ViewSonic VPC2-O-1B Series User manual

VPC2-O-1B Series
Slot in PC module
Quick Start Guide
Model No. P/N Model No. P/N
VS18766 VPC2C-W33-O1-1B VS18766 VPC27-W53-O1-1B
VS18766 VPC25-W33-O1-1B VS18766 VPC27-W55-O2-1B
VS18766 VPC25-W53-O1-1B VS18766 VPC25-S33-O1-1B
VS18766 VPC25-W53-O2-1B VS18766 VPC27-S53-O1-1B

2
Thank you for choosing ViewSonic®
As a world-leading provider of visual solutions, ViewSonic® is dedicated to exceeding
the world’s expectations for technological evolution, innovation, and simplicity.
At ViewSonic®, we believe that our products have the potential to make a positive
impact in the world, and we are confident that the ViewSonic® product you have
chosen will serve you well.
Once again, thank you for choosing ViewSonic®!

3
1. Interface
1110 6
1 2 3 4 5 6 7 8 9
Item Descripon
1POWER BUTTON
2MIC-IN
3LINE-OUT
4HDMI
5TYPE-C (DC5V, 500mA)
6USB 2.0 (DC5V, 500mA)
7LAN
8USB 3.2 (DC5V, 500mA)
9RESET
10 HDD/POWER_LED
11 DP

4
2. Installaon
2-1
2-2

5
2-3
*Antennas must be installed

6
3. InternetConnecon

7
4. InputSelecon
4242
To select an Input Source:
1. Press INPUT on the remote control, press the seng buon
4242
on the front
panel, or press the
4242
seng icon from the toolbar to display the Input Sengs
menu.
2. Press
4242
/
4242
/
4242
/
4242
to select PC.
3. Press
4242
on the remote control, or touch the input source.
4. Press
4242
on the remote control, or touch a blank area outside of the menu to
exit.

8
5. USBConnecon

9
6. Specicaons
Processor Intel® Comet Lake-S
PCH H510 Q570
Graphic Integrated Intel® UHD graphic
RAM 2 x DDR4 SO-DIMM, 32GB (Max)
Storage 1 x NVMe M.2 2280 PCIe SSD
IO ports 1 x USB Type-C
(USB 3.2 Gen1, Data Only)
3 x USB 2.0,
1 x USB 3.2 Gen1
1 x USB Type-C
(USB 3.2 Gen2x2, Data Only)
4 x USB 3.2 Gen2
1 x DP 1.2 out
1 x HDMI 1.4 out
1 x RJ45 Ethernet (with Intel I219LM)
1 x Microphone/Line out
2 x External antenna Holes
1 x Power On/O Buon
1 x Reset Buon
1 x Power LED
1 x HDD LED
1 x 80 Pin JAE OPS connector
WIFI/BT 1 x M.2 2230 (with Intel® AX200 WiFi 6 + BT 5.2 module)
Watchdog Support
vPro/AMT No Yes
BIOS AMI UEFI BIOS
Power DC in +19V @ 3.42A
65 W (Typical)
Operang
Condions
-5 °C to +45 °C
20% RH ~ 80% RH non-condensing
Storage
Condions
-20 °C to +70 °C
10% ~ 80% R.H. non-condensing

10
RegulatoryandServiceInformaon
ComplianceInformaon
This secon addresses all connected requirements and statements regarding
regulaons. Conrmed corresponding applicaons shall refer to nameplate labels
and relevant markings on the unit.
FCC Compliance Statement
This device complies with part 15 of FCC Rules. Operaon is subject to the following
two condions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may
cause undesired operaon.
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protecon against harmful interference in a residenal
installaon. This equipment generates, uses, and can radiate radio frequency
energy, and if not installed and used in accordance with the instrucons, may cause
harmful interference to radio communicaons. However, there is no guarantee that
interference will not occur in a parcular installaon. If this equipment does cause
harmful interference to radio or television recepon, which can be determined
by turning the equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separaon between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Warning: You are cauoned that changes or modicaons not expressly approved
by the party responsible for compliance could void your authority to operate the
equipment.

11
ISED compliance statement
This device contains licence-exempt transmier(s)/receiver(s) that comply with
Innovaon, Science and Economic Development Canada’s licence-exempt RSS(s).
Operaon is subject to the following two condions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause
undesired operaon of the device.
Warning for LE-LAN devices:
(1) the device for operaon in the band 5150–5250 MHz is only for indoor use
to reduce the potenal for harmful interference to co-channel mobile satellite
systems;
(2) where applicable, antenna type(s), antenna models(s), and worst-case lt
angle(s) necessary to remain compliant with the e.i.r.p. elevaon mask requirement
set forth in secon 6.2.2.3 shall be clearly indicated.
ISEDRadiaonExposurestatement
This equipment complies with IC RSS-102 radiaon exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20 cm between the radiator and your body.
Industry Canada Statement
CAN ICES-003(B) / NMB-003(B)
Contains FCC ID: GSS-VS18766
IC ID: 4280A-VS18766

12
CE Conformity for European Countries
The device complies with the EMC Direcve 2014/30/EU and Low Voltage
Direcve 2014/35/EU and Radio Equipment Direcve (RED) 2014/53/EU.
ThefollowinginformaonisonlyforEU-memberstates:
The mark shown to the right is in compliance with the Waste Electrical
and Electronic Equipment Directive 2012/19/EU (WEEE).The mark
indicates the requirement NOT to dispose the equipment as unsorted
municipal waste, but use the return and collection systems according
to local law. In all EU member states, operation of 5150-5350MHz is
restricted to indoor use only. This device should be installed and operated
with a minimum distance of 20cm between the radiator and your body.
DeclaraonofRoHS2Compliance
This product has been designed and manufactured in compliance with Direcve
2011/65/EU of the European Parliament and the Council on restricon of the use
of certain hazardous substances in electrical and electronic equipment (RoHS2
Direcve) and is deemed to comply with the maximum concentraon values issued
by the European Technical Adaptaon Commiee (TAC) as shown below:
Substance ProposedMaximumConcentraon ActualConcentraon
Lead (Pb) 0.1% < 0.1%
Mercury (Hg) 0.1% < 0.1%
Cadmium (Cd) 0.01% < 0.01%
Hexavalent Chromium (Cr6⁺) 0.1% < 0.1%
Polybrominated biphenyls (PBB) 0.1% < 0.1%
Polybrominated diphenyl ethers (PBDE) 0.1% < 0.1%
Bis (2-ethylhexyl) phthalate (DEHP) 0.1% < 0.1%
Butyl benzyl phthalate (BBP) 0.1% < 0.1%
Dibutyl phthalate (DBP) 0.1% < 0.1%
Diisobutyl phthalate (DIBP) 0.1% < 0.1%
CertaincomponentsofproductsasstatedaboveareexemptedundertheAnnex
IIIoftheRoHS2Direcvesasnotedbelow:
• Copper alloy containing up to 4% lead by weight.
• Lead in high melng temperature type solders (i.e. lead-based alloys containing
85% by weight or more lead).
• Electrical and electronic components containing lead in a glass or ceramic other
than dielectric ceramic in capacitors, e.g. piezoelectronic devices, or in a glass or
ceramic matrix compound.
• Lead in dielectric ceramic in capacitors for a rated voltage of 125V AC or 250V DC
or higher.

13
IndianRestriconofHazardousSubstances
Restricon on Hazardous Substances statement (India). This product complies
with the “India E-waste Rule 2011” and prohibits use of lead, mercury, hexavalent
chromium, polybrominated biphenyls or polybrominated diphenyl ethers in
concentraons exceeding 0.1 weight % and 0.01 weight % for cadmium, except for
the exempons set in Schedule 2 of the Rule.
Product Disposal at End of Product Life
ViewSonic® respects the environment and is commied to working and living
green. Thank you for being part of Smarter, Greener Compung. Please visit the
ViewSonic® website to learn more.
USA & Canada:
http://www.viewsonic.com/company/green/recycle-program/
Europe:
http://www.viewsoniceurope.com/eu/support/call-desk/
Taiwan:
https://recycle.epa.gov.tw/

14
Customer Service
For technical support or product service, see the table below or contact your
reseller.
NOTE: You will need the product’s serial number.
Country/ Region Website Country/ Region Website
AsiaPacic&Africa
Australia www.viewsonic.com/au/ Bangladesh www.viewsonic.com/bd/
中国 (China) www.viewsonic.com.cn 香港 (繁體中文) www.viewsonic.com/hk/
Hong Kong (English) www.viewsonic.com/hk-en/ India www.viewsonic.com/in/
Indonesia www.viewsonic.com/id/ Israel www.viewsonic.com/il/
日本 (Japan) www.viewsonic.com/jp/ Korea www.viewsonic.com/kr/
Malaysia www.viewsonic.com/my/ Middle East www.viewsonic.com/me/
Myanmar www.viewsonic.com/mm/ Nepal www.viewsonic.com/np/
New Zealand www.viewsonic.com/nz/ Pakistan www.viewsonic.com/pk/
Philippines www.viewsonic.com/ph/ Singapore www.viewsonic.com/sg/
臺灣 (Taiwan) www.viewsonic.com/tw/ ประเทศไทย www.viewsonic.com/th/
Việt Nam www.viewsonic.com/vn/ South Africa & Maurius www.viewsonic.com/za/
Americas
United States www.viewsonic.com/us Canada www.viewsonic.com/us
Lan America www.viewsonic.com/la
Europe
Europe www.viewsonic.com/eu/ France www.viewsonic.com/fr/
Deutschland www.viewsonic.com/de/ Қазақстан www.viewsonic.com/kz/
Россия www.viewsonic.com/ru/ España www.viewsonic.com/es/
Türkiye www.viewsonic.com/tr/ Україна www.viewsonic.com/ua/
United Kingdom www.viewsonic.com/uk/
