ViewSonic PJ503D - DLP Projector User manual

ViewSonic’s PJ503D DLP®projector delivers the best entry level
performance value in the market. Topping the list of performance
features is the AMAZING CLARITY OF DLP TECHNOLOGY. The
PJ503D is the right choice for the small offices, classrooms and even
home use. This versatile projector offers 1,500 lumens and a high
2000:1 contrast ratio (typ) in only 5.7 pounds. MULTIPLE INPUTS,
ADVANCED IMAGE PROCESSING and SUPPORT FOR 720P AND
1080I SIGNALS let you connect your PC, DVD player and more.
The native 800x600 SVGA resolution and digital keystone correction
ensure that you’ll get the best possible image in virtually any setting.
The PJ503D is a lightweight, versatile projector that’s perfect for
those on a tight budget or looking for their first home projector.
Brilliantly affordable
mobile projector.
PJ503D
LIGHT, BRIGHT, PORTABLE
DLP®PROJECTOR
WITH KEYSTONE CORRECTION
>Bright in virtually any setting with 1,500 lumens
Packs 1,500 lumens in just 5.7 lbs. It’s the bright
choice for mobile presenters.
>DLP®technology
Stunning all digital clarity delivers lifelike color,
sharp graphics, and outstanding video.
>Ultimate video source flexibility
Connect a computer or add a video source for
dynamic meetings and presentations.
>Advanced video features
Motion adaptive deinterlacer for superior video
performance.
>Whisper-mode extends lamp life
Extend the life of your lamp up to 3,000 hours**
and reduce noise output.
>OnView®controls for superior screen adjustability
Screen geometry and color adjustments are precisely
made via an easy-to-use, on-screen menu.
BEST LOW-COST VALUE

PROJECTOR Type 0.55" DMD, DLP®
Pixel Format 800x600 SVGA
Lens Manual focus
Keystone Vertical ± 7º
DISPLAY Size 38"–150" (diagonally)
Throw Distance 60"–236"
Throw Ratio 2:1
Lamp 160W, 2,000 hours normal, up to 3,000 whisper eco mode**
Brightness 1,500 ANSI lumens (max)
Contrast Ratio 2000:1 (max)
Aspect Ratio 4:3 (native), 16:9
INPUT SIGNAL Computer and Video NTSC M, NTSC 4.43, PAL, SECAM, HDTV
(480i, 480p, 576i, 576p, 720p, 1080i)
Frequency Fh: 30–100kHz; Fv: 50–87Hz
COMPATIBILITY PC Analog: from VGA up to SXGA (scaled)
Mac®†Analog: up to SXGA (may require a Mac adapter)
CONNECTOR RGB (input) 15-pin HD, D-sub cable (x1)
Composite Video (input) RCA jack (x1)
S-Video (input) Mini-Din 4-pin (x1)
Component Video (input) VGA DB-15 to HDTV/component cable*
Control 8-pin mini-Din for RS232
POWER Voltage 100–240 VAC, 50/60Hz (universal)
Consumption 250W (typ)
CONTROLS Basic Standby/On, input, menu
OnView®Display mode, brightness, contrast, keystone, aspect ratio,
blank screen, color temperature, user color, video
(sharpness, saturation, tint), display (phase, H. position,
V. position), advance (auto source select, eco mode, lamp
hours, lamp reset, auto shutdown, OSD timeout, menu
position, factory reset)
OPERATING Temperature 32–104°F (0–40°C)
CONDITIONS Humidity 10–90% (non-condensing)
NOISE LEVEL Normal mode 30 dB (typ)
Whisper mode 27 dB (typ)
DIMENSIONS Physical (mm) 263mm x 108mm x 218mm
(W x H x D) Physical (in.) 10.35" x 4.25" x 8.6"
WEIGHT Net 5.7 lb. (2.6 kg)
Gross 8.15 lb. (3.7 kg)
RECYCLE/DISPOSAL The lamp in this product contains mercury. Please dispose of
in accordance with local, state and federal laws.
REGULATIONS UL, FCC-B, CCC, CE, NOM, PSB, CUL, ICES-003, Argentina
TUV/GS, RoHS, IRAM, CB
OTHER Vertical digital keystone correction, 3:2 pull down,
whisper mode, high altitude mode
PACKAGE CONTENTS Projector, power cords, VGA cable, remote control, lens cap,
ViewSonic Wizard CD, Quick Start Guide
WARRANTY Two-year limited warranty on parts and labor, first-year
Express Exchange®Service. One-year limited warranty
on lamp.***
PJ503D
LIGHT, BRIGHT, PORTABLE DLP®PROJECTOR WITH KEYSTONE CORRECTION
For more product information, visit us on the web at ViewSonic.com
ViewSonic Corporation • 381 Brea Canyon Road, Walnut, CA 91789
Customer Service and Technical Support: [phone] • Sales: [phone] • [email protected] • ViewSonic.com
*Optional cables required. **Running whisper-mode exclusively can extend lamp life. ***See ViewSonic.com for full details. †Adapter may be required. Analog adapter available from ViewSonic. DLP®and the DLP logo are
registered trademarks of Texas Instruments. Specifications subject to change without notice. Selection, offers and programs vary by country. See your ViewSonic representative for complete details. Corporate names, trade-
marks stated herein are the property of their respective companies. Copyright © 2007 ViewSonic Corporation. All rights reserved. [13283-05B-09/07] PJ503D-1
Optional Accessories
• Replacement lamp . . . . . . . . . . . . . . . . .RLC-030
• Extended Express Exchange
®
. . . . . . .PRJ-EE-05-03
• Universal ceiling mount kit . . . . . . . . . .WMK-005
• VGA to component video adapter . . .ADPT-002
• Wireless G Presentation Gateway . . . .WPG-150
