viparspectra KS5000 User manual

660NM Diodes
LM301H Diodes
USER INSTRUCTIONS
Manual Version: 2022-1-8-001-002
Contact Us:
Follow us on Facebook @ViparSpectra
Sending an email to [email protected]
Contact us via Amazon or eBay message.
www.viparspectra.com

SAFETY INFORMATION
1 2
Dear Users,
Thank you for choosing our products! Please read this instruction carefully before
using your lights.
1. CAUTION: Do not look directly at the LED bulbs when the lighting equipment is
working.
2. The maximum temperature of the installed environment (ambient temperature) will
ensure the safe operation of the lighting equipment. So you will need to control the
temperature within the installed environment. (Example: mechanical ventilation or
cooling system is required to maintain the temperature within the growing space
below 104°F (or 40°C) when the lighting equipment is in operation).
3. Instructions to guide the installation such that cords:
4. This lighting equipment is for indoor use only. Not water-proof, protect your
lighting equipment from dampness, dust, and water.
5. CAUTION: For horticultural lighting structures, installation shall be performed by
qualified personnel and that the structures are intended for installation subject to
approval by the authority having jurisdiction.
6. Set up your light in the operating environment that allows for adequate air
circulation. Never push objects into the ventilation openings.
7. When cleaning the outside of your light and its components, first, you need to shut
off your light, then unplug the power cord. Using a clean, soft, lint-free cloth to wipe the
light. Avoid getting moisture in any openings.
8. CAUTION: Possibly hazardous optical radiation emitted from this product. Do not
stare at the operating lamp. May be harmful to the eyes.
Are not concealed or extended through a wall, floor, ceiling, or other parts of the building structure,
Are not located above a suspended ceiling or dropped ceiling,
Are not permanently affixed to the building structure,
Are routed so that they are not subject to strain and are protected from physical damage,
Are visible over their entire length, and
Are used within their rated ampacity as determined for the maximum temperature of the installed
environment specified in the instructions.
KS5000
Total Harmonic Distortion
Frequency
Input
LEDs
Actual Power Draw
Feature
Model
50/60Hz
AC100-240V~4.6A
< 15%
500W±3% at 120V
Dimmable
KS5000
SAMSUNG LM301H 3000K, 5000K
OSRAM 660NM
Lifespan
Item Weight
Housing Dimensions
Use for
Flowering Coverage at 16"
Vegetative Coverage at 28"
HID Replacement 1000W HPS/MH
≥ 100,000 hours
12.8 lbs
40 × 40 × 1.6 inches
all stages grow and flowering
4.0 × 4.0 ft
4.0 × 4.0 ft
KS5000 SPECIFICATION
PLANTING SUGGESTIONS
( µmol/m²/s )
Seedlings - You will need to hang the light high due to the delicate nature of seedlings. We
recommend a break-in period of about a week while a seed has broken the surface. The
first set of real leaves should be present while the seedling has been above ground for
about a week.
Clones - Clones are a little bit hardier than fresh seedlings, but still, need to be given gentle
light as they are entirely rootless when first cut, and need to conserve energy and moisture
to transition into a rooting stage.
Vegetative - The deeper red spectrum is utilized less by the plant than when it is in flower.
It uses high levels of white light that are essential for creating lush, thick plants that have
tight internodal spacing and minimal stretching.
Flowering - The plant has much work to do and is preforming many complex biological
processes in producing flowers and fruits. Because of this, the plant now requires large
amounts of light.
Late Flower - Most rapid development has stopped, and the plant is gearing up for the
scene in which the large flowers and fruits will mature or ripen.
If you expose plants to high light intensities too early in the crop cycle, you can damage
chlorophyll pigments causing photo-oxidation (photo-bleaching), so we recommend
slowly increasing your light intensity as your plant develops.
Seed Vegetative Cutting Vegetative Flower / Fruit /
Reproductiv
Species
Canna Plants 200-400 75-150 400-600 600-1000 (No CO2)
Tomatoes 150-350 75-150 350-600 600+
Cucumbers 100-300 - 300-600 600+
Peppers 150-350 - 300-600 600+

43
MOUNTING INSTRUCTIONS
4. Hang up each rope ratchets
in a safety mounting location
and raise them to the desired
hanging height.
1. Unfold your light fixture and
place it on the floor with the
LEDs facing downward.
2. Attach the rope ratchets to
each hanging hole on the light.
1.Mounting
Option 1 (Recommended)
Place the LED driver in a safety location outside the grow tent.
Option 2
Hang up the LED driver in a safety location in the grow tent.
KS5000 Product suspension diagram
3 4
1 2
* Light housing's temps would become higher after working several hours. Do not touch the operating lamp.
* SUITABLE FOR OPERATION IN AMBIENT NOT EXCEEDING 104°F (or 40°C).
USING SUGGESTIONS
Tested in a 4.0 x 4.0 ft Grow Tent
4 ft
4 ft
Seedling: 50% Distance: 30" (77cm)
397 393391371 380 365 369353
384 382377360 371 357 356347
368 369358350 362 353 335324
350 359347327 357 332 321326
403 398397381 384 372 372357
403 398399384 386 370 367366
397 390394380 379 363 355361
379362 379 375 363 353 325336
402
591 581584
560
550
529 565 551
559
530
535
520
516
490
589 583577540 565 534 536503
573 566560525 550 523 513498
546 541530510 529 511 480464
532 530513501 520 500 460468
601 593591560 573 550 542509
602 591591561 570 542 530520
515
484
601
Vegetative Stage:75% Distance:28"(70cm)
KS5000 PPFD MAP
Seedlings / Clones / Mother Plants Vegetative Stage Flowering StageKS5000
Brightness
Average PPFD
Using Hours
Maximum PPFD
Power Draw
Hanging Height (Above Plant)
50%
367 µmol/m²/s
18 on / 6 off
403 µmol/m²/s
30'' (77cm)
250 Watts
75%
540 µmol/m²/s
602 µmol/m²/s
28'' (70cm)
375 Watts
100%
833 µmol/m²/s
18 on / 6 off 12 on / 12 off
1000 µmol/m²/s
16'' (40cm)
500 Watts
Flowering Stage:100% Distance:16"(40cm)
Visit our website for more useful suggestions
and PPFD Maps.
999 976996
923
895
845 939 917
928
864
834
810
710
682
994 971977870 934 845 707697
963 940945838 898 818 717693
821 824806743 800 733 638619
801 816785720 750 721 618620
985 963969863 924 836 703703
992 967978873 925 833 705723
741
685
979
1000
Hanging Height: 16’’ (40cm)
Ave. PPFD: 833 µmol/m²/s
1000 µmol/m²/s
MAX PPFD:
1200 µmol/s
Usable PPF:
500W
Power Draw:
2.40 µmol/J
Usable PPE:
Usable PPE: 2.40 µmol/J
1000
1000 1000

WARRANTY TERMS
1. This warranty applies only if you purchased your products in the United States.
2. We offer 3 years warranty for our KS Series LED grow lights purchased against
manufacturing defects from the date of purchase. If you need any warranty assistance,
please contact us as soon as possible.
3. The warranty does not cover damage due to high moisture levels, water, power
surges, improper hanging or mounting, incorrectly use, dust build-up, or user
modifications.
4. If your light has any quality issue within 30 days, please kindly contact us. We will
email you a prepaid return label if the lights need to be returned to our warranty
center. You can choose:
5. Repairing. If any light has any quality issue over 30 days after delivery, please kindly
contact us to get a satisfactory solution. We can send the part free of charge
immediately if it is missing part or accessory issue. Or you also can choose to return the
light with the provided prepaid shipping label. We will send the light back to you after
fixing it — all for free.
6. Forcustomers outside the US, you will also enjoy 3 years US warranty. Back and forth
shipping cost from your country to our US warranty center would be buyer's
responsibility. All repairs are only processed within the United States.
7. If a light was not covered under warranty, we might still be able to perform warranty
service. However, that is at our discretion, and repair may bear a cost that will be
assessed before repairing the light.
Our company reserves the interpretation right of this warranty structure. If you have
any questions about our warranty policy, please kindly contact us.
Replacement. Please send the light back to our warranty center. A new
replacement will be shipped to you for free as soon as we receive the
defective light.
Money-Back. Please send the light back to our warranty center. You will get
your money back as soon as we receive the defective light.
Repairing. We can send the part immediately if it is missing part or
accessory issue. Or you also can choose to return the light. We will send the
light back to you after fixing it. It will not cost any repair charge — all for free.
MOUNTING INSTRUCTIONS
3.Connect LED Driver to Light(s)
3. Adjust the brightness based
on your desired light intensity
needs.
1. Connect the driver power
cord to the light. To remove the
connection, twist the locking
ring counter clockwise and pull.
2. Plug the light into an outlet.
First Driver
Third Driver
Second Driver
(1) Connect Output onthe first driver to Input on the next driver in the lighting system chain.
(2) Repeat until all drivers are connected.
(3) Adjust to EXT on all drivers except the first driver.
(4) All fixtures in the chain are controlled by the first driver.
* You can connect unlimited fixtures.
4. Connecting Multiple Fixtures
Side view
Input and Output
Controller
(Not included in the package)
KS enables integration with most third-party 10V PWM controllers.
(1) Connect Output on the Controller to Input on the first driver in the lighting system chain.
(2) Repeat “4. Connecting Multiple Fixtures.”
* Your controller decides how many products can be connected.
5. Use with a Controller
The order ofthe network cables ofOutput on your controller
MUST be conslstent with the order of the network cables of
Input on our driver.
1 2 3 4 5 6 7 8 9 10 11 12
1 & 6: PWM IN
7 & 12: PWM OUT
3 & 4: V-OUT
9 & 10: V-IN
2, 5, 8 & 11: GND
