive

Hauppauge, NY 11788

Phone: 631-952-CCTV (2288)

Toll-Free: 1-800-645-9116

Fax: 631-951-CCTV (2288)

For service or returns from countries in Europe,

contact:

Vicon Industries Ltd

Brunel Way

Fareham, PO15 5TX

United Kingdom

Phone: +44 (0) 1489 566300

Fax: +44 (0) 1489 566322

2. Attach a sheet of paper to the unit with the following

information:

a. Name and address of the company returning

the unit.

b. Name of the Vicon employee who issued the

R. A.

c. R. A. number.

d. Brief description of the installation.

e. Complete description of the problem and

circumstances under which it occurs.

f. Unit's original date of purchase, if still under

warranty.

3. Pack the unit carefully. Use the original shipping

carton or its equivalent for maximum protection.

4. Mark the R.A. number on the outside of the

carton on the shipping label.

6MODEL V739

TABLE 2: RECEIVER LED DIAGNOSTIC INDICATORS

TABLE 1: TRANSMITTER LED DIAGNOSTIC INDICATORS

LED Name

Color

Indicates/Corrective Action

Green

Sufficient optical power received. No action required.

LEVEL/

LOSS

Red

Optical power not being received. Fiber open or transmitter or receiver inoperative.

Check fiber loss, connectors, and splices (if any). On two-fiber units, verify TX port

connects to RX port.

Green

Video coax input to link is good. (Note that even a totally black screen is a valid

video signal.) No action required.

VIDEO IN

Red

Video coax input to link is not good. Check the camera and the coax into the link.

Green

Indicates PTZ command transmission (greater than 250 mV). No action required.

CMND OUT

Off

No activity or command being transmitted is less than 250 mV.

Green

Indicates response from camera is greater than 250 mV. No action required.

RESP IN

Off

No response from camera or signal is less than 250 mV. This may indicate a

problem with the camera. This function is not available in all systems.

Green

Indicates transmission of Genlock Synchronization signals greater than 2 volts,

where applicable.

SYNC OUT

Off

No Genlock Synchronization signal received or level is less than 2 volts.

LED Name

Color

Indicates/Corrective Action

Green

Sufficient optical power received. No action required.

LEVEL/

LOSS

Red

Optical power not being received. Fiber open or transmitter or receiver inoperative.

Check fiber loss, connectors, and splices (if any). On two-fiber units, verify TX port

connects to RX port.

Green

Valid video signal received. (Note that even a totally black screen is a valid video

signal.) No action required.

VIDEO OUT

Red

No video signal received. Check the camera and coax. Check the LEVEL/LOSS



indicator. If the indicator is green, check the VIDEO LED on the transmitter.

Green

Indicates PTZ command transmission (greater than 250 mV). No action required.

CMND IN

Off

No activity or command being transmitted is less than 250 mV.

Green

Indicates response from camera is greater than 250 mV. No action required.

RESP OUT

Off

No response from camera or signal is less than 250 mV. This may indicate a

problem with the camera. This function is not available in all systems.

Green

Indicates transmission of Genlock Synchronization signals greater than 2 volts,

where applicable.

SYNC IN

Off

No Genlock Synchronization signal received or level is less than 2 volts.

VICOAX®VIDEO AND DATA SYSTEM

FIGURE 4: DIAGNOSTIC LEDS

V739R Surface Mount Receiver V739R-R Rack Mount Receiver

V739T Surface Mount Transmitter

LVL/LOSS

VIDEO IN

CMND OUT

RESP IN

SYNC OUT

LVL/LOSS

VIDEO OUT

CMND IN

RESP OUT

SYNC IN

V739T-R Rack Mount Transmitter

V739-R

LVL/LOSS

VIDEO OUT

CMND IN

SYNC IN

RESP OUT

V739-T

LVL/LOSS

VIDEO IN

CMND OUT

SYNC OUT

RESP IN

MODEL V739

ELECTRICAL

Power Requirements:

Surface Mount: 12 - 16 VAC 50/60 Hz,

12 - 16 VDC.

Rack Mount (all): 13.5 - 16 VDC.

Transmitter Current

Requirement: 300 mA.

Receiver Current

Requirement: 380 mA.

Power Consumption:

Transmitter: 4.2 W.

Receiver: 5.3 W.

Heat Equivalent:

Transmitter: 0.24 btu/min (0.06 kg-cal/min).

Receiver: 0.30 btu/min (0.08 kg-cal/min).

Note: These figures represent the conversion of 100% of the elec-

trical energy to heat. Actual percentage of heat generated will be

less and will vary from product to product. These figures are pro-

vided as an aid in determining the extent of cooling required for an

installation.

Safety Standard: UL 1950.

Radio Frequency

Emissions Rating: FCC Class A.

European Community

(CE) Standards: EN60950.

VIDEO

Number of Channels: 1.

Formats Supported: Monochrome: EIA and CCIR.

Color: NTSC, PAL and SECAM.

Full System Bandwidth: 10 MHz per channel.

Horizontal Video Resolution: 800 TV lines.

Input/Output Impedance: 75 ohms.

Optimum Input Signal: 1 V p-p nominal composite video.

Output Signal Level: 1 V p-p nominal, composite video,

unity gain, ±5%.

Differential Phase: <3º.

Differential Gain: <3%.

Signal-to-Noise Ratio: >54 dB (0 dB loss).

Interconnection Distance: Video devices to transmitter:

≤

100 ft (30 m).

Receiver to video devices:

≤

100 ft (30 m).

Note: RG59/U coaxial cable, Belden No. 9259 or equivalent, is

Popular Microphone System manuals by other brands

Galaxy Audio

Galaxy Audio AS-1100 quick start guide

Radio Shack

Radio Shack 3201258 user guide

Spa

Spa SPA665 user manual

VocoPro

VocoPro FIELD-QUAD-H owner's manual

AKG

AKG WMS 40 User instructions

ETS

ETS SMI17 instructions

Dukane

Dukane WMIC2B quick start guide

Sennheiser

Sennheiser SENNSIS 2020-D quick guide

Pyle

Pyle PDWM 4520 manual

Nady Systems

Nady Systems 2W-1KU owner's manual

Luxlink

Luxlink TVS-1002 operating instructions

Shure

Shure SVX4 user guide

Gradus Group

Gradus Group Polsen CAM-2W product manual

JTS

JTS US-8010D instruction manual

PROEL

PROEL RM3000TR user manual

Azden

Azden Body-pack Transmitter 35BT user guide

SICK

SICK RFU65 Series operating instructions

Audio Technica

Audio Technica ARTIST ELITE 4000 Installation and operation guide
