Vintec VWM306SBA-R User manual

VWM306SBA-R, VWM306SBA-L
VWM306PBA-R, VWM306PBA-L

Contents
Warning ......................................................3
Before use ..................................................6
Reduction in energy consumption ..............6
Get to know your wine cabinet ...................7
Electrical connection ...................................9
Installation and start-up ..............................9
Installation ................................................10
Shelves and loading .................................12
Operation and function .............................14
Defrosting, cleaning and maintenance .....19
Fault fi nding ..............................................20
Warranty for Australia and New Zealand ..21
Disposal ....................................................24

As the appliance contains
a fl ammable refrigerant, it
is essential to ensure that
the refrigerant pipes are not
damaged.
The quantity and type of
the refrigerant used in your
appliance is indicated on the
rating plate.
Standard EN378 specifi es that
the room in which you install
your appliance must have
a volume of 1m³ per 8g of
hydrocarbon refrigerant used in
the appliances. This is to avoid
the formation of fl ammable gas/
air mixtures in the room where
the appliance is located in the
event of a leak in the refrigerant
circuit.
WARNING:
Keep ventilation openings in
the appliance’s cabinet or in
the built-in structure clear of
obstruction.
WARNING:
Do not use mechanical devices
or other means to accelerate
the defrosting process than
those recommended by the
manufacturer.
WARNING:
Do not damage the refrigerant
system.
WARNING:
Do not use electrical
appliances inside the
refrigerated storage
compartment, unless they are
of a type recommended by the
manufacturer.
WARNING:
This appliance is suitable for
indoor use only.
WARNING:
This appliance is not intended
for use by persons (including
children) with reduced physical,
sensory or mental capabilities,
or lack of experience and
knowledge, unless they have
been given supervision or
instruction concerning use
of the appliance by a person
responsible for their safety.
Children should be supervised to
ensure that they do not play with
the appliance.
Warning

WARNING:
Children must not clean the
appliance or carry out general
maintenance unless they are at
least 8 years old and are being
supervised.
WARNING:
Children must not play with, on,
or around the appliance.
WARNING:
This appliance contains
insulation formed with fl ammable
blowing gases. Avoid safety
hazards by carefully disposing of
this appliance.
WARNING:
Do not store explosives, such
as aerosol cans with fl ammable
propellants in the appliance.
WARNING:
When this symbol is used, it
indicates fl ammable materials
are used. To avoid relevant
hazards, it is required to carefully
dispose of this appliance.
!R600A REFRIGERANT
WARNING:
This appliance contains R600a
refrigerant. Avoid safety hazards
by carefully installing, handling,
servicing and disposing of this
appliance.
● It is hazardous for anyone
other than an Authorised
Service Person to service this
appliance. In Queensland –
the authorised Service Person
MUST hold a Gas Work
Authorisation for hydrocarbon
refrigerants, to carry out
Servicing or repairs which
involve the removal of covers.
● Ensure that the tubing of
the refrigerant circuit is not
damaged during transportation
and installation.
WARNING:
When positioning the appliance,
ensure the power cord is not
trapped or damaged.
WARNING:
Do not locate multiple portable
socket-outlets or portable power
supplies at the rear of the
appliance.

WARNING:
If the power cord is damaged,
it must be replaced by the
manufacturer, its service agent
or similarly qualifi ed persons
in order to avoid a hazard (For
Australia and New Zealand).
● Always keep the keys in a
separate place and out of
reach of children.
● Before servicing or cleaning
the appliance, unplug the
appliance from the mains
or disconnect the electrical
power supply.
● Frost formation on the
interior evaporator wall and
upper parts is part of normal
operation. Therefore, the
appliance may need to be
defrosted during normal
cleaning or maintenance.
● Please note that changes to
the appliance construction
may cancel all warranty and
product liability.
● If the supply cord is damaged,
it must be replaced by the
manufacturer, its service
agent, or similarly qualifi ed
persons inorder to avoid a
hazard.
● Do not use extension cords
● This appliance is intended to
be used exclusively for the
storage of wine.
● It is normal for some
condensation to appear on
the inside of the door when
the product is opened in
certain ambient conditions.
This condensation should
disappear after a time when
the product is operating.
CLASS 1 LED PRODUCT
WARNING:
LED lighting
Your appliance is fi tted with long
life LED lighting. In the unlikely
event the LED lights should fail,
then the LED lights should be
serviced by the service agent,
to avoid a safety hazard. Refer
to the warranty page for contact
details.

On receipt, check to ensure that the
appliance has not been damaged during
transport. Transport damage should be
reported to the local distributor before the
wine cooler is put to use. Do not remove
glass door tapes until the unit is positioned
at its fi nal location (see label at the glass
door).
Remove the packaging. Clean the inside of
the cabinet using warm water with a mild
detergent. Rinse with clean water and dry
thoroughly (see cleaning instructions). Use
a soft cloth.
If during transport the appliance has been
laid down, or if it has been stored in cold
surroundings (colder than + 5°C), it must be
allowed to stabilise in an upright position for
at least 24 hour before being switched on.
Before use
● the lower the ambient temperature.
● the warmer thermostat set point.
● the lower the number and the shorter the
length of the door openings.
The energy consumption is reduced when:
Note: for household use only
This appliance is intended to be used in
household and similar applications such as
● staff kitchen areas in shops, offi ces and
other working environments;
● farm houses and by clients in hotels,
motels and other residential type
environments;
● bed and breakfast type environments;
● catering and similar non-retail
applications.
Important Information that may
impact your Manufacturer’s
Warranty
Adherence to the directions for use in this
manual is extremely important for health
and safety. Failure to strictly adhere to the
requirements in this manual may result in
personal injury, property damage and af-
fect your ability to make a claim under the
Vintec manufacturer’s warranty provided
with your product. Products must be used,
installed and operated in accordance with
this manual. You may not be able to claim
on the Vintec manufacturer’s warranty in the
event that your product fault is due to failure
to adhere to this manual.

Get to know your wine cabinet
fi g.1
Control panel
Fans
Position 1: Fixed shelf
Positions 2-12
Telescopic shelves
Wheel
Adjustable feet
Name plate
VWM306PBA-R, VWM306PBA-L
Lock
Lighting
Door
Sealing strip

Get to know your wine cabinet
VWM306SBA-R, VWM306SBA-L
fi g.2
Control panel
Fans
Positions 1-6
Fixed shelves
Wheel
Adjustable feet
Name plate
Lock
Lighting
Door
Sealing strip

Placement
For safety and operational reasons, the
appliance must not be installed outdoors.
The appliance should be placed on a level
surface in a dry, well ventilated room (max.
75% relative air humidity). Never place the
appliance close to sources of heat such as
cookers or radiators, and avoid placing it in
direct sunlight.
Climate class is stated on the name plate.
This specifi es the optimum ambient tempe-
rature.
Installation and start-up
Electrical connection
Climate class Optimum room
temperature
SN +10 ºC to +32 ºC
T +16 ºC to +43 ºC
fi g.3
Wiring and connections in power supply
systems must meet all applicable (local and
national) electrical codes. Consult these
codes prior to cabinet installation.
Connect the appliance only to 220/240 V
/ 50Hz alternating current via a correctly
installed earthed socket.
The socket should be freely accessible.
Information regarding voltage, current or
power are given on the rating plate
The power cord may be replaced by a
technician only.
CAUTION: Never put the appliance in a
location that is too cold or unprotected, for
example in a garage or on a verandah.
The rating plate provides various technical
information as well as type and serial
number.

The surface on which the appliance is to be
placed must be level. Do not use a frame or
similar.
The appliance can be installed as a free-
standing unit against a wall, built into a
closet or lined up with other appliances.
It is important that the appliance be
well ventilated and that air can circulate
unhindered above, below and around it.
The fi gures below illustrate how the
necessary air circulation around the
appliance can be ensured (fi g 4).
Ensure the socket is accessible when the
appliance is in position, or a switch is incor-
porated in the fi xed wiring according to the
wiring rules. (See a licensed electrician for
further advice).
fi g. 4
fi g. 5
Installation
100 mm

fi g. 6
Anti-tip
It is recommended to install the supplied
anti-tip device to avoid the unit from tipping
over.
The appliance must be securely attached to
the wall by the anti-tip bracket device. The
hardware used to secure your appliance to
the wall depends on your wall material and
will need to be sourced separately to suit
the specifi c installation.
Use gloves during installation.
If there is not enough space (min 60 mm)
over the appliance turn the bracket upside
down.
Setting up
It is important that the appliance be
absolutely level. It can be levelled by
screwing the adjustable feet at the front of
the appliance up or down (fi g. 6).
Use a spirit level to check that the appliance
is absolutely level sideways.

Fixed shelf - VWM306SBA
Max. 80 kg.
fi g. 7
80
kg
Fixed shelf - VWM306PBA
Max. 65 kg.
fi g. 8
65
kg
fi g. 9
Telescopic shelf - VWM306PBA
Max. 15 kg.
15
kg
Shelves and loading

To optimise the storage capacity of your
wine cabinet it has been designed so that
only Bordeaux style bottles can be stored
on the outer position of the shelf.
The top fi xed shelf in the VWM306PBA
cabinet is designed for 2 or 3 rows of 10
bottles (20 or 30 bottles). However 3 rows
will result in approximately 3 mm defl ection
which is normal and will not damage the
shelf.

Operation and function
fi g. 9
Electronic control
The electronic control ensures that the
temperatures set at the top and at the bot-
tom of the appliance are maintained. This is
achieved by means of an advanced control
of the refrigeration system, the heating ele-
ment, and the fan. The set temperature will
be stored in the event of power failure.
The electronic control has the following
functions:
● Light switch *
● Temperature setting
● Temperature indication
● Alarm for too high and too low tempera-
tures
● Door alarm / Filter alarm
● Muliti / Single / Cellar mode
● Child lock
● Sabbath mode
* The light may either be turned on
constantly or only when the door is open.
4 diff erent modes- 9 levels for lighting.
Temperature indication
The display shows the actual temperature.
The left digits of the display indicate the
temperature at the top of the appliance, and
the right digits of the display indicate the
temperature at the bottom of the appliance.
Upper temperature set
Single press the up or down arrow to
decrease/increase the Set
temperature. First press shows the current
Set temperature and don’t increase/
decrease it. The numbers blink to indicate
that they are being changed. After 5
seconds without any interaction with the
“-/+”, the numbers stop blinking and show
the Current temperature.
Bottom temperature set
Single press the up or down arrow to
decrease/increase the Set
temperature. First press shows the current
Set temperature and don’t increase/
decrease it. The number blinks to indicate
that it is being changed. After 5 seconds
without any interaction with the “-/+”,
the numbers stop blinking and show the
Current temperature.
Mode Set temp. Upper temp. Bottom temp.
Alerts Set temp. Light
Upper zone Bottom zone.

Lights On/Off
Single press to turn the lights ON/OFF.
If Off , the light is always off (door opened
or closed). If On, light behaviour goes to
previous setting )1A-4A/ 1L-9L).
Lights settings menu
Press & Hold for 3 seconds to enter/exit
Lights settings menu.
Both temperature displays blink and show a
specifi c code.
Single press to increase/decrease the
“level”.
Lights behaviour
Upper temp. display shows the, diff erent
light mode.
1A: Lights always ON at highest dim
level when door is open. Changing to the
selected dim level immediately when the
door is closed (500ms).
2A: Lights always ON at highest dim level
when door is open (500ms) Turning OFF
immediately when the door is closed
(500ms).
3A: Lights always ON at selected dim level
when door is open and closed.
4A: Lights always ON at selected dim level
when door is open (500ms) changing to the
highest dim level when the door is closed
(500ms).
Default Factory settings:
Light Behavior: 1A
Dim Level: 9L
Lights dim level
Bottom temp. display shows the, light level
1L: Lowest level / least bright
2L:...
9L: Highest level / most bright
Child Lock
Press & Hold for 3 seconds on Mode to
activate/deactivate child lock.
Child lock feedback. It lit-up when Child lock
is activated.
Sabbath mode Activation
Press&Hold simultaneously the increase
top temperature arrow and the decrease
bottom temperature arrow for 5 seconds.
When activated, Bottom & Upper temper
displays shows and blinks “Sb” & “On” for 5
seconds and then shows "Sb" & "On" till the
Sabbath mode is deactivated.
All button commands are disabled except
the increase top temperature and decrease
bottom temperature combination command
used to deactivate the Sabbath mode.
All alerts will not be displayed until the
Sabbath Mode is deactivated, except the

High/Low Temperature alert. This alert will
display in case of a high or low temperature
inside the appliance. The alert icon will turn
on, but will not blink and will remain on till
Sabbath mode is deactivated. An audio
alarm will sound for 10 minutes and will
then shut off automatically.
Sabbath mode deactivation
Repeat the steps used for activation.
Upper and Lower temperature displays will
blink "Sb" & "Of" for 5 seconds and then the
displays revert to normal.
°C/°F set
Single combined press on increase bottom
temperature set & Light button to change
the temperature type (°C/F°).
When °C is set, Bottom & Upper
temperature display shows and blinks °C &
°C for 5 seconds.
Any alert turns off temporarily.
When F° is set, Bottom & Upper
temperature display shows and blinks “F°”
& “F°” for 5 seconds.
Any alert turns off temporarily.
Reset Filter alert
Press & Hold combined on Mode &
decrease bottons for 5 seconds to reset the
fi lter change counter.
If the alert is on, it turns off .
Single/Muliti/Cellaring zone set
Single press Mode to change the Single
zone, Multi zone, and Cellaring mode.
If the mode set is Single, the Single zone
feedback will light-up, and blink and both
temperatures change to 18°C. After 5
seconds without any interaction wih the
Mode button, the Single zone feedback
stops blinking and keeps steady, and both
temperatures show the current temperature.
In Single zone mode, both temperature
controls will work in sync.
If the mode set is Multi, the Multi zone
feedback will light-up, and blink and the
upper temperature changes to 18°C and
8°C on the bottom. After 5 seconds without
any interaction with the Mode button, the
Multi zone feedback stops blinking and
keeps steady and both temperatures show
the current temperature.
In Multi zone mode, each temperature
control will work separately.

If the mode set is Cellaring, the Single and
Multi zone feedback will be Off , and Bottom
& Upper temperature display shows “CE” &
“CE” blinking. After 5 seconds without any
interaction with the Mode button, the ”CE”
stops blinking and keeps showing ”CE” until
the Cellaring mode is deactivated.
In Cellaring mode, the temperature is fi xed
and can not be changed - 12°C.
Demo mode
Press & Hold combined on Mode & Lights
buttons for 5 seconds to activate/deactivate
Demo mode.
When activated, the bottom & Upper
temperature display shows and blinks ”dE &
”ON” for 5 seconds.
Any alert turns off temporarily.
To keep communication that the machine
is in Demo mode, - every 5 minutes the
Bottom & Upper temperature display shows
and blinks ”dE & ”OF” for 5 seconds.
When deactivated, Bottom & Upper
temperature display shows and blinks ”dE”
& ”OF for 5 seconds.
Any alert turns off temporarily.
Mute sounds
Press & Hold combined on decrease
bottom temperature set & Light buttons for 5
seconds to activate/deactivate Mute sounds.
High / Low temperature alert
If the Current temperature is 5°C above the
Set temperature for more than 60 minutes,
High Temperature alert shows “Hº” and
blinks the alert icon.
If the Current temperature is 2°C below the
Set temperature for more than 60 minutes,
Low Temperature alert shows “Lº” and
blinks the alert icon.
The alerts will not sound in the fi rst
90 minutes after power on.

Door open alert
When the door stays open for some amount
of time (5 minutes) the icon turns On and
the lights start to dim up and down. If
the door is kept open, after more than 2
minutes a sound is played.
Any interaction on the Control panel
disables the blinking and audio signal. The
icon stays on as long the door is open and
the lights go back to normal.
Change fi lter alert
After 6 months the icon turns On.
See "Reset" fi lter alert, to know how to reset
the alert. After reset, the icon turns Off and
the count is reset.

Automatic defrosting
The wine cabinet is defrosted automatically.
Defrost water runs through a pipe and is
collected in a tray above the compressor
where the heat generated by the compres-
sor causes it to evaporate. The defrost
water tray should be cleaned at intervals.
Cleaning
Before cleaning the appliance, unplug it
from the main supply. The cabinet is best
cleaned using warm water (max.65°C) with
a little mild detergent. Never use cleaning
agents that scour. Use a soft cloth. Rinse
with clean water and dry thoroughly. The
defrost water channel, in which condensa-
tion from the evaporator runs, is located
at the bottom of the rear inside wall of the
cabinet and must be kept clean. Add a few
drops of disinfectant, to the defrost water
drain a couple of times a year, and clean
the drain using a pipe cleaner or similar.
Never use sharp or pointed implements.
The sealing strip around the door must be
cleaned regularly to prevent discolouration
and prolong service life. Use clean water.
After cleaning the sealing strip, check that it
continues to provide a tight seal.
Dust collecting on the condenser on the
rear of the cabinet, the compressor and
in the compressor compartment is best
removed using a vacuum cleaner.
Defrosting, cleaning and maintenance
Spare parts
When ordering spare parts, please state
the type, serial and product numbers of
your appliance. This information is given on
the rating plate. The rating plate contains
various technical information, including type
and serial number.
fi g. 10
