Victorinox GENERAL MULTI-TOOL User manual

MULTI-TOOLS
14280
08/06
Place the opener on the can so that the
hook gets a firm hold on the underside
of the tin; then force the cutting-edge into
the lid by gently raising the tool handle.
Important!
Keep the cutting-edge close to the rim.
If your multi-tool has a manufacturer’s defect covered by our warranty, we
will either repair or replace it, at our option, without charge. Please send to
the address below. Include your name, address, phone number and
e-mail address (optional) with your return. In California and other states so
requiring, you may return the multi-tool through your place of purchase.
A damaged multi-tool not covered by the warranty can be repaired. Note
that repair costs and handling charges may apply. If so, you will be notified
prior to any service. Please send to the address below. Include your name,
address, phone number and e-mail address (optional) with your return.
Service Center: Swiss Army Brands, Inc., Service Center
65 Trap Falls Road, Shelton CT 06484-0897
REPAIRS
CAN OPENER
When closing, keep fingers
away from the danger zone.
CLOSING MULTI-TOOL
Only when you see
the name Victorinox
stamped on the blade
can you be assured
you have the Original
Swiss Army Knife.
Extend each implement halfway and
apply a few drops of oil at the base of
each implement. For implements that do
not move easily, open and close a few
times in warm water, then dry and oil.
This care will ensure a lifetime of
faithful service.
MAINTENANCE
Replacement Parts
Call customer service or visit our website at:
www.swissarmy.com to find an authorized
dealer near you.
Customer Information • 1-800-442-2706
IMPORTANT SAFETY NOTICE
Careless or improper use of this product or use
of its implements for purposes for which they
are not intended, such as the use of a knife
blade as a pry-bar, could result in serious
injury. Please keep this product and all sharp
or pointed implements away from children.
CUSTOMER SERVICE
Inspired by our heritage, the Victorinox spirit has been captured by
our designers in a broad range of inventive, classically designed
products that break new ground in performance, versatility and value.
From our completely new line-up of Swiss Army Timepieces, to our
innovative line of Victorinox Travel Gear and Apparel, you’ll find the
uncompromising craftsmanship and attention to detail that make all
of our products worthy to carry the Victorinox emblem.
For more information about our complete line of products, please visit
our website at: www.swissarmy.com.
© Swiss Army Brands, Inc. 2006. All Rights Reserved.
OUR PRODUCTS
In 1884, Karl Elsener opened his cutlery workshop in Ibach,
Switzerland. In 1891, he obtained the first contract to supply the
Swiss Army with a “Soldier’s Knife.” Six years later, he invented
the “Swiss Officer’s Knife” which was officially registered
on June 12, 1897. Since that time, the Victorinox Original
Swiss Army Knife has become well-known in more than
100 countries for precision, quality, functionality and versatility.
Enjoy your new Victorinox Original Swiss Army Knife. You will find it
to be an invaluable companion.
OUR LEGACY
Victorinox guarantees all multi-tools to be of first class steel and
provides a lifetime warranty against any defects in material and
workmanship. The warranty does not apply to damage caused by
abnormal or unreasonable use of any of the implements (including
repairs or alterations other than by our Authorized Repair Center).
This warranty gives you specific legal rights. Additional rights may
be available under the laws of your State or Province. It is in place
of all other warranties, including warranty of fitness for a particular
purpose and warranty of merchantability and excludes any liability
for incidental or consequential damages.
LIFETIME LIMITED WARRANTY

Guide to Implements SPECIAL FEATURES (available on select models)
➯
RETRACTABLE BALL POINT PEN
LARGE BLADE MAGNIFYING GLASS
CUT & PICKER BLADE W/SCRAPER
EMERGENCY BLADE
SMALL BLADE
LARGE SERRATED BLADE
BOTTLE OPENER W/LARGE
SCREWDRIVER & WIRE STRIPPER
SCREWDRIVER
WIRE STRIPPER
COMBINATION TOOL (BOTTLE OPENER,
CAN OPENER, SCREWDRIVER & WIRE
STRIPPER)
SCISSORS
REAMER W/SEWING EYE
MINI SCREWDRIVER
WOOD SAW
METAL FILE (NAIL FILE ON REVERSE)
METAL SAW
NAIL FILE W/NAIL CLEANER
NAIL FILE W/SCREWDRIVER TIP
FISH SCALER WITH HOOK DISGORGER
AND INCH/METRIC RULER
HOOK
BALL POINT PEN
ORANGE PEELER W/SCREWDRIVER TIP
ELECTRICIAN BLADE
TWEEZERS
PRUNING BLADE
TOOTHPICK
CAN OPENER W/SMALL SCREWDRIVER
WOOD CHISEL
PLIERS W/WIRE CUTTER
PHILLIPS SCREWDRIVER
FINE SCREWDRIVER KEY RING
1
2
CAP LIFTER W/ PHILLIPS SCREWDRIVER TIP
& WIRE STRIPPER
SCREWDRIVER W/RULER
PHARMACEUTICAL SPATULA
BIT CASE
#10/#15 TORX BIT
4mm FLAT HEAD/#2 PHILLIPS
#0/#1 POZIDRIVE BIT
#8 TORX BIT/4mm HEX BIT
4mm/5mm HEX SOCKET
SMALL PHILLIPS HEAD
CUTICLE PUSHER
ENGRAVING PANEL
STRAIGHT PIN
CAP LIFTER W/SCREWDRIVER TIP
& WIRE STRIPPER
CORKSCREW
SEAT BELT CUTTER
MINILIGHT
LARGE BLADE, WITHOUT POINT
WHISTLE
RETRACTABLE PEN
First push switch towards blades to release locking mechanism.
Once this is done, the switch can move easily back and forth to
extend or retract the pen. To ease pen use, open nail file to
extend the length of the multi-tool.
Replacing Ball Point Pen
Simply pull out empty ball point pen and
click new one into place.
MINI LIGHT
Depress shield emblem
to activate LED light.
Press emblem
to light.
Mini Light Battery Change
1 Use a metal paper clip to push the
worn battery into your open hand.
2 Carefully insert the new battery
(Panasonic CR 1025, 3V).
3 The positive side of the battery
should be facing up.
4 Insert battery cover into the tool.
The battery will last approximately 21⁄2years under normal conditions.
