ViewSonic VPC101 User manual

VPC101
19" (18.5" VIEWABLE)
ALL-IN-ONE TOUCH SCREEN PC
ViewSonic’s VPC101 All-in-One touch screen PC features a
space-saving, stylish design combined with a powerful Intel®
Atom™230 1.6GHz processor to give you all the computing
power you need without cluttering up your desktop. The VPC101
also comes with Microsoft®Windows®7 Home Premium, 10/100
Gigabit Ethernet and wireless 802.11b/g connectivity to easily
integrate into your home LAN or WAN network. With four USB
2.0 ports and a 4-in-1 card reader it’s easy to transfer and share
les, photos and more. Whether you are developing touch
applications or just staying in touch with family and friends, the
19" (18.5" viewable) LCD touch screen, integrated 1.3 megapixel
webcam and built-in speakers make it simple and fun.
Manipulate your Desktop
Easy to manipulate and develop
touch applications for a full
computing experience
View and modify documents and
surf the Internet in crisp detail with
the high resolution 18.5" touch screen
The Intel®Atom™1.6GHz processor
with 1GB of memory provides
plenty of power for most desktop
computing needs
>
>
>
Four high-speed USB 2.0 ports provide
easy connections for peripherals
4-in-1 card reader allows for easy
le transfers
Easily integrates into a LAN network
through the 10/100 Gigabit Ethernet
LAN connection
Stay connected wirelessly through
802.11b/g WiFi connectivity
>
>
>
>
Integrated 1.3 megapixel webcam
makes it easy to interact with friends
and co-workers
2x2-watt speakers complement
video conferencing and
Internet browsing
>
>

Smarter Greener Computing
For more product information, visit us on the web at ViewSonic.com
Sales: [phone] • [email protected] • ViewSonic.com
Microsoft, Windows, and the Windows logo are trademarks, or registered trademarks of Microsoft Corporation in the United States and/or other
countries. Specications subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic representative
for complete details. Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2009 ViewSonic
Corporation. All rights reserved. [14418-01B-11/09] VPC101-1
VPC101 19" (18.5" VIEWABLE) ALL-IN-ONE TOUCH SCREEN PC
LCD Type 18.5" Color TFT Active Matrix LCD
Display Area 16.1" horizontal x 9.1" vertical; 18.5" diagonal
Resolution 1366x768
Contrast Ratio 1000:1 static (typ)
Viewing Angles 170º horizontal, 160º vertical
Response Time 5ms
Light Source Long life, 50,000 hrs. (typ)
Brightness 300 cd/m2 (typ)
Touch Screen 5 wire analog resistive touch panel
WEBCAM 1.3 megapixel
CORE CPU Processor Type Intel®Atom™230
CPU Processor Speed 1.6GHz Single Core, 533MHz
Chipset Intel®945GC + ICH7M
MEMORY 1GB DDR2 SDRAM (expandable to 2GB)
SOFTWARE Operating System Windows®7 Home Premium
HARD DRIVE Capacity 2.5", 160GB SATA
COMMUNICATION Ethernet LAN 10/100 Gigabit Ethernet
Wireless LAN 802.11 b/g
INPUT/OUTPUT USB 2.0 (x4)
VGA in
RJ45 Gigabit Ethernet LAN
Microphone jack
Earphone jack
4-in-1 card reader (SD, MMC, MS, MS Pro)
AUDIO OUTPUT Speakers 2-watt (x2)
CONNECTORS Power Adapter 19V DC; 65W adapter
Power Cord 3-pin AC plug
POWER Voltage AC 100–240V (universal)
Consumption 65W (typ)
OPERATING Temperature 32–104ºF (0–40ºC)
CONDITIONS Humidity 10–90% (non-condensing)
Altitude 0–6,000 ft. (1800 m), operational up to 10,000 ft. (3048 m)
at reduced reliability and performance
DIMENSIONS Physical (W x H x D) 18.3" x 15.0" x 3.2" (466mm x 382mm x 82mm)
Carton (W x H x D) 20.8" x 17.6" x 7.1" (528mm x 448mm x 181mm)
WEIGHT Net 11.0 lb. (5.0 kg)
Gross 16.52 lb. (7.5 kg)
SECURITY Kensington®lock
REGULATIONS UL, CUL, FCC, CE, RoHS
RECYCLE/DISPOSAL The lamp in this product contains mercury. Please
dispose of in accordance with local, state or federal laws.
PACKAGE CONTENTS VPC101, power cord, power adapter, keyboard, mouse,
Driver CD, Quick Start Guide, ViewSonic Wizard CD
WARRANTY 1 year limited warranty on parts, labor and backlight.
ViewSonic Corporation’s QMS & EMS have been registered
to ISO 9001 & ISO 14001, respectively, by TUV NORD.
1– Touch Screen
2– Front Speaker
3– Controls
4 – Back Speaker
5– DVD Tray
5 6
7
9
4
321
8
6– USB/Card Reader
7– Inputs/Outputs
8– Kensington®Lock
9– Adjustable Stand
6 5 9
7
