viparspectra Timer Control Series User manual

MODEL: TC900S
Timer Control Series
For flowering stage: use all channels with 100% brightness.
This light includes IR (Infrared) LEDs which look dim/invisible, they are not faulty LEDs.
8pcs IR look dim
This product is UL Certified.

PART I Safety Information
1. CAUTION: UV and IR emitted from this lighting equipment, do not look directly at the LED
bulbs when the lighting equipment is working. This lighting equipment has passed Risk
Group 2 (IEC 62471).
2. CAUTION: The minimum required distances between adjacent lighting equipment is
4 inches(10cm) and between the lighting equipment and combustible materials is
40 inches(100cm) such as walls, ceilings, movable partitions, and the like (providing
this installation limitations are needed to prevent overheating of lighting equipment or
combustible materials within the installation environment).
3. The maximum temperature of the installed environment (ambient temperature) that will
ensure safe operation of the lighting equipment. So you will need to control the
temperature within the installed environment. (Example: a mechanical ventilation or
cooling system is required to maintain the temperature within the growing space below
104°F (or 40℃) when the lighting equipment is in operation).
4. Instructions to guide the installation such that cords:
a. Are not concealed or extended through a wall, floor, ceiling, or other parts of the
b. Are not located above a suspended ceiling or dropped ceiling,
c. Are not permanently affixed to the building structure,
d. Are routed so that they are not subject to strain and are protected from physical damage,
e. Are visible over their entire length, and
f . Are used within their rated ampacity as determined for the maximum temperature of
building structure,
the installed environment specified in the instructions.
5. This lighting equipment is Indoor use only. Not water-proof, protect your lighting equipment
from dampness, dust and water.
2
6. CAUTION: For horticultural lighting structures, installation shall be performed by qualified
the authority having jurisdiction.
personnel and that the structures are intended for installation subject to approval by
9.When cleaning the outside of your light and its components, first you need to shut off your
7.Set up your light in the operating environment that allows for adequate air circulation.
Never push objects into the ventilation openings.
light, then unplug the power cord. Using a clean, soft, lint-free cloth to wipe the light.
Please be aware of getting moisture or damage in any openings.
120V: 405W±3%
180pcs Epiled/Bridgelux LEDs
AC120V
60Hz
4x4ft
3x3ft
all stages grow and flowering
Vegetative Coverage at 32":
Flowering Coverage at 24":
Use for:
16.5 x 16.5 x 3 inches
42 x 42 x 7.5 cm
15.7 lbs
＜15%
Package includes:
1 x TC900S LED Lighting
1 x Hanging Kit
1 x 6ft Power Cord
1 x Remote
2pcs Adjustable Rope Hangers
10. CAUTION: Possibly hazardous optical radiation emitted from this product. Do not stare at
operating lamp. May be harmful to the eyes.
INSTALLATION INSTRUCTIONS
TC900S
Two fans will work while VEG channel on, the rest one fan will work while BLOOM channel on.

SETTING WITH REMOTE
SETTING SYSTEM WITH REMOTE
The following section will help guide you in the process of evaluating the best methods
adjust the height of your light according toyour plants desired level for optimal growth.
TC900S Height (above plants' canopy) Using hours Brightness (VEG/BLOOM)
3-5 days Acclimation Period
Seedlings/Young Vegetative
Flowering Stage
44"-48" 10 on / 14 off
12 on / 12 off
12 on / 12 off
40"-44"
32"-40"
24"-28"
4
3
for each stage of plant growth. Like many other growers, you can use this light
throughout the seeding and flowering stages of your plants life. Remember to properly
Using Suggestions:
18 on / 6off

SETTING SYSTEM WITH CONTROL KNOB
6
5

8
VIPARSPECTRA 1/8'' Adjustable Rope Hanger
Installation Instruction:
Adjust to the desired height by simply pulling the loose rope end.To release,
hold the loose rope end and depress the lever recessed in the Rope Hanger.
7
PART II Installation Instructions
1. Remove this lighting equipment from packaging.
2. Joining the buckles to the hanging holders one by one.
3. Hanging the light on a hard, stable bracket or the ceiling of grow tent with the carabiner.
4. Install this lighting equipment above your plants - Do not proceed unless it's safely and
securely mounted.
5. Plug power cord into this lighting equipment (do not plug into wall yet).
6. Rotate counterclockwise to turn off the dimmer knob.
7.
INSTALLATION ROPE HANGER INSTALLATION
Rope hanger
Power on this lighting equipment by plugging into wall socket and turn on the dimmer knob.

9
Purchase date
WARRANTY TERMS
WARRANTY TERMS
For USA buyers, if any lights stop working within 30 days, you can choose:
