Victaulic VicFlex I-VICFLEX User manual

I-VICFLEX
FIELD INSTALLATION HANDBOOK
Victaulic®VicFlex™ Products
Revision A 03/2021
WARNING
• Read and understand all instructions before attempting to install any
Victaulic products.
• Always verify that the piping system has been completely depressurized
and drained immediately prior to installation, removal, adjustment, or
maintenance of any Victaulic products.
• Confirm that any equipment, branch lines, or sections of piping that may
have been isolated for/during testing or due to valve closures/positioning
are identified, depressurized, and drained immediately prior to installation,
removal, adjustment, or maintenance of any Victaulic products.
• Wear safety glasses, hardhat, foot protection, and hearing protection.
Failure to follow these instructions could result in death or serious personal
injury and property damage.
Contact Victaulic with any questions regarding safe and proper installation
of products featured in this handbook.
Visit victaulic.com for the most up-to-date information on Victaulic products.

I-VICFLEX_3
TABLE OF CONTENTS REV_A
Table of Contents
GENERAL
INFORMATION ....................................................................... 11
Hazard Identification ...................................................................12
Introduction.................................................................................12
CONSTRUCTION REQUIREMENTS ........................................... 17
STYLES AB1, AB2, AND AB10 BRACKETS ............................... 21
Introduction.................................................................................22
Style AB1 Bracket Assembly Drawing ..........................................22
Style AB2 Bracket Assembly Drawing ..........................................23
Style AB10 Bracket Assembly Drawing ........................................24
Installation of Style AB1, AB2, and AB10 Brackets for ASTM
635 Ceiling Suspension Systems in Accordance with ASTM 636
Standards....................................................................................24
Installation of the Style AB2 Bracket for ASTM C645 Hat Furring
Channel Ceiling Systems Installed in Accordance with ASTM C754
Standards (FM and VdS only) ......................................................26
Wood Joists/Studs Installation
(FM Only for AB1 and FM/UL for AB2) ........................................28
ASTM C645 Metal Joists/Studs in Accordance with ASTM C754
Standards Installation (FM Only for AB1 and
FM/UL for AB2)...........................................................................29
Alternative #1 – Wood Joist/Stud Installation
(FM Only for AB1 and AB2).........................................................30
Alternative #1 – Metal Joist/Stud Installation
(FM Only for AB1 and AB2).........................................................31
Alternative #2 – Wood Joist/Stud Installation
(FM Only for AB1 and AB2).........................................................32
Alternative #2 – Metal Joist/Stud Installation
(FM Only for AB1 and AB2).........................................................33
STYLE AB3 BRACKET ............................................................ 35
Introduction.................................................................................36
Style AB3 Bracket Assembly Drawing ..........................................36
Installation of the Style AB3 Surface-Mount Bracket on a Wall or
Ceiling.........................................................................................37

I-VICFLEX_4TABLE OF CONTENTS REV_A
STYLE AB4 BRACKET ............................................................ 39
Introduction.................................................................................40
Style AB4 Bracket Assembly Drawing..........................................40
Installation of AB4 Bracket for ASTM C645 Hat Furring Channel
Ceiling Systems in Accordance with ASTM C754 Standards......... 41
STYLE AB5 BRACKET ............................................................ 43
Introduction.................................................................................44
Style AB5 Bracket Assembly Drawing ..........................................44
Installation for Wood Joists/Studs.................................................45
STYLE AB6 BRACKET ............................................................ 51
Introduction.................................................................................52
Dry Sprinkler Installation Example................................................52
Technical Data for Models V33, V36, AND V40 Dry Sprinklers.....53
Assembly Weights .......................................................................55
Notes For Preparation of Sleeve And Skirt And Recessed
Configurations .............................................................................56
Installation of the Style AB6 Bracket Assembly ............................57
Adjusting the Location of the V33, V36, or V40 Dry Sprinkler.......58
Installation of the Series AH2 or AH2-CC Flexible Hose to the
Style AB6 Threaded Inlet Adapter................................................59
Installation of the Skirt, Recessed Escutcheon, or Flush Plate......59
Instructions for Using the Style AB6 Adapter for Draining the
Assembly ....................................................................................60
Bulb Protector Removal...............................................................60
STYLE AB7 BRACKET ............................................................ 61
Introduction.................................................................................62
Style AB7 Bracket Assembly Drawing ..........................................62
Installation of Style AB7 Bracket Assembly for ASTM C635 Ceiling
Suspension Systems installed in Accordance with ASTM C636
Standards....................................................................................63
Installation for Wood Joists/Studs
(FM Only) ....................................................................................64
Installation for ASTM C645 Metal Joists/Studs in Accordance
with ASTM C754 Standards (FM Only).........................................65
Alternative Wood Joists/Studs Installation (FM Only).....................66
Alternative Metal Joist/Stud Installation (FM Only)........................67

I-VICFLEX_5
TABLE OF CONTENTS REV_A
STYLE AB11 BRACKET........................................................... 69
Introduction.................................................................................70
Style AB11 Bracket Assembly Drawing ........................................70
Installation of Style AB11 Brackets for ASTM C635 Ceiling
Suspension Systems Installed in Accordance with ASTM C636 or
ASTM C754 Standards ................................................................71
STYLE AB12 BRACKET........................................................... 73
Introduction.................................................................................74
Style AB12 Bracket Assembly Drawing ........................................74
Installation of Style AB12 Brackets Onto 3/8-inch/M10 Threaded
Rod.............................................................................................75
Style AB12 Bracket Installation Dimensions .................................77
ABBA/ABMM BRACKET .......................................................... 79
Introduction.................................................................................80
Style ABMM Bracket Assembly Drawing ......................................80
Style ABBA Bracket Assembly Drawing........................................81
Installation Notes for the Style ABBA Bracket ..............................82
Installation Configurations for the Style ABBA Bracket .................83
Installation Notes for the Style ABMM Bracket .............................84
Installation Configurations for the Style ABMM Bracket ................85
STYLE AQC-U BRACKET......................................................... 87
Introduction.................................................................................88
AQC-U Bracket Installation Components (Standard Installation) ...88
Attaching the Style AQC-U to the Cleanroom Ceiling Grid
(Gordon Installation) ....................................................................90
STYLE C-AQC BRACKET ......................................................... 93
Introduction.................................................................................94
Connection to the Sprinkler Piping Using an Adapter Nipple and
a Style C-AQC Sprinkler...............................................................94
Attaching the Style C-AQC to the Cleanroom Ceiling Grid .............95
STYLE AQD-M BRACKET ........................................................ 97
Introduction.................................................................................98
Style AH2-CC Flexible Hose Assembly Drawing ...........................98
Style AQD-M Bracket Assembly Drawing .....................................99
Connection to the Sprinkler Piping Using the Supplied No. 140
Male NPT or BSPT Thread X Groove Adapter ............................100
Installing the Style AQD-M Bracket onto the Duct ......................100
Sprinkler Installation ..................................................................102
Sprinkler Bag Inspection/Maintenance.......................................103

I-VICFLEX_6TABLE OF CONTENTS REV_A
STYLE AQD BRACKET .......................................................... 105
Introduction...............................................................................106
Connecting the Style AQD Sprinkler Fitting to the Branchline .....106
Installing the Style AQD onto the Duct .......................................107
Inspection ................................................................................. 112
VS1 DRY SPRINKLER ............................................................113
Introduction............................................................................... 114
Important Installation Information .............................................. 114
Style VS1 Sprinkler Assembly Drawing....................................... 115
Style VB1 Bracket Assembly Drawing ........................................ 115
Style VB2 Bracket Assembly Drawing ........................................ 116
Style VB3 Bracket Assembly Drawing ........................................ 117
Style VB4 Bracket Assembly Drawing ........................................ 118
Style VS1 Sprinkler Assembly Pitching Requirements................. 119
Style VB1 Bracket Installation for Wood or Metal Joists/Studs.....121
Style VB2, Style VB3, and VB4 Brackets- Installation for ASTM
C635 Ceiling Suspension Systems Installed with Lay-in Tiles
(in Accordance with ASTM C636 Standards) .............................124
Style VB3 and VB4 Brackets - Installation for Wood Joists/
Studs ........................................................................................126
Style VB3 and VB4 Brackets – Installation for ASTM C645 Metal
Joists/Studs Installed in Accordance with ASTM C754
Standards..................................................................................127
CONNECTION TO THE SPRINKLER PIPING............................ 129
Connection to the Sprinkler Piping Using an Adapter Nipple and a
Series AH1,
AH1-LP, AH2, AH2-LP, AH2-300, AH3,
AH3-LP, AH4, AH4-LP, AH5, or AH2-638 VICTAULIC®VicFlex™
Flexible Hose ............................................................................130
1-inch/DN25 IGS™Connection to the Sprinkler Piping Using a
Series AH1-CC, AH1-CC-LP, AH2-CC, AH2-CC-LP, or AH2-CC-300
VICTAULIC®VicFlex™Flexible Hose ...........................................131
Instructions for the Initial Use of A Victaulic®Firelock™No. 101 90°
Elbow or No. 102 Straight Tee Installation-Ready™Fitting with a
VICTAULIC®VicFlex™Flexible Hose
(1-inch/DN25 IGS™Connection) ................................................135
Instructions for Reassembly of a Series AH1-CC, AH1-CC-LP, AH2-
CC, AH2-CC-LP, or AH2-CC-300 VICTAULIC®VicFlex™ Flexible
Hose .........................................................................................137

I-VICFLEX_7
TABLE OF CONTENTS REV_A
CONNECTING THE SPRINKLER REDUCING NIPPLE TO THE
FLEXIBLE HOSE................................................................... 139
Connecting the Sprinkler Reducing Nipple to the Flexible Hose
(AB1/AB2/AB3/AB4/AB5/AB7/AB8/AB10/ABBA/ABMM) ............140
Connecting the Sprinkler Reducing Nipple to the Flexible Hose
(AB11/AB12) .............................................................................140
SPRINKLER REDUCING NIPPLE INSTALLATION......................141
Sprinkler Reducing Nipple Installation for
Style AB1/AB7/AB10/AB11 Brackets ..........................................142
Sprinkler Reducing Nipple Installation for the Style AB2
Bracket .....................................................................................143
Sprinkler Reducing Nipple Installation for Style AB4/AB5/AB8
Brackets....................................................................................144
Sprinkler Reducing Nipple Installation for Style ABBA/ABMM
Brackets....................................................................................145
Sprinkler Reducing Nipple Installation for Style VB2/VB3/VB4
Brackets....................................................................................146
SPRINKLER INSTALLATION .................................................. 149
Sprinkler Installation for AB1, AB2, AB3, AB4, AB5, AB7, AB10,
AB11, AB12, ABBA, and ABMM Brackets .................................150
Ceiling Tile Installation for AB1 and AB2 Brackets......................150
VICTAULIC®VICFLEX™TAMPER-EVIDENT LABELS ..................151
Overview ..................................................................................152
Applying the Tamper-Evident Label to the Style AB7 End
Bracket .....................................................................................153
MINIMUM BEND RADIUS GUIDES......................................... 155
Minimum Bend Radius Guide USAGE........................................156
TECHNICAL DATA................................................................. 157
Flexible Hose Bend Characteristics............................................158
Maximum Working Pressure Rating of Flexible Hoses ................158
Maximum Ambient Temperature Rating of Flexible Hoses..........159
Ambient Temperature for Wet Piping Systems Installed with Style
VS1 Dry Sprinklers ....................................................................159
Listing and Approval Information – Flexible Hose and Bracket
Combinations (AH1/AH1-LP)......................................................160
Listing and Approval Information – Flexible Hose and Bracket
Combinations (AH1-CC/AH1-CC-LP) ..........................................161
Listing and Approval Information – Flexible Hose and Bracket
Combinations (AH2/AH2-LP) .....................................................162
Listing and Approval Information – Flexible Hose and Bracket
Combinations (AH2-CC/AH2-CC-LP)..........................................163

I-VICFLEX_8TABLE OF CONTENTS REV_A
Listing and Approval Information – Flexible Hose and Bracket
Combinations (AH2-CC-300/AH2-300 AND AH3/AH3-LP).........164
Listing and Approval Information – Flexible Hose and Bracket
Combinations (AH4/AH4-LP).....................................................165
Listing and Approval Information – Flexible Hose and Bracket
Combinations (AH5 AND VS1) ........................................... 166
Listing and Approval Information – Sprinkler Fittings for Cleanroom
Applications and Ceiling Grid Manufacturer Combinations
(AQC-U and C-AQC)..................................................................167
Listing and Approval Information– Sprinkler Fittings for Duct
Applications and Duct Material Combinations
(AQD and AQD-M) ....................................................................167
Flexible Hose Minimum Bend Radius........................................168
Branchline Connection ..............................................................169
Series AH1/AH1-CC Flexible Hose Friction Loss Data (FM) ........ 170
Series AH1-LP/AH1-CC-LP Flexible Hose Friction Loss Data
(FM).......................................................................................... 171
Series AH2/AH2-CC Flexible Hose Friction Loss Data (FM) .......172
Series AH2-LP/AH2-CC-LP Flexible Hose Friction Loss Data
(FM)..........................................................................................173
Series AH2-300/AH2-CC-300 Flexible Hose Friction Loss Data (FM)
174
Series AH2-AB6/AH2-CC-AB6 Friction Loss Data (FM).............. 175
Series AH3/AH3-LP Flexible Hose Friction Loss Data (FM) ........ 176
Series AH4/AH4-LP Flexible Hose Friction Loss Data (FM) ........177
Style AQC-U Flexible Hose Sprinkler Fitting Friction Loss Data
(FM).........................................................................................178
Style C-AQC Flexible Hose Sprinkler Fitting Friction Loss Data
(FM)..........................................................................................179
Style AQD-M Flexible Hose Sprinkler Fitting Friction Loss Data
(FM)..........................................................................................180
Style AQD Flexible Hose Sprinkler Fitting Friction Loss Data
(FM)..........................................................................................181
Series AH1/AH1-CC Flexible Hose Friction Loss Data (UL) .........182
Series AH1-LP Flexible Hose Friction Loss Data (UL) .................183
Series AH2/AH2-CC Friction Loss Data (UL) ..............................184
Series AH2-300/AH2-CC-300 Flexible Hose Friction Loss Data
(UL) ..........................................................................................186
Series AH2-LP/AH2-CC-LP Flexible Hose Friction Loss Data
(UL) ..........................................................................................187

I-VICFLEX_9
TABLE OF CONTENTS REV_A
Series AH2-AB6/AH2-CC-AB6 Flexible Hose Friction Loss Data
(UL) ..........................................................................................189
Series AH5 Flexible Hose Friction Loss Data (UL)......................190
Series AH1, AH1-CC, AH1-LP, and AH1-CC-LP Flexible Hose
Friction Loss Data (VDS)............................................................191
Series AH2, AH2-CC, AH2-LP, and AH2-CC-LP Flexible Hose
Friction Loss Data (VDS)............................................................192
Series AH3, AH3-LP and AH4 Flexible Hose Friction Loss Data
(VDS) ........................................................................................193
Series AH1, AH1-CC, AH2, and AH2-CC Flexible Hose Friction
Loss Data (LPCB)......................................................................194
Series AH1 Flexible Hose Friction Loss Data (CCC) ....................195
Series AH2 Flexible Hose Friction Loss Data (CCC)....................196
Series AH3 Flexible Hose Friction Loss Data (CCC)....................197
Series AH4 Flexible Hose Friction Loss Data (CCC)....................198
Style C-AQC Flexible Hose Sprinkler Fitting Friction Loss Data
(CCC) ........................................................................................199
Series AH4 Assembly Model Number Correlation ..................... 200
Series AH5 Assembly Model Number Correlation ..................... 200
Low-Profile Elbow Product Marking Information .........................201

I-VICFLEX_10
This page intentionally left blank

I-VICFLEX_11
General
Information

I-VICFLEX_12 GENERAL INFORMATION REV_A
HAZARD IDENTIFICATION
Definitions for identifying the various hazard levels are provided below.
This safety alert symbol indicates important safety messages. When you
see this symbol, be alert to the possibility of personal injury. Carefully read
and fully understand the message that follows.
DANGER
• The use of the word "DANGER"
identifies an immediate hazard
with a likelihood of death or serious
personal injury if instructions,
including recommended
precautions, are not followed.
WARNING
• The use of the word "WARNING"
identifies the presence of hazards
or unsafe practices that could
result in death or serious personal
injury if instructions, including
recommended precautions, are not
followed.
CAUTION
• The use of the word "CAUTION"
identifies possible hazards or
unsafe practices that could result
in personal injury and product or
property damage if instructions,
including recommended
precautions, are not followed.
NOTICE
• The use of the word "NOTICE"
identifies special instructions that
are important but not related to
hazards.
INTRODUCTION
This field handbook is a guide for installation of Victaulic®VicFlex™Sprinkler System Fittings
and shall be used in combination with Victaulic®VicFlex™submittal documents and local
building codes to ensure proper product selection and application. Additional copies of
installation instructions and submittal documents are available to download on the Victaulic®
website, victaulic.com.
Always follow good piping practices. Specified pressures, temperatures, performance
standards, and tolerances shall never be exceeded. Many applications require recognition of
special conditions, code requirements, and the use of safety factors, which shall be evaluated
by qualified system engineers.
Always check compliance with local codes, as well as engineering specifications.
NOTICE
• Victaulic®maintains a continual policy of product improvement. Therefore, Victaulic®
reserves the right to change product specifications, designs, and standard equipment
without notice and without incurring obligation.
• Victaulic®is not responsible for system design, nor does the company assume any
responsibility for systems that are designed improperly.
• This handbook is not intended to be a substitute for competent, professional
assistance, which is a prerequisite for any product application.
• The information published in this handbook and other Victaulic®literature supersedes
all previously published information.
• Drawings and/or pictures in this manual may be exaggerated for clarity.
• The field assembly handbook contains trademarks, copyrights, and products with
patented features that are the exclusive property of Victaulic®.
• While every effort has been made to ensure its accuracy, Victaulic®, its subsidiaries,
and its affiliated companies make no expressed or implied warranty of any kind
regarding the information contained or referenced in this handbook. Anyone who uses
the information contained herein does so at their risk and assumes any liability that
results from such use.

I-VICFLEX_13GENERAL INFORMATION REV_A
WARNING
• Read and understand all instructions before attempting to install any Victaulic®
products.
• Always verify that the piping system has been completely depressurized and
drained immediately prior to installation, removal, adjustment, or maintenance
of any Victaulic®products.
• Confirm that any equipment, branch lines, or sections of piping that may
have been isolated for/during testing or due to valve closures/positioning are
identified, depressurized, and drained immediately prior to installation, removal,
adjustment, or maintenance of any Victaulic®products.
• Wear safety glasses, hardhat, and foot protection.
Failure to follow these instructions could result in death or serious personal injury
and property damage.
• Victaulic®VicFlex™products shall be used only in fire protection systems that
are designed and installed in accordance with current, applicable National Fire
Protection Association (NFPA 13, 13D, 13R, etc.) standards, or equivalent
standards, and in accordance with applicable building and fire codes. These
standards and codes contain important information regarding protection of
systems from freezing temperatures, corrosion, mechanical damage, etc.
• These installation instructions are intended for an experienced, trained installer.
The installer shall understand the use of this product and why it was specified
for the particular application.
• The installer shall understand common industry safety standards and potential
consequences of improper product installation.
• It is the system designer’s responsibility to verify suitability of stainless steel
flexible hose for use with the intended fluid media within the piping system and
external environment.
• The material specifier shall evaluate the effect of chemical composition, pH
level, operating temperature, chloride level, oxygen level, and flow rate on
stainless steel components to confirm system life will be acceptable for the
intended service.
• It is the responsibility of the owner of a building or their authorized agent
to provide the sprinkler system installer with any knowledge that the water
supply might be contaminated with or conducive to the development of
microbiologically influenced corrosion (MIC), including as required by NFPA 13.
Failure to identify adverse water quality issues may affect the VicFlex product
and void the manufacturer’s warranty.
Failure to follow installation requirements and local and national codes and
standards could compromise system integrity or cause system failure, resulting in
death or serious personal injury and property damage.
• Replacement/relocation of Victaulic®VicFlex™products SHALL be performed by
qualified personnel familiar with the system’s original design criteria, sprinkler
listings/approvals, and state and local codes (including NFPA 13 standards).
Failure to properly replace/relocate a Victaulic®VicFlex™product could affect its
performance during a fire, resulting in death or serious personal injury and property
damage.

I-VICFLEX_14 GENERAL INFORMATION REV_A
California Customers – Proposition 65 Compliance:
WARNING:
• The painted surface of these products can expose you to
chemicals, including BBP, which are known to the State of
California to cause birth defects or other reproductive harm. For
more information, go to www.p65warnings.ca.gov.
• Brass components, even those manufactured from “low lead” or
“no lead” brass can expose you to trace amounts of chemicals,
such as lead, which is known to the State of California to cause
cancer and birth defects of other reproductive harm. For more
information go to www.p65warnings.ca.gov.
IMPORTANT INSTALLATION INFORMATION
The below instructions apply to all Victaulic® VicFlex™products. For additional
information, always refer to the specific product’s installation instructions featured in this
handbook.
CAUTION
• To protect hoses from dirt, debris, moisture, and other environmental factors,
hoses shall remain in factory packaging and be stored in a dry location prior to
installation.
Failure to protect hoses may cause product failure, resulting in joint leakage and
property damage.
• Victaulic®VicFlex™products shall be installed according to current, applicable
National Fire Protection Association (NFPA 13, 13D, 13R, etc.) standards or
equivalent standards and in accordance with applicable building and fire codes.
Victaulic®VicFlex™products are intended to be installed in wet, dry, or preaction
actuated systems. Deviations from these standards or alterations to Victaulic®
VicFlex™products or sprinklers will void any Victaulic®warranty and will impact
system integrity. Installations shall meet the provisions of the local authority
having jurisdiction and local codes, as applicable, and shall comply with all design
specifications.
• Victaulic® VicFlex™products shall not be intermixed with other manufacturer’s
flexible sprinkler products.
• For recessed sprinklers, a standard long elbow reducer is recommended.
• For concealed sprinklers, a short 90° elbow reducer is recommended.
• Refer to the specific Victaulic®product publication for applications and listing
information. In addition, when installing Victaulic®FireLock™Automatic
Sprinklers with Victaulic®VicFlex™Sprinkler Fittings, refer to the I-40
Installation and Maintenance Instructions for details on sprinkler installation
requirements. Product publications and installation instructions can be
downloaded at victaulic.com.
• Size the piping system to meet or exceed the minimum required flow rate for the
sprinkler system.
• Per NFPA requirements, flush the system to remove foreign material. Continue to
flush the system until water runs clear.
• DO NOT install sprinkler system piping through heating ducts.

I-VICFLEX_15GENERAL INFORMATION REV_A
• DO NOT connect sprinkler system piping to domestic hot water systems.
• DO NOT allow electrical wiring or other cabling to be hung or wrapped around the
sprinkler piping system.
• DO NOT install sprinklers and sprinkler fittings where ambient conditions may fall
below or exceed the maximum listed or approved temperature ratings.
• The flexible hose shall not be bent or fluctuated up-and-down or side-to-side when
pressurized.
• Victaulic®VicFlex™flexible hoses may be painted or coated, provided that the paint
or coating is compatible with stainless steel material. Care shall be taken to ensure
that the sprinkler and associated components are not painted.
• When using recessed sprinklers, the standard long elbow reducer is recommended.
• Flexible hose and fittings have limited flexibility and are intended only to be
installed with bends not less than their respective minimum bend radii. DO NOT
install a flexible hose in a straight configuration.
• Victaulic®VicFlex™Series AH1 and AH2 Flexible Hoses can be installed for
hydrostatic testing and then readjusted for final sprinkler placement once the
ceiling structure and associated Victaulic®VicFlex™brackets are installed.
• Protect wet piping systems from freezing temperatures.
• If construction is altered, the building owner or their representative is responsible
for referencing applicable standards to determine if additional sprinklers or other
system adjustments are required.
• The building owner or their representative is responsible for maintaining the fire
protection system in proper operating condition.
• After installation is complete, the entire sprinkler system shall be tested in
accordance with applicable standards (NFPA 13, NFPA 25, etc.) that describe
the care and maintenance of sprinkler systems. In addition, the authority having
jurisdiction may have additional maintenance, testing, and inspection requirements
that shall be followed. NOTE: A successful test is not a substitute for proper system
installation and maintenance.
• Victaulic®VicFlex™flexible hoses may penetrate drywall.

I-VICFLEX_16
This page intentionally left blank

I-VICFLEX_17
Construction
Requirements

I-VICFLEX_18 CONSTRUCTION REQUIREMENTS REV_A
Overview
The following section identifies the requirements for ceiling or wall construction. Contact
Victaulic®for information regarding applications that do not appear in this section.
Style AB1, AB2, AB7, and AB10 Brackets
Construction shall meet the requirements of ASTM C635 for ceiling suspension systems
and shall be installed in accordance with ASTM C636 standards. VdS Approval for Style
AB1, AB2, AB7, and AB10 Brackets applies only for use with the following manufacturers’
ceiling suspension systems:
AMF Dipling Gema-
Armstrong Lafarge Richter Suckow & Fischer
Armstrong Durlum Hilti Lindner Rigips USG Donn
Chicago
Metallic Geipel Knauf Odenwald Rockfon Pagos
Style AB3 Bracket
The Victaulic®VicFlex™ Style AB3 Bracket is designed for use as a surface-mount bracket
for pendent or sidewall applications in wood, metal, or concrete block walls or ceilings.
Style AB4 Bracket
Construction shall meet the requirements of ASTM C645 for hat furring channel ceiling
systems and shall be installed in accordance with ASTM C754 standards. NOTE: VdS
Approval for the Style AB4 Bracket does not require specific approval for manufacturers
of hat furring channel ceiling systems.
Style AB5 Bracket
The Victaulic®VicFlex™ Style AB5 Bracket is designed for use on wood or metal joists/
studs and CD Profile (60 mm) channel ceiling systems.
Style AB6 Bracket
The Victaulic®VicFlex™ Style AB6 assembly shall be installed only in applications where
the minimum thickness of the ceiling or wall is 3 inches/76 mm and the strength and
structure of the ceiling or wall is comparable to or stronger than thin-clad aluminum
freezer panel.
Style AB11 Bracket
Construction shall meet the requirements of ASTM C635 for ceiling suspension systems
and shall be installed in accordance with ASTM C636 or ASTM C754 standards. VdS
Approval for Style AB11 Brackets applies only for use with the following manufacturers’
ceiling suspension systems:
AMF Dipling Gema-
Armstrong Lafarge Richter Suckow & Fischer
Armstrong Durlum Hilti Lindner Rigips USG Donn
Chicago
Metallic Geipel Knauf Odenwald Rockfon Pagos
Style AB12 Bracket
The Victaulic®VicFlex™ Style AB12 Threaded Rod Bracket is designed for use in
suspended and hard-lid ceilings.
Style ABBA and ABMM Brackets
The Victaulic®VicFlex™ Style ABBA and ABMM Brackets are designed for installation in
multiple configurations on various wall and ceiling surfaces. Refer to the specific product
instructions in this handbook for a complete listing of installation configurations.

I-VICFLEX_19CONSTRUCTION REQUIREMENTS REV_A
Style AQC-U
The Victaulic®VicFlex™Style AQC-U Sprinkler Fitting is FM Approved for use with
cleanroom ceilings. Refer to the “Listing and Approval Information - Flexible Hose
Assemblies with Corresponding Maximum Working Pressure Rating (AQC-U/AQC and
AQD)” section in this handbook.
Style C-AQC (Regional Availability Only)
The Victaulic®VicFlex™Style C-AQC Sprinkler Fitting is FM Approved and CCC Approved
for use with cleanroom ceilings. Refer to the “Listing and Approval Information - Flexible
Hose Assemblies with Corresponding Maximum Working Pressure Rating (AQC-U/C-AQC
and AQD)” section in this handbook.
NOTES FOR STYLE AQC-U AND C-AQC:
Channel Systems is a product of Channel Systems, Inc.
CLIN is a product of Cleanroom Industries Sdn. Bdh.
Gordon is a product of Gordon Incorporated.
M+W Zander Facility Engineering GmbH is a company of the M+W Group.
SBB Daldrop and SBB Gorilla Grid are products of SBB, Inc.
Topwell is a product of Chyi Lee Industry Co., Ltd.
Tenryo is a product of Tenryo Technology & Engineering Co., Ltd.
Topline is a product of Topline System Engineering Co., Ltd.
Style AQD
The Victaulic®VicFlex™ Style AQD Sprinkler Fitting is designed for use on round or square
fiberglass reinforced pipe (FRP) ducts.
Style AQD-M
The Victaulic®VicFlex™ Style AQD-M Sprinkler Fitting is designed for use on round or
square metal ducts.
Style VB1 Bracket for Style VS1 Dry Sprinklers
The Victaulic®VicFlex™ Style VB1 Bracket is designed for use on wood or metal joists.
Style VB2 Bracket for Style VS1 Dry Sprinklers
The Victaulic®VicFlex™ Style VB2 Bracket is designed for use with ASTM C635
suspended ceilings only.
Style VB3 and VB4 Brackets for Style VS1 Dry Sprinklers
Construction shall meet the requirements of ASTM C635 for ceiling suspension systems
installed with lay-in tiles (in accordance with ASTM C636 standards). In addition, the
Style VB3 and VB4 Brackets are designed for use on wood joists/studs and on ASTM
C645 metal joists/studs installed in accordance with ASTM C754 standards.

I-VICFLEX_20
This page intentionally left blank
