Temperature Control
Each oven has a separate temperature
control dial and a separate oven
function selector. The controls can be
set at any temperature from 200°F
(93.3°C) to 550°F (2 7. °C). There are separate
settings for broiling and self-cleaning. ALWAYS be
sure the controls are in the OFF position when the
ovens are not in use.
Interior Oven Lig t Control
The upper and lower ovens have
interior oven lights that are controlled
by one switch on the control panel.
Push the switch to turn the interior
oven lights on and off.
Two-Element
Bake
Full power heat is
radiated from the bake
element in the bottom
of the oven cavity and
supplemental heat is
radiated from the broil
element. This function is recommended for single rack
baking. Many cookbooks contain recipes to be cooked
in the conventional manner. Conventional baking/
roasting is particularly suitable for dishes that require a
high temperature. Use this setting for baking, roasting,
and casseroles.
TruConvec™
The rear element only
operates at full power.
There is no direct heat
from the bottom or
top elements. The
motorized fan in the
rear of the oven
circulates air in the oven cavity for even heating.
Use this setting for foods that require gentle cooking
such as pastries, souffles, yeast breads, quick breads
and cakes. Breads, cookies, and other baked goods
come out evenly textured with golden crusts. No
special bakeware is required. Use this function for
single rack baking, multiple rack baking, roasting,
and preparation of complete meals. This setting is
also recommended when baking large quantities of
baked goods at one time.
Setting the Clock Oven Controls Oven Settings and Functions
OVEN FUNCTION
OFF
BAKE
UPPER OVEN
CLEAN OVEN CLEAN OVEN
OVEN
LIGHT
TRU
CONVEC
LOW
BROIL
CONV.
BAKE
SELF
CLEAN
MED
BROIL
HI
BROIL CONV.
BROIL
TEMPERATURE
OFF
400
CONV.
ROAST
200
300 500
BROIL
CLEAN
OVEN FUNCTION
OFF
BAKE
LOWER OVEN
TRU
CONVEC
LOW
BROIL
CONV.
BAKE
SELF
CLEAN
MED
BROIL
HI
BROIL CONV.
BROIL
TEMPERATURE
OFF
400
CONV.
ROAST
200
300 500
BROIL
CLEAN
Off/On
Indicator Light
Temperature Control
Each oven has a separate temperature
control dial. The controls can be set at
any temperature from 200˚F to 550˚F.
There are separate settings for broiling
and self-cleaning.
Interior
Oven Light
Switch
Oven Function Selector
Bake
Conventional, single rack baking (breads,
cakes, cookies, pastry, pies, entrees,
vegetables)
Convection Bake
Multi-rack baking for heavier or frozen
foods (e.g., 4 frozen pies, pizzas, entrees,
vegetables)
TruConvecTM
Multi-rack baking for breads, cakes,
cookies (up to 6 racks of cookies
at once)
High-Broil
Dark meats at 1” thickness or less where rare
or medium doneness is desired
Medium-Broil
White meats such as chicken or meats
greater than 1” thick that would be
over-browned in high broil
Low-Broil
Delicate broiling such as meringue
Convection Broil
Thicker meats, faster than regular broil &
with less smoke generation
Convection Roast
Whole turkeys, whole chickens, hams, etc.
Self-Clean
A pyrolytic self-cleaning cycle where the
oven reaches elevated
temperatures in order to burn
off soils and deposits
Self-Clean
Indicator Light
Electronic Timing Center
The Electronic Timing Center
is used to program and control
all timing functions.
IMPORTANT: The Time-of-day
must be set before any other
program can be used.
BAKE
TIME
MIN/SEC
TIMER
START
TIME
PROBE
TEMP
SET
MANUAL
UPPER
TIMED
LOWER
TIMED
Timed Bake
Knob
(Premier Models)
Digital Clock
(Select Models)
SET
off
bake
conv.
bake
tru.
convec.
med
broil
low
broil
high
broil
conv.
broil
self-
clean
conv.
roast
OFF
400
200
300 500
BROIL
CLEAN
OVEN
LIGHT
two-element bake
OFF
BAKE
TRU
CONVEC
LOW
BROIL
CONV.
BAKE
SELF
CLEAN
MED
BROIL
HI
BROIL CONV.
BROIL
CONV.
ROAST
TruConvecTM
OFF BAKE
TRU
CONVEC
LOW
BROIL
CONV.
BAKE
SELF
CLEAN
MED
BROIL
HI
BROIL CONV.
BROIL
CONV.
ROAST
