Vinotemp Designer VT-DS26SB149 User manual

A PROUD HERITAGE OF EXPERIENCE AND QUALIT
Y
149 Bottle Seamless
Dual-Zone Wine Cooler
VT-DS26SB149
17621 South Susana Road
Rancho Dominguez, CA 90221
1.800.777.8466 | Fax [phone]
WWW.VINOTEMP.COM

Vinotemp International ●[e-mail] ●P: 1.800.777.8466 ●F: 310-886-3310
2

Vinotemp International ●17621 S. Susana Road, Rancho Dominguez, CA 90221
Your Wine Cellar
This unit can be used for storage and/or service. The unit has a glass door
and soft interior light that you can use to display your wine.
Serving Wines
Storing wines at the proper temperature is important. To preserve them
as long as possible, wine should be stored long term at approximately 55°
Fahrenheit. The chart below suggests the optimal serving temperatures
for different styles of wine.
°C °F Wine Style
19 66 Armagnac, Brandy, Cognac
18 64
Full Bodied Red Wines,
Shiraz
17 62 Tawny Port
15 59 Medium Bodied Red Wines
14 57 Amontillado Sherry
13 55 Light Bodied Red Wines
12 54 Full Bodied White Wines
11 52 Medium Bodied White Wines
10 50
Rosé, Light Bodied White
Wines
9 48 Vintage Sparkling
8 46 Fino Sherry
7 45 Non Vintage Sparkling
3

Vinotemp International ●[email protected] ●P: 1.800.777.8466 ●F: 310-886-3310
General Operating Instructions
Remove all external and internal packaging from your wine cooler. Be sure that
all parts have been included before discarding any packaging materials. You may
want to keep the box and packing materials for use at a later date.
Upon receipt and inspection of unit, the supply cord must be replaced if it is
damaged. Contact our customer service at 1-800-777-8466 or
[email protected].
•Let the unit rest UNPLUGGED for 24 hours once you have it placed in your
home.
•Please fully read the instruction manual.
•Save these instructions.
Please read and follow all safety rules
and operating instructions before using.
To register your product,
it:vis xhttp://www.vinotemp.com/Warranty.asp
Register your warranty within 10 days of receiving the unit.
Please be sure to retain your proof of purchase.
4

Vinotemp International ●17621 S. Susana Road, Rancho Dominguez, CA 90221
5

Vinotemp International ●[email protected] ●P: 1.800.777.8466 ●F: 310-886-3310
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS.................................................. 7
CORD INSTRUCTIONS...................................................................... 7
PARTS AND SPECIFICATIONS ........................................................... 8
WINE COOLER INSTALLATION........................................................... 9
OPERATING INSTRUCTIONS ............................................................. 9
CARE AND MAINTENANCE .............................................................. 12
TROUBLESHOOTING GUIDE ............................................................ 13
TERMS OF SALE AND WARRANTY .................................................... 14
SERVICE & IMPORTANT NOTICE ...................................................... 15
6

Vinotemp International ●17621 S. Susana Road, Rancho Dominguez, CA 90221
IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of fire, electrical shock, or injury when using your appliance,
follow these basic precautions:
•Read all instructions before using the wine cooler.
•This product is intended for household and commercial use.
•To protect against electric shock, do not immerse unit, plug or cord in water
or other liquids.
•Do not place the appliance or any of its parts near an open flame or other
heat generating appliances.
•Place the unit on a dry, level surface.
•Unit is not designed for use in a garage or basement
•Before you throw away your old wine cooler, remove the door and leave the
shelves in place so that children may not easily climb inside.
•Never allow children to operate, play with, or crawl inside the appliance.
•Never clean the appliance with flammable fluids. The fumes can create a fire
hazard or explosion.
•Do not store or use gasoline or any other flammable vapors and liquids in the
vicinity of this or any other appliance. The fumes can create a fire hazard or
explosion.
•Do not operate the cooler in the presence of explosive and/or flammable
fumes.
•Locate the cooler away from direct sunlight and sources of heat (stove,
heater, radiator, etc.). Direct sunlight will affect/alter the exterior color of the
appliance.
•To prevent damaging the door gasket, make sure to have the door opened all
the way when pulling the shelves out of the rail compartment.
•Install the wine cooler in an area where it is easy to access the cord and plug.
•Disconnect the cooler before moving to another location.
•Remove all bottles of wine inside the unit before moving the wine cooler.
•If the supply cord is damaged, it must be replaced by the manufacturer or a
certified electrician.
CORD INSTRUCTIONS
For your protection, this unit should be properly
grounded. Unit is equipped with a 3-conductor cord
set that has a molded 3-prong grounding-type plug,
and should be used in combination with a properly
connected grounding-type outlet as shown in figure A.
It is not recommended to use this wine cooler with a
extension cord or power board. Please ensure that
the appliance is plugged directly into the electrical
outlet.
n
7

Vinotemp International ●[email protected] ●P: 1.800.777.8466 ●F: 310-886-3310
PARTS AND SPECIFICATIONS
1. Top Hinge
2. Door
3. Body
4. Glass
5. Handle
6. Feet
7. Shelf
8. Top Zone NTC
9. Top Zone Fan
10. Control Panel
11. Bottom Zone NTC
12. Bottom Zone Fan
13. Grille
14. Lock
15. Power Button
16. Light Button
17. Cooling Mode Indicator Light
18. Upper Zone Display
19. Bottom Zone Display
20. Top Zone Temperature
Adjustment
21. Bottom Zone Temperature
Adjustment
Product Number VT-DS26SB149
Type 2 temp.
Bottle Capacity Approx. 154 without display shelf
Approx. 149 with display shelf
Capacity 416L (14.69 Cu. Ft.)
Voltage 115V
Frequency 60Hz
Input power 200W
Temperature control range Top Zone: 40°F – 54°F
Bottom Zone: 54°F – 65°F
Ambient temperature range 41°F – 95°F
Net weight 255.73 lbs
Gross weight 282.19 lbs
Product dimensions (WxDxH) 23.42” x 26.77” x 69.45”
Package dimensions (WxDxH) 25.59” x 29.53” x 76.77”
*Note: This wine cooler is designed to store standard Bordeaux 750 ml bottles. Storing large and/or oddly
shaped bottles (including champagne and sparkling wine bottles) will decrease the capacity of your wine cooler.
8

Vinotemp International ●17621 S. Susana Road, Rancho Dominguez, CA 90221
WINE COOLER INSTALLATION
Before Using Your Wine Cooler
•Remove the exterior and interior packing.
•Before connecting the wine cooler to the power source, let it stand upright for
approximately 24 hours. This will reduce the possibility of a malfunction in
the cooling system from handling during transportation.
•Clean the interior surface with lukewarm water, using a soft cloth.
Installation of Your Wine Cooler
•Place your wine cooler on a surface that is strong enough to support it when
it is fully loaded. To level your wine cooler, adjust the front leveling leg at the
bottom of the wine cooler.
•Locate the wine cooler away from direct sunlight and sources of heat (stove,
heater, radiator, etc.). Direct sunlight may affect the acrylic coating and heat
sources may increase electrical consumption. Extreme cold ambient
temperatures may also cause the unit to not perform properly.
•Avoid locating the unit in areas with high humidity.
•Plug the wine cooler into an exclusive, properly installed-grounded wall outlet.
Do not under any circumstances cut or remove the third (ground) prong from
the power cord.
•Any questions concerning power and/or grounding should be directed toward
a certified electrician.
OPERATING INSTRUCTIONS
The wine cooler should be placed in an area where the ambient temperature is
between 41°-95° Fahrenheit. If the ambient temperature is above or below this
range, it may affect the cooler’s ability to maintain its set temperature. For
example, placing your unit in extreme cold or hot conditions may cause the
interior temperature to fluctuate, which can make it difficult for the unit to
achieve an interior temperature within the 40°-54° F range for the top zone, and
54°-65° F range for the bottom zone.
The above temperatures may fluctuate depending on whether or not the interior
light is ON or OFF, or whether the bottles are located on the upper/middle or
lower section.
9

Vinotemp International ●[e-mail] ●P: 1.800.777.8466 ●F: 310-886-3310
The controls of your wine Cooler
•Cooling Mode Indicator Light
Indicator light illuminates to signify the cooling mode is currently in operation.
•Light
Turns the interior light on/off.
•Power
Turns the wine cooler on/off.
•“Top Zone Temperature Adjustment”
Press the button to the left of the arrow to set the temperature for the top zone.
•“Bottom Zone Temperature Adjustment” Button
Press the button to the left of the arrow to set the temperature for the bottom
zone.
•“Top Zone Display”
Displays the temperature for the top zone.
•“Bottom Zone Display”
Displays the temperature for the bottom zone.
Setting the Temperature Control
Each zone of the wine cooler (top & bottom) is independently controlled. To set
the temperature:
•Connect the power cord to a properly grounded outlet.
•In the event of a power interruption, all previous temperature settings are
automatically erased and each compartment will default to a preset
temperature setting of 43°F for the top zone and 54°F for the bottom zone.
•Set the desired temperature by pressing the “Top Zone Temperature
Adjustment” arrow and “Bottom Zone Temperature Adjustment” arrow. By
pressing either temperature adjustment button, you can increase or decrease
the temperature in the corresponding temperature zone by 1°F. The selected
temperature will flash in the temperature display screen for approximately 5
seconds; it will then display the current internal temperature of the cooler.
•Top Zone: The temperature setting can be adjusted from 40°F to 54°F.
•Bottom Zone: The temperature setting can be adjusted from 54°F to 65°F.
10
