Viking VGIC245-4B Series User manual

PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 3 / 2 9 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
All mod ls includ
• Large convection oven
o Overall capacity—3.1 cu. ft.
(18”W. x 16-1/8”H. x 18-3/4”D.)
oAHAM* capacity—3.0 cu. ft.
(18”W. x 16-1/8”H. x 17-5/8”D.)
• Three heavy- uty racks/six rack
positions
• Drip tray with roller bearing gli es an
two-quart rip pan
•Exclusive combination of single bake
burners an infrare broil burner, all
with automatic ignition
• Six functions
oNatural airflow bake
oConvection bake
oInfrare broil
oConvection infrare broil
oConvection ehy rate
oConvection efrost
• 6”H. stainless steel backguar
• Stan ar kickspace height
4B mod l includ s
•Four 15,000 BTU stainless steel
burners with porcelain/cast iron caps
an automatic ignition/re-ignition
•Exclusive VariSimmer™ setting for all
burners
G mod l includ s
• 24”W. thermostatically controlle
steel gri le/simmer plate (separate
burner/control for left an right
si es)
Q mod l includ s
• 24”W. grill with flavor generator plates
an automatic ignition/re-ignition
K mod l includ s
• One 27,500 BTU porcelain/cast iron
burner with automatic ignition/re-ignition
• 20”W. steel wok/top
•Exclusive agency-certifie center
trivet allows use of large stock pots
*The Association of Home Appliance
Manufacturers (AHAM) stan ar for
measuring oven capacity subtracts
the oor plug an convection baffle
imension from the total oven
volume.
VGIC245-4B*
Four-Burner Range
• Stainless steel han le/chrome-plate
brackets an stainless steel rip tray
pull, control panel, an lan ing le ge.
• Brass Trim Option (BR)—nameplate,
win ow trim, han le, rip tray pull,
knob bezels, thermal-convection switch
bezel, an grate support si e trim.
Brass components have a urable
protective coating for maintenance-free
normal use.
o Black porcelain grates, black porcelain
burner caps, an black porcelain grate
supports/burner bowls, with black
knobs/switches.
• White (WH)
o Finish esignates oor front, lower
front panel, si e panels, porcelain
grate supports/burner bowls,
porcelain center worktop, an
knobs/switches.
o Black porcelain grates an black
porcelain burner caps.
FINISH DETAILS FOR ALL MODELS
• Stainless Steel (SS), Black (BK), White
(WH), Metallic Silver (MS), Graphite Gray
(GG), Stone Gray (SG), Taupe (TP), Biscuit
(BT), Cotton White (CW), Oyster Gray
(OG), Gol en Mist (GM), Lemona e (LE),
Sage (SA), Mint Julep (MJ), Sea Glass
(SE), Iri escent Blue (IB), Viking Blue (VB),
Pumpkin (PM), Racing Re (RR), Apple
Re (AR), Burgun y (BU), Plum (PL),
Chocolate (CH), an Cobalt Blue (CB).
o Finish esignates oor front, lower
front panel, an si e panels.
VGIC245-G*
Griddle Range
VGIC245-Q*
Grill Range
Standard F atur s & Acc ssori s
Mod l Options
COOKING
Prof ssional Fr standing Gas 24”W.
Op n Burn r Rang
VGIC245-K*
Wok/Cooker Range
*Shown throughout with 6”H. backguard. See Installation Not s & Acc ssori s or details.
ORDERING INSTRUCTIONS
First specify mo el number, an then color co e (VGIC245-4BSS). If or ering optional brass trim, specify co e at en (VGIC245-4BSSBR).
If or ering optional LP conversion, specify co e at en (VGIC245-4BSSBRLP).

24-5/16” (61.8 cm)
42-5/16” (107.5 cm)
18” (45.7 cm)
6” (15.2 cm)
26-3/16” (66.5 cm)
1-5/8” (4.1 cm)
6” (15.2 cm)
COOKING
Prof ssional Fr standing Gas 24”W.
Op n Burn r Rang
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 3 / 2 9 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E

Please see
Installation Notes &
Accessories
for important
information,
including
backguard, high-
shelf, island trim,
and curb base front.
23-7/8”
(60.6cm)
35-7/8”
(91.1cm)min.
to
37-5/8”
(95.6cm) max.
6”
(15.2cm)
27-3/4”
(70.5 cm)
26-1/4”
(66.7 cm)
24-5/16”
(61.8 cm)
All mod ls
Overall w dth 23-7/8” (60.6 cm)
Overall he ght
Base he ght
To top of grate support 35-7/8” (91.1 cm) min. to 37-5/8” (95.6 cm) max.
Legs adjust 1-3/4” (4.5 cm)
Add t ons to base he ght
To top of grate Add 1-1/8” (2.9 cm)
To top of sland tr m Add 1-1/4” (3.2 cm)
To top of 6” backguard Add 6” (15.2 cm)
To top of h gh shelf Add 23-1/2” (59.7 cm)
Overall depth (from rear)
To end of s de panel 24-5/16” (61.8 cm)
To end of control panels 26-1/4” (66.7 cm)
To end of knobs 27-3/4” (70.5 cm)
Oven
Inter or w dth 18” (45.7 cm)
Inter or he ght 16-1/8” (41.0 cm)
Inter or depth 17-5/8” (44.8 cm)
Overall nter or s ze 3.0 cu. ft.
Star-K Kosher
Certi ication or
use on the Jewish
Sabbath or Jewish
holidays
VGIC245-4B
Four-Burner Range
VGIC245-G
Griddle Range
VGIC245-Q
Grill Range
VGIC245-K
Wok/Cooker Range
Dim nsions & Sp cifications
PRODUCT DIMENSIONS & DOOR SWING
ALL MODELS

PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 3 / 2 9 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
COOKING
Prof ssional Fr standing Gas 24”W.
Op n Burn r Rang
42” min.
(106.7cm)
13”max.
(33.0cm)
23-7/8”
(60.6cm)
A
18” min.
(45.7cm)
3/8”
(0.95cm)
36”
(91.4cm)
A
4B Model 6” (15.2 cm)
G Model 6”(15.2 cm)
K Model 6” (15.2 cm)
Q Model 9”(22.9cm)
Minimum clearances rom adjacent
combustible construction
• Cooking surface an below, i.e., 36”
(91.4 cm) an below
o Si es—0”
o Rear—0” with backguar or high
shelf; 0” with islan trim an non-
combustible rear wall; 6” (15.2 cm)
with islan trim an combustible rear
wall
o Top grate support—36” (91.4 cm)
• Above cooking surface, i.e., above 42”
(91.4 cm)
o Si es: 4B/G/K—6” (15.2 cm); Q—9”
(22.9 cm)
o Within 6” (15.2 cm) si e clearance,
wall cabinets no eeper than 13”
(33.0 cm) must be minimum 18”
(45.7 cm) above cooking surface
o Wall cabinets irectly above pro uct
must be minimum 42” (106.7 cm)
above cooking surface
• Use range only with factory supplie legs
1. This range may be installe irectly
a jacent to existing 36” (91.4 cm) high
base cabinets. Important: The top
grate support must be 3/8” (0.95 cm)
above the a jacent base cabinet
countertop. This may be accomplishe
by raising the unit using the
a justment spin les on the legs.
2. The range cannot be installe irectly
a jacent to si ewalls, tall cabinets, tall
appliances, or other si e vertical
surfaces above the 36” (91.4 cm)
counter height. There must be a
minimum of 6” (15.2 cm) si e
clearance for the Four-Burner an
Gri le mo el ranges an a minimum
of 9” (22.9 cm) si e clearance for
the Char-Grill mo el to such
combustible surfaces above the 36”
(91.4 cm) counter height.
3. Within the si e clearance to
combustible vertical surfaces above
36” (91.4 cm), the maximum wall
cabinet epth must be 13” (33.0 cm)
an wall cabinets within this si e
clearance must be 18” (45.7 cm)
above the 36” (91.4 cm) high
countertop.
4. Wall cabinets above the range must
be a minimum of 42” (106.7 cm)
above the range cooking surface for
the full wi th of the range. This
minimum requirement oes not apply
if a hoo is installe over the cooking
surface.
Dim nsions & Sp cifications
CLEARANCE DIMENSIONS

5”
(12.7 cm)
6”
(15.2 cm)
3”
(7.6 cm)
12”
(30.5 cm)
11”
(27.9 cm)
Electrical
connection in
this area
Gas
connection in
this area
COOKING
Prof ssional Fr standing Gas 24”W.
Op n Burn r Rang
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 3 / 2 9 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
UTILITY
REQUIREMENTS
GAS
• Shippe natural
gas stan ar ;
fiel convert to
LP/propane with
optional accessory
kit or or er as LP
by a ing LP after
color co e
• Accepts stan ar
resi ential 1/2” ID
gas service line
• Gas manifol
pressure
o Natural gas 5.0”
W.C.P.
o LP/Propane
10.0” W.C.P.
ELECTRICAL
• Four-foot (121.9
cm) cor inclu e
with range
• Three-wire with
groun /three-
prong plug
• 120 V/60 Hz
• Maximum amp
usage—
o4B—4.3
oG—11.5
oQ—4.3
oK—4.3
PLUMBING
Not applicable
Installation R quir m nts
ACCESS REQUIREMENTS
VGIC245-4B
Four-Burner Range
VGIC245-G
Griddle Range
VGIC245-Q
Grill Range
VGIC245-K
Wok/Cooker Range
VGIC245-4B VGIC245-G VGIC245-Q VGIC245-K
Surface burner rat ng
Four grated burners (each) 15,000 BTU Nat. (4.4 kW)/
13,500 BTU LP (4.0 kW)
Two gr ddle (each) 15,000 BTU Nat. (4.4 kW)/
13,500 BTU LP (4.0 kW)
Two gr ll (each) 18,000 BTU Nat. (5.3 kW)/
16,000 BTU LP (4.7 kW)
Wok top 27,500 BTU Nat./LP (8.1 kW)
Bro l burner rat ng 15,000 BTU Nat. (4.4 kW)/13,500 BTU LP (4.0 kW)
Bake burner rat ng 30,000 BTU Nat./LP (8.8 kW)
Note: Ground plug and electrical wire toward the direction of the electrical outlet.

6”H. Backguard
• Stainless Steel (SS)
•Coor inates with all finishes
• Inclu e (an shippe ) automatically with 24”W. companion mo els
High-sh lf
• Stainless Steel (SS)
• Coor inates with all finishes
• Shelf comes attache to a 24”H. backguar
Island Trim
• Stainless Steel (SS)
• Coor inates with all finishes
• For islan /peninsula installation
• Can replace backguar if wall is non-combustible
Count rtop Sid Trim
• Stainless Steel (SS)
• Coor inates with all finishes
• Installs on si e of unit; overlaps countertop
COOKING
Prof ssional Fr standing Gas 24”W.
Op n Burn r Rang
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 3 / 2 9 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
Installation Not s & Acc ssori s
A backguar , high-shelf, or islan trim must be use for all installations.
Mod l D scription Approx. ship wt. lbs. (kg)
T24BG6 24”W. backguard 11 (5.0)
Mod l D scription Approx. ship wt. lbs. (kg)
T24HS24 24”W. h gh-shelf 40 (18.0)
Mod l D scription Approx. ship wt. lbs. (kg)
T24TII 24”W. sland tr m 9 (4.1)
Mod l D scription Approx. ship wt. lbs. (kg)
CT24ST 24”D. s de tr m 2 (0.9)

COOKING
Prof ssional Fr standing Gas 24”W.
Op n Burn r Rang
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 3 / 2 9 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
Curb Bas Front Custom Curb Bas Front
• Stainless Steel (SS) • Remove stainless steel front an recycle
• Coor inates with all finishes • Attach locally supplie trim
•Front only • Conceals range legs
• Conceals range legs • Completely assemble
• Completely assemble • Easily clips onto range legs after range is installe
• Easily clips onto range legs after range is installe • Provi es rop-in range look
LP/Propan Conv rsion Kit
• Allows for fiel conversion of range from natural gas to LP
Complianc Information
WARRANTY SUMMARY*
• One-year full warranty—complete pro uct
• Ten-year limite warranty—porcelain oven an porcelain inner oor panel
• Five-year limite warranty—surface burners, gri le burners, grill burners, an oven burner
• Ninety- ay limite warranty—cosmetic parts such as glass, painte , an ecorative items
* For complete warranty see Use & Care Guide. Warranty vali on Viking pro ucts shippe within the Unite States an Cana a.
Mod l D scription Approx. ship wt. lbs. (kg)
LPKPDR Natural to LP/propane convers on k t 2 (0.9)
Installation Not s & Acc ssori s
Mod l D scription Approx. ship wt. lbs. (kg)
RS24CBF4 24”W. curb base front 8 (3.6)
