ViewSonic VS18283 User manual

PD1013
PD1013T
Pen Display
User Guide
Model No. VS18283
P/N: PD1013 | PD1013T
IMPORTANT: Please read this User Guide to obtain important information on installing and using your product in
a safe manner, as well as registering your product for future service. Warranty information contained in this User
Guide will describe your limited coverage from ViewSonic®Corporation, which is also found on our web site at
http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right
corner of our website.

2
Thank you for choosing ViewSonic®
As a world-leading provider of visual solutions, ViewSonic® is dedicated to exceeding
the world’s expectations for technological evolution, innovation, and simplicity.
At ViewSonic®, we believe that our products have the potential to make a positive
impact in the world, and we are confident that the ViewSonic® product you have
chosen will serve you well.
Once again, thank you for choosing ViewSonic®!

3
Safety Precautions
Please read the following Safety Precauons before you start using the device.
• Keep this user guide in a safe place for later reference.
• Read all warnings and follow all instructions.
• Allow at least 4" (10 cm) clearance around the device to ensure proper
ventilation.
• Place the device in a well-ventilated area. Do not place anything on the device
that prevents heat dissipation.
• Do not use the device near water. To reduce the risk of fire or electric shock, do
not expose the device to moisture.
• Avoid exposing the device to direct sunlight or other sources of sustained heat.
• Do not install near any heat sources such as radiators, heat registers, stoves, or
other devices (including amplifiers) that may increase the temperature of the
device to dangerous levels.
• Use a soft, dry cloth to clean the external housing. Please see the "Maintenance"
section for more information.
• Oil may collect on the screen if you touch it. Please see the "Maintenance"
section for more information.
• Do not touch the screen surface with sharp or hard objects, as it may cause
damage to the screen. Only use the supplied pen, or fingers for models that
support touch input.
• When moving the device, be careful not to drop or bump the device on
anything.
• Do not place the device on an uneven or unstable surface. The device may fall
over resulting in an injury or a malfunction.
• Do not place any heavy objects on the device or connection cables.
• If smoke, an abnormal noise, or a strange odor is present, immediately turn the
device off and call your dealer or ViewSonic®. It is dangerous to continue using
the device.
• When connecting to a power outlet, DO NOT remove the grounding prong.
Please ensure grounding prongs are NEVER REMOVED.
• Protect the power cord from being treaded upon or pinched,
particularly at the plug, and at the point where it emerges from
the equipment. Ensure that the power outlet is located near the
equipment so that it is easily accessible.
• Only use attachments/accessories specified by the manufacturer.
• Disconnect the device if it is not going to be used for a long period of time.

4
Contents
Safety Precautions....................................................... 3
Introduction ................................................................ 6
Package Contents ...................................................................................................6
Product Overview...................................................................................................7
Making Connections.................................................... 8
Installing Drivers and Software...............................................................................8
DisplayLink Driver.................................................................................................... 8
Pen Display Driver ................................................................................................... 9
Connecting the Pen Display..................................................................................10
Using the Display....................................................... 11
Using the Pen Tether............................................................................................11
Using the Touch Function (PD1013T only) ...........................................................12
Adjustable Stand Legs...........................................................................................13
Changing to Portrait Orientation........................................................................... 14
Setting the Display Area .......................................................................................15
Pen Input Area Mapping.......................................................................................16
Appendix................................................................... 18
Specifications........................................................................................................18
Display................................................................................................................... 18
Pen ........................................................................................................................ 18
Product Dimensions .............................................................................................19
Troubleshooting ...................................................................................................20
Pen ........................................................................................................................ 20
Maintenance.........................................................................................................21
General Precautions.............................................................................................. 21
Cleaning the Screen............................................................................................... 21
Cleaning the Case.................................................................................................. 21
Replacing a Pen Nib..............................................................................................22

5
Regulatory and Service Information .......................... 23
Compliance Information.......................................................................................23
FCC Compliance Statement................................................................................... 23
Industry Canada Statement................................................................................... 23
CE Conformity for European Countries ................................................................. 23
Declaration of RoHS2 Compliance......................................................................... 24
Indian Restriction of Hazardous Substances ......................................................... 25
Product Disposal at End of Product Life................................................................ 25
Copyright Information ..........................................................................................26
Customer Service .................................................................................................. 27
Limited Warranty .................................................................................................. 28
Mexico Limited Warranty...................................................................................... 31

6
Introduction
Package Contents
Pen Display
USB 2.0, 2 in 1
Y-cable (Micro USB
to Type A x 2)
Pen Replacement Pen
nib x 3
Pen tether Nib removal tool Screwdriver AC/DC Power
Adapter 5V/2A
Download Driver / Télécharger le pilote / Descargar controlador / 椃↓䣉ⷍ᳉巇
http://www.viewsonicglobal.com/public/products_download/software/pendisplay/DRIVER_DISPLAY_LINK.zip
PD1013
Pen Display
Quick Start Guide
Guide de démarrage rapide
Guía rápida de inicio
⺩廝‣搾ㄉ⁈

2
3
ViewSonicPen Display Website: https://www.viewsonic.com/viewsign/products
Customerservice contact information: USA- [email protected] / China- [email protected] / Global- [email protected]
Choose direction / Choisissez le sens / Elija la dirección / ㏷婈倱㙴僅䨄ⵥ㑷⋏
InstallDisplayLink and PenDisplayDriver
InstallerDisplayLink et PenDisplayDriver
InstalarDisplayLink y PenDisplayDriver
⭰壄'LVSOD\/LQN3HQ'LVSOD\樬⊼䧲⻶
ViewSonicMicro USB 2 in 1
CâbleMicro USB 2 en 1 ViewSonic
CableViewSonic Micro-USB 2 en 1
9LHZVRQLF0LFUR86%⏯󰶈䷁
PowerAdapter
Adaptateursecteur
Adaptadorde alimentación
曢㹷ᾂㆰ♏
Quick Start Guide
NOTE: The contents included in your package may vary depending on your


7
Product Overview
1
1
2
3
4
5
6
7
7
10
7
8
8
8
9
9
9
1
1
2
3
4
5
6
7
7
10
7
8
8
8
9
9
9
1. Micro USB Port 2. Pen Tether
Anchor Point
3. Pen Holder 4.
Points
5. Display Screen/
Touch Screen¹
6. Security Lock
Slot
7. Adjustable
Stand Leg
8. Pen 9. Pen Holder

Point
10.
Leg
Touch screen only available on PD1013T.

8
Making Connecons
Installing Drivers and Soware
System Requirements:

PC I/O: USB 2.0/above



DisplayLink Driver

NOTE: DisplayLink Driver can be installed through Windows Update.

99
Pen Display Driver

pen.
1. 
2. 
NOTE: 


1010
Connecng the Pen Display
1. 
Main USB A
Connector
Secondary USB A
Connector
Top Boom
2. Plug the Micro USB end of the USB cable into the Micro USB Port on the device.
Main USB A
Connector
Secondary USB A
Connector
3. Connect the Main USB A cable to the computer. The Secondary USB A cable can
be connected to a fully powered USB port on the computer, or to an AC outlet
using the supplied power adapter.
Main USB A
Connector
Secondary USB A
Connector
NOTE: 

please connect the secondary USB A cable (shown in red) to the power
adapter and plug the adapter into an AC outlet to ensure that there is
enough power for the pen display.
