Victron energy BlueSolar MPPT 150/60 User manual

www.victronenergy.com
Victron Energy B.V. | De Paal 35 | 1351 JG Almere | The Netherlands
General phone: [phone] | Fax: [phone]
E-mail: [e-mail] | www.victronenergy.com
Ultra-fast Maximum Power Point Tracking (MPPT)
Especially in case of a clouded sky, when light intensity is changing continuously, an ultra-fast MPPT
controller will improve energy harvest by up to 30% compared to PWM charge controllers and by up
to 10% compared to slower MPPT controllers.
Advanced Maximum Power Point Detection in case of partial shading conditions
If partial shading occurs, two or more maximum power points may be present on the power-voltage
curve.
Conventional MPPT’s tend to lock to a local MPP, which may not be the optimum MPP.
The innovative BlueSolar algorithm will always maximize energy harvest by locking to the optimum
MPP.
Outstanding conversion efficiency
No cooling fan. Maximum efficiency exceeds 98%.
Flexible charge algorithm
Fully programmable charge algorithm (see the software page on our website), and eight
preprogrammed algorithms, selectable with a rotary switch (see manual for details).
Extensive electronic protection
Over-temperature protection and power derating when temperature is high.
PV short circuit and PV reverse polarity protection.
PV reverse current protection.
Internal temperature sensor
Compensates absorption and float charge voltage
for temperature.
Real-time data display options
- Apple and Android smartphones, tablets and other devices:
see the VE.Direct to Bluetooth Smart dongle
- ColorControl panel
BlueSolar charge controllers
with screw- or MC4 PV connection
MPPT 150/45 MPPT 150/60 MPPT 150/70
Maximum Power Point Tracking
Upper curve:
Output current (I) of a solar panel as function of
output voltage (V).
The maximum power point (MPP) is the point
Pmax along the curve where the product I x V
reaches its peak.
Lower curve:
Output power P = I x V as function of output
voltage.
When using a PWM (not MPPT) controller the
output voltage of the solar panel will be nearly
equal to the voltage of the battery, and will be
lower than Vmp.
Solar charge controller
MPPT 150/70-MC4
BlueSolar charge controller MPPT 150/45 MPPT 150/60 MPPT 150/70
Battery voltage
12 / 24 /48 V Auto Select (software tool needed to select 36 V)
Rated charge current 45 A 60 A 70 A
Maximum PV power, 12V 1a,b) 650 W 860 W 1000 W
Maximum PV power, 24V 1a,b) 1300 W 1720 W 2000 W
Maximum PV power, 48V 1a,b) 2600 W 3440 W 4000 W
Maximum PV open circuit voltage
150V absolute maximum coldest conditions
145V start-up and operating maximum
Maximum efficiency 98 %
Self-consumption 10 mA
Charge voltage 'absorption' Default setting: 14,4 / 28,8 / 43,2 / 57,6 V (adjustable)
Charge voltage 'float' Default setting: 13,8 / 27,6 / 41,4 / 55,2 V (adjustable)
Charge algorithm multi-stage adaptive
Temperature compensation -16 mV / °C resp. -32 mV / °C
Protection
Battery reverse polarity (fuse, not user accessible)
PV reverse polarity / Output short circuit / Over temperature
Operating temperature -30 to +60°C (full rated output up to 40°C)
Humidity 95 %, non-condensing
Data communication port and
remote on-off
VE.Direct (see the data communication white paper on our website)
Synchronized parallel operation Not possible
ENCLOSURE
Colour Blue (RAL 5012)
PV terminals 2) 35 mm² / AWG2 (Tr models), or Dual MC4 connectors (MC4 models)
Battery terminals 35 mm² / AWG2
Protection category IP43 (electronic components), IP22 (connection area)
Weight 3 kg
Dimensions (h x w x d) 200 x 250 x 95 mm
STANDARDS
Safety EN/IEC 62109
1a) If more PV power is connected, the controller will limit input power to the stated maximum.
1b) PV voltage must exceed Vbat + 5V for the controller to start.
Thereafter minimum PV voltage is Vbat + 1V
2) MC4 models: several splitter pairs will be needed to parallel the strings of solar panels
Solar charge controller
MPPT 150/70-Tr

Manual
EN
Handleiding
NL
Manuel
FR
Anleitung
DE
Manual
ES
Användarhandbok
SE
Appendix
BlueSolar charge controllers
MPPT 150/45-Tr MPPT 150/45-MC4
MPPT 150/60-Tr MPPT 150/60-MC4
MPPT 150/70-Tr MPPT 150/70-MC4

1
EN NL FR DE ES SE Appendix
1. General Description
1.1 Ultra-fast Maximum Power Point Tracking (MPPT)
Especially in case of a clouded sky, when light intensity is
changing continuously, an ultra fast MPPT controller will
improve energy harvest by up to 30% compared to PWM charge
controllers and by up to 10% compared to slower MPPT
controllers.
1.2 Advanced Maximum Power PointDetection in case of
partial shading conditions
If partial shading occurs, two or more maximum power points
may be present on the power-voltage curve.
Conventional MPPT’s tend to lock to a local MPP, which may
not be the optimum MPP.
The innovative BlueSolar algorithm will always maximize energy
harvest by locking to the optimum MPP.
1.3 Outstanding conversion efficiency
No cooling fan. Maximum efficiency exceeds 98%. Fulloutput
current up to 40°C (104°F).
1.4 Flexiblechargealgorithm
Eight preprogrammed algorithms, selectable with a rotary
switch.
1.5 Extensive electronic protection
Over-temperature protection and power derating when
temperature is high.
PV short circuit and PV reverse polarity protection.
PV reverse current protection.
1.6 Internal temperature sensor
Compensates absorption and float charge voltages for
temperature.
1.7 Automatic battery voltagerecognition
The controllers will automatically adjust to a 12V, 24V or a 48V
system. A computer or a Color Control panel is required to set the
controller to 36V.

2
1.8 Adaptive three step charging
The BlueSolar MPPT Charge Controller is configured for a three
step charging process: Bulk – Absorption - Float.
A regular equalization charge can also be programmed: see
section 3.8 of this manual.
1.8.1. Bulk stage
During this stage the controller delivers as much charge current
as possible to rapidly recharge the batteries.
1.8.2. Absorption stage
When the battery voltage reaches the absorption voltage setting,
the controller switches to constant voltage mode.
When only shallow discharges occur theabsorption time is kept
short in order to prevent overcharging of the battery. After a deep
discharge the absorption time is automatically increased to make
sure that the battery is completely recharged. Additionally, the
absorption period is also ended when the charge current
decreases to less than 2 A.
1.8.3. Float stage
During this stage, float voltage is applied to the battery to
maintain it in a fully charged state.
1.9 Connectivity
See section3.8 of this manual.
1.10 Remote on-off
VE.Direct non inverting remote on-off cable (ASS030550300)
needed. An input HIGH (Vi > 8V) will switchthe controller on, and
an input LOW (V < 2V, or free floating) will switch the controller
off.
Application example: on/off control by a VE.Bus BMS when
charging Li-ion batteries.
1.11 Real-timedatadisplayon AppleandAndroid
smartphones, tabletsand otherdevices
VE.Direct to Buetooth Low
Energy (BLE) dongle
needed: seeour w ebsite.

3
EN NL FR DE ES SE Appendix
2. Safety instructions
● please read this manual carefully before the product is
installed and put into use.
● This product is designed and tested in accordance with
international standards. The equipment should be used for the
designated application only.
● Install the product in a heatproof env ironment. Ensure
therefore that there are no chemicals, plastic parts, curtains or
other textiles, etc. in the immediate vicinity of the equipment.
● Ensure that the equipment is used under the correct operating
conditions. Never operate it in a wet environment.
● Nev er use the product at sites where gas or dust explosions
could occur.
● Ensure that there is alway s suf f icient free space around the
product for ventilation.
● Refer to the specifications provided by the manufacturer of the
battery to ensure that thebattery is suitable for use with this
product. The battery manufacturer's safety instructions should
always be observed.
● Protect the solar modules from incident light during
installation, e.g. cover them.
● Nevertouchuninsulated cable ends.
● Use only insulated tools.
● Connections must always be made in the sequence described
in section3.5.
● The installer of the product must prov ide a means f or cable
strain relief to prevent the transmission of stress to the
connections.
● In addition to this manual, the sy stem operation or serv ice
manual must include a battery maintance manual applicable to
the type of batteries used.
Danger ofexplosion fromsparking
Danger of electric shock

4
3. Installation
3.1 General
● Mount vertically on a non-flammable surface, with the power
terminals facing downwards.
● Mount close to the battery , but nev er directly abov e the battery
(in order to prevent damage due to gassing of the battery).
● Grounding: the heatsink of the controller should be connected
to the grounding point.
Tr models: use flexible multistranded copper cable for the battery
and PV connections (Tr models).
MC4 models: several splitter pairs will be needed to parallel the
strings of solar panels.
The maximum diameter of the individual strands is
0,4 mm/0,125mm² (0.016 inch/AWG26).
A 25 mm² cable, for example, should have at least 196 strands
(class 5 or higher stranding according to VDE 0295, IEC 60228
and BS6360). Also known as H07V-K cable.
An AWG2 gauge cable should have at least 259/26 stranding
(259 strands of AWG26).
In case of thicker strands the contact area will be too small and
the resulting high contact resistance will cause severe
overheating, eventually resulting in fire.
3.2 PV configuration
● The controllers will operate only if the PV voltage exceeds
battery voltage (Vbat).
● PV voltage must exceed Vbat + 5V for the controller to start.
Thereafter minimum PV voltage is Vbat + 1V.
● Maximum open circuit PV voltage: 150V.
The controllers can be used with any PV configuration that
satisfies the three above mentioned conditions.
For example:
24V battery and mono- or polycristalline panels

5
EN NL FR DE ES SE Appendix
● Minimum number of cells in series: 72 (2x 12V panel in series
or one 24V panel).
● Recommended number of cells for highest controller
efficiency: 144 cells (4x 12V panel or 2x 24V panel in series).
● Maximum: 216 cells (6x 12V or 3x 24V panel in series).
48V battery and mono- or polycristalline panels
● Minimum number of cells in series: 144 (4x 12V panel or 2x
24V panel in series).
● Maximum: 216 cells.
Remark: at low temperature the open circuit voltage of a 216
cell solar array may exceed 150 V, depending on local
conditions and cell specifications. In that case the number of
cells in series must be reduced.
3.3 Cable connection sequence (see figure 1)
First:connect the battery.
Second:connect the solar array (when connected with reverse
polarity, the controller will heat up but will not charge the
battery).
3.4 Moreaboutautomatic battery voltagerecognition
The system voltage is stored in non volatile memory.
In case of a 24 V or 48 Vbattery, a reset (to 12 V) occurs only
when the output voltage decreases to less than 2 V and the
voltage on the PV input exceeds 7 V. This may occurwhen the
battery has been disconnected before PV voltage starts torise
in the early morning. When the (24 V or 48 V) battery is
reconnected later during the day, the system voltage is restored
to 24 V resp. 48 V after 10 seconds if the battery voltage
exceeds 17,5 V resp. 35 V.
Automatic voltage recognition can be switched off and a fixed
12/24/36 or 48 V system voltagecan be set with a computer or
a Color Controlpanel.
The controller can be reset by short circuiting the output and
applying a voltage exceeding 7 V on the input (for example with a
small power supply, or a solar panel) during a fewseconds. After
a reset, the controller will automatically adjust itself to a 12V
system, a 24V system (when connecting a 24 V battery with at
least 17,5 V) or a 48V system (when connecting a 48 V battery
with at least 35 V). A computer or a Color Control panel is
required to set the MPPT to 36V.

6
3.5 Configuration ofthecontroller
Fully programmable charge algorithm (see the software page on
our website) and eight preprogrammed charge algorithms,
selectable with a rotary switch:
Pos
Suggested battery type
Absorption
V Float
V
Equalize
V
@%Inom
dV/dT
mV/°C
0 Gel Victron long life (OPzV)
Gel exide A600 (OPzV)
Gel MK
28,2 27,6
31,8
@8% -32
1
Gel Victron deep discharge
Gel Exide A200
AGM Victron deep discharge
Stationary tubular plate (OPzS)
Rolls Marine (flooded)
Rolls Solar (flooded)
28,6 27,6 32,2
@8% -32
2
Defaultsetting
Gel Victron deep discharge
Gel Exide A200
AGM Victron deep discharge
Stationary tubular plate (OPzS)
Rolls Marine (flooded)
Rolls Solar (flooded)
28,8 27,6 32,4
@8% -32
3
AGM spiral cell
Stationary tubular plate (OPzS)
Rolls AGM
29,4 27,6
33,0
@8% -32
4
PzS tubular plate traction
batteries or
OPzS batteries
29,8 27,6
33,4
@25% -32
5
PzS tubular plate traction
batteries or
OPzS batteries
30,2 27,6
33,8
@25% -32
6
PzS tubular plate traction
batteries or
OPzS batteries
30,6 27,6
34,2
@25% -32
7
Lithium Iron Phosphate
(LiFePo4) batteries 28,4 27,0 n.a. 0
Note: divide all values by two in case of a 12V system and
multiply by two in case of a 48V system.

7
EN NL FR DE ES SE Appendix
A binary LED code helps determining the position of the rotary
switch.
After changing the position of the rotary switch, the LED’s will
blink during 4 seconds as follows:
Thereafter, normal indication resumes, as described below.
3.6 LED’s
LED indication:
is permanent on
is blinking
is off
Regular operation
LEDs
Bulk
Absorption
Float
Bulk (*1)



Absorption



Automatic equalisation (*2)



Float



Note (*1): The bulk led will blink briefly every 3 seconds when
the system is powered but there is insufficient power to start
charging.
Note (*2): Automatic equalisation is introduced in firmware v1.16
Fault situations
LEDs
Bulk
Absorption
Float
Charger temperature too high



Charger over-current



Charger or panel over-voltage



Internal error (*3)



Note (*3): E.g. calibration and/or settings data lost, current sensor
issue.
Swit ch
position
LED
Float
LED
Abs
LED
Bulk
Blink
frequency
0
1
1
1
fast
1
0
0
1
slow
2
0
1
0
slow
3
0
1
1
slow
4
1
0
0
slow
5
1
0
1
slow
6
1
1
0
slow
7
1
1
1
slow

8
3.7 Batterycharging information
The charge controller starts a new charge cycle every moring,
when the sun starts shining.
The maximum duration of the absorption period is determined by
the battery voltage measured just before the solar charger starts
up in the morning:
Battery voltage Vb (@start-up) Maximum absorption time
Vb < 23,8V 6 h
23,8V < Vb < 24,4V 4 h
24,4V < Vb < 25,2V 2 h
Vb > 25,2V 1 h
(divide voltages by 2 for a 12 V system and multiply by two in
case of a 48V system)
If the absorption period is interrupted due to a cloud or due to a
power hungry load, the absorption process will resume when
absorption voltage is reached again later on the day, until the
absorption period has been completed.
The absorption period also ends when the output current of the
solar charger drops to less than 2 Amps, not because of low solar
array output but because the battery is fully charged (tail current
cut off).
This algorithm prevents overcharge of the battery due to daily
absorption charging when the system operates without load or
with a smallload.

9
EN NL FR DE ES SE Appendix
3.7.1 Automatic equalization
Automatic equalization is default set to “OFF”. By using the
configuration tool mpptprefs this setting can be configured with a
number between 1 (every day) and 250 (once every 250 days).
When automatic equalization is active, the absorption charge
will be followed by a voltage limited constant current period (see
table in section3.5). The current is limited to 8% of the bulk
current for all VRLA (Gel or AGM) batteries and some flooded
batteries, and to 25% of the bulk current for all tubular plate
batteries and the user defined battery type. The bulk current is
the rated charger current unless a lower maximum current
settinghas been chosen.
In case of all VRLA batteries and some flooded batteries
(algorithm number 0, 1, 2 or 3) automatic equalization ends
when the voltage limit maxV has been reached, or after
t = (absorption time)/8, whichever comes first.
For all tubular plate batteries and the user defined battery type
automatic equalization ends after t = (absorption time)/2.
When automatic equalisation is not completely finished within
one day, it will not resume the next day, the next equalisation
session will take place as determined by the day interval.
3.8 Connectivity
Severalparameters can be customized (VE.Direct to USB
cable, ASS030530000, and a computer needed). See the data
communication white paper on our website.
The required software can be downloaded from
http://www.victronenergy.nl/support-and-downloads/software/
The charge controller can be connected the toa Color Control
panel, BPP000300100R, with a VE.Direct to VE.Direct cable.

10
4. Troubleshooting
Problem
Possible cause
Solution
Charger does not
function
Reversed PV connection Connect PV correctly
Reverse battery
connection
Non replacable fuse
blown.
Return to VE for repair
The battery is not fully
charged
A bad battery connection
Check battery
connection
Cable losses too high
Use cables with larger
cross section
Large ambient
temperature difference
between charger and
battery (Tambient_chrg >
Tambient_batt)
Make sure that
ambient conditions
are equal for charger
and battery
Only for a 24V system:
wrong system voltage
chosen (12V instead of
24V) by the charge
controller
Disconnect PV and
battery, after making
sure that the battery
voltage is at least
>19V, reconnect
properly
(reconnect battery
first)
The battery is being
overcharged
A battery cell is defect
Replace battery
Large ambient
temperature difference
between charger and
battery (Tambient_chrg <
Tambient_batt)
Make sure that
ambient conditions
are equal for charger
and battery

11
EN NL FR DE ES SE Appendix
5. Specifications
BlueSolar charge controller MPPT 150/45 MPPT 150/60
MPPT
150/70
Battery voltage
12/24/48 V Auto Select (36 V: manual)
Maximum battery current
45 A
60 A
70 A
Maximum PV power, 12V 1a,b)
650 W
860 W
1000 W
Maximum PV power, 24V 1a,b)
1300 W
1720 W
2000 W
Maximum PV power, 48V 1a,b) 2600 W 3440 W 4000 W
Maximum PV open circuit voltage
150 V
Peak efficiency
98 %
Self consumption
Less than 35 mA @ 12 V / 20 mA @ 48 V
Charge voltage 'absorption'
Default setting: 14,4 V / 28,8 V / 57,6 V (adjustable)
Charge voltage 'equalization'
Default setting: 16,2 V / 32,4 V / 64,8 V (adjustable)
Charge voltage 'float'
Default setting: 13,8 V / 27,6 V / 55,2 V (adjustable)
Charge algorithm
multi-stage adaptive
(eight preprogrammed algorithms)
Temperature compensation
-16 mV/°C / -32 mV/°C / -64 mV/°C
Protection
Battery reverse polarity (fuse, not user accessible)
Output short circuit / Over temperature
Operating temperature
-30 to +60°C (full rated output up to 40°C)
Humidity 95 %, non-condensing
Maximum altitude
2000m
Environmental condition
Indoor, unconditioned
Pollution degree
PD3
Data communication port and
remote on/off VE.Direct See the data
communicationwhite paper on our website
Synchronized parallel operation
Not possible
ENCLOSURE
Colour
Blue (RAL 5012)
PV terminals 2)
35 mm² / AWG2 (Tr models),
or dual MC4 connectors (MC4 models)
Battery terminals
35 mm² / AWG2
Protection category IP43 (electronic components)
IP 22 (connection area)
Weight
3 kg
Dimensions (h x w x d)
200 x 250 x 95 mm
STANDARDS
Safety EN/IEC 62109
1a) If more PV poweris connected, the controller will limit input power to the maximum power.
1b) PV voltage must exceed Vbat + 5V for the controllerto start.
Thereafter minimum PV voltage is Vbat + 1V.
2) MC4 models: several splitter pairs will be needed to parallel the strings of solar panels

12

1
EN NL FR DE ES SE Appendix 1. Algemene beschrijving
1.1 UltrasnelleMaximum Power PointTracking (MPPT)
Vooral als het bewolkt is en de lichtintensiteit voortdurend
verandert, verbetert een ultrasnelle MPPT-controller de
energieopbrengst tot 30% in vergelijking met PWM-
laadcontrollers en tot 10% in vergelijking met tragere MPPT-
controllers.
1.2 Advanced Maximum Power PointDetection in het geval
van wisselende schaduw
In het geval van wisselende schaduw kan de vermogen-
spanningscurve twee of meer maximale vermogenspunten
bevatten.
Conventionele MPPT's benutten meestal plaatselijke MPP,
hetgeen mogelijk niet het optimale MPP is.
Het innovatieve BlueSolar-algoritme maximaliseert de
energieopbrengst altijd door het optimale MPP te benutten.
1.3 Uitstekend omzettingsrendement
Geen koelventilator. Het maximale rendement bedraagt meer
dan 98%. Volledige uitgangsstroom tot 40°C (104°F).
1.4 Flexibel laadalgoritme
Acht voorgeprogrammeerde algoritmes die met een
draaischakelaar gekozen kunnen worden.
1.5 Uitgebreideelektronischebeveiliging
Beveiliging tegen overtemperatuur en vermogensvermindering
bij hoge temperaturen.
Beveiliging tegen PV-kortsluiting en omgekeerde PV-polariteit.
Beveiliging tegen PV-sperstroom.

2
1.6 Interne temperatuursensor
Compenseert absorptie- en druppelladingsspanningen voor
temperatuur.
1.7 Automatische herkenning van deaccuspanning
De controllers passen zich automatischaan aan een systeem van
12V, 24V of 48V. Om de controller op 36V in testellen, is een pc
of Color Control-paneel vereist.
1.8 Adaptief drietraps laden
De BlueSolar MPPT-laadcontroller is geconfigureerd voor een
drietraps oplaadproces: Bulklading, absorptielading en
druppellading.
Een regelmatige egalisatielading kanook worden
geprogrammeerd: zie paragraaf 3.8 van deze handleiding.
1.8.1. Bulklading
Tijdens deze fase levert de controller zo veel mogelijk laadstroom
om de accu's snel op te laden.
1.8.2. Absorptielading
Als de accuspanning de ingestelde absorptiespanning bereikt,
schakelt de controller over op de constante spanningsmodus.
Als enkel lichte ontladingen optreden, wordt de absorptietijd kort
gehouden om overlading van de accu te voorkomen. Na een
diepe ontlading wordt de absorptietijd automatischverhoogd om
ervoor te zorgen dat de accu opnieuw volledig wordt geladen.
Daarnaast wordt de absorptietijd ook beëindigd als de laadstroom
onder 2 A daalt.
1.8.3. Druppellading
Tijdens deze fase wordt de druppelladingsspanning toegepast op
de accu om deze volledig opgeladen te houden.
1.9 Connectiviteit
Zie paragraaf 3.8 in deze handleiding.
1.10 Aan/uit op afstand
De MPPT 150/35 kan op afstand worden bestuurd door een
VE.Direct niet-omvormende kabel voor het op afstand in- of
uitschakelen (ASS030550300). De ingang HIGH (Vi > 8V)
schakelt de controller in en de ingang LOW (V < 2V, of "free
floating") schakelt de controller uit.

3
EN NL FR DE ES SE Appendix
Toepassingsvoorbeeld: in-/uitschakelen op afstand door een
VE.Bus BMS voor het opladen van lithium-ionaccu's.
1.11 Real-time-gegevensweergaveop Apple-en
Android-smartphones, -tabletsen andereapparaten
Hiervooris een ‘VE.Direct to Buetooth Low Energy
(BLE)’-dongle vereist:zieonzewebsite.

4
2. Veiligheidsvoorschriften
● Lees deze handleiding zorgv uldig v oordat het product wordt
geïnstalleerd en in gebruik wordt genomen.
● Dit product is ontworpen en getest conform de internationale
normen. De apparatuur mag enkel worden gebruikt voor de
bedoelde toepassing.
● Installeer het product in een hittebestendige omgev ing. Zorg er
daarom voor dat zich geen chemische stoffen,
kunststofonderdelen, gordijnen of andere soorten textiel enz. in
de onmiddellijke omgeving van de apparatuur bevinden.
● Zorg erv oor dat de apparatuur wordt gebruikt onder de juiste
bedrijfsomstandigheden. Gebruik het product nooit in een
vochtige omgeving.
● Gebruik het product nooit op plaatsen waar zich gas- of
stofexplosies kunnen voordoen.
● Zorg erv oor dat er altijd v oldoende v rije ruimte rondom het
product is voor ventilatie.
● Raadpleeg de specif icaties v an de accuf abrikant om te
waarborgen dat de accu geschikt is voor gebruik met dit product.
Neem altijd de veiligheidsvoorschriften van de accufabrikant in
acht.
● Bescherm de zonne-energiemodules tegen rechtstreekse
lichtinval tijdens de installatie, bv. door deze af te dekken.
● Raak niet geïsoleerde kabeluiteinden nooit aan.
● Gebruik alleen geïsoleerd gereedschap.
● De aansluitingen moeten altijd plaatsvinden in de volgorde
zoals beschreven in paragraaf 3.5.
● Degene die het product installeert moet zorgen v oor een
trekontlasting voor de accukabels, zodat een eventuele spanning
niet op de kabels wordt overgedragen.
● Naast deze handleiding moet de bedieningshandleiding of de
onderhoudshandleiding een onderhoudshandleiding voor de accu
bevatten dievan toepassing is op de gebruikte accutypen.
Kansop ontploffing door vonken
Kans op elektrische schok

5
EN NL FR DE ES SE Appendix 3. Installatie
3.1. Algemeen
● Installeer verticaal op een onbrandbaar oppervlak met de
voedingsklemmen omlaag gericht.
● Installeer dicht bij de accu, maar nooit rechtstreeks bov en de
accu (om schade door gasvormingbij de accu te voorkomen).
● Aarding: het koellichaam v an de controller dient te worden
aangesloten op het aardingspunt.
Tr-modellen:gebruikflexibelemeeraderigekoperen
kabel voor de accu- enzonnepaneelaansluitingen(Tr-
modellen).
MC4-modellen:er zijnmeerderesplitterparennodig om
de aders vande zonnepanelenparallel te laten lopen.
De maximale diameter vande afzonderlijkeadres is
0,4 mm/0,125 mm² (0,016inch/AWG26).
Een 25 mm²-kabel dient bijvoorbeeld uit tenminste 196
aders te bestaan(vanklasse5of hoger conformVDE
0295, IEC 60228 en BS6360).Ook H07V-Kkabel
genoemd.
Een AWG2-kabeldient tenminste 259/26aders (259
aders vanAWG26) te hebben.
In gevalvan dikkere aders is het contactvlakteklein en
zal deresultererendehogecontactweerstandleidentot
ernstigeoververhitting,met uiteindelijk brand tot gevolg.
3.2. PV-configuratie
● De controller werkt alleen als de PV-spanning de accuspanning
(Vaccu) overschrijdt.
