ViewSonic VPC100 - 1 GB RAM User manual

-UserGuide
-Guidedel’utilisateur
-Bedienungsanleitung
-Guíadelusuario
-Pyководствопользователя
-Οδηγόςχρηστών
- 使用手冊(繁中)
- 使用手冊(简中)
- 사용자 안내서
VPC100
All-in-OnePC
ViewSonic®
ModelNo.:VS12489

ViewSonic VPC100 i
TableofContents
Preface................................................................................................... iv
Compliance Information ..................................................................................... iv
Important Safety Instructions ............................................................................. vi
Declaration of RoHS Compliance ..................................................................... vii
Copyright Information ........................................................................................viii
U.S. Patent Numbers ........................................................................................viii
Product Registration........................................................................................... ix
Specications ...................................................................................................... x
Chapter1:GettingStarted.................................................................... 1
Package Contents ...............................................................................................2
Features ..............................................................................................................3
System Overview ................................................................................................4
Front View ................................................................................................4
Rear View ................................................................................................5
Side Views ...............................................................................................6
Chapter2:Installation........................................................................... 7
Attaching the Stand .............................................................................................8
Tilting the Screen ................................................................................................8
Removing the Stand............................................................................................8
Connecting PS/2® Devices ..................................................................................9
Connecting a PS/2® Keyboard .................................................................9
Connecting a PS/2® Mouse .....................................................................9

ViewSonic VPC100 ii
Connecting the Power .......................................................................................10
Connecting Audio Components.........................................................................10
Connecting the Headset ........................................................................10
Connecting a Microphone ......................................................................10
Connecting USB Devices .................................................................................. 11
Connecting to a Network ................................................................................... 11
Chapter3:Operating........................................................................... 12
Using the Power Button ....................................................................................13
Turning On the All-in-One PC ................................................................13
Turning Off the All-in-One PC ................................................................13
Using the Card Reader .....................................................................................13
Inserting the card ...................................................................................13
Removing the card.................................................................................13
Using the Optical Disc Drive .............................................................................14
Inserting a Disc ......................................................................................14
Removing a Disc....................................................................................14
Using the keyboard ...........................................................................................14
Hot keys .................................................................................................14
Chapter4:BIOSSetupUtility............................................................. 15
When to Use the BIOS Setup Utility..................................................................16
Starting BIOS Setup ..........................................................................................16
Moving Around and Making Selections .............................................................16
Main Menu .............................................................................................17
Advanced Menu .....................................................................................18
Boot Menu .............................................................................................22

ViewSonic VPC100 iii
Security Menu ........................................................................................25
Chipset Menu.........................................................................................27
Exit Menu ...............................................................................................29
Chapter5:SystemRecovery.............................................................. 30
When to Use System Recovery ........................................................................31
Running ViewSonic® Recovery Manager ..........................................................31
How to Create the System Recovery Disk ........................................................33
Chapter6:Troubleshooting................................................................ 36
Chapter7:OtherInformation............................................................. 40
Customer Support .............................................................................................40
Limited Warranty ...............................................................................................41
Appendix:VPC100BundleSoftware................................................. 43
NTI (New Tech Infosystems, Inc.) Media Maker OEM version ..........................43
WinRAR (40 days trial) ......................................................................................44
Trend Micro Internet Security (2009), 60-day trial version ................................44

ViewSonic VPC100 iv
Preface
ComplianceInformation
ForU.S.A.
This device complies with part 15 of FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy, and if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Warning: You are cautioned that changes or modications not expressly approved
by the party responsible for compliance could void your authority to operate the
equipment.
ForCanada
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du
Canada.
CEConformityforEuropeanCountries
The device complies with the EMC Directive 2004/108/EC and Low Voltage
Directive 2006/95/EC.
FollowinginformationisonlyforEU-memberstates:
The mark shown to the right is in compliance with the Waste Electrical and
Electronic Equipment Directive 2002/96/EC (WEEE).
The mark indicates the requirement NOT to dispose the equipment as
unsorted municipal waste, but use the return and collection systems
according to local law.
If the batteries, accumulators and button cells included with this equipment,
display the chemical symbol Hg, Cd, or Pb, then it means that the battery has
a heavy metal content of more than 0.0005% Mercury or more than, 0.002%
Cadmium, or more than 0.004% Lead.

ViewSonic VPC100 v
FCCRadiationExposureStatement
This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
This wireless module device complies with part 15 of FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including interference that
may cause undesired operation.
IndustryCanadaNotice
This wireless module device complies with Canadian RSS-210.To prevent radio
interference to the licensed service, this device is intended to be operated indoors
and away from windows to provide maximum shielding. Equipment (or its transmitting
antenna) that is installed outdoors is subject to licensing. The installer of this radio
equipment must ensure that the antenna is located or pointed such that it does not
emit RF eld in excess of Health Canada limits for the general population; consult
Safety Code 6, obtainable from Health Canada’s web site www.hc-sc.gc.ca/rpb.
R&TTEComplianceStatement
This wireless module device complies with the Essential Requirements of the R&TTE
Directive of the European Union (1999/5/EC). This equipment meets the following
conformance standards:
ETSI EN 300 328V1.7.1 (2006)
EN 301 489-01 V1.6.1 (2005)
EN 301 489-17 V1.2.1 (2002)
EN 62311 (2008)
NotiedCountries:Germany, UK, Netherlands, Belgium, Sweden, Denmark,
Finland, France, Italy, Spain, Austria, Ireland, Portugal, Greece, Luxembourg,
Estonia, Latvia, Lithuania, Czech Republic, Slovakia, Slovenia, Hungary, Poland and
Malta.

ViewSonic VPC100 vi
ImportantSafetyInstructions
1. Read these instructions completely before using the equipment.
2. Keep these instructions in a safe place.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this equipment near water. Warning: To reduce the risk of re or
electric shock, do not expose this apparatus to rain or moisture.
6. Clean with a soft, dry cloth. If further cleaning is required, see “Cleaning the
Display” in this guide for further instructions.
7. Do not block any ventilation openings. Install the equipment in accordance with
the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or
other devices (including ampliers) that produce heat.
9. Do not attempt to circumvent the safety provisions of the polarized or grounding-
type plug. A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The wide blade
and the third prong are provided for your safety. If the plug does not t into your
outlet, consult an electrician for replacement of the outlet.
10. Protect the power cord from being tread upon or pinched, particularly at the plug,
and the point where if emerges from the equipment. Be sure that the power outlet
is located near the equipment so that it is easily accessible.
11. Only use attachments/accessories specied by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specied by the
manufacturer, or sold with the equipment. When a cart is used, use
caution when moving the cart/equipment combination to avoid injury
from tipping over.
13. Unplug this equipment when it will be unused for long periods of time.
14. Refer all servicing to qualied service personnel. Service is required when the
unit has been damaged in any way, such as: if the power-supply cord or plug is
damaged, if liquid is spilled onto or objects fall into the unit, if the unit is exposed
to rain or moisture, or if the unit does not operate normally or has been dropped.

ViewSonic VPC100 vii
DeclarationofRoHSCompliance
This product has been designed and manufactured in compliance with Directive
2002/95/EC of the European Parliament and the Council on restriction of the use of
certain hazardous substances in electrical and electronic equipment (RoHS Directive)
and is deemed to comply with the maximum concentration values issued by the
European Technical Adaptation Committee (TAC) as shown below:
Substance ProposedMaximumConcentration ActualConcentration
Lead (Pb) 0,1% < 0,1%
Mercury (Hg) 0,1% < 0,1%
Cadmium (Cd) 0,01% < 0,01%
Hexavalent Chromium (Cr6+) 0,1% < 0,1%
Polybrominated biphenyls (PBB) 0,1% < 0,1%
Polybrominated diphenyl ethers
(PBDE) 0,1% < 0,1%
Certain components of products as stated above are exempted under the Annex of
the RoHS Directives as noted below:
Examples of exempted components are:
1. Mercury in compact uorescent lamps not exceeding 5 mg per lamp and in other
lamps not specically mentioned in the Annex of RoHS Directive.
2. Lead in glass of cathode ray tubes, electronic components, uorescent tubes, and
electronic ceramic parts (e.g. piezoelectronic devices).
3. Lead in high temperature type solders (i.e. lead-based alloys containing 85% by
weight or more lead).
4. Lead as an allotting element in steel containing up to 0.35% lead by weight,
aluminium containing up to 0.4% lead by weight and as a cooper alloy containing
up to 4% lead by weight.

ViewSonic VPC100 viii
CopyrightInformation
Copyright © ViewSonic® Corporation, 2011. All rights reserved.
Microsoft®, Windows®, Windows NT®, and the Windows® logo are registered
trademarks of Microsoft® Corporation in the United States and other countries.
ViewSonic®, the three birds logo, OnView®, ViewMatch™, and ViewMeter® are
registered trademarks of ViewSonic® Corporation.
Intel®, Pentium®, and Atom™ are registered trademarks of Intel Corporation.
AMD®, Athlon™, Athlon™ XP, Thoroughbred™ and Duron™ are registered
trademarks of AMD® Corporation.
NVIDIA®, the NVIDIA® logo, DualNet® and nForce® are registered trademarks or
trademarks of NVIDIA® Corporation in the United States and/ or other countries.
PS/2® and OS/2® are registered trademarks of International Business Machines
Corporation.
Netware® is a registered trademark of Novell, Inc.
Award® is a registered trademark of Phoenix Technologies Ltd.
AMI® is a registered trademark of American Megatrends Inc.
Disclaimer: ViewSonic® Corporation shall not be liable for technical or editorial errors
or omissions contained herein; nor for incidental or consequential damages resulting
from furnishing this material, or the performance or use of this product.
In the interest of continuing product improvement, ViewSonic® Corporation reserves
the right to change product specications without notice. Information in this document
may change without notice.
No part of this document may be copied, reproduced, or transmitted by any means,
for any purpose without prior written permission from ViewSonic® Corporation.
U.S.PatentNumbers
This item incorporates copy protection technology that is protected by U.S. patents
and other intellectual property rights of Rovi Corporation. Reverse engineering and
disassembly are prohibited.

ViewSonic VPC100 ix
ProductRegistration
To meet your future needs, and to receive any additional product information as it
becomes available, please register your product on the Internet at: www.viewsonic.
com. The ViewSonic® Wizard CD-ROM also provides an opportunity for you to print
the registration form, which you may mail or fax to ViewSonic®.
ForYourRecords
ProductName:
ModelNumber:
DocumentNumber:
SerialNumber:
PurchaseDate:
VPC100
ViewSonic All-in-One PC
VS12489
VPC100-1_UG_ENG Rev. 1D 12-15-10
Productdisposalatendofproductlife
The lamp in this product contains mercury which can be dangerous to you and the
environment. Please use care and dispose of in accordance with local, state or
federal laws.
ViewSonic respects the environment and is committed to working and living green.
Thank you for being part of Smarter, Greener Computing. Please visit ViewSonic
website to learn more.
USA & Canada: http://www.viewsonic.com/company/green/recycle-program/
Europe: http://www.viewsoniceurope.com/uk/support/recycling-information/
Taiwan: http://recycle.epa.gov.tw/recycle/index2.aspx

ViewSonic VPC100 x
Specications
Processor Intel® Atom™ N280
1.66GHz Single Core, FSB, 667MHz
OperatingSystem Microsoft® Windows XP Home
Chipset North Bridge: Intel® 945GSE Chipset
South Bridge: Intel® ICH7M Chipset
Memory 1 DDR2 SO-DIMM slot
Supports DDR2 400/533 SDRAM (200-Pin/1.8V)
Max. memory size: 2GB
Storage 160GB SATA hard disk
LAN Supports Gigabit Ethernet Controller for PCI ExpressTM
Audio Stereo speaker 3W*2
LCDDisplay 19” TFT LCD Display (18.5” viewable)
1366 x 768 native resolution
Webcam 1.3 Megapixel camera
Keyboard PS/2 100 keys
Mouse PS/2 Optical sensor
Input/Outputports 1 LAN jack
1 Power jack
2 PS/2 ports (keyboard and mouse)
1 Mic in jack
1 Headphone jack
2 USB ports - rear mounted
2 USB ports - side mounted
4-in-1 card reader (XD/SD/MMC/MS)
Built-inDrive 12.7mm slim type tray-in DVD Super Multi
WirelessLAN 802.11 b/g
PowerSupply 65W power adapter with active PFC
19V DC; 65W Power Adapter
Dimension 450mm (W) x 432mm (H) x 35mm (D) - with stand
17.8” (W) x 16.7” (H) x 1.4” (D) - with stand
Weight 11.7 lbs (5.3 kg)

ViewSonic VPC100 1
Congratulations on your purchase of the
ViewSonic® VPC100 All-In-One PC! The
VPC100 All-in-One PC is engineered for
powerful computing performance.
Unlike conventional computers, this All-
in-One PC is portable and can be easily
moved anytime, anywhere. With its built-in
components, it is flexible yet economical,
providing users with maximum computing
experience without compromising system
performance.
Read this chapter for more information about
the following topics:
• Package contents
• Features
• System Overview
Chapter1
GettingStarted

ViewSonic VPC100 2
GettingStarted
PackageContents
The following items come with your package. If any of them is damaged or missing,
please contact your retailer.
All-in-One PC Stand Power adapter
Power cord ViewSonic Wizard CD System Recovery and
Driver Disk
Quick Start Guide Keyboard Mouse
NOTE
Keyboard and mouse will be based on actual received units.

ViewSonic VPC100 3
GettingStarted
Features
All-in-one
The functionality of a standard multiple-parts computer and its monitor are
combined together in this all-in-one PC. With a built-in card reader, an optical
disc drive, and I/O ports, you can connect various peripherals to maximize
computer performance.
Spacesaver
The slim and sleek design provides more desk space. Because of its
compactness, fewer cables are required which creates a tidy and uncluttered
work space.
Highvideoquality
The 19” (18.5” viewable) LCD display supports an optimal resolution of
1366x768.
Mountable
For more exibility options, use VESA mounting to hang this All-in-One PC on the
wall.
Lowpowerconsumption
This All-in-One PC consumes a maximum of 65 watts of power with active PFC.

ViewSonic VPC100 4
GettingStarted
SystemOverview
FrontView
2
1
3
4
5
No. Item Description
1 Webcam Use for taking pictures, recording videos, and
video conferencing.
2 Microphone Use for chatting and other interactive
applications.
3 LCD display Provides visual output on a 1366x768
resolution display.
4 Power button / LED
Press to power on / off the All-in-One PC. The
power LED turns blue when the All-in-One PC
is turned on.
5 Stand Holds the All-in-One PC in place.

ViewSonic VPC100 5
GettingStarted
RearView
No. Item Description
1 Cooling vent Used for air convection to prevent the All-in-One
from overheating. Do not cover the cooling vent .
2 Power jack inlet Use to connect the power adapter.
3 Stereo speakers Output high quality sound with Hi-Fi function.
4HDD and memory
compartment
Contains the hard disk and memory modules. Do
not cover the compartment ventilation holes.
5 Mouse port Connects a PS/2® mouse to the All-in-One PC.
6 Keyboard port Connects a PS/2® keyboard to the All-in-One PC.
7 Headphone jack Connects a headphone to the All-in-One PC.
8 External microphone jack Connects a external microphone to the All-in-One
PC.
9 USB ports Connect USB devices such as a mouse,
keyboard, printer, scanner, and other peripherals.
10 RJ-45 LAN jack Connects to a local area network (LAN) using a
network cable.
11 VESA mount holes Mount the All-in-One PC on the wall using VESA
mounts.
NOTE
VESA mounts are not included in the package and are sold separately.
10
9
8
7
6
5
3
11
11
1
2
3
4

ViewSonic VPC100 6
GettingStarted
SideViews
XD
SD
MMC
MS
No. Item Description
1 Optical disk drive Plays or records DVD or CD disk
2 USB ports
Connect USB devices such as a mouse,
keyboard, printer, scanner, and other
peripherals.
3 Card reader port
Supports memory cards including XD
(eXtreme Digital), SD (Secure Digital), SDHC
(SD High Capacity), MS (Memory Stick), MS
Pro (Memory Stick Pro), or MMC (Multi-media
Card) cards.
1
2
3

ViewSonic VPC100 7
This chapter will guide you in installing
necessary and additional components to
maximimize the system performance of
your All-in-One PC. The following topics are
covered:
• Attaching the Stand
• Tilting the Screen
• Removing the Stand
• Connecting PS/2® Devices
• Connecting the Power
• Connecting Audio Components
• Connecting USB Devices
• Connecting to a Network
Chapter2
Installation

ViewSonic VPC100 8
Installation
TiltingtheScreen
After installing the stand, the screen can be tilted about 20o
to suit the user’s preference.
A
B
RemovingtheStand
Should there be a need to detach the stand (i.e., for wall mounting), follow the steps
below:
1. Lay the All-in-One PC on at and stable surface. Use a soft cloth to protect
the display screen.
2. Release screw located on bottom of stand (A).
3. Pull the stand out (B).
AttachingtheStand
1. Lay the All-in-One PC on a at and stable surface. Use a soft cloth to protect
the display screen.
2. Attach the stand. Tighten the stand until it is rmly locked in place.
3. Tighten the screw on the bottom of the stand.
5o front and 15o back

ViewSonic VPC100 9
Installation
ConnectingPS/2®Devices
You can connect a keyboard and a mouse using the PS/2® ports on the rear of your
All-in-One PC. Before making any connections, ensure that the All-in-One PC is
turned off.
ConnectingaPS/2®Keyboard
Plug the keyboard’s PS/2® cable into the
purple PS/2® port of the All-in-One PC.
ConnectingaPS/2®Mouse
Plug the mouse’s PS/2® cable into the
green PS/2® port of the All-in-One PC.
NOTE
• The PS/2 devices should be connected
when the unit is powered off. This will allow
Windows to detect the devices once the
system is turned on.
• You can also connect a USB keyboard or
mouse using the USB ports.
