The ViewSonic®PJL7211 is an advanced 3LCD projector that delivers
2200 lumens with a 1024 x 768 XGA native resolution. Designed for table-
top use or ceiling mount, this projector is perfect for classrooms and
meeting rooms. The top load lamp and bottom filter with slide design
provide for easy maintenance. With 7 default picture modes (Normal,
Cinema, Dynamic, Blackboard, Greenboard, Whiteboard and Daylight
modes) to choose from depending on the projected source. Whisper
mode extends the lamp life and drops the fan noise down to 30dB. For
increased security, a PIN lock feature allows you to set a password to
prevent unauthorized use and Kensington security lock port provides for
theft deterrence.
A Perfect Presentation.
PJL7211
BRIGHT PERFORMANCE
PROJECTOR
WITH 3LCD TECHNOLOGY
VERSATILE PERFORMANCE
Great Connectivity
Supports 720p and 1080i with VGA and Composite inputs.
Easy, cost-effective maintenance
The sliding filter cover and simple lamp replacement
from the top of the unit make maintenance a breeze,
even when the projector is mounted.
Eco-mode for green savings
Automatically dims projector lamp, lowers power consumption
to <5w, which extends lamp life up to 6000 hrs. and lowers noise.
Enhanced security features
PIN lock feature prevents unauthorized use. Kensington®
security lock and a security bar allow you to secure the
projector to deter theft.
Off-to-Go feature
This feature allows the busy presenter to simply unplug
the projector and go without waiting for the usual cool
down phase. This feature also protects lamp life from
sudden power blackout.
One of the best warranties in the business
Covered by a 3-year limited parts, 1-year lamp and first
year free Express Exchange®service.
The perfect image in any setting
Digital keystone correction, and
optical zoom ensure
the perfect image
in any venue.
>
>
>
>
>
>
>

DISPLAY Type 0.63" (x3) Poly-Si TFT with Micro Lens
Resolution XGA 1024x768 (Native) / UXGA 1600×1200 (compressed)
Lens 1.2× Manual optical zoom / Manual focus
Keystone Vertical digital keystone correction: +/– 30 degrees
Size 30"–300" / 0.8m–7.6m
Throw Distance 0.8m–10.4m / 2.62ft.–34.5ft.
Throw Ratio 1.4:1–1.7:1
Lamp 190 watt
Lamp Life (Normal / Eco-mode) 3000 / 6000* hours
Brightness 2,200 Lumens
Contrast Ratio 400:1 (typ)
Aspect Ratio 4:3 (native)
INPUT SIGNAL Computer and Video NTSC M (3.58MHz), 4.43MHz, PAL (B, D, G, H, I, M, N),
SECAM, SD (480i/576i), ED (480p/576p), HD (720p/1080i)
Frequency Fh: 31–106KHz, Fv: 56–120Hz
COMPATIBILITY PC Analog: VGA to UXGA
Mac®Analog: Up to SXGA
CONNECTOR RGB Input 15-pin mini D-sub
Composite Input/Output RCA jack
Component Share with RGB
POWER Voltage 90~132 VAC/198~264 AC (Auto Switching), 50/60Hz (universal)
Consumption 250W (typ) / <5W (stand-by mode)
CONTROLS Basic Power, keystone/arrow keys, left/blank, menu/exit,
right/panel key lock, auto, mode/enter, source
OSD Picture Menu: Brightest, contrast, gamma, color temp,
color tint, sharpness, My Memory
Image Menu: Aspect, over scan, V. position, H. position,
H. phase, H. size, auto adjust execute
Input Menu: Progressive, video NR, color space,
video format, frame lock, computer in, resolution
Setup Menu: Keystone V., eco-mode, mirror
Screen Menu: Language, menu postion, blank, start up,
My Screen, My Screen lock, message, source name
Option Menu: Auto search, auto on, auto off, lamp time,
filter time, My Button, service (fan speed, auto adjust,
ghost, filter message, key lock, remote frequency,
information, factory reset)
Security Menu: Security password change, My Screen
password change, PIN lock, My Text
OPERATING Temperature 41ºF–95ºF (5ºC–35ºC)
CONDITIONS Humidity 10%–85% (non-condensing)
Altitude 0 to 6,000 ft (1,800m), operational up to 10,000 ft (3048m)
at reduced reliability and performance
NOISE LEVEL Normal / Eco-mode 37dB / 30dB
DIMENSIONS Physical 12.5 × 3.9 × 11.3 (in) / 317 × 98 × 288 (mm)
(W x H x D) Packaging 17.7 × 7.9 × 14.7 (in) / 450 × 200 × 372 (mm)
WEIGHT Net 7.3 lb. (3.3 kg)
Gross 14.0 lb. (6.4 kg)
REGULATIONS UL60950-1/C-UL, FCC part 15 Class B, CE approval:
EN61000-3-2, EN61000-3-3, EN55022, EN55024 (EMC
directive), EN60950-1 (low voltage directive); DEMKO-GS
(Germany), WEEE, RoHS, C-Tick (AS/NZS CISPR22 Class B)
(Australia/New Zealand)
PACKAGE CONTENTS Projector, power cable, RGB cable, remote control with
batteries, lens cap, strap, Quick Start Guide, ViewSonic
Wizard CD (with User Guide)
WARRANTY 3-year limited warranty on parts, 1-year limited warranty
on lamp, 1st year Express Exchange®service.
Sales: [phone] . [email protected] . ViewSonic.com
*Running eco-mode exclusively can extend lamp life. See ViewSonic.com for full Express Exchange details. Specifications subject to change without
notice. Selection, offers and programs may vary by country; see your ViewSonic representative for complete details. Corporate names, trademarks
stated herein are the property of their respective companies. Copyright © 2009 ViewSonic Corporation. All rights reserved [14550-00B-09/09] PJL7211-1
Projection Distance
For more product information, visit us on the web at ViewSonic.com
PJL7211
BRIGHT PERFORMANCE PROJECTOR WITH 3LCD TECHNOLOGY
ViewSonic Corporation’s QMS & EMS have been registered
to ISO 9001 & ISO 14001, respectively, by TUV NORD.
Feet
4.6
5.6
7.9
11.5
14.8
19.7
28.9
M
1.4
1.7
2.4
3.5
4.5
6
8.8
Inches
40–50
50–60
70–83
100–120
130–157
173–213
250–300
M
1.0–1.3
1.3–1.5
1.8–2.1
2.5–3.0
3.3–4.0
4.4–5.4
6.4–7.6
Optional Accessories
> Replacement Lamp.................................. RLC-054
> Universal Ceiling Mount Kit ..................WMK-005
> Wireless G Presentation Gateway.........WPG-350
> Extended Express Exchange®....... PRJ-EE-08-03
4:3 Screen Size
