Viking Installation Guide
Combi Steam/Convect™Oven and Built-In Trim Kit
111 Front Street
Greenwood, Mississippi 38930 USA
IMPORTANT–Please Read and Follow!
• Before beginning, please read these instructions completely and carefully.
• Be sure to DISCONNECT THE PLUG of the microwave oven from the electrical outlet before installing the built-in trim kit.
Remove the turntable from the oven cavity.
• Because the kit includes metal parts, caution should be used in handling and installation to avoid the possibility of injury.
• Do not remove permanently affixed labels, warnings, or plates from the product. This may void the warranty.
• Please observe all local and national codes and ordinances.
• Theinstallershouldleavetheseinstructionswiththeconsumerwhoshouldretainforlocalinspector’suseandfor
futurereference.
• This built-in trim kit is designed for use ONLY WITH VIKING COMBI STEAM/CONVECT™ OVEN.
• Your oven can be built into a cabinet or wall or above any electric wall oven, gas wall oven or warming drawer.
• NOTE: The bottom of the cut-out opening for built-in use must be 36 inches (915 mm) or higher from the floor.
• The electrical requirements for this oven are 120 volts, 15 amps. The oven has a 5-15 plug and requires a 5-15 receptacle.
• PLEASE READ THESE INSTRUCTIONS THOROUGHLY BEFORE BEGINNING INSTALLATION!
HEIGHT WIDTH DEPTH
Cabinet or wall opening 19" - 19 1/8"
(482 mm - 486 mm)
28"
(712 mm)
23 1/4" minimum
(509.5 mm minimum)
Built-in kit frame assembly 22 1/8"
(562.1 mm)
29 1/2"
(749.3 mm)
Combi Steam/Convect™ Oven 17 1/4"
(438 mm)
21 3/4"
(553 mm)
18 3/8"
(468 mm)

E2
Provided Parts
PartName Qty
Exhaust Duct Back
PDUC-B107WRWZ 1
Exhaust Duct Upper
PDUC-B105WRWZ 1
Divide Plate L
PSKR-A486WRWZ 1
Divide Plate R
PSKR-A487WRWZ 1
Rectifier Plate L
PSKR-A484WRWZ 1
Exhaust Duct Left
PDUC-B108WRWZ 1
Exhaust Duct Right
PDUC-B117WRWZ 1
Exhaust Duct Bottom
PDUC-B106WRWZ 1
Frame Assembly
DDECAB012MRK0 1
Parts Included in VTKS300 kits
Exhaust Duct Back
QtY 1
DiviDE PlatE l
QtY 1 DiviDE PlatE R
QtY 1
REaR sPacER
QtY 1
Exhaust
Duct lEft
QtY 1
Exhaust Duct Bot tom
QtY 1 fRamE assEmBlY
QtY 1
scREw a - shoRt
QtY 23
scREw B - loNG
QtY 8
Exhaust
Duct RiGht
QtY 1
Exhaust Duct uPPER
QtY 1
REctifiER PlatE l
QtY 1
PartName Qty
Screw (A)
XHTS740P08000 23
Screw (B)
XMMS841P13000 8
Rear Spacer
PSPAFA003WRWZ 1
Cushion 15/8" x 16", 15 mm x 405 mm
PCUS-A245WRPZ 1
Cushion 21/4" x 24-3/8", 5 mm x 618 mm
PCUS-A247WRPZ 1
Cushion 31-1/8" x 27-1/8", 30 mm x 689 mm
PCUS-A249WRPZ 1
Cushion 41/4" x 12", 5 mm x 305 mm
PCUS-A251WRPZ 1
Cushion 51/4" x 15", 5 mm x 382 mm
PCUS-A253WRPZ 1

E3
Preparation
Follow the directions from 1 to 5 to attach cushions to some parts.
1CUSHIONS 1CUSHIONS 1
1. EXHAUST DUCT UPPER
Remove the backing paper from each CUSHION 1. Attach the
CUSHIONS 1to each side flange of the EXHAUST DUCT UPPER as
shown in the Figure 1.
2
CUSHIONS 2
2. EXHAUST DUCT BACK
Remove the backing paper from CUSHION 2. Attach the CUSHIONS
2at the lower flange of the EXHAUST DUCT BACK as shown in the
Figure 2.
3CUSHIONS 3
A
3. EXHAUST DUCT BOTTOM
Remove the backing paper from CUSHION 3. Attach the CUSHIONS
3to the EXHAUST DUCT BOTTOM as shown in the Figure 3.
* Start A to attach the CUSHION.
4CUSHIONS 4
4. DIVIDE PLATE L
Remove the backing paper from CUSHION 4. Attach the CUSHIONS
4to the DIVIDE PLATE L as shown in the Figure 4.
5CUSHIONS 5
5. DIVIDE PLATE R
Remove the backing paper from CUSHION 5. Attach the CUSHIONS
5to the DIVIDE PLATE R as shown in the Figure 5.

E4
Installation
19" - 19
1
/ 8 "
(482 mm - 486 mm)
23
1
/
4
(590.5 mm)
"
(712 mm)
28”
CL
7
7
/
8
"
(200 mm)
1
STEP 1: CABINET OR WALL OPENING
Provide an opening in the wall or cabinet shown in Figure 1.
The depth should be minimum 23 1/4" (590.5 mm). The floor of the
opening should be constructed of plywood strong enough to support
the weight of the oven (about 51 lbs.,23 kg) and should be level for
proper operation of the oven.
NOTE: While the proper functioning of the oven does not require
that the opening be enclosed (with sides, ceiling and rear partition),
this may be required by local code, and it is suggested that the local
code be checked for any such requirement.
ELECTRICAL SUPPLY
At the rear of the opening, provide a 3 pronged, polarized, electrical
outlet, 120 volt A.C., 15 amp. or larger.
This outlet should be located in the shaded area of Figure 1.
It is exceedingly important that the outlet be 120 volts and 15 amps.
for optimum oven performance.
STEP 2: INSTALLATION OF EXHAUST DUCT BOTTOM & DIVIDE
PL ATE L/R
It is recommended that a sheet of cardboard or other protective
material should be placed on the table or countertop to prevent
damage to the surface during assembly.
2.1 Place DIVIDE PLATE L/R over 2 catches on EXHAUST DUCT
BOTTOM.
2.2 Lock them into EXHAUST DUCT BOTTOM by sliding DIVIDE
PLATE L/R in the direction of the arrow as shown in Figure 2-A.
2.3 Tighten 4 SCREWS (A) from the bottom at the left and right sides
as shown in Figures 2 and 2-A.
2DIVIDE PLATE L
SCREW (A)
EXHAUST DUCT
BOTTOM
SCREW (A)
SCREW (A)
CATCHES
DIVIDE PLATE R
FIGURE 2-A

E5
STEP 3: EXHAUST DUCT BOTTOM INSTALLATION
Place the oven onto the EXHAUST DUCT BOTTOM, lowering the 4
feet of the oven onto the projections at the 4 corners of EXHAUST
DUCT BOTTOM as shown in Figure 3-A.
3
STEP 4: EXHAUST DUCT BACK INSTALLATION
4.1 Remove 2 screws (#1) from upper both sides of the oven as shown
in Figure 4-A to install the EXHAUST DUCT BACK. (Save 2 screws
to be used at step 4.2.)
4.2 Secure EXHAUST DUCT BACK to the oven with the screws (#1)
removed at step 4.1 and a SCREW (A) as shown in Figure 4-B.
4
#1
#1
FIGURE 4-A
FIGURE 4-B
SCREW (A)
EXHAUST DUCT BACK
EXHAUST DUCT
BOTTOM
Installation
FIGURE 3-A
SCREW (A)

E6
Installation
STEP 5: INSTALLATION OF REAR SPACER AND EXHAUST DUCT
UPPER
5.1 Attach RECTIFIER PLATE L to inside of EXHAUST DUCT UPPER
with 4 SCREWS (A) as shown in Figure 5-A.
5.2 Place EXHAUST DUCT UPPER over the oven and EXHAUST DUCT
BACK, and attach REAR SPACER with 2 SCREWS (A) in Figure
5-B.
5.3 Tighten together EXHAUST DUCT UPPER and EXHAUST DUCT
BACK at the left and right sides with 2 SCREWS (A) as shown in
Figure 5-B.
6
4 SCREWS (A)
EXHAUST DUCT UPPER
EXHAUST
DUCT LEFT
2 SCREWS (A)
DIVIDE PLATE L
STEP 6: INSTALLATION OF EXHAUST DUCT LEFT
6.1 Attach EXHAUST DUCT LEFT to the left wall of the oven.
6.2 Tighten with 6 screws (A) as shown in Figure 6.
7EXHAUST DUCT UPPER
EXHAUST
DUCT RIGHT
2 SCREWS (A)
2 SCREWS (A)
DIVIDE PLATE R
STEP 7: INSTALLATION OF EXHAUST DUCT RIGHT
7.1 Attach EXHAUST DUCT RIGHT to the right wall of the oven.
7.2 Tighten with 4 screws (A) as shown in Figure 7.
5
REAR SPACER
FIGURE 5-A
FIGURE 5-B
EXHAUST DUCT
UPPER
EXHAUST DUCT UPPER
EXHAUST DUCT BACK
4 SCREWS (A)
SCREW (A)
SCREW (A)
SCREW (A) SCREW (A)
RECTIFIER PLATE L

E7
Installation
CL
28" (712 mm)
8
FIGURE 8-A
FIGURE 8-B
FLANGE
STEP 8: OVEN INSTALLATION
MOUNTING TEMPLATE: Align the mounting template center line with
the center of the cutout and the floor line with the floor of the cutout.
Tape it into place. Predrill 4 holes marked "A" with a 1/16" drill bit.
Remove template from the cabinet.
CAUTION: Never hold the handle when moving the oven. Two persons
are required to install the oven.
8.1 Establish center line of opening and mark front edge.
8.2 Place the oven on a table or stand positioned in front of the
cabinet where the oven is to be installed. One person should
hold the oven while the other connects it to the electrical outlet.
8.3 Install the oven into the shelf with adjusting mark on EXHAUST
DUCT BOTTOM to the center line marked on front edge as
shown in Figures 8 and 8-A. Then push the oven until the flange
of EXHAUST DUCT BOTTOM touches the edge of the wall or
cabinet opening. Avoid pinching the cord between the oven and
any wall as shown in Figure 8.
9
SCREW (B)
SCREW (B)
SCREW (B)
SCREW (B)
STEP 9: FRAME INSTALLATION
Position the BACK FRAME to align with the predrilled holes that were
drilled with the mounting template. Check that it is level and then
secure with four SCREWS (B). See Figure 9.
!SNAP
ATTACHMENT
STEP 10: DECORATION INSTALLATION
Place the FRONT decoration onto the FRAME and align ball studs
and receivers. Secure the DECORATION to the FRAME by firmly
pushing the front frame onto the back frame engaging the four (4)
snap attachments. See Figure 10.
SCREW (B)
SCREW (B)

TINSLB030MRR0
