All models include
•Exclusive VariSimm r™ s tting for all
burn rs
• R movabl porc lain burn r bowls
• Drip tray with roll r b aring glid s and
two-quart drip pan
6G model includes
•Six 15,000 BTU stainl ss st l burn rs
with porc lain/cast iron caps and
automatic ignition/r -ignition
• 24”W. th rmostatically controll d st l
griddl /simm r plat (s parat
burn rs/controls for l ft and right sid s)
6GQ model includes
• Six 15,000 BTU stainl ss st l burn rs
with porc lain/cast iron caps and
automatic ignition/r -ignition
• 12”W. th rmostatically controll d st l
griddl /simm r plat
• 12”W. grill with flavor g n rator plat s
and automatic ignition/r -ignition
VGRT600-6G*
60”W. Six-Burner/
Griddle Ran etop
• Whit (WH)
o Whit finish s hav whit nam l
control pan ls, black porc lain
grat s, black porc lain burn r caps,
whit porc lain grat support/burn r
bowls and whit knobs.
• All finish s hav stainl ss st l drip tray
pull, and landing l dg .
• Brass Trim Option (BR)—nam plat ,
drip tray pull, knob b z ls and grat
support sid trim. Brass compon nts
hav a durabl prot ctiv coating for
maint nanc -fr normal us
FINISH DETAILS FOR ALL MODELS
• Stainl ss St l (SS), Black (BK), Whit
(WH), M tallic Silv r (MS), Graphit
Gray (GG), Ston Gray (SG), Taup (TP),
Biscuit (BT), Cotton Whit (CW), Oyst r
Gray (OG), Gold n Mist (GM),
L monad (LE), Sag (SA), Mint Jul p
(MJ), S a Glass (SE), Irid sc nt Blu (IB),
Viking Blu (VB), Pumpkin (PM), Racing
R d (RR), Appl R d (AR), Burgundy
(BU), Plum (PL), Chocolat (CH), and
Cobalt Blu (CB).
o Finish d signat s color of nam l
control pan l.
o Units hav black porc lain grat s,
black porc lain burn r caps, black
porc lain grat support/burn r bowls
and whit knobs.
VGRT600-6GQ*
60”W. Six-Burner/
Griddle/Grill Ran etop
Standard Features & Accessories
Model Options
COOKING
Pro essional Built-In Gas 60”W.
Open Burner Rangetop
*Shown throu hout with 6”H. back uard. See Installation Notes & Accessories for details.
ORDERING INSTRUCTIONS
First sp cify mod l numb r, and th n color cod (VGRT600-6GSS). If ord ring optional brass trim, sp cify cod at nd (VGRT600-6GSSBR).
If ord ring optional LP conv rsion, sp cify cod at nd ( VGRT600-6G SSBRLP).

VGRT600-6G
60”W. Six-Burner/
Griddle Ran etop
VGRT600-6GQ
60”W. Six-Burner/
Griddle/Grill Ran etop
R E L E A S E D 0 5 / 1 4 / 0 8
© 2 0 0 7 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
COOKING
Pro essional Built-In Gas 60”W.
Open Burner Rangetop
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1

Please see
Installation Notes &
Accessories
for important
installation
information,
including
backguard, high-
shelf, and island
trim.
24”
(61cm)
25-3/4”
(65.4cm)
27-3/4”
(70.5cm)
59-1/2”
(151.1 cm)
9-1/4”
(23.5cm)
13-7/8”
(35.2cm)
(tocookingsurface)
All models
Overa width 59-1/2” (151.1cm)
Overa height (from bottom)
To cooking surface 9-1/4” (23.5 cm)
To top of is and trim 8-7/8” (22.5 cm)
To top of 6” backguard 13-7/8” (35.2 cm)
To top of 10” backguard 17-7/8” (45.4 cm)
To top of high she f 31-3/8” (79.7 cm)
Overa depth (from rear)
To end of side pane 24” (61.0 cm)
To end of contro pane 25-3/4” (65.4 cm)
To end of knobs 27-3/4” (70.5 cm)
Star-K Kosher
Certification for
use on the Jewish
Sabbath or Jewish
holidays
Dimensions & Speci ications
PRODUCT DIMENSIONS
ALL MODELS

PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 0 5 / 1 4 / 0 8
© 2 0 0 7 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
COOKING
Pro essional Built-In Gas 60”W.
Open Burner Rangetop
18”min.
(45.7cm)
6”min.
(15.2 cm)
36”
(91.4 cm)
13”max.
(33.0cm)
36”*
(91.4 cm)min.
7-1/2”
(19.1 cm)
59-5/8”
(151.4 cm)min.
Minimum clearances from adjacent
combustible construction
• Cooking surfac and b low, i. ., 36”
(91.4 cm) and b low
o Sid s—0”
o R ar
•0” with backguard or high-sh lf
•0” with island trim and non-
combustibl r ar wall
•6” (15.2 cm) with island trim and
combustibl r ar wall.
o Top grat support—36” (91.4 cm)
Important: Th top grat support
must b 3/8” (0.95 cm) abov th
adjac nt bas cabin t count rtop.
• Abov cooking surfac , i. ., abov
36” (91.4 cm)
o Sid s—6” (15.2 cm)
o Within 6” (15.2 cm) sid cl aranc ,
wall cabin ts no d p r than
13” (33.0 cm) must b minimum
18” (45.7 cm) abov cooking surfac .
• Wall cabin ts dir ctly abov product
must b minimum 36” (91.4 cm) for
op n top burn rs abov cooking
surfac .
* This minimum h ight r quir m nt do s
not apply if a rang hood is install d
ov r th cooking surfac .
Do not install two or more units
side-by-side.
Dimensions & Speci ications
CLEARANCE DIMENSIONS

VGRT600-6G
60”W. Six-Burner/
Griddle Ran etop
VGRT600-6GQ
60”W. Six-Burner/
Griddle/Grill Ran etop
R E L E A S E D 0 5 / 1 4 / 0 8
© 2 0 0 7 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
24”
(60.9cm)min.
25-3/4”
(65.4cm) max.
3/4”
(1.9cm) min.
9/16”
(1.8cm)
14-3/8”
(36.5cm)
COOKING
Pro essional Built-In Gas 60”W.
Open Burner Rangetop
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
UTILITY
REQUIREMENTS
GAS
o Shipp d natural
gas standard;
conv rt to
LP/propan with
standard
conv rtibl
r gulator
o Acc pts standard
r sid ntial 1/2”
(1.3 cm) ID gas
s rvic lin
o Gas manifold
pr ssur
o Natural gas 5.0”
W.C.P.
o LP/Propan
10.0" W.C.P.
ELECTRICAL
• Four-foot
(121.9 cm) cord
includ d with
rang top
• Thr -wir with
ground/thr -
prong plug
• 120 V/60 Hz
• Max. amp usag —
o 6G—7.8
o 6GQ—4.2
PLUMBING
Not applicabl
Installation Requirements
ACCESS REQUIREMENTS
VGRT600-6G VGRT600-6GQ
Cutout width 59-5/8” (151.4 cm)
Cutout height 7-1/2” (19.1 cm)**
Cutout depth 24” (61.0 cm) min. to 25-3/4” (65.4 cm) max.
Surface burner rating
Six grated burners, 15,000 BTU Nat. (4.4 kW)/ 15,000 BTU Nat. (4.4 kW)/
13,500 BTU LP (4.0 kW) 13,500 BTU LP (4.0 kW)
One gridd e 15,000 BTU Nat. (4.4 kW)/
13,500 BTU LP (4.0 kW)
One gri 18,000 BTU Nat. (5.3 kW)
16,000 BTU LP (4.7 kW)
Two gridd es (each) 15,000 BTU Nat. (4.4 kW)/
13,500 BTU LP (4.0 kW)
**Top of grate support shou d be 3/8" (1.0 cm) above countertop.
*120 VAC/50 Hz within 48” (121.9 cm) of right r ar of rang top.
*

6”H. Backguard
• Stainl ss St l (SS)
•Coordinat s with all finish s
10”H. Backguard
• Stainl ss St l (SS)
• Coordinat s with all finish s
High-shel
• Stainl ss St l (SS)
• Coordinat s with all finish s
• Sh lf com s attach d to a 24”H. backguard
Island Trim
• Stainl ss St l (SS)
• Coordinat s with all finish s
• For island/p ninsula installation
• Can r plac backguard if wall is non-combustibl
Countertop Side Trim
• Stainl ss St l (SS)
• Coordinat s with all finish s
• Installs on sid of unit; ov rlaps count rtop
• On pair of trim
LP/Propane Conversion Kit
• Allows for fi ld conv rsion of rang from natural gas to LP
Compliance In ormation
WARRANTY INFORMATION*
• On -y ar full warranty—compl t product
• T n-y ar limit d warranty—surfac burn rs, griddl burn rs and grill burn rs
• Nin ty-day limit d warranty—cosm tic parts such as glass, paint d, and d corativ it ms
* For compl t warranty s Use & Care Guide . Warranty valid on Viking products shipp d within th Unit d Stat s and Canada.
COOKING
Pro essional Built-In Gas 60”W.
Open Burner Rangetop
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 0 5 / 1 4 / 0 8
© 2 0 0 7 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
Installation Notes & Accessories
A backguard, high-sh lf, or island trim must b us d for all installations.
Model Description Approx. ship wt. lbs. (kg)
T60BG6 60”W. backguard 31 (14.0)
Model Description Approx. ship wt. lbs. (kg)
T60BG10 60”W. backguard 39 (17.6)
Model Description Approx. ship wt. lbs. (kg)
T60HS24 60”W. high-she f 70 (31.5)
Model Description Approx. ship wt. lbs. (kg)
T60TII 60”W. is and trim 19 (8.6)
Model Description Approx. ship wt. lbs. (kg)
T24CST Side trim 2 (0.9)
Model Description Approx. ship wt. lbs. (kg)
LPKRR Natura to LP/propane conversion kit 2 (0.9)
