Victron Pylontech UP2500 User manual

2023-02-21 22:12 1/12 Victron & Pylontech UP2500, US2000, US3000, US2000C, US3000C, US5000, US5000B, UP5000, Phantom-S, Force-
L1 & L2
Victron Energy - https://www.victronenergy.com/live/
Victron & Pylontech US2000, US3000 and
Phantom-S
The combination of Victron products with Pylontech lithium batteries has been tested and certified by
the Victron and Pylontech R&D departments.
General information about the battery is found in Pylontech's documentation.
This manual is intended to be used in conjunction with the product manual supplied by Pylontech. It
provides additional and specific information regarding integration with Victron systems.
The Pylontech includes a Battery Management System (BMS) with each battery module. This
interfaces with the Victron GX device and can support multiple battery modules connected in parallel.
1. Product & system compatibility
Battery UP2500 US2000 (Plus) US3000 Force-L1
Nominal voltage 24V 48V 48V 48V
Module capacity 2.55 kWh 2.4 kWh 3.5 kWh 3.55 kWh
1.1 Offgrid, Backup and Energy Storage Systems are possible
Victron + Pylontech can be used for the following system types:
Off-grid (DVCC)
Grid Backup (DVCC or ESS)
Energy Storage Systems (ESS) - Self Consumption (ESS - Start page)
1.2 A GX-device is required, eg Cerbo GX or Venus GX (VGX)
It is essential to use the CAN-bus connection of the GX device (e.g. Cerbo GX or CCGX) with the
batteries for the keep-alive signal, communication of charge and discharge limits, error codes and
state of charge.

Last
update:
2020-05-25
10:56
battery_compatibility:pylontech_phantom https://www.victronenergy.com/live/battery_compatibility:pylontech_phantom?rev=1590396991
https://www.victronenergy.com/live/ Printed on 2023-02-21 22:12
For new systems, the minimum required firmware version for the GX Device (e.g. Cerbo GX is v2.42. It
is highly recommended to use the latest firmware version on all connected devices, including the GX
device Inverter/Charger and MPPTs. There are regular updates to improve performance and reliability.
Legacy systems installed with v2.15 can continue to be used without upgrade as long as they do not
present any issues.
1.3 All Multi, MultiPlus, MultiGrid and Quattro are compatible
As long as you are using the appropriate model for the nominal battery voltage, all VE.Bus inverters
and inverter/chargers are compatible.
The minimum firmware version for new installations is 469. Though updating to the latest firmware is
recommended where possible, and a necessary first step when troubleshooting issues.
These inverter/charger units must be connected to the GX device via the VE.Bus connection port.
Legacy systems installed with VE.Bus firmware 422 can continue to be used without upgrade as long
as they do not present any issues.
1.4 All VE.Direct BlueSolar and SmartSolar MPPT Chargers are compatible
For proper operation, the Pylontech battery needs to be able to control the charge current. Therefor it
is recommended to use Victron 48V compatible MPPTs models with VE.Direct port for charging.
MPPTs with a VE.Direct port
MPPTs are controlled via the GX device. Make sure the GX device runs v2.15 or later, and the MPPTs
to 1.37 or the latest available version.
The MPPT requires connection to the GX device to regulate charge currents as the batteries require
(due to temperature, etc) To test operation, try disconnecting the GX device from the MPPT. After a
time-out, the MPPT will stop charging and flash an error code on its LEDs. The error code is error #67:
no BMS.
MPPTs with a VE.Can port
New Model (2019 and later) VE.Can MPPTs are also supported. Be aware that some GX devices (e.g.
CCGX) only have a single CANBus interface, and that is required for the battery communications. So if
you use a new VE.Can MPPT, it must also be with a GX device that has more than one CANbus
interface, e.g. the Cerbo GX.
Old model VE.Can MPPTs (pre 2019) are not supported.
2. Minimum Battery Sizing Recommendations

2023-02-21 22:12 3/12 Victron & Pylontech UP2500, US2000, US3000, US2000C, US3000C, US5000, US5000B, UP5000, Phantom-S, Force-
L1 & L2
Victron Energy - https://www.victronenergy.com/live/
The charge and discharge rates are managed automatically by the Pylontech battery and GX device.
Using very large solar arrays with battery banks that are too small can exceed the limits of the
batteries ability to charge and possibly lead to the BMS triggering over-current alarms.
You must have the minimum number of battery modules to supply the inverters startup inrush surge
currents that charge the capacitors when the inverter is first connected, this occurs prior to any loads
being connected. There is also the subsequent potential current demands of the loads connected to
the inverter. It is much more desirable to have the inverter/charger overload than the battery, as the
inverter will automatically recover, whereas the battery may require intervention once in a fault state.
Some suggested battery sizings for common Victron inverter/chargers are listed below. These are
suggestions for reliable operation for single phase off grid and are not specified by Pylontech.
Using the above formula, an example of minimum system sizing based on the US2000B Plus battery
module is below. Each battery module is approximately 50Ah at 48V, can provide 25A continuous
charge and discharge and 100A peak for 1 minute.
Inverter / Charger Model
Inv
continuous
watts @ 25
degrees
Inverter
peak
watts
surge
rating
Number of
Pylontech
modules
Battery
continuous
discharge
watt rating
Battery
peak
discharge
watt rating
Multiplus 48/500/6 430 900 1 1200 4800
Multiplus 48/800/9 700 1600 1 1200 4800
Multiplus 48/1200/13 1000 2400 1 1200 4800
Multiplus 48/3000/35 2400 6000 2 2400 9600
Multiplus 48/5000/70 4000 10000 4 4800 19200
Quattro 48/8000/110-100/100 6500 16000 6 7200 28800
Quattro
48/10000/140-100/100 8000 20000 7 8400 33600
Quattro
48/15000/200-100/100 12000 25000 10 12000 48000
3. CAN-bus Wiring

Last
update:
2020-05-25
10:56
battery_compatibility:pylontech_phantom https://www.victronenergy.com/live/battery_compatibility:pylontech_phantom?rev=1590396991
https://www.victronenergy.com/live/ Printed on 2023-02-21 22:12
You can connect multiple battery modules together to form a single large battery by connecting the
RJ-45 cable supplied by Pylontech using the link ports on the battery. This is shown in more detail in
the example wiring diagram and Pylontech manual.
For all models up to 8 connected battery modules, the batteries will automatically detect and link to
each other, no adjustment of dip switches on the battery module are necessary. In some models when
using more than 8 parallel units, some limitations, additional configuration or equipment (e.g.
Pylontech LV-Hub) may apply. See your Pylontech dealer, and Pylontech documentation for more
details.
The battery with the empty link port 0 is the master battery. You must use the VE.Can to CAN-bus
BMS type B Cable, part number ASS030720018, you cannot use the cable supplied by Pylontech.
Plug the type B cable with the side which is labeled Battery BMS into the Pylontech CAN port of the
master battery. Plug the side labeled Victron VE.Can into the GX device.
Then, plug a VE.Can terminator in the other VE.Can socket on the GX device. Two VE.Can terminators
are included with the package of the GX device as an accessory, only one is used. Keep the other one
as a spare.
More information about the cable can be found in its manual.
Without properly connecting this cable, the battery will not show up on the display of the GX device.
The battery will also turn itself off.
It is important to ensure this connection and display of the battery on the GX device display before
attempting firmware updates or settings changes on other devices if they depend on the power
supply from the battery. Without this connection, the battery may turn off unexpectedly.

2023-02-21 22:12 5/12 Victron & Pylontech UP2500, US2000, US3000, US2000C, US3000C, US5000, US5000B, UP5000, Phantom-S, Force-
L1 & L2
Victron Energy - https://www.victronenergy.com/live/
4. VEConfigure Settings
When using the latest firmware on all compatible connected devices, and once the battery module
has been detected by the GX device, battery charging parameters (e.g. Maximum Charge Current,
Target Battery Voltage, etc) are automatically configured by the Pylontech BMU, and communicated
to the rest of the Victron components in the system via DVCC.
It is possible to override some of these automatic settings to provide additional limitations (e.g.
reduce the total charge current that would be provided but the MultiPlus). The following information is
provided for that purpose, though is not required for the safe operation of the system.
This section presumes familiarity with VEConfigure software.
4.1 General tab
Check the “Enable battery monitor” function
Set the battery capacity to the total capacity of the battery: eg 50Ah times the number of
battery modules for the 2000B Plus model.
The other parameters (“State of charge when bulk finished” and “Charge efficiency”) can be left
to their default setting: They are ignored for a Pylontech installation.
4.2 Charge Settings
Charger tab
Parameter Setting
Battery type Lithium
Charge curve Fixed
Absorption voltage 52.0 V
Float voltage 51.0 V
Absorption time 1 Hr
Note: make sure to double check the float voltage after completing Assistants, and if necessary set it
back to 51.0 V.
Note For off-grid use: ignore the 'bms assistant required' warning.
4.3 Inverter Settings
In the Inverter tab of VEConfigure
VEConfigure Inverter Parameter Setting
DC input low shut-down 44V
DC input low restart 48V
DC input low pre-alarm* 48V

Last
update:
2020-05-25
10:56
battery_compatibility:pylontech_phantom https://www.victronenergy.com/live/battery_compatibility:pylontech_phantom?rev=1590396991
https://www.victronenergy.com/live/ Printed on 2023-02-21 22:12
* The pre-alarm setting is dependant on your preference and on site specific requirements. You may
wish for this to be activated earlier in an off grid situation to allow time to start a backup generator.
ESS System Settings
If you are using the battery as part of a grid connected ESS system, please review the ESS Quickstart
guide and Design and Installation Manual.
The settings that are specific to the Pylontech battery in the VEConfigure ESS Assistant are below:
Select the externally managed Lithium battery option
ESS Parameter Settings
Sustain voltage. 48V
Dynamic cut-off values set all values to 46V.
Restart offset: 1.2V (Default)
Due to the reliability of the grid supply and the behaviour of the sustain voltage threshold in ESS; you
may wish to suppress the low voltage pre-alarm warning so that it does not trigger every day on its
regular deep cycle. See ESS FAQ Q5 - about suppressing the low-voltage alarm.
Hardware Protection Points
In normal operation, the charge parameter limits are set by the Pylontech battery and communicated
through the system by the GX device to the inverter/charger and MPPT.
Low Voltage: When the battery discharges to 44.5V or less, battery protection will turn on.
High Voltage: If charging voltage above 54V, battery protection will turn on.
Working discharge temperature range is from -10 to 50 degrees celsius.
Charging temperature range is from 0 to 50 degrees celsius.
Discharge Current Limit set to 0A at 47V, inverter will turn off.

2023-02-21 22:12 7/12 Victron & Pylontech UP2500, US2000, US3000, US2000C, US3000C, US5000, US5000B, UP5000, Phantom-S, Force-
L1 & L2
Victron Energy - https://www.victronenergy.com/live/
Over-charge and Over-discharge Current Limit 102A for 15 seconds, 200A for 0.1 seconds and
400A short circuit current.
If operation is attempted outside the operating range, the battery will disconnect to protect itself.
5. GX Device Settings
On the GX device, go to Settings, System setup:
Venus Settings → System Setup Parameter Value
DVCC ON
Shared Voltage Sense OFF
Shared Temperature Sense OFF
Select the CAN-bus BMS (500 kbit/s) CAN-profile in the CCGX. Menu path: Settings → Services →
CAN-profile.
After properly wiring and setting up, the Pylontech will be visible as a battery in the device list.
If you have multiple batteries a single entry will show up, which represents all batteries:
The parameters option within the battery page shows the actual battery charge and discharge
limits

Last
update:
2020-05-25
10:56
battery_compatibility:pylontech_phantom https://www.victronenergy.com/live/battery_compatibility:pylontech_phantom?rev=1590396991
https://www.victronenergy.com/live/ Printed on 2023-02-21 22:12
This parameters page is also a good place to check that all batteries are connected and working
properly. In normal working conditions, the current limit is 25A per cell. For example, 75A charge
current limit ( 75 / 25 = 3 ) means there are 3 Pylontech battery modules connected.
6. VE-Direct MPPT Settings
In normal operation the MPPT charge characteristics are governed by the GX device via DVCC, with
instructions from the connected Pylontech battery.
This section presumes familiarity with VictronConnect
The settings below are a precautionary measure.
MPPT Parameter Setting
Battery voltage. 48V
Absorption voltage 53V
7. Example Wiring Diagram

2023-02-21 22:12 9/12 Victron & Pylontech UP2500, US2000, US3000, US2000C, US3000C, US5000, US5000B, UP5000, Phantom-S, Force-
L1 & L2
Victron Energy - https://www.victronenergy.com/live/
8. Troubleshooting
If the system is not operating correctly, go through these steps.
Step 0. If the Inverter/Charger or GX device does not switch on
As a safety precaution, the inverter/charger will not switch on if the GX device is not on. If you are
unable to start the system due to a total system blackout / battery shutdown due to low voltage, you
may need to disconnect the VE.BUS connection cable between the inverter/charger and GX device.
You can then start the inverter/charger from an external charge source such as a generator or grid

Last
update:
2020-05-25
10:56
battery_compatibility:pylontech_phantom https://www.victronenergy.com/live/battery_compatibility:pylontech_phantom?rev=1590396991
https://www.victronenergy.com/live/ Printed on 2023-02-21 22:12
connection. Once the inverter/charger has started, it should supply power to the DC terminals and this
should start the GX device and Pylontech battery again. You will need to then reconnect the VE.Bus
Communications cable back to the inverter/charger and GX device.
Step 1. Check that the Pylontech battery is visible on the GX device list
If its not visible, check:
GX device firmware version (update to latest version, v2.15 or later)
CAN-bus communication cabling between Pylontech and Victron system. Make sure that it is in
the right way around.
Pylontech system is up and running (LEDs are on)
Step 2. Check that the Pylontech battery is ready for use
Check the Max Charge Voltage parameter. This voltage parameter is sent, together with the other
three parameters, by the Pylontech system via the CAN-bus cable. They are visible on the GX device:
Device List → Pylontech battery → Parameters menu.
Step 3. Check the Pylontech manual
The Pylontech manual contains additional diagnostic and troubleshooting information, specifically
around decoding any indicator LEDs.
9. FAQ and Known Issues
The maximum charge and discharge current is limited to 25A, but the data
sheet tells me the maximum is 100A.
The maximum current is limited to keep the battery healthy and reach the 10 year guarantee. In off-

2023-02-21 22:12 11/12 Victron & Pylontech UP2500, US2000, US3000, US2000C, US3000C, US5000, US5000B, UP5000, Phantom-S, Force-
L1 & L2
Victron Energy - https://www.victronenergy.com/live/
grid, the inverter can draw more than the 25A limit to run the loads, make sure you have sufficient
batteries installed to keep the load per battery around this limit.
After charging the battery the charge current often changes between 0A and
25A.
This is caused by cell balancing inside the battery. This happens with new batteries and after a deep
discharge.
My system isn't charging at the rated capacity, or my PV is shutting down
Pylontech's BMS will restrict the Charge Current Limit of the battery in cold weather. The precise
temperatures and limits are not published by Pylontech, but anecdotally from reports on Victron
Community it would appear that batteries begin to be limited below 18 degree C, severely limited
below 10 degrees C, and completely restricted from charging below 2 degrees C.
You can confirm if this is affecting your installation be entering the Pylontech Battery menu on your
GX device, and then the Parameters Menu. This will report the Charge Current Limit (CCL) and
Discharge Current Limit (DCL).
My system only charges the battery to 52V
When DVCC is enabled, the battery (via the CAN-bms) is responsible for the charge voltage. The
Pylontech battery requests a charge voltage of 53.2V. We have however found that in practice this is
too high.
The Pylontech battery has 15 cells in series, so 53.2V equates to 3.55V per cell. This is very highly
charged and makes the system prone to go overvoltage.
It should also be noted that a LiFePO4 cell stores very little additional energy above 3.45V.
For this reason we opted to override the BMS and cap the voltage at 52V. This sacrifices almost none
of the capacity and greatly improves the stability of the system.
The battery won't charge to 100%
Also see the question above. The state of charge of the battery is estimated based on the overall
voltage and on how well balanced the internal cells are. Because we cap the battery voltage at 52V,
the state of charge will sometimes rise very slowly once it reaches the mid-90s. This is normal and
usually resolves over time.
10. Further Information
For information about where to buy or find suitably qualified installers, visit the Where to Buy Page.

Last
update:
2020-05-25
10:56
battery_compatibility:pylontech_phantom https://www.victronenergy.com/live/battery_compatibility:pylontech_phantom?rev=1590396991
https://www.victronenergy.com/live/ Printed on 2023-02-21 22:12
Further community discussion about installing and using Pylontech and Victron can found at Victron
Community, use the topic label 'Pylontech'.
DISQUS
View the discussion thread.
From:
https://www.victronenergy.com/live/ - Victron Energy
Permanent link:
https://www.victronenergy.com/live/battery_compatibility:pylontech_phantom?rev=1590396991
Last update: 2020-05-25 10:56
