Vimco Lutron sivoia Manual

Page 1

shading solutions byVIMCOTM

1System Dimensions Overview pg. 3

2Fasten Mounting Brackets pg. 4,5

3Attaching MDU and Idler Support pg. 6

4Hanging the Shade pg. 6,7

5Wiring the System pg. 8,9

6MDU Setup pg. 10,11

7Shade Controls pg. 12

8MDU w/ SV-IR Module pg. 13

9Troubleshooting pg. 14

10 Part Specs pg. 15

Contents

Infrared Handheld

Transmitter

Idler

Support

Fabric & Roller Assembly

Motor Drive Unit (MDU)

Wallstation Controls

Transformer

SV-IR Infrared Receiver Module

A Typical SivoiaTM Motorized Shade System

(Wallstation Controls, Transformer, SV-IR Infrared Receiver Module, and Infrared Handheld Transmitter not included with this kit)

Installation & Operating Instructions

Single Shade

Installation Kit

Motorized Shade Systems

Page 2

shading solutions byVIMCOTM

CARTON CONTENTS

Motor Drive Unit (MDU)

(exploded view - ships assembled)

SV-IR Module Connecting

Wire (SV-IR Module sold

separately)

MDU & Idler Support Mounting

Brackets

MDU & Idler Support

Ceiling-Mount Brackets

Idler Support

1/2” Idler and MDU

Truss-head Screws

(x8)

2” Pan-Head Mounting

Bracket Screws (x8)

• #2 Phillips Screwdriver

• 1/8 in. Straight Blade Screwdriver

• Power Drill: Drill Bits, Screwdriver Attachments

• Level

• Pliers

• Tape Measure

• Wire Cutter

• Wire Stripper

TOOLS REQUIRED

Page 3

shading solutions byVIMCOTM

SYSTEM DIMENSIONS OVERVIEW

Use the following diagrams in conjunction with the Sivoia®Order Invoice to accurately position the mounting brackets.

Bracket to Bracket Width

(FW + 4" (102 mm))

Fabric Width (FW)

2 3/4"

(70 mm)

1 1/4"

(32 mm)

Bracket to Bracket Width

(FW + 4" (102 mm))

Fabric Width (FW)

2 3/4"

(70 mm)

1 1/4"

(32 mm)

Figure 1: Standard Mounting Bracket Application

Figure 2: Ceiling-Mount Bracket Application

Page 4

shading solutions byVIMCOTM

FASTEN MOUNTING BRACKETS

A. Position the bracket’s “teeth” for each bracket at the ends of the fabric width as shown. Use a level to ensure the

brackets are at the same height and parallel to the window casing.

Note: Fasten the top of the brackets 5 in. (127 mm) from the top of the window trim to ensure complete window

exposure when the shades are in full up position.

B. Fasten the brackets to studs in the wall using no less than four(4) pan-head mounting bracket screws.

Note: All four (4) screws must be securely fastened to stud or other structural member.

Fabric Width

(127mm) 5"

(127mm)

Fabric Edge

Teeth

Line up the bracket teeth with the

fabric edge

Once the mounting brackets have been fastened to the wall, confirm the Bracket to Bracket Width

as listed on the Sivoia®Order Invoice. Refer to Figure 1 on page 3 for a detailed diagram. Make any

necessary bracket position adjustments based on this assessment.

Note: Only mount system where ambient temperature will be 0˚C - 50˚C (32˚F - 122˚F).

Page 5

shading solutions byVIMCOTM

FASTEN MOUNTING BRACKETS (CONT’D)

For Ceiling-Mount Applications...

Follow steps A & B from the previous page, then line up and fasten the brackets as shown.

Notes:

•Make sure the opening of the ceiling bracket faces outward towards the room.

•All four (4) screws must be securely fastened to stud or other structural member.

Fabric Edge

Wall

Ceiling

Bracket

Top View

(127mm)

Line up this bracket edge with the

fabric edge

Face this

opening outward

towards the room

when mounting

Once the ceiling-mount brackets have been fastened to the ceiling, confirm the Bracket to Bracket

Width as listed on the Sivoia®Order Invoice. Refer to Figure 2 on page 3 for a detailed diagram.

Make any necessary bracket position adjustments based on this assessment.

Page 6

shading solutions byVIMCOTM

ATTACH MDU and IDLER SUPPORT

A. Attach the idler support to the mounting bracket using

three (3) truss-head screws.

B. Attach the MDU to the mounting bracket using three (3)

truss-head screws.

HANGING THE SHADE

A. Unwrap approximately 1 ft. (0.3 m) of material.

B. Attach the shade to the MDU first by engaging the roller’s hexagonal socket with the motor’s hexagonal drive ball. You

may need to rotate the roller in order to push the shade over the hexagonal drive ball.

C. Insert the idler pin into the upper slot of the idler support and drop it into place.

Page 7

shading solutions byVIMCOTM

HANGING THE SHADE (CONT’D)

D. Tighten the idler's shade retaining screw to keep the

idler pin secure/ “locked”.

E. Adjust the shade leveling screw to level the shade

roller.

Shade Retaining

Screw “Locked”

Shade Retaining

Screw

Shade

Leveling

Screw

CAUTION! Not setting the shade retaining screw into the

"locked" position prior to operating the unit can result in

damage to the system.

Page 8

shading solutions byVIMCOTM

12345678

Cntrl 1

Cntrl 2

Ground

Com

MUX

Do not connect if there is only one MDU in the system. If

there are multiple MDU's in the system, the MDU's must be wired

together. Connect the MUX, Drain, and MUX terminals of each MDU

together in a daisy chain or homerun configuration.

To a Sivoia®wall mounted keypad, or a Sivoia®interface such

as the SV-CCI-GRP or the SV-GRXI. The CNTRL1 and CNTRL2

wires are polarity sensitive.

MDU WIRING - SINGLE MOTOR

Connecting Wires to the MDU Terminal Block

The terminal block located at the bottom of the MDU is the wire

connection point for: power, communication, keypads, and interfaces.

A. Remove terminal block cover (if not yet removed) by pressing in on

the cover and then pulling downward.

B. Grasp terminal block and pull down to separate from connecting

block.

C. Connect wires to the terminal block according to the diagram

below.

D. Replace the terminal block and the terminal block cover.

Wire to a Sivoia®plug-in transformer, junction box mount

transformer, or a Sivoia®power panel. Each MDU must be EARTH

grounded. One Sivoia®transformer can power ONLY ONE MDU

regardless of shade size.

Control

Comm

Link

Power

Supply

Comm & Power

( & combined)

Wire Type

Control

Description

2 conductors / #22-24 AWG

3 conductors (2 shielded, 1 common) / #24 AWG

Belden®wire model #1883A

3 conductors #22 AWG

Lutron model # SV-IR-EXT-10

3 conductors:

2 / #18-22 AWG (24 VAC power supply)

1 / #18-22 AWG (earth ground)

6 conductors:

2 / #16 AWG (24 VAC power supply)

1 / #18 AWG (earth ground)

3 #22 AWG shielded + 1 #24 AWG common (comm link)

(Lutron wire model no. SV-CBL-MDU-250)

Control to MDU: 250 ft. (76 m)

Max. Length

4000 ft. (1333 m) per system

1000 ft. (333 m) from MDU to MDU

50 ft. (15 m) per system - total of 5

SV-IR-EXT-10, 10 ft. (3 m) each

MDU to Sivoia®power panel:

200 ft. (61 m)

Transformer to MDU:

#18 AWG - 150 ft. (46 m)

#20 AWG - 100 ft. (31 m)

#22 AWG - 60 ft. (18 m)

Comm Link B

Power Wires C

SV-IR Extension

Cable E

Com

MUX

12345678

Cntrl 1

Cntrl 2

Ground

Com

MUX

12345678

Cntrl 1

Cntrl 2

Ground

Com

MUX

B B

Comm & Power

( & combined)

Page 9

shading solutions byVIMCOTM

MDU WIRING - WIRING MULTIPLE MOTORS TOGETHER

Wire to a Sivoia®plug-in transformer, junction box mount

transformer, or a Sivoia®power panel. Each MDU must be

EARTH grounded. One Sivoia®transformer can power ONLY

ONE MDU regardless of shade size.

To a Sivoia®wall

mounted keypad, or

a Sivoia®interface

To a Sivoia®wall

mounted keypad, or

a Sivoia®interface

A maximum of 64 MDU's can be wired

together per system

MDU Terminal Blocks

Control

Comm Link

Power

Supply

Control

MDU

Comm Link

Power Supply

Wire Type

Control

Description

2 conductors / #22-24 AWG

3 conductors (2 shielded, 1 common) / #24 AWG

Belden®wire model #1883A

3 conductors #22 AWG

Lutron model # SV-IR-EXT-10

3 conductors:

2 / #18-22 AWG (24 VAC power supply)

1 / #18-22 AWG (earth ground)

6 conductors:

2 / #16 AWG (24 VAC power supply)

1 / #18 AWG (earth ground)

3 #22 AWG shielded + 1 #24 AWG common (comm link)

(Lutron wire model no. SV-CBL-MDU-250)

Control to MDU: 250 ft. (76 m)

Max. Length

4000 ft. (1333 m) per system

1000 ft. (333 m) from MDU to MDU

50 ft. (15 m) per system - total of 5

SV-IR-EXT-10, 10 ft. (3 m) each

MDU to Sivoia®power panel:

200 ft. (61 m)

Transformer to MDU:

#18 AWG - 150 ft. (46 m)

#20 AWG - 100 ft. (31 m)

#22 AWG - 60 ft. (18 m)

Comm Link B

Power Wires C

SV-IR Extension

Cable E

Press the Set button to save the

corrent position as the “Close

Limit.” The display will read

and blink for 4 seconds, then go

blank.

SET

OPEN

MODE

Page 10

shading solutions byVIMCOTM

MOTOR DRIVE UNIT (MDU) SETUP - SINGLE MDU

Open Limit: The position the shade moves to when it opens.

Close Limit: The position the shade moves to when it closes.

Programming Table

STEPS MODE

Open Limit:

Press the Mode

button on the MDU

until the display

reads

Close Limit:

Press the Mode

button on the MDU

until the display

reads

STEP 2

Use the Open and Close buttons on the

MDU to adjust the shade to the open

position desired.

Use the Open and Close buttons on the

MDU to adjust the shade to the closed

position desired.

Press the Set button to save the

corrent position as the “Open

Limit.” The display will read

and blink for 4 seconds, then go

blank.

ADJUST SET

Mode Button

Open and Close

Buttons

Set Button

Display on bottom of MDU

STEP 1

The Motor Drive Unit (MDU) should come from the factory with open and close limits. To change the factory limits,

follow the steps below. If there is only one MDU in the system, open and close limits are the only steps required.

Follow the programming steps outlined in the programming table below. If the system has multiple MDUs, follow the

single MDU setup directions for each MDU and then continue with the setup codes for multiple MDU systems on the

next page.

Page 11

shading solutions byVIMCOTM

All MDU’s with the same room

address and the

same address

Multiple MDU Set-Up Codes

MOTOR DRIVE UNIT (MDU) SETUP - MULTIPLE MDU's

Control Station: Determines which MDU's in the system will respond to a "Group" keypad or "Group" interface control

that is wired to the MDU being setup. It is not necessary to change the control station setting of an MDU that does not have

any keypads or interfaces wired to it.

Room Address: The room address groups MDU's on the communication link. A group is defined as all MDU's with the

same room address number. There are 32 room addresses available in a single system, therefore, a system can have up to

32 groups. Typically, all MDU's in a room will be set to the same room address. Use the room address to help determine

how keypads will control the MDU's in the system. Refer to the control station setting table below for information on how

the room address setting affects how the system is controlled by keypads or interfaces.

Scene Lockout: Turns off the ability to set or adjust PRESET stop points. To activate, set the scene lockout setting to 1. To

deactivate, set the scene lockout setting to 0. Changing this setting on any MDU will adjust all the MDU's in the system. It

is not necessary to deactivate the scene lockout setting from the same MDU it was activated it on.

Link Address: Each MDU must be set to a unique Link Address number to allow the MDU's to communicate on the

communication link. There are 64 link addresses available, meaning the maximum number of MDU's in a single system is

64.

Any keypad or interface CANNOT be wired to more

than one MDU.

Group keypads/interfaces and individual

keypads/interfaces can be wired to the same MDU.

A maximum of 9 keypads/interfaces can be wired

to one MDU.

There are two types of Sivoia®keypads and

interfaces, group and individual types. The table

to the left describes how a group type controls a

system depending on the setting of the MDU

it is wired to. An individual type only controls the

MDU it is wired to, regardless of the setting

of the MDU it is wired to.

SPECIAL NOTES:

Control Station Setting Table

MDU

Setting

Which MDU’s in a System Will

Respond

All MDU’s with the same room

address

All MDU’s in the system

All MDU’s with the same room

address and the same Front (F)

or Rear (r) assignment in the

address

All MDU’s with the same room

address and the same number (1,

2, 3, or 4) in the address setting

All Front MDU’s or all Rear MDU’s

in the system

What MDU Address Settings

Determine which MDU in the

System Will Respond

Room address

IR address

Not dependent on and

address settings

Room address

Front or Rear in the

IR address

Room address

Same number (1, 2, 3, 4, 5, 6, 7 or

8) in the IR address

Front or Rear in the

IR address

IR Address: Used to set the IR address a MDU will respond to. Some IR hand controls have the ability to control

subgroups of shades within a group, as defined by the room address described above. There are 16 subgroups available.

Each IR address (subgroup) is made up of two parts, the IR address number (1, 2, 3, 4, 5, 6, 7 or 8) and its shade location

(F or r), the FRONT shade or the REAR shade. Any number of MDU's can have the same IR address. The IR address can

also be used to determine subgroups of the MDU's when a keypad or interface is used to control the system. Refer to the

control station setting table below for information on how the IR address affects how the system is controlled by keypads or

interfaces.

LUTRON

Page 12

shading solutions byVIMCOTM

SHADE CONTROLS

Surface Mount Group Wall Keypad - SV-1PG-WH

Note: Pressing any button while shade is moving will stop the shade.

SETTING PRESET:

1.) Use the Raise and Lower buttons until shade is at the level you wish to store as the "PRESET".

2.) Press and hold the Preset button (approximately 4 seconds) until appears in the MDU's LED display.

OPEN

PRESET

PRESS ONCE:

Shade goes to open

limit

PRESS ONCE:

Shade goes to close

limit

PRESS:

To lower shade

PRESS:

To raise shade

PRESS ONCE:

Shade goes to preset

level

Front View Rear View

MDU Pin 1

CNTRL 1

MDU Pin 2

CNTRL 2

PRESS:

To lower shade

PRESS ONCE:

Shade goes to open

limit

PRESS ONCE:

Shade goes to close

limit

PRESS:

To raise shade

Note: Pressing any button while shade is moving will stop the shade.

Split Button Open/Close Infrared Handheld Transmitter - SV-OCIT

Page 13

shading solutions byVIMCOTM

MDU WITH SV-IR INFRARED RECEIVER MODULE

Sivoia®system covered by

decorative valence

The SV-IR allows the MDU to be controlled directly with a Sivoia®Infrared Handheld Transmitter (SV-OCIT, SV-3PIT, or

SV-4GD-OCIT). The SV-IR receiver connects to the MDU via a 20 in. (51 cm) cable. This provides the SV-IR receiver

ample mounting range to offset any infrared signal restriction caused by a protective/decorative covering for the shade

system. To extend the IR receiver mounting range, add up to five (5) SV-IR-EXT-10 extension cables (10 ft. [3 m] each).

Note: To control an individual shade with an IR transmitter, the SV-IR must be connected to that MDU. If there is a

Group/Subgroup of MDU’s with the same Room/IR Address (see page 11),the SV-IR need only be connected to

one of those MDU’s to control the entire Group/Subgroup.

- The SV-IR receiver must be located to allow line-of-sight reception of infrared signals.

- The SV-IR has a range of 30 ft. when receiving infrared signals.

- The SV-IR must NOT be located near lighting fixtures or in direct sunlight.

- The SV-IR must be located within 50 ft. (15 m) of the MDU it is connected to. Add up to five (5) SV-IR-EXT-10

extension cables (10 ft. [3 m] each).

MDU

SV-IR Infrared Receiver Module

Page 14

shading solutions byVIMCOTM

PROBLEM SOLUTION

The shade will not go up or down. 1. Check power to the motor unit by pressing the MODE

button. If the LED display does not show anything check

that:

• transformer is plugged into a live outlet.

• power wiring is not shorted.

• power wiring terminal is not miswired or

disconnected.

2. If the LED display shows something, try to raise and lower

the shade using the buttons marked open and close on the

motor drive unit. If the shade does not respond, the shade

material or weight bar may be binding on the roller frame or

end brackets. Check for and clear all obstructions.

The shade does not respond to control. 1. Check that power is connected to the shade.

2. Check that the wall keypad has been wired correctly.

3. Check that the control terminal block is connected securely

and in the proper order.

4. Check batteries if using IR remote

The shade does not roll straight. (Fabric veers or telescopes) 1. If the shade veers or telescopes toward the right, correct by

lowering shade completely and place a piece of tape as

close to the left edge of the roller as possible. If shade veers

or telescopes towards the left, tape must be placed as close

to the right edge of the roller as possible. Note multiple

pieces may be necessary.

TROUBLESHOOTING

Page 15

shading solutions byVIMCOTM

PART SPECS

1.63"

(41 mm)

4.80"

(122 mm)

2.75"

(70 mm)

2.40"

(61 mm) 2.40"

(61 mm)

2.76"

(70 mm)

1.25"

(32 mm)

2.76"

(70 mm)

3.91"

(99 mm)

3.91"

(99 mm)

2.84"

(72 mm)

2.20"

(56 mm)

3.20"

(81 mm)

0.5"

(13 mm)

Idler Support

MDU Mounting Bracket Idler Mounting Bracket

Ceiling-Mount Bracket

MDU Dimensions

Side View “A” Side View “B”

Front

View

Front ViewSide View

Top ViewSide View Top ViewSide View

Back

View

3.25"

(82 mm)

2.40"

(61 mm)

(102 mm)

6.75"

(171 mm)

shading solutions byVIMCOTM

LIMITED WARRANTY

SIVOIA®MOTORIZED WINDOW SHADE SYSTEM EIGHT YEAR LIMITED WARRANTY

Vimco warrants, for eight years from shipment, each new SIVOIA Motorized Window Shade System to be free from defects in materials or workmanship under

conditions of normal use and specified ambient temperature when installed and operated in accordance with Vimco product specifications, applicable local

electrical and building codes, applicable National Electrical Code®provisions, and the Safety Standards of Underwriter's Laboratories.

What Vimco Will Do

Upon the return of a system or system component, subsequently determined by Vimco to be defective, Vimco will, in its sole discretion, repair or replace the

defective system or system component, provided that Vimco was promptly notified of the alleged defect within the warranty period, and provided that the

system or system component was properly installed, wired, insulated, used, and maintained, as determined solely by Vimco. Vimco shall not be required to

remove, install, or re-install any system or system component alleged to be defective.

Vimco will issue a credit for the cost of the repair or the replacement in accordance with the following schedule:

For the first 2 years after the date of shipment 100%

For years 3, 4, and 5 after the date of shipment 50%

For years 6, 7, and 8 after the date of shipment 25%

What This Warranty Does Not Cover

1. Damage or improper operation determined by Vimco to be due to normal wear and tear, or to abuse, misuse, or accident, such as:

a. Use of incorrect line voltages;

b. Use of incorrect fuses or circuit breakers;

c. Failure to follow operating instructions provided by Vimco;

d. Unauthorized repairs or adjustments or alterations;

e. Direct exposure to corrosive materials;

f. Vandalism;

g. Fire, flood, "Acts of God", and other factors beyond the control of Vimco.

2. The cost of labor, including any labor required to remove, install, or re-program any replacement item.

3. Components and equipment external to the SIVOIA Motorized Window Shade System, such as:

a. Non-Lutron lighting and automation systems;

b. Building wiring; and

c. Other manufacturers’ equipment, including, but not limited to:

i. Time clocks;

ii. Audio-visual equipment; and

iii. Photo sensors.

4. The cost of repairing or replacing property or equipment other than the warranted system.

How to Get Service under This Warranty

Should you experience the need for service under this warranty, please contact your SIVOIA Motorized Window Shade System service representative

immediately; or

Contact Vimco by telephone toll-free at:

1-800-446-1503; or

By mail to: VIMCO Shading Systems

11520 Sun Shade Lane

Ashland, VA 23005

or;

By E-mail: [email protected]

LIMITATIONS AND EXCLUSIONS

THIS WARRANTY IS EXCLUSIVE. THERE ARE NO OTHER EXPRESS WARRANTIES.

THE IMPLIED WARRANTY OF MERCHANTABILITY IS LIMITED TO TWO YEARS FROM THE DATE OF SHIPMENT. VIMCO SHALL NOT BE LIABLE FOR

ANY REPAIR WORK UNDERTAKEN WITHOUT ITS PROPER WRITTEN CONSENT, OR FOR INCIDENTAL, CONSEQUENTIAL, OR SPECIAL DAMAGES.

VIMCO’S LIABILITY ON ANY CLAIM FOR DAMAGES ARISING OUT OF OR IN CONNECTION WITH THE MANUFACTURE, SALE, INSTALLATION,

DELIVERY, USE, REPAIR, OR REPLACEMENT OF THE SHADING SYSTEM SHALL NEVER EXCEED THE PRICE PAID FOR THE SYSTEM. SOME

STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU.

SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR

EXCLUSION MAY NOT APPLY TO YOU.

This product may be covered under one or more of the following U.S. Patents: 5,467,266; 5,671,387; 5,848,634; 6,100,659; 6,201,364; 6,313,588; 6,346,781 DES.

317,593; DES. 344,068; DES. 370,663; DES. 378,814; DES. 387,736 DES. 391,924; DES. 396,448; DES. 437,585; and DES 450,043; and corresponding foreign

patents. U.S. and foreign patents pending. Lutron, Sivoia and the Sunburst logo are registered trademarks of Lutron Electronics Co., Inc. VIMCO, and shading solutions

by VIMCO are trademarks of Virginia Iron & Metal Company, Inc.

Internet: www.vimco.com, www.lutron.com

VIMCO

Made and printed in U.S.A.

P/N 045-003 Rev. D 12/02

Other Vimco Window Blind manuals
