Viking VCWH3048SS User manual

VWH Professional
Wall Hood
VCWH Professional
Chimney Wall Hood
VENTILATION
Professional Built-In 1 ”H.
Wall Hood/Chimney Wall Hood
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
All models include
o Brass Accent Option (BR)—nameplate,
rail, supports/brackets, an hooks
(inclu e ). Brass components have a
urable protective coating for
maintenance-free normal use.
• Finish esignates front an si es.
• Accessory Rail Option—Front of hoo .
(Must be or ere factory installe )
o Stainless Steel/Chrome (CR)—Stainless
steel rail with chrome supports/brackets
an hooks (inclu e ).
FINISH DETAILS
• Stainless Steel (SS), Black (BK), White
(WH), Metallic Silver (MS), Graphite Gray
(GG), Stone Gray (SG), Taupe (TP), Biscuit
(BT), Cotton White (CW), Oyster Gray
(OG), Gol en Mist (GM), Lemona e (LE),
Sage (SA), Mint Julep (MJ), Sea Glass (SE),
Iri escent Blue (IB), Viking Blue (VB),
Pumpkin (PM), Racing Re (RR), Apple
Re (AR), Burgun y (BU), Plum (PL),
Chocolate (CH), an Cobalt Blue (CB).
Standard Features & Accessories
Model Options
ORDERING INSTRUCTIONS
First specify mo el number, followe by color co e (VWH24481SS). If or ering optional ecorative rail, specify co e at en
(VWH24481SSCR).
• Must also purchase interior, exterior or
in-line ventilator kit, sol separately
(see Installation Notes & Accessories
for recommen e Viking ventilator
pro ucts)
• Heavy- uty construction; Professional-
type size, esign, an styling
o Virtually seamless stainless steel
esign with no visible screws
• Heat sensor turns the ventilator on full
power when cooking temperatures
reach uncomfortable levels
• Easy cleanup
o Commercial-type baffle filter system
efficiently removes grease an
heate vapors from the air;
especially esigne for use with
commercial-type pro ucts
•See Dimensions & Specifications
table for number of filters per
mo el
o Design of low-profile filter system
means less interior hoo space to
be cleane
o Canopy interior is completely line
in stainless steel for increase
rigi ity, seamless appearance, an
easy cleaning
o Separate removable trough catches
liquefie grease
• Heat lamp(s) stan ar —250-watt
bulb(s) not inclu e
o See Dimensions & Specifications
table for number of lamps per mo el
o High-shelf (cooking pro uct
accessory) or warming shelf panel
(see Installation Notes &
Accessories) shoul be installe for
use with heat lamp
• 50-watt halogen lights with immer
control
o Power switch an immer control
are separate, allowing you to leave
immer at favorite position
o See Dimensions & Specifications
table for number of lights per mo el
Extra feature on chimney wall
hoods
• A justable uct cover (for 8’ – 9’
ceilings) is stan ar
Model numbers*
WALL HOODS, 24”D.**
• VWH24481—24”W.
• VWH30481—30”W.
• VWH36481—36”W.
• VWH42481—42”W.
• VWH48481—48”W.
• VWH54481—54”W.
• VWH60481—60”W.
• VWH66481—66”W.
WALL HOODS, 27”D.
• VWH36781—36”W.
• VWH48781—48”W.
• VWH60781—60”W.
CHIMNEY WALL HOODS, 24”D.**
• VCWH3048—30”W.
• VCWH3648—36”W.
• VCWH4248—42”W.
• VCWH4848—48”W.
• VCWH5448—54”W.
• VCWH6048—60”W.
• VCWH6648—66”W.
*A 1,200 CFM interior or 1,500 CFM
exterior (if applicable) ventilator shoul
be use when installe over
ranges/rangetops with gas grill.
**Tests show 24”D. hoo s perform
properly over 27”D. ranges.
R E V I S E D 5 / 2 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE

VENTILATION
Professional Built-In 1 ”H.
Wall Hood/Chimney Wall Hood
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
✪
Please see
Installation Notes &
Accessories for
important information,
including ventilator
kits, duct covers,
backsplashes, and
warming shelf
panels.
Dimensions & Specifications
PRODUCT DIMENSIONS
B
A
18”
(45.7cm)
12”
(30.5cm)
12”
(30.5cm)
6”
(15.2 cm)
VWH Professional
Wall Hood
WALL HOOD
Model Hood Duct Cover Lights Filters Heat Approx.
Width (A) Depth (B) Width Depth Height Lamps Ship. wt.
VWH24481 23 7/8” (60.6 cm) 24” (61.0 cm) 23 7/8” 12” (30.5 cm) 12” (30.5 cm) 22 152 lbs.
(60.6 cm) (23.6 kg)
VWH30481 29 7/8” (75.9 cm) 24” (61.0 cm) 29 7/8” 12” (30.5 cm) 12” (30.5 cm) 22 160 lbs.
(75.9 cm) (27.0 kg)
VWH36481 35 7/8” (91.1 cm) 24” (61.0 cm) 35 7/8” 12” (30.5 cm) 12” (30.5 cm) 22 1 68 lbs.
(91.1 cm) (30.6 kg)
VWH42481 41 7/8” (106.4 cm) 24” (61.0 cm) 41 7/8” 12” (30.5 cm) 12” (30.5 cm) 22 176 lbs.
(106.4 cm) (34.2 kg)
VWH48481 47 7/8” (121.6 cm) 24” (61.0 cm) 47 7/8” 12” (30.5 cm) 12” (30.5 cm) 33 288 lbs.
(121.6 cm) (39.6 kg)
VWH54481 53 7/8” (136.8 cm) 24” (61.0 cm) 53 7/8” 12” (30.5 cm) 12” (30.5 cm) 33 296 lbs.
(136.8 cm) (43.2 kg)
VWH60481 59 7/8” (152.1 cm) 24” (61.0 cm) 59 7/8” 12” (30.5 cm) 12” (30.5 cm) 44 2108 lbs.
(152.1 cm) (48.6 kg)
VWH66481 65 7/8” (167.3 cm) 24” (61.0 cm) 65 7/8” 12” (30.5 cm) 12” (30.5 cm) 44 2121 lbs.
(167.3 cm) (54.5 kg)
VWH36781 35 7/8” (91.1 cm) 27” (68.6 cm) 35 7/8” 12” (30.5 cm) 12” (30.5 cm) 22 174 lbs.
(91.1 cm) (33.3 kg)
VWH48781 47 7/8” (121.6 cm) 27” (68.6 cm) 47 7/8” 12” (30.5 cm) 12” (30.5 cm) 33 294 lbs.
(121.6 cm) (42.3 kg)
VWH60781 59 7/8” (152.1 cm) 27” (68.6 cm) 59 7/8” 12” (30.5 cm) 12” (30.5 cm) 44 2114 lbs.
(152.1 cm) (51.3 kg)
R E V I S E D 5 / 2 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE

VENTILATION
Professional Built-In 1 ”H.
Wall Hood/Chimney Wall Hood
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
✪
Please see
Installation Notes &
Accessories for
important information,
including ventilator
kits, duct covers,
backsplashes, and
warming shelf
panels.
Dimensions & Specifications
PRODUCT DIMENSIONS
24”
(61.0cm)
A
B
C
18”
(45.7cm)
12”
(30.5cm)
to
24”
(61.0cm)
6”
(15.2 cm)
CHIMNEY WALL HOOD
VCWH Professional
Chimney Wall Hood
Model Hood Duct Cover Lights Filters Heat Approx.
Width (A) Depth Width (B) Depth (C) Height Lamps Ship. wt.
VCWH3048 29 7/8” (75.9 cm) 24” (61.0 cm) 12” (30.5 cm) 12” (30.5 cm) 12” (30.5 cm)— 22 1120 lbs.
24” (61.0 cm) (54.5 kg)
VCWH3648 35 7/8” (91.1 cm) 24” (61.0 cm) 12” (30.5 cm) 12” (30.5 cm) 12” (30.5 cm)— 22 1127 lbs.
24” (61.0 cm) (57.7 kg)
VCWH4248 41 7/8” (106.4 cm) 24” (61.0 cm) 12” (30.5 cm) 12” (30.5 cm) 12” (30.5 cm)— 22 1138 lbs.
24” (61.0 cm) (62.7 kg)
VCWH4848 47 7/8” (121.6 cm) 24” (61.0 cm) 18” (45.7 cm) 12” (30.5 cm) 12” (30.5 cm)— 32 2145 lbs.
24” (61.0 cm) (65.8 kg)
VCWH5448 53 7/8” (136.8 cm) 24” (61.0 cm) 18” (45.7 cm) 12” (30.5 cm) 12” (30.5 cm)— 33 2153 lbs.
24” (61.0 cm) (69.5 kg)
VCWH6048 59 7/8” (152.1 cm) 24” (61.0 cm) 24” (61.0 cm) 12” (30.5 cm) 12” (30.5 cm)— 44 2160 lbs.
24” (61.0 cm) (72.6 kg)
VCWH6648 65 7/8” (167.3 cm) 24” (61.0 cm) 24” (61.0 cm) 12” (30.5 cm) 12” (30.5 cm)— 44 2167 lbs.
24” (61.0 cm) (75.8 kg)
R E V I S E D 5 / 2 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE

VENTILATION
Professional Built-In 1 ”H.
Wall Hood/Chimney Wall Hood
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
30”min.
(76.2 cm)
to
36”max.
(91.4 cm)
66”min.
(167.6 cm)
to
72”max.
(182.9 cm)
36”
(91.4cm)
30”min.
(76.2cm)
to
36”max.
(91.4cm)
66”min.
(167.6cm)
to
72”max.
(182.9cm)
36”
(91.4cm)
Dimensions & Specifications
CLEARANCE DIMENSIONS
CHIMNEY WALL HOOD
WALL HOOD
R E V I S E D 5 / 2 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE

Proper installation/ducting is
extremely important to ensure
maximum performance. Use a qualified
and trained installer.
DUCTING
• Check with a qualifie an
traine installer or local co es
for makeup air requirements,
if any.
• Max. uct run
o For 300 – 1,200 CFM—50’
(15.2 m)
o For 1,500 CFM—75’
(22.9 m)
o Duct run length is for
general reference only;
always use a qualifie an
traine installer.
o Straight runs an gra ual
turns are best; for example,
each 90° elbow is equivalent
to 5’ – 10’ (1.52 –
3.05 cm) of straight run.
• 7” roun uct for 300 – 600
CFM; 10” for 900 – 1500 CFM
o Never use flexible uct; it
creates back pressure/air
turbulence an greatly
re uces performance.
GAS
Not applicable
ELECTRICAL
• Har wire irect with two-wire
with groun
• 120 VAC/60 Hz
• Max. amp usage (rating
inclu es rec. ventilator kit
rating)
PLUMBING
Not applicable
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
VCWH Professional
Chimney Wall Hood
VWH Professional
Wall Hood
VENTILATION
Professional Built-In 1 ”H.
Wall Hood/Chimney Wall Hood
Installation Requirements
Model Ventilator Kits Duct Size Max. Amps
Interior Exterior Interior Exterior Interior Exterior
VWH24481 VINV300/600 DEV900/1200*/DIL900/1200 7” (17.8 cm) 10” (25.4 cm) 5.0/6.2 8.7/6.1
VWH30481 VINV300/600 DEV900/1200*/DIL900/1200 7”(17.8 cm)/10” (25.4 cm) 10” (25.4 cm) 5.0/6.2/8.7 8.7/6.1
VWH36481 VINV300/600/1200* DEV900/1200*/DIL900/1200 7”(17.8 cm)/10” (25.4 cm) 10” (25.4 cm) 5.0/6.2/8.7 8.7/6.1
VWH42481 VINV600/1200* DEV900/1200*/DIL900/1200 7”(17.8 cm)/10” (25.4 cm) 10” (25.4 cm) 6.2/8.7 8.7/6.1
VWH48481 VINV1200* DEV1200/1500**/DIL1200 10” (25.4 cm) 10” (25.4 cm) 11.1 8.4/9.1
VWH54481 VINV1200* DEV1200/1500**/DIL1200 10” (25.4 cm) 10” (25.4 cm) 11.1 8.4/9.1
VWH60481 VINV1200* DEV1200/1500**/DIL1200 10” (25.4 cm) 10” (25.4 cm) 11.5 8.8/9.5
VWH66481 VINV1200* DEV1200/1500**/DIL1200 10” (25.4 cm) 10” (25.4 cm) 11.5 8.8./9.5
VWH36781 VINV300/600/1200* DEV900/1200*/DIL900/1200 7”(17.8 cm)/10” (25.4 cm) 10” (25.4 cm) 5.0/6.2/8.7 8.7/6.1
VWH48781 VINV1200* DEV1200/1500**/DIL1200 10” (25.4 cm) 10” (25.4 cm) 11.1 8.4/9.1
VWH60781 VINV1200* DEV1200/1500**/DIL1200 10” (25.4 cm) 10” (25.4 cm) 11.5 8.8/9.5
VCWH3048 VINV300/600 DEV900/1200*/DIL900/1200 7” (17.8 cm) 10” (25.4 cm) 3.9/6.0 8.7/6.0
VCWH3648 VINV300/600* DEV900/1200*/DIL900/1200 7” (17.8 cm) 10” (25.4 cm) 3.9/6.0 8.7/6.0
VCWH4248 VINV600* DEV900/1200*/DIL900/1200 7” (17.8 cm) 10” (25.4 cm) 6.0 8.7/6.
VCWH4848 VINV1200* DEV1200/1500*/DIL1200 10” (25.4 cm) 10” (25.4 cm) 11.5 8.5/9.2
VCWH5448 VINV1200* DEV1200/1500/DIL1200 10” (25.4 cm) 10” (25.4 cm) 11.5 8.5/9.2
VCWH6048 VINV1200* DEV1200/1500/DIL1200 10” (25.4 cm) 10” (25.4 cm) 11.9 8.9/9.7
VCWH6648 VINV1200* DEV1200/1500/DIL1200 10” (25.4 cm) 10” (25.4 cm) 11.9 8.9/9.7
* A 1,200 CFM interior- or exterior-power ventilator shoul be use when installe over range/rangetop with gas char-grill.
** It is recommen e that the 1,500 CFM ventilator be use with longer uct runs.
Note: Maximum amp ating fo hoods includes ecommended ventilato kit ating; All p oducts must be ha d wi ed with 2-wi e with g ound. An inte io -
o exte io -powe ventilato kit must be pu chased fo installation with all 18”H. hoods.
Note: All CFMs a e based on tests with 0.1 static p essu e. Without applying static p essu e (some b ands do not), CFM could be
g eatly ove stated.
UTILITY REQUIREMENTS
R E V I S E D 5 / 2 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE

PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
VENTILATION
Professional Built-In 1 ”H.
Wall Hood/Chimney Wall Hood
Recommended Ventilator Kits
• See Installation Requirements table for recommen ations for each hoo mo el
• One ventilator, one uct run for any size hoo /ventilator
•Variable spee controls for custom venting—separate on/off switch allows you to leave ventilator at favorite/most-use
setting
• Choose from interior- or exterior-power ventilator kits
• Must use Viking ventilator kits with Viking hoo s; use of non-Viking kits voi s pro uct warranty
Duct Covers
• Specify finish co e following accessory mo el number (for example, DCW24-SS)
o Professional mo els
•For VWH hoo s
•12”D.
•Exten s height of hoo by 12”—conceals uct
•Available in Stainless Steel (SS), Black (BK), White (WH), Metallic Silver (MS), Graphite Gray (GG), Stone Gray (SG),
Taupe (TP), Biscuit (BT), Cotton White (CW), Oyster Gray (OG), Gol en Mist (GM), Lemona e (LE), Sage (SA), Mint
Julep (MJ), Sea Glass (SE), Iri escent Blue (IB), Viking Blue (VB), Pumpkin (PM), Racing Re (RR), Apple Re (AR),
Burgun y (BU), Plum (PL), Chocolate (CH), an Cobalt Blue (CB).
Duct Cover Extensions
• For use with Professional chimney wall hoo s (VCWH)
• Exten s height of hoo by up to 12” (for 10’ ceilings)
• Replaces a justable uct cover supplie with hoo
• Specify finish co e following accessory mo el number (for example, DCCE1210-SS)
o Available in Stainless Steel (SS), Black (BK), White (WH), Metallic Silver (MS), Graphite Gray (GG), Stone Gray (SG),
Taupe (TP), Biscuit (BT), Cotton White (CW), Oyster Gray (OG), Gol en Mist (GM), Lemona e (LE), Sage (SA), Mint
Julep (MJ), Sea Glass (SE), Iri escent Blue (IB), Viking Blue (VB), Pumpkin (PM), Racing Re (RR), Apple Re (AR),
Burgun y (BU), Plum (PL), Chocolate (CH), an Cobalt Blue (CB).
✪Installation Notes & Accessories
Kit model Description Hood models Approx. ship wt. lbs. (kg)
VINV300 300 CFM interior power VWH/VCWH24481/30481/36481/36781 27 (12.2)
VINV600 600 CFM interior power VWH/VCWH24481/30481/36481/36781/42481 27 (12.2)
VINV1200 1,200 CFM interior power VWH/VCWH36481/36781/42481/48481/ 43 (19.4)
48781/54481/60481/60781/66481
DEV900 900 CFM exterior power VWH/VCWH24481/30481/36481/36781/42481 39 (17.6)
DEV1200 1,200 CFM exterior power VWH/VCWH24481/30481/36481/36781/42481/ 53 (23.9)
48481/48781/54481/60481/60781/66481
DEV1500 1,500 CFM exterior power VWH/VCWH48481/48781/54481/60481/60781/66481 47 (21.3)
DIL900 900 CFM in line power VWH/VCWH24481/30481/36481/36781/42481 20 (9.1)
DIL1200 1,200 CFM in line power VWH/VCWH24481/30481/36481/36781/42481/48481/ 25 (11.3)
48781/54481/60481/60781/66481
Model Description Approx. ship wt. lbs. (kg)
DCW24 Professional 24”W. duct cover 9 (4.0)
DCW30 Professional 30”W. duct cover 10 (4.5)
DCW36 Professional 36”W. duct cover 11 (5.0)
DCW42 Professional 42”W. duct cover 13 (5.9)
DCW48 Professional 48”W. duct cover 14 (6.3)
DCW54 Professional 54”W. duct cover 23 (10.4)
DCW60 Professional 60”W. duct cover 24 (10.8)
DCW66 Professional 66”W. duct cover 26 (11.7)
Model Description Approx. ship wt. lbs. (kg)
DCCE1210 Duct cover extension (for 30”W., 36”W., & 42”W. hoods) 6 (2.7)
DCCE1810 Duct cover extension (for 48”W. & 54”W. hoods) 8 (3.6)
DCCE2410 Duct cover extension (for 60”W. & 66”W. hoods) 11 (4.9)
R E V I S E D 5 / 2 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE

PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
VENTILATION
Professional Built-In 1 ”H.
Wall Hood/Chimney Wall Hood
Backsplashes
• Stainless Steel (SS)
• 30”H.
•For both VWH & VCWH hoo s
• Backsplashes protect the wall space below hoo
• Create a continuous finish between cooking surface an hoo
• Low maintenance, easy to clean
• Hemme e ges with screw holes
• Kit inclu es backsplash an fastening screws
Warming Shelf Panels
• Stainless Steel (SS)
• 12”D./12”H.
• For use with any backsplash
• Shelf panels hol cookware an con iments
• Fol up/ own, heavy- uty warming shelves (non-removable), factory installe on stainless steel backsplash
• 15-7/8”W. X 10-1/8”D.
• Kit inclu es shelf (or shelves) an fastening screws
Compliance Information
WARRANTY SUMMARY*
• Three-year full warranty—complete pro uct (Professional an Designer)
• Five-year limite warranty—all ventilator motors (Professional an Designer)
• Ninety- ay limite warranty—cosmetic parts such as glass, painte , an ecorative items (Professional an Designer)
*Must use Vi ing ventilator its with Vi ing hoods; use of non-Vi ing its voids product warranty. For complete warranty see Use & Ca e Guide.
Warranty vali on Viking pro ucts shippe within the Unite States an Cana a.
✪Installation Notes & Accessories
Model Description Approx. ship wt. lbs. (kg)
BKS24 24”W. backsplash 5 (2.3)
BKS30 30”W. backsplash 7 (3.2)
BKS36 36”W. backsplash 9 (4.1)
BKS42 42”W. backsplash 12 (5.4)
BKS48 48”W. backsplash 14 (6.3)
BKS54 54”W. backsplash 17 (7.7)
BKS60 60”W. backsplash 20 (9.0)
BKS66 66”W. backsplash 23 (10.4)
Model Description Approx. ship wt. lbs. (kg)
WGP24 24”W. warming shelf panels (one shelf) 6 (2.7)
WGP30 30”W. warming shelf panels (one shelf) 9 (4.1)
WGP36 36”W. warming shelf panels (two shelves) 12 (5.4)
WGP42 42”W. warming shelf panels (two shelves) 14 (6.3)
WGP48 48”W. warming shelf panels (two shelves) 16 (7.2)
WGP54 54”W. warming shelf panels (two shelves) 20 (9.0)
WGP60 60”W. warming shelf panels (three shelves) 23 (10.4)
WGP66 66”W. warming shelf panels (three shelves) 26 (11.7)
R E V I S E D 5 / 2 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
