Victoria Arduino Venus Family Brass User manual

Congratulations, you have chosen a really spectacular machine.
Read carefully what is advised in the instruction manual for “setting-up” of your
“Venus Family”. You will see how easy it is to make delicious coffee and creamy
cappuccinos. With the passing of time, you will also realise how little maintenance is needed.
Victoria Arduino
VENUSFAMILY

fkajfasjf

Model: Venus Family - Groups: 1 Net weight: 16 Kg - Gross weight: 18 Kg - Thermal power: 1000 W - Volts 208-240V 110-120V 50/60Hz
Dimensions: Length 320 mm Height 510 mm Width 320 mm - Finishing in beaten sheet metal: copper, chrome, brass
The international approval labels certify that all the machines have regularly undergone expert checks and tests
VENUSFAMILY

The machine and its parts are generally consigned
to palletised boxes. In any case when receiving it,
please do check that:
1) the packaging is intact
2) the contents are:
a) machine
b) accessories’ box:
b1) Fileter holder b2) Spring filter
b3) Double filter b4) Single filter
b5) Small press b6) Measuring spoon
b7) Single spout b8) Double spout
b9) Eagle
3) The machine or accessories aren’t damaged.
In case of damage or missing pieces, please inform
the manufacturer immediately or its agents in the
area or its insurance.
b5
b6
b7
b8
b1
b9
b3
b4
b2

SAFETY REGULATIONS
1 The present manual is an integral and
essential part of the product and will have to be
handed over to the user. Read carefully the
written warnings in the present manual as they
give important suggestions concerning the safety
of installation and set-up, use and maintenance.
Keep this manual in a safe place for further
information.
2
After removing the packaging, check the
integral parts of the machine are intact. If in
doubt, do not use the machine and contact the
professionally qualified personnel. The
elements of the packaging (plastic bags,
polystyrene, nails, etc.) must be kept out of
children’s reach as they can be potential
sources of danger and they mustn’t be
disposed of in the environment.
m POLLUTION DANGER
3 Before connecting the machine, make sure
that the data of the plate correspond to those of
the electrical distribution network. The plate is
located under the machine’s base. The
installation has to be carried out in compliance
with the regulations of the Country where the
machine is set-up, according to the instructions
by the manufacturer and qualified personnel.
The manufacturer can’t be considered
responsible for possible damage caused by
failure in earthing the plant. For the electrical
safety of this machine it is obligatory to arrange
the earthing plant, contact an electrician with
proper and certified technical suitability, to check
the electrical capacity of the plant is adequate to
the maximum power of the machine, stated on
the plate. In particular the electrician will
have to make sure that the section of the
plants’ cables is suitable to the power
absorbed by the machine.
The use of adaptors, multi-sockets and
extensions is forbidden. If their use is
necessary, it is compulsory to call a licensed
electrician.
4 The machine must be set-up according to the
sanitary and health regulations valid for hydraulic
plants. For the hydraulic plant contact an
authorised technician.
GENERAL REMARKS ON THE CONSIGNMENT

m THIS EQUIPMENT IS TO BE INSTALLED TO COMPLY
WITH THE APPLICABLE FEDERAL , STATS , OR LOCAL
PLUMBING CODES
.
5 This machine will have to be used only for the
purpose described in this manual.
The manufacturer can’t be considered
responsible for possible damage caused by
improper, wrong, or unreasonable uses.
m
WARNING
Before using the machine read carefully and
completely the instruction manual, safety
regulations and the machine tuning/ directions.
6 The use of any electrical device must comply
with fundamental regulations. In particular:
• do not touch the machine with wet hands or
feet;
m
WARNING DANGER OF ELECTRICAL SHOCK
Any cleaning operation, the washing or other
interventions inside the machine must be
carried out when the "energetic state is
zero", connecting plug to the net (3)
disconnected from the net itself.
• do not use the machine barefoot;
• do not use extensions in places used as a bath
or shower;
• do not pull the supply cable, to disconnect the
machine from the supplying net;
• do not leave the machine exposed to
atmospheric agents (rain, sun, etc);
• do not allow the machine to be used by
children or by non-authorised personnel that
haven’t read and understood this manual.
7 The authorised technician has to, before
carrying out any maintenance operation, unplug
the socket after having switched off the
machine switch.
7 bis For the cleaning operations bring the
machine to energetic state “O”, that is to say
“machine is switched off and socket
unplugged” and keep exclusively to what is
stated in the present manual.
8 In case of breakdown or wrong
functioning of the machine, switch it off.
Any intervention is strictly forbidden.
Contact exclusively professionally authorised
personnel.
The possible repair of the products will have
to be made by the manufacturer only or by an
authorised service using exclusively original
spare parts.
Non-compliance with the above stated can
compromise the safety of the machine.
9 When setting it up, the licensed electrician
will have to check an omni-polar switch is

provided by the actual safety regulations with
opening distance from the contacts the same or
bigger than 3 mm.
J To avoid dangerous overheating, we do
recommend you uncoil the supply cable to its full
length.
K The user mustn’t replace the supply cable of
this machine. In case of damage, switch the
machine off and for its replacement contact
exclusively professionally qualified personnel.
L In the event that you decide not to use a
machine of this kind anymore, we advise you
make it ineffective by unplugging the socket,
then cut the supply cable.
m
WARNING DANGER OF POLLUTION
Do not dispose of the machine in the environment:
for waste disposal, contact a specialised authorised
centre or contact the manufacturer that will give
you information about this.
M To help the aeration of the machine place it
15 cm from the walls or from other machines on
the aeration side.
N When using the vapour spear, pay much
attention and do not place hands under it and do
not touch it immediately after its use.
m WARNING DANGER OF BURNING
O Remember that before carrying out any set-
up operation, maintenance, download, or
tuning, the qualified operator has to wear
working gloves and safety shoes.

TRANSPORT AND HANDLING
MACHINE’S IDENTIFICATION
For any communication with the manufacturer
Victoria Arduino, always have the plate
number of the machine to hand.
The machine is carried in a pallet further more
machinery is inside cardboard boxes connected
to the pallet by frameworks.
Before starting any operation of transport and
movement, the operator has to:
• Wear safety gloves, shoes and an overall with
elastic bands at the ends. The pallet transport
has to be made by suitable lifting means (like a
forklift truck).
m ATTENTION DANGER OF COLLISION OR CRUSHING
During the handling the operator must pay
attention that in the operating area there
aren't any people, things or other objects.
Lift the pallet slowly at about a height of 30
cm. from the ground and then reach the
loading area. Proceed to the loading only after
having checked that there aren't any obstacles,
things or people in the way.
Once arrived at destination, always using a
suitable lifting means (e.g. forklift truck) make
sure that there aren't any things or people in
the download area, then bring the pallet to the
ground and handle it to reach 30 cm. from the
ground until the stocking and warehouse area.
m ATTENTION DANGER OF COLLISION OR CRUSHING
Before the following operation, please check
that the load is in the correct position and that
it won't fall when cutting the frameworks.
The operator with gloves and safety shoes
must cut the frameworks and then stock the
product. For this operation please refer to the
technical characteristics of the product to
check the weight of the machine to be stocked
and act or proceed consequently.
m ATTENTION DANGER OF POLLUTION
Once having taken the machine out of the
pallet or the container, do not dispose of it in
the environment, danger of pollution.

INSTALLATION AND SET-UP
1_Assemble the eagle on the dome that is in the
accessories box.
2_Lift the dome and fill the white plastic container
with drinking water, then reassemble the dome.
3_ Connect the supply plug to an electric socket
with earthing.
4_
P osition the vapour tube in correspondence to
the drip tray, then action the switch for the
coffee supply and at the same time open, by
rotating it, the vapour tap . When the water
comes out, turn the tap and wait for the water
to come out from the machine.
At this stage press the on/off switch for coffee
supply .
5_Hook the filter holder bowl with a movement
from left to right.
6_
Press the switch with the symbol “on/off”
and wait about five minutes (necessary time for
the machine preparation).
MAKING COFFEE
1_Take off the filter holder with a movement
from right to left. In the equipment there are
two filters (a bigger and a smaller one) and
two spouts ( a single and a double one). The
bigger filter will be used, together with the
double spout, for two coffees, while the
smaller filter together with the single spout,
will be used to make one coffee. The filter
holder spring must be inserted in the filter
holder.
For one coffee you will use the smaller filter filled
with a single measure from the measuring
spoon, for two coffees you will use the bigger
filter instead, filled with two measures of the
measuring spoon. Press the coffee with the small
press, then hook safely the filter holder with a
movement from left to right.
2_Place one or two cups in correspondence with
the exits of the filter holder and press the switch
for coffee supply; once you have the desired
quantity, press the on/off switch for coffee
supply .
USE OF THE VAPORISER
1_Turn the knob of the thermostat into
position .
INSTRUCTIONS

2_Open the vaporiser tap to download all the
water coming out of the container. Reclose the
tap and wait for about one minute.
3_Prepare whatever you wish to warm (milk,
water, chocolate, etc.).
4_Plunge the vaporiser tube and turn the tap,
leaving it in that position until it reaches the
suitable temperature for the drink.
Warning. Very important
When finished using the vaporiser, put the
thermostat knob back into the coffee position
and press the switch for coffee supply until
some water comes out from the machine.
ADVICE:
Before using the machine, always check that
there is enough water in the container. After
approximately ten coffees, empty the drip tray
paying attention to reconnecting the plastic tube
when repositioning it. If the machine is not used
continuously, leave the filter holder hooked
without clamping it forcibly.
BODY CLEANING
Do not use any detergent product, use only a
soft well cleaned sponge with some water.
Possible tarnishing of the body is normal, as it is
made with natural brass or copper (according to
the models).
_
THE USE OF THE COFFEE MACHINE BY CHILDREN IS
STRICTLY FORBIDDEN
_ DO NOT PLUNGE THE COFFEE MACHINE IN WATER
_ BEFORE CARRYING OUT ANY OPERATION INSIDE THE
MACHINE
, DISCONNECT THE ELECTRIC PLUG .
