Vip-Vision VSIP2MPVDIRFV2 User manual

VDIRFV2 Series
Camera Quick Install Guide
Version 290517
Available in 2.0MP & 4.0MP
Applicable Models
VSIP2MPVDIRFV2 2.0MP H.265 WDR Infrared Fixed Wedge Dome (3.6mm)
VSIP4MPVDIRF2.8V2 4.0MP H.265 WDR Infrared Fixed Wedge Dome (2.8mm)
VSIP4MPVDIRF3.6V2 4.0MP H.265 WDR Infrared Fixed Wedge Dome (3.6mm)
VSIP4MPVDIRF6.0V2 4.0MP H.265 WDR Infrared Fixed Wedge Dome (6.0mm)
Thank you for purchasing a VDIRFV2 Series CCTV Surveillance Camera.
This Quick Install Guide covers basic setup, installation and use of your surveillance system.
For the full user manual, instructional videos, tips on using your surveillance system &
warranty information, please visit: www.vip-vision.com

2
Crucial evidence. Always.
VDIRFV2 Series | Surveillance Cameras
Electrical safety
• All installation and operation here should conform to your local electrical safety codes.
• Check that the power supply is correct before operating the camera.
•Ensure the power supply conforms to the requirement in the SELV (Safety Extra Low Voltage) and the
Limited power source is rated DC 12V or AC 24V in the IEC60950-1. (Power supply requirement is subject
to the device label).
• Do not install wiring while the camera is powered on.
•Prevent the power cable from being trampled or pressed, especially the plug, power socket and junction.
•We assume no liability or responsibility for any fires or electrical shock caused by improper handling or
installation.
•We assume no liability or responsibility for any problems caused by unauthorized modification or
attempted repair.
Environment
•Do not aim the camera at strong light (such as lighting, sunlight, etc) to focus; this may cause overexposure,
which will affect the longevity of the CCD and/or CMOS.
• Transport, use and store the camera within the specified range of humidity and temperature.
•Do not store the camera in a wet, dusty, extremely hot, or extremely cold location, or in an area with
strong electromagnetic radiation or unstable lighting.
• Do not allow water or other liquids to fall into the camera; this may damage internal components.
•Do not allow water or other liquids to make contact with indoor cameras (cameras with no IP rating); this
may damage the camera or cause fire/electrical shocks.
• Keep the camera well ventilated in case of heat accumulation.
•Pack the camera with the included factory packaging (or material of similar quality) while transporting
to prevent damage.
• While being transported, stored or installed, ensure the camera does not experience heavy stress, strong
vibration or liquid contact .
Warning
• Change the default password after login in order to avoid unauthorised access.
•Install the camera using the standard accessories provided by the manufacturer and make sure the
device is installed and fixed by professionals.
• Keep the camera away from laser beams while using a laser device.
•Do not connect two power sources to the device at the same time; this may result in damage to the
camera.
Statement
• Refer to the actual product for more details; the manual is just for reference.
•The manual will be regularly updated as the product updates; the updated content will be added to the
manual without prior announcement.
• Contact the supplier or customer service if there is any problem occurred camera using the camera.
• Contact the supplier or customer service for the latest procedure and supplementary documentation.
•Actual value of some data and the value provided in the manual may differ due to environmental
differences, etc.
• VIP Vision is not liable for any damages caused by operation which is not followed in the manual.
Safety Information

3
www.vip-vision.com
VDIRFV2 Series | Surveillance Cameras
FCC Information
Operation and Daily Maintenance
• Do not touch the heat dissipation component of the camera directly in order to avoid burns.
• Do not dismantle the device; there is no component which can be fixed directly by users in the camera.
Contact the supplier to replace desiccant if it becomes green.
• Grounding the camera is recommended to enhance the reliability of it.
• Do not touch the CCD (CMOS) optic component directly. Use an air duster to clean dust or dirt on the lens
surface, or use a cloth lightly wet with alcohol to wipe away dust gently.
• Use a dry soft cloth to clean the camera. If there’s a large amount of dust, use a mild detergent diluted
with water first. Don’t use volatile solvents such as alcohol, benzene, thinner or strong detergents, as this
may damage the surface coating or damage the camera.
• To clean the lens, use a dry soft cloth to wipe water or oil gently until dry, then use an oil-free cotton cloth
or paper soaked with alcohol/detergent to wipe from the centre of the lens outwards.
FCC conditions
• This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including interference that may cause undesired
operation.
FCC compliance
• This equipment has been tested and found to comply with the limits for a digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference. This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to
radio communication. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced technician for help.
Note: Refer to the disk for more details, check and download corresponding user’s manual and tool.
Before installation, open the package and check that all components are included. If any components are
broken, contact your local supplier.

4
Crucial evidence. Always.
VDIRFV2 Series | Surveillance Cameras
Port Name Function
1 Internet access Network data in/out and PoE
2 Power input Power input port (optional)
3 Audio input Input audio signal, receives analog audio
4 Audio output Output audio signal to speakers, etc
5 Alarm input Receive on-off signal from external alarm source
6 Alarm output Alarm signal sent to alarm device
7 Alarm ground terminal Ground terminal
8 Mobile aviation port Network data in/out and PoE power supply
Connection ports
Dimensions
Included Components
1 x VDIRFV2 Series IP Camera
1 x Quick Start Guide
1 x
Installation Accessories Bag:
• Position installation map
• Expansion bolts
• Self-tapping screws
• Screwdriver
1 x CD
1. Pre-install Information

5
www.vip-vision.com
VDIRFV2 Series | Surveillance Cameras
Here, will we walk through the installation process of your “VDIRFV2 Series” camera. We will show
you how to set up and adjust your camera, all included components and how to get it up and run-
ning. Be sure to check the Pre-install Information to have an understanding of the included compo-
nents, dimensions, and connection ports.
2. Camera Installation
1. Install the microSD card. (Optional, see 1.2 Accessing the microSD card slot).
2. Loosen M4 x 20 screws and take down the dome enclosure.
3. Position the installation map to a wall or ceiling and drill holes where marked.
4. Insert the expansion bolts into the drilled holes.
5. Adjust the dome pedestal according to the top or side outlet.
6. Tighten tapping screws into the expansion bolts to fix the camera to the surface.
7. Tighten the M4 x 20 screws and fix the enclosure on the dome pedestal.
8. Plug in the external cables according to usage requirements.
9. Adjust monitoring direction of the device (See 1.3 Adjusting the camera angle).
10. Setup your alarm system (See 1.4 Alarm setup).
11. Setup is complete!
2.1 Position the camera

6
Crucial evidence. Always.
VDIRFV2 Series | Surveillance Cameras
1.2 Accessing the microSD card slot (optional)
1.2.2 Advantages of the microSD
1. Locate the lower cover on the bottom of the camera and open it.
2. Install the microSD card into its dedicated slot, making sure it’s properly secured.
3. Replace the lower cover.
1.2.1 Installing the microSD card
Note: Having a standalone microSD card will not ensure that you have the same quality playback, nor
the capacity compared to a separate NVR or storage device.
The microSD card is useful for anyone who wishes to have another way to back up storage, or is on a
budget and doesn’t have a recorder. The microSD card is placed inside of the camera, and can hold
a set amount of storage (dependent on size of card) for any intended use, such as: video playback,
storage, backup etc.
The microSD card utilises “Edge Recording”. This is when the camera records video directly onto the
installed card in the camera, instead of a separate NVR or storage device. This gives the user more
flexibility in recording video.

7
www.vip-vision.com
VDIRFV2 Series | Surveillance Cameras
• Loosen the locking screw(s), the lens horizontal adjustment can be directly adjusted manually.
• For vertical adjustment, get the inner hex wrench and insert into the lens surface, then rotate it to adjust.
• Tighten the locking screw(s) firmly after adjustment is completed.
Note: The range of lens adjustment angle: horizontal rotation direction (-30°~+30°), vertical rotation direction (0°~+80°),
image rotation direction (0°~+360°).
1.3 Adjusting the camera angle

www.vip-vision.com
Note:
This quick install guide is for reference only. Slight difference may be found in user interface.
All the designs and software here are subject to change without prior written notice.
If there is any uncertainty or controversy, please refer to the final explanation of us.
Please visit our website or contact your local service engineer for more information.
For the full user manual, instructional videos, tips for using your surveillance system and
warranty information, please visit:
Your local VIP Vision™ IP solutions professional: www.activeonline.com.au 1300 816 742
