ViewSonic PJ513D User manual




with BrilliantColor™ Technology
ViewSonic’s PJ513DB DLP® projector delivers amazingly clear
images with the digital clarity of DLP technology with BrilliantColor™
. The PJ513DB is the right choice for small ofces, classrooms and
even home use. It weighs just 5.7 pounds and produces 2,200 lumens.
The image reversing function allows for installation exibility, while
the multiple inputs and support for 720p and 1080i signals provide
for versatile, dynamic presentations when you connect your PC,
DVD player and more. The native 800x600 SVGA resolution, digital
keystone correction and zoom lens ensure that you’ll get the best possible
image in virtually any setting. The PJ513DB DLP® projector delivers
excellent performance and value for business and education markets.


Bright in virtually any setting with 2,200 lumens 
Packs 2,200 lumens in just 5.7 pounds. It’s the bright choice
for mobile presenters.
BrilliantColor ™ technology
DLP® projectors with BrilliantColor™ feature multi-color processing
to produce nearly 50% brighter colors for a vibrant image on the
screen that won’t fade over time.
Supports HD signals including 720p and 1080i 
Capable of displaying HDTV signals as well as other
video and data sources.*
Mulitple color correction modes 
Brightest, presentation, photo, cinema, and standard modes give
you the best possible picture regardless of the projection surface.
OnView ® controls for superior screen adjustability
Screen geometry and color adjustments are precisely
made via an easy-to-use on-screen menu.
Eco-mode extends lamp life 
Extend the life of your lamp up to
3,000 hours** and reduce noise output.
My Screen Startup 
Customize your startup with a company
logo or favorite picture using the
MyScreen function.

PJ513DB
LIGHT, BRIGHT AND PORTABLE PROJECTOR WITH BrilliantColor™
Type 0.55 DDR DMD, DLP®
Pixel Format 800x600 SVGA
Lens Manual zoom, manual focus
Zoom Factor 1.1
Keystone Vertical ± 25º
Size 37"–162" (diagonally)
Throw Distance 59"–236.2"
Throw Ratio 1.8–1.98:1
Lamp 180W, 2,000 hrs. normal, up to 3,000 hrs. eco-mode**
Brightness (max) 2,200 ANSI lumens
Contrast Ratio 2000:1
Aspect Ratio 4:3 (native), 16:9
Computer and Video RGB analog, NTSC, NTSC 4.43, PAL, SECAM, HDTV
(480p, 720p, 1080i)
Frequency Fh:30–70kHz; Fv:50–87Hz
PC Analog: from VGA up to SXGA (scaled)
Mac® Analog: up to SXGA
RGB (input)/(output) 15-pin HD, D-sub
Composite Video (input) RCA jack
S-video (input) Mini-Din 4-pin
Component Video (input) VGA DB-15 to HDTV/component cable*
RS232 mini din-8
Audio (input) mini mono jack
Voltage 100–240VAC, 50–60Hz (universal)
Consumption 260W (typ)
Basic Standby/on, input, menu
OnView® Display mode (aspect ratio, keystone, position, phase,
H. size, digital zoom), picture (preset mode, reference
mode, brightness, contrast, color, tint, sharpness, Brilliant
Color™, color temperature, save settings), system setting
(projector position, auto power off, blank timer, panel key
lock, timer controller, splash screen, quick cooling, high
altitude mode, dynamic contrast ratio, audio settings,
menu settings, lamp settings, reset all), information (source,
preset mode, resolution, color system, equivalent lamp hour)
Temperature 32–104ºF (0–40ºC)
 Humidity 10–90% (non-condensing)
Altitude 0–10,000 ft.
 Normal 32 dB (typ)
Eco-mode 28 dB (typ)
Physical (W x H x D) 10.3" x 4.2" x 8.6" (263mm x 218mm x 108mm)
Net 5.7 lb. (2.6 kg)
Gross 8.3 lb. (3.8 kg)
 FCC-B, CE, CB, CCC, NOM, C-TICK, ICES 003, GS,
GOST-R, HYGIENIC, UKrSEPRO, RoHS
Projector, power cable, VGA cable, remote control with
batteries, lens cap, Quick Start Guide, ViewSonic Wizard
CD (with User Guide)
 3-year limited warranty on parts and labor, 1-year limited
warranty on lamp, 1-year free Express Exchange® service.***
For more product information, visit us on the web at ViewSonic.com
Sales: [phone] • [email protected] • ViewSonic.com
*Optional cables required. **Running eco-mode exclusively can extend lamp life. ***See ViewSonic.com for full details. †Adapter may be required. Analog adapter available from ViewSonic. DLP® and the DLP logo are
registered trademarks of Texas Instruments and BrilliantColor™ is a trademark of Texas Instruments. Specications subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic
representative for complete details. Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2009 ViewSonic Corporation. All rights reserved. [14353-00B-03/09] PJ513DB-1
ViewSonic Corporation’s QMS & EMS have been
registered to ISO 9001 & ISO 14001, respectively,
by the British Standards Institution.

• Replacement lamp ............................ RLC-035
• Extended Express Exchange® ................ PRJ-EE-05-03
• Universal ceiling mount kit ...............WMK-005
• VGA to component video adapter ...ADPT-002
• Wireless G Presentation Gateway .... WPG-150
