NRB-4 STEELSITES™ SERIES
ASSEMBLY INSTRUCTIONS
CHECK ALL PARTS
• Be certain there are no missing parts.
• Be certain all required tools are available.
REQUIRED TOOLS
• 9/16-inch Wrench or Ratchet
• 4 towels (or something soft) for the seat to rest on
to protect the fi nish
ASSISTANCE REQUIRED
• 2 people recommended to assemble product
• Necessary to handle, fi t and secure components
• Heavy lifting
WWW.VICTORSTANLEY.COM
Should you have any problems, please contact Victor Stanley, Inc.
READ ALL INSTRUCTIONS THOROUGHLY
BEFORE YOU BEGIN.
© Copyright 2006 Victor Stanley, Inc. All Rights Reserved
DELIVERY, STORAGE, and HANDLING
A. Delivery: Deliver products to site in manufacturer’s original,
unopened containers and packaging. Upon delivery,
examine packages immediately to ensure all products are
complete and undamaged.
B. Storage: Store products in a protected, dry area in
manufacturer’s unopened containers and packaging.
C. Handling: Protect product’s fi nish from damage during
handling and installation
INSTALLATION
A. Clearance for 3/8-inch (9.53mm) anchor bolts (anchor bolts
not provided by Victor Stanley, Inc.)
B. Mounting: It is not recommended to locate anchor bolts until
bench is in place. This Victor Stanley, Inc. product must be
permanently affi xed to the ground. Consult your local codes
for regulations.
PROTECTION
A. Protect products prior to installation by having them remain in
the manufacturer’s packaging and container.
All specifi cations are subject to change. Contact manufacturer for details.
PAGE 1 OF 4

WWW.VICTORSTANLEY.COM
Should you have any problems, please contact Victor Stanley, Inc.
PARTS LIST
COMPONENTS HARDWARE
3/8-inch x 1-1/2-inch
SS CARRIAGE BOLTS 3/8-inch LOCK WASHER 3/8-inch SS FLAT WASHER
EXAMPLE
CONFIGURE FOR USE
A B C
LEG
BENCH SECTION
x32 x32 x32
x8
x4
PAGE 2 OF 4
© Copyright 2006 Victor Stanley, Inc. All Rights Reserved
NRB-4 STEELSITES™ SERIES
ASSEMBLY INSTRUCTIONS
TOOLS REQUIRED
4 TOWELS
(or something soft to protect finish) HANDS
9/16-inch WRENCH or RATCHET
D
x32
3/8-inch SS NUTS

WWW.VICTORSTANLEY.COM
STEP #1
NRB-4 STEELSITES™ SERIES
ASSEMBLY INSTRUCTIONS
PAGE 3 OF 4
© Copyright 2006 Victor Stanley, Inc. All Rights Reserved
#2
Remove all parts from their boxes and bags, and place on a soft surface to
prevent scratching (cardboard, grass, etc...).
Attach Curved bench section on 2 support legs using the center mount and 1
side mount. Hand tighten only!
Repeat so that 3 bench sections have only those 2 legs attached. (4th bench
section should not have any legs attached at this time)
Attach 2 of the bench-leg combinations (created in step 2) together using the
support leg, making a half circle. Hand tighten only!
a. If necessary due to uneven or irregular surfaces stainless steel washers can be
used as shims, (not supplied by Victor Stanley, Inc.) to make the seating surface
line up correctly.
Be certain of bench placement/location.
a. Check and review location and positioning.
b. Make any adjustments to bench placement/location now.
Attach 3rd bench-leg combination (created in step 2) to the half circle section
(created in step 3), making a 3/4 circle. Hand tighten only!
Attach 1 support leg on remaining join section of 3/4 circle section.
You should have (7) total legs mounted to the 3/4 circle section at this time.
Attach the last remaining leg to center mount position of final Curved bench
section. Hand tighten only!
Attach final Curved bench section to 3/4 circle. Hand tighten only!
Once everything is straight and aligned properly, Mechanically tighten all
sections.
Carefully inspect the bench again to make sure that all Curved sections are
aligned and evenly spaced.
Permanently affix to ground. Consult local codes for regulations. Anchor
bolts are not provided.
NOTE: It is important not to tighten the hardware too much in Steps
2-8 to allow for potential minor adjustments and / or corrections.
Should you have any problems, please contact Victor Stanley, Inc.
#3
#4
#5
#6
#7
#8
#9
#10
#11

WWW.VICTORSTANLEY.COM
NRB-4 STEELSITES™ SERIES
ASSEMBLY INSTRUCTIONS
PAGE 4 OF 4
© Copyright 2006 Victor Stanley, Inc. All Rights Reserved
NRB-4 STEELSITES™ SERIES
FINAL PRODUCT
