Viconics VTR7300 Series User manual

1 | PIR Ready VTR7300 Series-Installation Guide
CONTENTS
Installation 2
Location 2
Installation 2
Operation Overview 3
Model Chart 5
Network ready 6
Terminal, Identification and Function 6
Communication wiring to VC3xxxX Relay Pack 6
Network wiring topology 7
VC3xxx LED Operation 7
Wiring of local inputs to VTR73xxA Terminal Equipment Controller 8
Configuring and Status Display Instructions 8
Status display 8
User Interface 10
Local keypad interface 10
Dual occupied setpoints adjustment 11
Single occupied setpoints adjustment 11
Unoccupied and stand-by setpoints adjustments 11
Mode button menu sequence. 11
Installer Configuration Parameter Menu 12
Configuration interface 13
PIR Ready VTR7300 Series
Terminal Equipment Controller
Installation Guide
For Commercial and Lodging HVAC
Fan Coil Applications
May 3rd, 2012 / 028-0298-R8

2 | PIR Ready VTR7300 Series-Installation Guide
INSTALLATION
Remove the security screw on the bottom of
Terminal Equipment Controller cover.
Open unit by pulling on the bottom
side of Terminal Equipment Controller
(fig. 1).
Remove wiring terminals from sticker.
Please read the FCC ID and IC label
installed in the cover upon removal of
cover for the wireless products.
Location
1. Should not be installed on an outside
wall.
2. Must be installed away from any
direct heat source.
3. Should not be installed near an air
discharge grill.
4. Should not be affected by direct sun
radiation.
5. Nothing should restrict vertical air
circulation to the Terminal Equipment
Controller.
Installation
1. Swing open the Terminal Equipment
Controller PCB to the left by pressing
the PCB locking tabs (fig. 2).
2. Pull out cables 6” out from the wall.
3. Wall surface must be flat and clean.
4. Insert cable in the central hole of the
base.
5. Align the base and mark the location
of the two mounting holes on the wall.
Install proper side of base up.
6. Install anchors in the wall.
7. Insert screws in mounting holes on
each side of the base (fig. 2).
8. Gently swing back the circuit board on
the base and push on it until the tabs
lock it.
9. Strip each wire 1/4 inch from end.
10. Insert each wire according to wiring
diagram.
11. Gently push excess wiring back into
hole (fig. 3).

3 | PIR Ready VTR7300 Series-Installation Guide
12. Re-Install wiring terminals in their correct locations (fig. 3).
13. Re-install the cover (top side first) and gently push extra wire length back into the
hole in the wall.
14. Install security screw.
OPERATION OVERVIEW
The VC3xxxX Series Line Voltage Switching Transformer Relay Pack(s) operate as slave
unit(s) under the control of a single master VTR73xxA Terminal Equipment Controller.
Fan operation can be configured and wired for the following:
3 Speed configuration using 3 fan relays ( Low - Med - High )
2 Speed configuration using 2 fan relays ( Low - High )
3 Speed configuration with auto fan speed mode using 3 fan relays
( Low - Med - High - Auto )
2 Speed configuration with auto fan speed mode using 2 fan relays
( Low - High - Auto )
Single fan speed configuration.
The VTR7300 Controller can be configured for typical 2 or 4 pipe heating / cooling FCU
(Fan Coil Unit) applications.
2 or 4 pipe only operation can be configured and wired for the following:
oCooling only
oHeating only
oCooling / Heating with network or local auto changeover
If replacing an existing Line Voltage FCU Thermostat, label the wires
before removal of the thermostat.
Electronic controls are static sensitive devices. Discharge yourself
properly before manipulating and installing the Terminal Equipment
Controller.
A short circuit or wrong wiring may permanently damage the Terminal
Equipment Controller or the equipment.
All VTR7300 series controls are designed for use as operating controls
only and are not safety devices. These instruments have undergone
rigorous tests and verification prior to shipping to ensure proper and
reliable operation in the field. Whenever a control failure could lead to
personal injury and/or loss of property, it becomes the responsibility of
the user / installer / electrical system designer to incorporate safety
devices ( such as relays, flow switch, thermal protections, etc…) and/or
an alarm system to protect the entire system against such catastrophic
failures. Tampering with the devices or unintended application of the
devices will result in a void of warranty.

4 | PIR Ready VTR7300 Series-Installation Guide
2 or 4 pipe only with electric reheat can be configured and wired for the following:
oCooling only
oHeating only
oCooling / Heating with network or local auto changeover
oOn-Off electric reheat only
oCooling with On-Off or modulating VDC pulsed electric reheat
( model dependent )
oHeating with On-Off or modulating VDC pulsed electric reheat
( model dependent )
oCooling / Heating with network or local changeover with On-Off
or modulating VDC pulsed electric reheat ( model dependent )
The VC3xxxX Relay Pack supplies power to the wall VTR73xxA Terminal
Equipment Controller.
The VTR73xxA Controller controls the VC3xxxX Relay Pack(s) via a simple
communication bus.
A maximum of 10 VC3xxxX Relay Pack can be used under a single VTR73xxA
Terminal Equipment Controller.
3 wires minimum are required between the VTR73xxA Controller and the first
VR7300 Relay Pack.
The 3 wire functions are known as the following:
o1 Tx / Rx Communication
o2 Power Hot 7.0 VDC 4 Watts maximum ( required for the
VTR73xxA Controller power )
o3 Power common
Commands for fan speed and valve operation are issued from the VTR73xxA
Terminal Equipment Controller to the VC3xxxX Relay Pack(s)

5 | PIR Ready VTR7300 Series-Installation Guide
MODEL CHART

6 | PIR Ready VTR7300 Series-Installation Guide
Network ready
All Viconics VTR7300 series Terminal Equipment Controllers are designed for
stand-alone operation.
They can be fully integrated into your choice of automation systems using the
available communication adapter options.
If required, stand-alone (Network Ready) Terminal Equipment Controllers can be
field retrofitted with the following communication adapters:
oVCM7000V5000W, Terminal Equipment Controller wireless
communication adapter
oVCM7300T5000B, Terminal Equipment Controller BACnet™ MS-TP
communication adapter
TERMINAL,IDENTIFICATION AND FUNCTION
TERMINAL
IDENTIFICATION
ALL VTR73XXA5X00(X)
TERMINAL EQUIPMENT CONTROLLER
Terminal 3
Tx –Rx Communication
Terminal 4
Power Hot 7.0 VDC
Terminal 5
Power Common
Terminal 13
BI 1 ( Configurable )
Terminal 14
Scom
Terminal 15
BI 2 ( Configurable )
COMMUNICATION WIRING TO VC3XXXXRELAY PACK
Only ONE VC3xxxX Relay Pack with remote monitoring inputs can be used under a single
VTR73xxA Controller. All other slave units must be VC3xxxX Relay Pack(s) WITHOUT
remote inputs. A maximum of 10 VC3xxxX Relay Packs can be used for a single
VTR73xxA Terminal Equipment Controller.

7 | PIR Ready VTR7300 Series-Installation Guide
From the VTR73xxA to the first VC3xxxX Relay Pack
Uses existing or new field wires
A minimum of 3 wires are required 14-22 Ga Solid or Stranded. Shield not
necessary.
From the first VC3xxxX to all other slave VC3xxxX Relay Pack(s)
Uses existing or new field wires
A minimum of 2 wires are required 14-22 Ga Solid or Stranded. Shield not
necessary.
Connect only wires #1 Power Common and #2 Tx/Rx Communication
Network wiring topology
VC3XXX LED OPERATION
LED / Time (Status operation)
Condition of the Status LED
Cause
Solution
2 short blinks
No communication between
the VTR73xxA and the
VC3xxxX relay pack. The
VC3xxxX Relay Pack will
resume its output “no
communication active” status
Check communication
wiring and or power
cycle the controllers
2 short blinks and a
longer blink
Normal communication
between the VTR73xxA and
the VC3xxxX relay pack.
N/A
0.2
2.5
0.6
0.4
0.0
1.0
5.0 sec
Power On
Online to
VTR73xxA

8 | PIR Ready VTR7300 Series-Installation Guide
Wiring of local inputs to VTR73xxA Terminal Equipment Controller
CONFIGURING AND STATUS DISPLAY INSTRUCTIONS
Status display
The VTR73xxA Terminal Equipment Controller features a two-line, eight-character display.
There is a low-level backlight that is always active and can only be seen at night.
When left unattended, the Terminal Equipment Controller has an auto scrolling display
that shows the status of the system. There is an option in the configuration menu to
lockout the scrolling display and to only display the room temperature and conditional
outdoor temperature to the user. With this option enabled, no local status of mode,
occupancy and relative humidity is shown.
Each item scrolls individually with the back lighting in low level mode. Pressing any key
will cause the back light to come on to high level. When left unattended for 10 seconds
after changes are made, the display will resume automatic status display scrolling.
To activate the back light to high level, press any key on the front panel. The back light
display will return to low level when the Terminal Equipment Controller is left unattended
for 45 seconds.
Sequence of auto-scroll status display:
ROOM &
HUMIDITY
SYSTEM MODE
SCHEDULE
STATUS
OUTDOOR
TEMPERATURE
ALARMS
x.x °C or °F
XX % RH
Sys mode
auto
Occupied
Outdoor
x.x °C or °F
Service
If humidity display
enabled
Sys mode
cool
Stand-By
Network value only
Filter
RoomTemp
x.x °C or °F
Sys mode
heat
Unoccup
n/a
Window
If humidity display
is not enabled
Sys mode
off
Override
n/a
Low Batt
VTR73xxA
Terminal Controller
13
-
BI 1
14
-
Scom
15
-
BI 2
Local BI 1 Input by configuration:
-
None (monitoring only)
-
Remote motion detector: Motion NO or Motion NC
- Remote Night Setback: RemNSB
Local BI 2 Input by configuration:
-
None (monitoring only)
-
Door contact: DoorDry
- Window contact Window:

9 | PIR Ready VTR7300 Series-Installation Guide
% RH display is conditional to:
(Humidity display is model and configuration dependent)
Model with RH sensor built in
Display function can be enabled with RH display parameter. Displayed range is
10 to 90 % RH
Outdoor air temperature
Display is only enabled when outdoor air temperature network variable is
received.
Occupancy status
Occupied, Stand-By, Unoccupied and Override status are displayed on the
scrolling display.
Alarms
If alarms are detected, they will automatically be displayed at the end of the
scrolling status display.
When an alarm message is displayed, the backlit screen will illuminate at the
same time as the message and shut off during the rest of the status display.
A maximum of two alarms can appear at any given time. The priority for the
alarms are as follows:
Three status LED’s on the Terminal Equipment Controller cover are used to indicate the
status of the fan (any speed), a call for heat, or a call for cooling.
Fan coil models
When any of the fan speeds are ON, the FAN LED will illuminate
When heating & reheat is ON, the HEAT LED will illuminate
When cooling is ON, the COOL LED will illuminate
Service
Indicates that there is a service alarm as per one of the configurable binary
inputs ( BI2 )
Filter
Indicates that the filters are dirty as per one of the configurable binary
inputs ( BI2 )
Window
Indicates that the outside window or door is opened and that the Terminal
Equipment Controller has cancelled any cooling or heating action ( BI1 )
Low
Batt
Indicates that attached wireless switching devices ( Door or window contact ) have
a low battery condition.
(Only functional when used with a wireless communication adapter)

10 | PIR Ready VTR7300 Series-Installation Guide
USER INTERFACE
Unoccupied mode override
An Override can be made on commercial models during an unoccupied period. If the
Override option is enabled in the lockout configuration, pressing the middle override
button will resume occupied setpoints for a time specified by the parameter “ToccTime”.
Local keypad interface
Any setpoint change can be permanent or temporary based on configuration
parameter (Setpoint Type)
Any setpoint written through the network, will be permanent and cancel any
active temporary setpoints
Lockouts of access to certain functions is made with configuration parameter
(lockout)
Is used to toggle between the different system modes available as per
sequence and menu selected.
Repetitively pressing the button will toggle between all the available modes.
Available menus are dependent on selected sequence of operation.
Is used to toggle between the different fan modes available as per the
sequence and menu selected
Repetitively pressing the button will toggle between all the available modes
Available menus are dependent on selected sequence of operation and menu
selected for Fan
Hotel and lodging applications. Toggles the local user temperature scale
between °F and °C
Commercial and institutional applications. Set a local unoccupied timed
override to occupied mode
In cooling mode only the cooling setpoint is displayed,
In heating mode only the heating setpoint is displayed
In auto mode, (See below)
In cooling mode only the cooling setpoint is displayed,
In heating mode only the heating setpoint is displayed
In auto mode, (See below)

11 | PIR Ready VTR7300 Series-Installation Guide
Dual occupied setpoints adjustment
(Local occupied setpoint adjustment when “Stp Func” = Dual Stp)
Heat/Cool setpoint toggle with MODE button to be active only in AUTO mode.
If cooling, heating or off mode is active, function is disabled.
Single occupied setpoints adjustment
(Local occupied setpoint adjustment when “Stp Func” = Attch Stp )
Unoccupied and stand-by setpoints adjustments
Setting of the stand-by and unoccupied setpoints is done through the network or through
configuration setup only.
Mode button menu sequence.
Modes presented to the user are dependent on the sequence of operation selected.
Default mode is shown in bold when sequence of operation parameter is changed.
AutoMode set to ON = Auto system mode ACTIVE
SEQUENCE SELECTED
MODE MENU
0 = Cooling Only
Off - Cool
1 = Heating Only
Off - Heat
2 = Cooling / Heating
Cooling With Electric Reheat
Off –Auto –Heat –Cool
3 = Heating With Electric Reheat
Off - Heat
4 = Electric Reheat Only
Off –Heat
COOLING
MODE
HEATING
MODE
OFF
MODE
AUTO MODE
Setpoint presented to user is the setpoint from the last
action taken by the Terminal Equipment Controller or
the one currently in use.
If the other setpoint is the one desired, then the
MODE button is used to toggle between the current
displayed one and the other.
Cool XX.X
°F or °C
Heat XX.X
°F or °C
No access to
setpoint
Cool XX.X °F or °C or Heat XX.X °F or °C
Toggle to ( Heat or Cool )with MODE button
COOLING
MODE
HEATING
MODE
OFF
MODE
AUTO MODE
Setpoint presented to user is the setpoint from
the last action taken by the Terminal Equipment
Controller or the one currently in use.
Both heating and cooling setpoints are changed
simultaneously while respecting the minimum
configured deadband
If the other setpoint is the one desired, then the
MODE button is used to toggle between the
current displayed one and the other.
Cool XX.X
°F or °C
Heat XX.X
°F or °C
No access
to setpoint
Cool XX.X °F or °C and Heat XX.X °F or °C
Both heating & cooling setpoints change simultaneously
Toggle from ( Heat or Cool ) using the system MODE button

12 | PIR Ready VTR7300 Series-Installation Guide
AutoMode set to OFF = Auto system mode NOT ACTIVE
SEQUENCE SELECTED
MODE MENU
0 = Cooling Only
Off - Cool
1 = Heating Only
Off - Heat
2 = Cooling / Heating
Cooling With Electric Reheat
Off –Heat –Cool
3 = Heating With Electric Reheat
Off - Heat
4 = Electric Reheat Only
Off –Heat
Available fan button menu sequences
FAN BUTTON
MENU
CONFIGURATION
MENU PRESENTED ARE DEPENDENT ON MODEL USED
AND SEQUENCE OF OPERATION SELECTED
DEFAULT VALUE
WHEN SEQUENCE
TOGGLED
0Low-Med-High
3 Speed configuration using 3 fan relays ( L-M-H )
High
1Low-High
2 Speed configuration using 2 fan relays ( L-H )
High
2Low-Med-
High-Auto
3 Speed configuration with Auto fan speed mode using
3 fan relays ( L-M-H-A )
High
3Low-High-Auto
2 Speed configuration with Auto fan speed mode using
2 fan relays ( L-H-A )
High
4On-Auto
Single Speed configuration. Auto is for Fan on demand /
On is On all the time
Auto
Auto speed fan mode is also offered in heating mode applications; it will not have any
effect on dehumidification. It will strictly be used for noise comfort issues.
Auto Speed Fan Mode operation for sequences 2 and 3 is dependent on Auto Fan
parameter. When Auto Fan is set to:
AS ( Default ) = Auto Speed during occupied periods. Fan is always on during
occupied periods. Low, medium and high speeds operate on temperature offset
from setpoint.
AS AD = Auto Speed / Auto Demand during occupied periods.
oMedium and high speeds operate on temperature offset from setpoint.
oLow speed operates on demand and will shut down when no
demand is present.
INSTALLER CONFIGURATION PARAMETER MENU
Configuration can be done through the network or locally at the Terminal Equipment
Controller.
To enter configuration, press and hold the middle button (°C/°F or Override) for
8 seconds.
If a password lockout is active, “Password” is prompted. Enter password value
using the “up” and “down” arrows and press the middle button again to gain

13 | PIR Ready VTR7300 Series-Installation Guide
access to all configuration properties of the Terminal Equipment Controller.
Entering a wrong password will prevent local access to the configuration menu.
Press the same middle button repetitively to scroll between all the available
parameters.
Use the up and down key to change the parameter to the desired value.
To acknowledge and save the new value, press the middle button again.
The next parameter will now be displayed.
Configuration interface
CONFIGURATION
PARAMETERS
DEFAULT VALUE
SIGNIFICANCE AND ADJUSTMENTS
PswrdSet
Configuration parameters
menu access password
Default value = 0
Range is: 0 to 1000
This parameter sets a password access to prevent
unauthorized access to the configuration menu
parameters. A default value of “0” will not prompt a
password or lock the access to the configuration
menu.
Range is: 0 to 1000
Com Addr
Terminal Equipment
Controller networking address
Default value = 254
Range is: 0 to 254
Conditional parameter to BACnet™ MS-TP models
VTR73xxX5x00B
Conditional parameter to Wireless models
VTR73xxX5x00W
For BACnet™ MS-TP models, the valid range is
from 1 to 127. Default value of 254 disables
BACnet™ communication for the Terminal
Equipment Controller.
For wireless models, the valid range is 0 to 254
with a maximum of 30 Terminal Equipment
Controller per VWG
Re-starts the configuration parameter list from the beginning
Enters the configuration mode. Press and hold for 8 seconds
Pressing repetitively will individually scroll all the available parameters
Adjust / rotate parameter value down
Adjust / rotate parameter value up

14 | PIR Ready VTR7300 Series-Installation Guide
PAN ID
Personal Area Network
Identification
Default value = 0
Range is: 0 to 1000
Conditional parameter to Wireless models
VTR73xxX5x00W
This parameter will only appear when a wireless
network adapter is present. If the Terminal Equipment
Controller is installed as a stand-alone unit or with a
BACnet™ or Echelon™ adapter, this parameter will
not be used or displayed.
This parameter (Personal Area Network Identification)
is used to link specific Terminal Equipment
Controllers to a single specific Viconics wireless
gateway ( VWG ). For every Terminal Equipment
Controller reporting to a gateway ( maximum of 30
Terminal Equipment Controllers per gateway ), be
sure you set the SAME PAN ID value both on the
gateway and the Terminal Equipment Controller(s).
The default value of 0 is NOT a valid PAN ID.
The valid range of available PAN ID is from 1 to 1000.
Range 1 to 500 for centralized networked applications
using a VWG or a Jace with the wireless stat driver
Range 501 to 1000 is for stand-alone applications
where no VWG or Jace with the wireless stat driver is
used.
Channel
Channel selection
Default value = 10
Range is: 10 to 26
Conditional parameter to Wireless models
VTR73xxX5x00W
This parameter will only appear when a wireless
network adapter is present. If the Terminal Equipment
Controller is installed as a stand-alone unit or with a
BACnet™ or Echelon™ adapter, this parameter will
not be used or displayed.
This parameter (Channel) is used to link specific
Terminal Equipment Controllers to specific Viconics
wireless gateway(s) ( VWG ). For every Terminal
Equipment Controller reporting to a gateway
( maximum of 30 Terminal Equipment Controllers per
gateway ), be sure you set the SAME channel value
both on the gateway and the Terminal Equipment
Controller(s).
Viconics recommends using only the usage of
channels 15 and 25 only.
The default value of 10 is NOT a valid channel. The
valid range of available channel is from 11 to 26

15 | PIR Ready VTR7300 Series-Installation Guide
Get From
Terminal Equipment
Controller Get From
another device
configuration utility
Default value = 0
Range is: 0 to 254
Conditional parameter to Wireless models
VTR73xxX5x00W
Entering a MAC address enables an automatic routine that
automatically fetches all the required configuration properties of
the current device from another already configured device an
copies the same required configured property values.
If a value other than the default value of 255 is entered, user
will then be prompted to exit the Configuration Menu thus
leaving all other parameter configuration to be copied from the
referenced controller MAC address.
Ex.: If you are currently configuring MAC12 and the settings
matches exactly the settings of ZN MAC5, then enter 5 as the
current parameter value.
If the process is successful and all required configuration
properties have been copied, the value will revert back to
255
If the process is NOT successful and all required
configuration properties have NOT been copied ( either the
reference device is NOT the same model number or is
offline or does not exists ) the value will revert back to 254
to indicate the failure of the process
Leaving the Get From parameter to 255 means that every
configuration parameters will be set manually.
BI 1
Binary input no.1
configuration
Default value = None
(None): No function will be associated with the input. Input can
be used for remote network monitoring.
(Rem NSB): remote NSB timer clock input. The scheduling will
now be set as per the binary input. It provides low cost setback
operation via a dry contact
Contact opened = Occupied
Contact closed = Unoccupied
(Motion NO) or (Motion NC): Advanced PIR occupancy
functions using a Normally Open (NO) or Normally Closed (NC)
remote PIR motion sensor. Occupancy mode is now set as per
applied PIR function and configuration. Application information
and examples are available in document: APP-PIR-Guide-Exx.
This document will provide the installers and system designers
with detailed examples on applications, parameter configuration
information, sequence of operation, troubleshooting and
diagnostic help required for the proper usage of the PIR
accessory covers
(Window) EMS: Forces the system to disable any current
heating or cooling action by the Terminal Equipment Controller.
The mode stays the same and the current setpoints are the
same Occupied setpoints. Only the outputs are disabled. There
is a Door/Window alarm displayed on the Terminal Equipment
Controller to indicate to the local tenant that the door/window
needs to be closed for cooling or heating to resume.
Contact opened = Window Opened
Contact closed = Window Closed

16 | PIR Ready VTR7300 Series-Installation Guide
BI 2
Binary input no.2
configuration
Default value = None
(None): No function will be associated with the input. Input can
be used for remote network monitoring.
(Door Dry) Door contact & Motion detector: This
configuration is only functional if binary input #1 is set to
Motion NO or Motion NC or a PIR accessory cover is used.
With this sequence enabled, the occupancy is now commanded
through those 2 inputs. Any motion detected will set the zone to
occupied status. The zone will remain in occupied mode until
the door contact switch opens and closes. The Terminal
Equipment Controller will then go in stand-by mode. If more
movements are detected, the occupied mode will resume.
While the door is opened, any movements detected by the
remote PIR sensor or the PIR accessory cover will be ignored.
Use a Normally Closed contact switching device.
Contact opened = Door opened
Contact closed = Door closed
RUI 1
Remote Universal input
no.1 configuration
Default value = None
(None): No function will be associated with the input. Input can
be used for remote network monitoring.
(COC/NH) Change over dry contact. Normally Heat: Used
for hot / cold water or air change over switching in 2 pipe
systems.
Contact closed = Cold water or air present
Contact opened = Hot water or air present
Only used and valid if system is setup as 2 pipes. Parameter
( Pipe No ) set as 2 pipes.
(COC/NC) Change over dry contact. Normally Cool: Used
for hot / cold water or air change over switching in 2 pipe
systems.
Contact closed = Hot water present
Contact opened = Cold water present
Only used and valid if system is setup as 2 pipes. Parameter
(Pipe No ) set as 2 pipes.
(COS) Change over analog sensor: Used for hot / cold water
or air change over switching in 2 pipe systems.
Only used and valid if system is setup as 2 pipes. Parameter
(Pipe No ) set as 2 pipes.
If water temperature is > 78 °F = Hot water present
If water temperature is < 75 °F = Cold water present
(Filter): A backlit flashing Filter alarm will be displayed on the
Terminal Equipment Controller LCD screen when the input is
energized. It can be tied to a differential pressure switch that
monitor filters.

17 | PIR Ready VTR7300 Series-Installation Guide
RUI 1
Cont’d
Contact opened = No alarm
Contact closed = Alarm displayed
(Service): A backlit flashing Service alarm will be displayed on
the Terminal Equipment Controller LCD screen when the input
is energized. It can be tied in to the AC unit control card, which
provides an alarm in case of malfunction.
Contact opened = No alarm
Contact closed = Alarm displayed
RBI 2
Remote Binary input no.2
configuration
Default value = None
(None): No function will be associated with the input. Input can
be used for remote network monitoring.
(Filter): a backlit flashing Filter alarm will be displayed on the
Terminal Equipment Controller LCD screen when the input is
energized. It can be tied to a differential pressure switch that
monitor filters.
Contact opened = No alarm
Contact closed = Alarm displayed

(Service): a backlit flashing Service alarm will be displayed on
the Terminal Equipment Controller LCD screen when the input
is energized. It can be tied in to the AC unit control card, which
provides an alarm in case of malfunction.
Contact opened = No alarm
Contact closed = Alarm displayed
MenuScro
Menu scroll
Default value = On =
Scroll active
Removes the scrolling display and displays the room
temperature/humidity to the user. With this option enabled, no
mode, schedule and outdoor temperature status is given.
On = Scroll active
Off = Scroll not active
AutoMode
Enables Auto menu for
Mode button
Default value = On
Enables Auto function for the mode button
For sequences 2, 4 & 5 only
On = Auto active (Off-Cool-Heat-Auto)
Off = auto not active (Off-Cool-Heat)
C or F
Sets scale of the Terminal
Equipment Controller
Default value = °F
°F for Fahrenheit scale
°C for Celsius scale
On hotel models, this sets the default value when the Terminal
Equipment Controller powers up

18 | PIR Ready VTR7300 Series-Installation Guide
%RH disp
Local %RH Display
Default value = Off
Models with Humidity
sensor only
Conditional parameter to Humidity models
VTR735xX5x00(X)
Enables the display of humidity value below the room
temperature value on the display
On = Display %RH
Off = No display of %RH
Lockout
Keypad lockout levels
Default value = 0 No lock
USER KEY FUNCTIONS
LEVEL
0
1
2
3
4
5
PulsedHt
VDC output configuration
Default Value = Off
VDC output configuration. VC3000 series model dependent
Off = Regular On-Off control for VC350xE models only
Can be used with 2 & 4 pipes applications
On = VDC SSR electric heat 10 second pulsed time
base modulation for VC340xE models only
Can only be used with 2 pipes system only.
Occ Out = VDC Occupancy output follows local device
occupancy for VC3514E model only.

Occupied & Temporary Occupied = Contact closed
Stand-By & Unoccupied = Contact opened
Pipe No
System type installation
Number of pipes
Default is: 4.0 Pipes
Defines the type of system installed
2.0 Pipes, will limit the number of sequences of operation
available from 0 to 4
Will enable heat/cool operation from the same output
4.0 Pipes, can access all the sequences of operation from
0 to 2
Will enable heat/cool operation from different output

19 | PIR Ready VTR7300 Series-Installation Guide
SeqOpera Sequence of
operation
Default is: Sequence #1
Selects the initial sequence of operation required by the
installation type and the application
SYSTEM = 2 PIPES
SYSTEM = 4 PIPES
0 = Cooling Only
Available
Available
1 = Heating Only
Available
Available
2 = Cooling / Heating
or
Cooling With
Electric Reheat
Available
Cooling With Electric Reheat
Available
Cooling / Heating
3 = Heating With
Electric Reheat
Available
Not available
4 = Electric Reheat Only
Available
Not available
For 2 Pipe output applications, the system access is limited
if RUI 1 is configured for local changeover COS, COC/NC
or COC/NC. The current water temperature detected by the
RUI 1 then limits the system mode available for the local
configuration or network write.
For sequence 2 & 3, set PulsedHt to On to enable pulsed
electric reheat applications with VR7300B & E
Fan Menu
Mode button menu
configuration
Default is: Menu #4
Menu displayed are dependent on model used and sequence
of operation selected
Auto Mode operation for sequences 2 and 3 is dependent on
Auto Fan parameter
0 = Low-Med-High
3Speed configuration using 3 fan relays ( L-M-H )
1 = Low-High
2Speed configuration using 2 fan relays ( L-H )
2 = Low-Med-High-Auto
3Speed configuration with Auto fan speed mode
using 3 fan relays ( L-M-H-A )
3 = Low-High-Auto
2Speed configuration with Auto fan speed mode using
2 fan relays ( L-H-A )
4 = On-Auto
Single Speed configuration. Auto is for Fan on demand / On
is On all the time
DHumiLCK
Dehumidification lockout
Default value:
On = Authorized
Conditional parameter to Humidity models
VTR735xX5x00(X)
Typically toggled via the network.
This variable enables or disables dehumidification based on
central network requirements from the BAS front end
On = Dehumidification Authorized
Off = Dehumidification Not Authorized

20 | PIR Ready VTR7300 Series-Installation Guide
%RH set
Dehumidification setpoint
Default is 50 % RH
Conditional parameter to Humidity models
VTR735xX5x00(X)
Used only if dehumidification sequence is enabled:
Range is: 30-95% RH
DehuHyst
Dehumidification
Hysterisys
Default is 5 % RH
Conditional parameter to Humidity models
VTR735xX5x00(X)
Humidity control hysterisys. Used only if dehumidification
sequence is enabled:
Range is: 2 to 20% RH
DehuCool
Maximum
Dehumidification
Cooling output
Default is 100 %
Conditional parameter to Humidity models
VTR735xX5x00(X)
Maximum cooling valve position when dehumidification is
enabled. This can be used to balance smaller reheat loads
installed relative to the capacity of the cooling coil.
Range is: 20 to 100 %
St-By TM
Stand-by Timer value
Default 0.5 hours
Time delay between the moment when the PIR sensor
detected the last movement in the area and the time when the
Terminal Equipment Controller stand-by mode and setpoints
become active.
Range is: 0.5 to 24.0 hours in 0.5hr increments
Unocc TM
Unoccupied Timer value
Default 0.0 hours
Time delay between the moment when the Terminal
Equipment Controller toggles to stand-by mode and the time
when the Terminal Equipment Controller unoccupied mode
and setpoints become active.
The factory value or 0.0 hours: Setting this parameter to its
default value of 0.0 hours disables the unoccupied timer.
This prevents the Terminal Equipment Controller to drift from
stand-by mode to unoccupied mode when PIR functions are
used
Range is: 0.0 to 24.0 hours in 0.5hr increments
St-By HT
Stand-by heating
setpoint
Default value = 69 °F
The value of this parameter should reside between the
occupied and unoccupied heating setpoints and make sure
that the difference between the stand-by and occupied value
can be recovered in a timely fashion when movement is
detected in the zone.
Stand-by heating setpoint range is: 40 to 90 °F
( 4.5 to 32.0 °C )
St-By CL
Stand-by cooling
setpoint limit
Default value = 78 °F
The value of this parameter should reside between the
occupied and unoccupied cooling setpoints and make sure
that the difference between the stand-by and occupied value
can be recovered in a timely fashion when movement is
detected in the zone.
Stand-by cooling setpoint range is: 54 to 100 °F
( 12.0 to 37.5 °C )
