Viking VGRT480-6G User manual

R E L E A S E D 0 5 / 1 4 / 0 8
© 2 0 0 7 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
All models include
•Exclusive VariSimm r™ s tting for all
burn rs
• R movabl porc lain burn r bowls
• Drip tray with roll r b aring glid s and
two-quart drip pan
6G model includes
•Six 15,000 BTU stainl ss st l burn rs
with porc lain/cast iron caps and
automatic ignition/r -ignition
• 12”W. th rmostatically controll d st l
griddl /simm r plat
6Q model includes
• Six 15,000 BTU stainl ss st l burn rs
with porc lain/cast iron caps and
automatic ignition/r -ignition
• 12”W. grill with flavor g n rator plat s
and automatic ignition/r -ignition
4G model includes
• Four 15,000 BTU stainl ss st l burn rs
with porc lain/cast iron caps and
automatic ignition/r -ignition
• 24”W. th rmostatically controll d st l
griddl /simm r plat (s parat
burn rs/controls for l ft and right sid s)
VGRT4 0-6G*
4 ”W. Six-Burner/
Griddle Rangetop
• Brass Trim Option (BR)—nam plat ,
drip tray pull, knob b z ls and grat
support sid trim. Brass compon nts
hav a durabl prot ctiv coating for
maint nanc -fr normal us
o Units hav black porc lain grat s,
black porc lain burn r caps, black
porc lain grat support/burn r bowls
and whit knobs.
• Whit (WH)
o Whit finish s hav whit nam l
control pan ls, black porc lain
grat s, black porc lain burn r caps,
whit porc lain grat support/burn r
bowls and whit knobs.
• All finish s hav stainl ss st l drip tray
pull, and landing l dg .
FINISH DETAILS FOR ALL MODELS
• Stainl ss St l (SS), Black (BK), Whit
(WH), M tallic Silv r (MS), Graphit
Gray (GG), Ston Gray (SG), Taup (TP),
Biscuit (BT), Cotton Whit (CW), Oyst r
Gray (OG), Gold n Mist (GM),
L monad (LE), Sag (SA), Mint Jul p
(MJ), S a Glass (SE), Irid sc nt Blu (IB),
Viking Blu (VB), Pumpkin (PM), Racing
R d (RR), Appl R d (AR), Burgundy
(BU), Plum (PL), Chocolat (CH), and
Cobalt Blu (CB).
o Finish d signat s color of nam l
control pan l.
VGRT4 0-6Q*
4 ”W. Six-Burner/
Grill Rangetop
VGRT4 0-4G*
4 ”W. Four-Burner/
Double Griddle Rangetop
Standard Features & Accessories
Model Options
COOKING
Pro essional Built-In Gas 48”W.
Open Burner Rangetop
*Shown throughout with 6”H. backguard. See Installation Notes & Accessories for details.
ORDERING INSTRUCTIONS
First sp cify mod l numb r, and th n color cod (VGRT480-6GSS). If ord ring optional brass trim, sp cify cod at nd (VGRT480-6GSSBR).
If ord ring optional LP conv rsion, sp cify cod at nd ( VGRT480-6G SSBRLP).

COOKING
Pro essional Built-In Gas 48”W.
Open Burner Rangetop
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 0 5 / 1 4 / 0 8
© 2 0 0 7 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
All models include
•Exclusive VariSimm r™ s tting for all
burn rs
• R movabl porc lain burn r bowls
• Drip tray with roll r b aring glid s and
two-quart drip pan
4GQ model includes
•Four 15,000 BTU stainl ss st l burn rs
with porc lain/cast iron caps and
automatic ignition/r -ignition
• 12”W. th rmostatically controll d st l
griddl /simm r plat
• 12”W. grill with flavor g n rator plat s
and automatic ignition/r -ignition
4K model includes
• Four 15,000 BTU stainl ss st l burn rs
with porc lain/cast iron caps and
automatic ignition/r -ignition
• On 27,000 BTU porc lain/cast iron
burn r with automatic ignition/
r -ignition
• 20”W. st l wok top—standard
• Two-pi c porc lain/cast iron grat
• Exclusiv —ag ncy-c rtifi d c nt r triv t
allows us of larg stock pots
VGRT4 0-4GQ*
4 ”W. Four-Burner/
Griddle/Grill Rangetop
• Brass Trim Option (BR)—nam plat ,
drip tray pull, knob b z ls and grat
support sid trim. Brass compon nts
hav a durabl prot ctiv coating for
maint nanc -fr normal us
o Units hav black porc lain grat s,
black porc lain burn r caps, black
porc lain grat support/burn r bowls
and whit knobs.
• Whit (WH)
o Whit finish s hav whit nam l
control pan ls, black porc lain
grat s, black porc lain burn r caps,
whit porc lain grat support/burn r
bowls and whit knobs.
• All finish s hav stainl ss st l drip tray
pull, and landing l dg .
FINISH DETAILS FOR ALL MODELS
• Stainl ss St l (SS), Black (BK), Whit
(WH), M tallic Silv r (MS), Graphit
Gray (GG), Ston Gray (SG), Taup (TP),
Biscuit (BT), Cotton Whit (CW), Oyst r
Gray (OG), Gold n Mist (GM),
L monad (LE), Sag (SA), Mint Jul p
(MJ), S a Glass (SE), Irid sc nt Blu (IB),
Viking Blu (VB), Pumpkin (PM), Racing
R d (RR), Appl R d (AR), Burgundy
(BU), Plum (PL), Chocolat (CH), and
Cobalt Blu (CB).
o Finish d signat s color of nam l
control pan l.
VGRT4 0-4K*
4 ”W. Four-Burner/
Wok Burner Rangetop
Standard Features & Accessories
Model Options
*Shown throughout with 6”H. backguard. See Installation Notes & Accessories for details.
ORDERING INSTRUCTIONS
First sp cify mod l numb r, and th n color cod (VGRT480-4GQSS). If ord ring optional brass trim, sp cify cod at nd (VGRT480-4GQSSBR).
If ord ring optional LP conv rsion, sp cify cod at nd ( VGRT480-4G SSBRLP).

R E L E A S E D 0 5 / 1 4 / 0 8
© 2 0 0 7 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
VGRT4 0-6G
4 ”W. Six-Burner/
Griddle Rangetop
VGRT4 0-6Q
4 ”W. Six-Burner/
Grill Rangetop
VGRT4 0-4G
4 ”W. Four-Burner/
Double Griddle
Rangetop
VGRT4 0-4GQ
4 ”W. Four-Burner/
Griddle/Grill
Rangetop
VGRT4 0-4K
4 ”W. Four-Burner/
Wok Burner
Rangetop
COOKING
Pro essional Built-In Gas 48”W.
Open Burner Rangetop
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1

Please see
Installation Notes &
Accessories
for important
installation
information,
including backguard
high-shelf and
island trim.
47-7/8”
(121.6cm)
24”
(61cm)
25-3/4”
(65.4cm)
27-3/4”
(70.5cm)
9-1/4”
(23.5cm)
13-7/8”
(35.2cm)
(tocookingsurface)
All models
Overall width 47-7/8” (121.6 cm)
Overall height (from bottom)
To coo ing surface 9-1/4” (23.5 cm)
To top of island trim 8-7/8” (22.5 cm)
To top of 6” bac guard 13-7/8” (35.2 cm)
To top of 10” bac guard 17-7/8” (45.4 cm)
To top of high shelf 31-3/8” (79.7 cm)
Overall depth (from rear)
To end of side panel 24” (61.0 cm)
To end of control panel 25-3/4” (65.4 cm)
To end of nobs 27-3/4” (70.5 cm)
Star-K Kosher
Certification for
use on the Jewish
Sabbath or Jewish
holidays
Dimensions & Speci ications
PRODUCT DIMENSIONS
ALL MODELS

PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 0 5 / 1 4 / 0 8
© 2 0 0 7 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
COOKING
Pro essional Built-In Gas 48”W.
Open Burner Rangetop
18”min.
(45.7cm)
6”min.
(15.2cm)
36”
(91.4 cm)
13”max.
(33.0cm)
7-1/2”
(19.1 cm)
36”*
(91.4 cm)min.
48”
(121.9 cm)
Minimum clearances from adjacent
combustible construction
• Cooking surfac and b low, i. ., 36”
(91.4 cm) and b low
o Sid s—0”
o R ar
•0” with backguard or high-sh lf
•0” with island trim and non-
combustibl r ar wall
•6” (15.2 cm) with island trim and
combustibl r ar wall.
o Top grat support—36” (91.4 cm)
Important: Th top grat support
must b 3/8” (0.95 cm) abov th
adjac nt bas cabin t count rtop.
• Abov cooking surfac , i. ., abov 36”
(91.4 cm)
o Sid s—6” (15.2 cm)
o Within 6” (15.2 cm) sid cl aranc ,
wall cabin ts no d p r than 13”
(33.0 cm) must b minimum 18”
(45.7 cm) abov cooking surfac .
• Wall cabin ts dir ctly abov product
must b minimum 36” (91.4 cm) for
op n top burn rs abov cooking
surfac
* This minimum h ight r quir m nt do s
not apply if a rang hood is install d
ov r th cooking surfac .
Do not install two or more units
side-by-side.
Dimensions & Speci ications
CLEARANCE DIMENSIONS

VGRT4 0-6G
4 ”W. Six-Burner/
Griddle Rangetop
VGRT4 0-6Q
4 ”W. Six-Burner/
Grill Rangetop
VGRT4 0-4G
4 ”W. Four-Burner/
Double Griddle
Rangetop
VGRT4 0-4GQ
4 ”W. Four-Burner/
Griddle/Grill
Rangetop
VGRT4 0-4K
4 ”W. Four-Burner/
Wok Burner
Rangetop
R E L E A S E D 0 5 / 1 4 / 0 8
© 2 0 0 7 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
24”
(60.9 cm) min.
25-3/4”
(65.4 cm) max.
3/4”
(1.9cm)min.
2-1/4”
(5.7cm)
3”
(7.6 cm)
COOKING
Pro essional Built-In Gas 48”W.
Open Burner Rangetop
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
UTILITY
REQUIREMENTS
GAS
o Shipp d natural
gas standard;
conv rt to
LP/propan with
standard
conv rtibl
r gulator
o Acc pts standard
r sid ntial 1/2”
(1.3 cm) ID gas
s rvic lin
o Gas manifold
pr ssur
o Natural gas 5.0”
W.C.P.
o LP/Propan
10.0" W.C.P.
ELECTRICAL
• Four-foot (121.9
cm) cord includ d
with rang top
• Thr -wir with
ground/thr -
prong plug
• 120 V/60 Hz
• Maximum amp
usag —
o 6G—4.2
o 6Q—0.6
o 4G—7.2
o 4GQ—4.2
o 4K—0.6
PLUMBING
Not applicabl
Installation Requirements
ACCESS REQUIREMENTS
VGRT4 0-6G VGRT4 0-6Q VGRT4 0-4G VGRT4 0-4GQ VGRT4 0-4K
Cutout width 48” (121.9 cm)
Cutout height 7-1/2” (19.1 cm)**
Cutout depth 24” (61.0 cm) min. to 25-3/4” (65.4 cm) max.
Surface burner rating
Four grated burners 15,000 BTU Nat. (4.4 W)/ 15,000 BTU Nat. (4.4 W)/ 15,000 BTU Nat. (4.4 W)/
13,500 BTU LP (4.0 W) 13,500 BTU LP (4.0 W) 13,500 BTU LP (4.0 W)
Six grated burners 15,000 BTU Nat. (4.4 W)/ 15,000 BTU Nat. (4.4 W)/
13,500 BTU LP (4.0 W) 13,500 BTU LP (4.0 W)
One griddle 1 5,000 BTU Nat. (4.4 W)/ 1 5,000 BTU Nat. (4.4 W)/
13,500 BTU LP (4.0 W) 13,500 BTU LP (4.0 W)
One grill 18,000 BTU Nat. (5.3 W)/ 18,000 BTU Nat. (5.3 W)/
16,000 BTU LP (4.7 W) 16,000 BTU LP (4.7 W)
Two griddles (each) 15,000 BTU Nat. (4.4 W)/
13,500 BTU LP (4.0 W)
One wo burner 27,000 BTU Nat./LP (8.2 W)
**Top of grate support should be 3/8” (1.0 cm) above countertop.
*120 VAC/60 Hz within 48” (121.9 cm) of right r ar of rang top
*

R E L E A S E D 0 5 / 1 4 / 0 8
© 2 0 0 7 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
6”H. Backguard
• Stainl ss St l (SS)
•Coordinat s with all finish s
10”H. Backguard
• Stainl ss St l (SS)
• Coordinat s with all finish s
High-shel
• Stainl ss St l (SS)
• Coordinat s with all finish s
• Sh lf com s attach d to a 24”H. backguard
Island Trim
• Stainl ss St l (SS)
• Coordinat s with all finish s
• For island/p ninsula installation
• Can r plac backguard if wall is non-combustibl
Countertop Side Trim
• Stainl ss St l (SS)
• Coordinat s with all finish s
• Installs on sid of unit; ov rlaps count rtop
• On pair of trim
LP/Propane Conversion Kit
• Allows for fi ld conv rsion of rang from natural gas to LP
Compliance In ormation
WARRANTY INFORMATION*
• On -y ar full warranty—compl t product
• T n-y ar limit d warranty—surfac burn rs, griddl burn rs, and grill burn rs
• Nin ty-day limit d warranty—cosm tic parts such as glass, paint d, and d corativ it ms
* For compl t warranty s Use & Care Guide. Warranty valid on Viking products shipp d within th Unit d Stat s and Canada.
COOKING
Pro essional Built-In Gas 48”W.
Open Burner Rangetop
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
Installation Notes & Accessories
A backguard, high-sh lf, or island trim must b us d for all installations.
Model Description Approx. ship wt. lbs. (kg)
T48BG6 48”W. bac guard 24 (10.8)
Model Description Approx. ship wt. lbs. (kg)
T48HS24 48”W. high-shelf 60 (27.0)
Model Description Approx. ship wt. lbs. (kg)
T48BG10 48”W. bac guard 27 (12.2)
Model Description Approx. ship wt. lbs. (kg)
T48TII 48”W. island trim 15 (6.8)
Model Description Approx. ship wt. lbs. (kg)
T24CST Side trim 2 (0.9)
Model Description Approx. ship wt. lbs. (kg)
LPKRR Natural to LP/propane conversion it 2 (0.9)
