EASY LIFT- LIFTING PLATFORM
DATE APPROVED

Easy Lift
1
ASSEMBLY INSTRUCTIONS
Table of contents
Definition of the lift way ........................................................................ 2
Installation of the carriage assembly .................................................................... 8
Inserting the nuts ................................................................................. 14
Lift way and carriage assembly nishing ............................................................... 17
Preparation of cables and wiring for upper door fixing ........................... 21
Door shutter fixing ............................................................................ 25
Stop adjustments and operating check ................................................... 26
Panel closing ........................................................................................ 29

Easy Lift
2
1) Check if space and position correspond to the drawing. Check if there is a telephone line.
2) The pit must be clean and levelled.
FIG.1
FIG.2 FIG.3
d
Denition of the lift way
3) Place the frame down into the pit as per attached drawing of the lift. Side “d” is the one with the
protruding tubular sections. Lay the frame down on the pit as per attached drawing, (if any, the pit
depth should be 50 mm) Figure 1.

Easy Lift
3
4) Fix the guide on the LH side in the corner between sides “a” and “d” (Figures 4-5).
FIG.5
FIG.4
a
d

Easy Lift
4
5) Fix the rst side panel (marked “a1” or “c1”, see drawing and Figure 7) to the guide by means of
ST6 6.3x16 screws.
6) Fix the rst “L”-shaped prole (marked “a1 or “c1”) closing the panels with ST6.3x16 screws and
at the base with 4.2x13 screws (gures 7-8-9).
a1
FIG.8 FIG.9
FIG.7
a1
7) Then proceed in
sequence with the other
panels (a2-a3 etc.
see g. 8-9-10-11).

Easy Lift
5
FIG.10 FIG.11
8) Fix another 2 or 3 panels on the same sides.

Easy Lift
6
9) Fix the rst panel of the guide side (d1) using ST6.3x16 screws (g.12). Put a 30 mm shim under
the panel to place it horizontally (0°) (g.13).
d1
FIG.12
FIG.13
d1

Easy Lift
7
FIG.14
10) Fix also the upper panel (g. 14) on the side “d” called “d2”.
d1
d2

Easy Lift
8
Installation of the carriage assembly.
1) Prepare the platform / machinery unit to be inserted in the guides.
FIG.15
2) Remove the sliding guides on the right side of the machinery (g 15).
FIG. 15
SOPRA SOTTO

Easy Lift
9
3) Now proceed with inserting the machinery, arranging rst a support below the platform landing so
that the whole structure is raised from the ground thus making assembly easier (g. 16/b rif.1), and di-
sconnect the safety edge (g.16/a).
FIG.16
1
b) c)
a)

Easy Lift
10
5) Fix the upper cross-beam supporting the worm screw to the guides using special rubber insulators
(g. 17).
4) Now insert the right side guide using ST6.3x14 screws
to the lower frame and to the panels of side “d”.
FIG.17

Easy Lift
11
FIG.18
6) Insert the worm screw in the supporting cross-beam (g. 18), then place the bearing needed for manual
operation in the top section.
7) After inserting the worm screw in the cross-beam, insert the axial bearing (51106), then the shims and
nally tighten with the special nut (g. 19).
FIG.19
Attention: the nut must be locked with Loctite.

Easy Lift
12
7) Now x the joint to the worm screw and the lever for manual emergency operation (g. 20/21).
FIG.20
FIG.21

Easy Lift
13
8) Now x the sliding blocks on the right guide (g. 22).
FIG. 22

Easy Lift
14
7-12mm
Inserting the nuts.
a) b)
c)
FIG.23
1) Insert the safety nut (g. 23/a) in the pulling nut (g. 23/b), trying to get them spaced about 7-12 mm
apart (g. 23/c).

Easy Lift
15
FIG.24
2) Fasten the nuts to the pulley using the special pin, and then turn the worm screw to tighten the two
parts. (g. 24).
FIG.25
3) Get the safety microswitch closer to the groove of the speed governor nut (g. 25)

Easy Lift
16
FIG.26
4) The 11 mm distance between the nuts (see g. 23/c) must always be monitored, since it indicates the
nut wear level.To make this check easier, shape the attached metal template (g. 26). Keep it on the ma-
chine (see g.27).
FIG.27

Easy Lift
17
Lift way and carriage assembly nishing.
1) Fix and check the proper function of the safety edge, both electrically and mechanically (g. 27).
FIG. 27

Easy Lift
18
FIG.28
2) After xing the door frame to the lower level, remove the pallet from under the platform (in manual
emergency mode) and complete the assembly of the panels on sides “a”, “b” and “d”
(g. 28- 29-30-31-32).
FIG.29
