viparspectra Timer Control TC450 User manual

02
Setting system with Remote
For flowering stage: use all channels with 100% brightness.
This light includes IR (Infrared) LEDs which look dim/invisible, they are not faulty LEDs.
One fan will work while VEG channel on, the rest one fan will work while BLOOM channel on.
The digital display will be turned off so it will not illuminates/emits blue light during light off-working time.
MODEL: TC450
USER INSTRUCTIONS
Timer Control Series
www.viparspectra.com
Height (above plants' canopy) Using Hours Brightness (VEG/BLOOM)
10 on / 14 off 40 / 15
60 / 30
100 / 60
100 / 100
36" - 40"3-5 days acclimation period
Seedlings/ Young vegetative
Vegetative Stage
Flowering Stage
32" - 36"
24" - 32"
18" - 24"
12 on / 12 off
12 on / 12 off
18 on / 6 off
TC450
IR3pcs look dim
Step 1. Remove the plastic separator from the battery.
Step 2. Press to turn on the light.
Step 3. Press to setup brightness for VEG channel. Using and , select the
desired brightness. Press to save settings.
Step 4. Press , repeat step 3 to setup brightness for BLOOM channel.
Step 5. Press to setup current time of day, the hour will flash. Using and ,
select the desired hour. Press or to save the hour and activate the minutes.
Using and , select the desired minutes. Press to save settings, or wait
about 3 seconds and the programmed time will be automatically saved.
OK
OK
VEG
BLOOM
CLOCK
Step 6. Press to setup light's start-working time, the hour will flash. Using and
, select the desired start-working hour. Press or to save the hour and
activate the minutes. Using and , select the desired minutes. Pressto
save settings, or wait about 3 seconds and the programmed time will be automatically
saved.
Step 7. Press , repeat step 6 to setup light's off-working time.
Step 8. Press to confirm that the system has saved the desired start-working and
off-working time.
PREVIEW
ON
OFF
OK
Using Suggestions
PREVIEW
OK
VEG BLOOM
ON CLOCK OFF
VIPARSPECTRA
To setup brightness for
BLOOM channel.
To setup light's start-working
time.
To setup light's off-working
time.
To setup brightness for
VEG channel.
To setup current time of day.
To turn ON/OFF the light.
To increase value.
Switch to other setting.
To decrease value.
Switch to other setting.
To save settings.
To preview start-working
and off-working time.
Note: Timer controls both channels on/off together. Cannot turn VEG and BLOOM channel
on/off separately.
Adjust the height and brightness accordingly to desired coverage and how well each individual
plants responds as the brightness increases. The key is to always observe your plants and listen
to what they're telling you. If the leaves are pointing hard towards the light, they love it! Give
them more! If they shy away or appear limp and unhappy, while all other components and
environmental variables are correct, back off with the light! They'll let you know very quickly how
they feel. This is of course... the key to horticulture in general.
The following section will help guide you in the process of evaluating the best methods
for each stage of plant growth. Like many other growers, you can use this light throughout
the seeding and flowering stages of your plants life. Remember to properly adjust the height
and brightness of your light according to your plants desired level for optimal growth.
Specifications:
Model:
LED Power:
Actual Power Draw:
LED Quantities:
Total Harmonic Distortion:
Input Voltage:
Frequency:
TC450
450W
110V: 205W±3%; 220V: 200W±3%
90pcs Epiled/Bridgelux LEDs
AC100-240V
50-60Hz
HID Replacement:
Vegetative Coverage at 24":
Flowering Coverage at 18":
Use for:
Housing Dimensions:
Item Weight:
Lifespan:
400W HPS/MH
2.5x2.5ft
2x2ft
all stages grow and flowering
19.7 x 8.5 x 2.8 inches
50 x 21.5 x 7 cm
10.5 lbs
≥100,000 hours
15%
<

Setting system with Control Knob
flashing select desired hour
brightness
press the knob
press the knob
same method as setting
same method as setting
clockwise
clockwise
to increase value
select desired
brightness
to decrease value
counterclockwise
press the knob
press the knob
rotate
the knob
rotate
the knob
rotate
the knob
rotate
the knob
select desired minuteflashing
to decrease value
rotate
the knob
press
the knob
clockwise
to decrease value
rotate
the knob
same method as setting
Sub-menus of “H-SE”:Main menus:
: VEG channel
: BLOOM channel
: Timer setting
: Start-working time
: Off-working time
: Current time
Digital Display OVERVIEW
Setting Process
Press the knob to start
counterclockwise
to increase value to increase value
counterclockwise
NOTE:
1. Keep pressing the knob around 3 seconds can turn off the light.
2. System will save settings and back to superior menu if no action within 3-5 seconds.
3. Timer controls both channels on/off together. Cannot turn VEG and BLOOM channel
on/off separately.
Action Function
Press the knob
Rotate clockwise
Rotate counterclockwise
1. power on/off 2. change mode 3. save settings
1. enter mode 2. increase value (+1)
1. enter mode 2. decrease value (-1)
Actions OVERVIEW
wait about 3-5 seconds to
save desired start-working
time and go to next step
press the knob to save
desired brightness and
go to next step
WARRANTY TERMS
Customer Service
Email: [email protected]
Phone: [phone](United States)
1.We offer three years warranty, from the date of purchase, for all of our products purchased
against manufacturing defects. If you need warranty assistance, please contact us as
soon as possible.
2.The warranty does not cover damage due to high moisture levels, water, power surges,
improper hanging/mounting, improper use, dust build-up or user modifications.
3. For USA buyers, if any lights stop working within 30 days, you can choose:
(A) Exchange. We will email you a prepaid return label, please ship the light back to our
USA warranty center. A replacement will be sent to you for free as soon as we receive the
defective light.
(B) Money back. We will email you a prepaid return label, please ship the light back to
our USA warranty center. You will get your money back as soon as we receive the defective
light.
(C) Repairing. We can send parts free of charge immediately if you’d like to repair simple
defect. Or we will email you a prepaid return label to bring light back, then ship back to you
after we repair it. All for free.
4. For buyers outside of the USA, if any lights stop working within 30 days, you can choose:
(A) Exchange. Please ship the light back to our warehouse, buyer pays return shipping.
A replacement will be sent to you for free as soon as we receive the defective light.
(B) Money back. Please ship the light back to our warehouse, buyer pays return shipping.
You will get your money back as soon as we receive the defective light.
(C) Repairing. We can send parts free of charge immediately if you’d like to repair simple
defect.
5.To all customers: if any lights stop working over 30 days after delivery, please contact us
to get a satisfactory solution.
6.If a light is sent in with damage that is not covered under warranty, we may still be able to
offer warranty service, however that is at our discretion and repairs may bear a cost which
will be assessed prior to repairing the light.
7. Our company reserves the interpretation right of this warranty terms. If you have any
questions about our warranty policy, please contact us.
