Viper DRAGON Series User manual

www.viperind.com
IMPORTANT: READOWNERSMANUALCAREFULLY
DRAGONSERIES
SERIAL#
MODEL# DR1500H
Pleasefillout&returnyourwarrantycard!
OWNERSMANUAL
VIPER
HIGHSPEEDS
VF41528HK
REV.00(05-07)
VIPER...exceptional
value
VIPERINDUSTRIALESTATE
TEL: [phone]
LIANGBIAN,LIAOBU
DONGGUAN,GUANG DONG
CHINA
FAX: [phone]

CONGRATULATIONSon yourpurchaseofaViper
product,andwelcometotheV.I.P.family.We
appreciateyourbusinessandwill doeverythingin our
powertokeepyou happywith yourpurchaseformany
yearstocome.
AspartoftheV.I.P.family,you areentitled tothebest
protection byoneofthemostcomprehensivewarranties
in
theindustry.
Thank-youforpurchasingViperproducts!
TomVanderBie,CEO
TABLEOFCONTENTS
SafetyPrecautions1
MachineOperation 2
MachineMaintenance&Storage2
PartsList3-8
Wiring Diagram9

SAFETYPRECAUTIONS
!!! Thismachinemustbegrounded!
Groundingprovidesthepathofleast
resistanceforelectricalcurrent. To
reducetheriskofelectricalshock
should themachinemalfunction, the
machinehasaspecialgroundingplug.
Donotremovethegroundpin under
any circumstances!
Thismachineisintendedforcommercial
use. Itisconstructedforusein an
indoorenvironmentandisnotintended
forany otheruse. Useonly
recommendedaccessories.
All operatorsshall read, understand
andexercisethefollowingsafety
precautions:
1)Donotoperatemachine:
-Unless trainedandauthorized
-Unless youhavereadand
understandoperatorsmanual
-Inflammableorexplosiveareas.
-Withdamagedcordorplug.
-Ifnotinproperoperatingcondition.
-Inoutdoorareas.
-Instandingwater.
-Withtheuseofextensioncords.
2)Beforeoperatingmachine:
-Makesureall safetydevicesare
in placeandoperateproperly.
3)Whenusingmachine:
-Donotrunmachineovercord.
-Donotpull machinebycordor
plug.
-Donotpull cordaroundsharp
edgesorcorners.
-Turnpowerswitch to off prior
tounpluggingmachine.
-Donotunplug bypullingonthe
cord.
-Donotstretch cord.
-Donothandleplug withwet
hands.
-Keepcordawayfrom heated
surfaces.
-Donotpickupburningor
smokingdebrissuch as
cigarettes, matchesorhot
ashes.
-Report machinedamageor
faultyoperationimmediately.
4)Beforeleavingorservicingmachine:
-Turnoff machine.
-Unplug cordfrom outlet.
5)Whenservicingmachine:
-Unplug cordfrom outlet.
-Usemanufacturersuppliedor
approvedreplacementparts.
1

OperationofHighSpeedFloorMachine
*Readoperatorsmanualthoroughlyprior
tooperatingorservicingthismachine.
GENERALUSE
1]Removeanyobstructionsorother
obstaclesintheareawhichistobe
cleaned.
2]Placehandleinuprightpositionandtilt
machinebackuntilhandlerestsonthe
floor.
*Besurethemachineisnot plugged
intoanoutlet.
3]Removethepadcentergrippingdevice
byunscrewingthethumbscrews.
4]Placeappropriateburnishingpadonpad
driverandre-attachthecenter
grippingdevice.
5]Placemachinebackintoitsupright
position.
6]Plugpowercordintogrounded outlet.
*Do notuseanextensioncordin
conjunctionwiththestandard power
cord.
7]Adjustheighttoacomfortable
operatingposition.
8]Tostartthemachine, pushonthe
Redhandlemountedsafetyswitch
andsqueezeanyofthetwoswitch
levers.
9]Whenthemachineisinoperation,both
handsshouldbeplacedonthehandle.
10]Tostopthemachineatanytime,
simplyrelease the switch lever,andthe
machinewillstopautomatically.
MAINTENANCE
Tokeep themachineperformingwell for
manyyears,pleasefollowthefollowing
maintenanceprocedures.
* Alwaysconfirmthatthemachineis
unplugged priortoperformingany
maintenance orrepairs.
1]Unplug machineassoonasyouare done
using it.
2]Tiltmachinebackandremovepaddriver
orbrush.
3]Cleantheoutsideofthemachinewitha
mild cleaner.
4]Checkpowercordforanydamage.If any
damage isdetected,replacethecord
immediately.
5]Lubricatewheelswithawaterresistant
lubricant everymonth.
6]Checkmachineforlooseormissingnuts
andbolts,andreplace asnecessary.
7]Ifthemachineisusedinadusty
environment,youmayremovethemotor
coverandblowthemotorcleanwith
compressedair.Thiswill allowforgood
ventilationandhelpthemotorrun
cooler.
STORAGE
1]Unplug machinefrompowersource.
2]Store inuprightpositioninadryarea.
2

PARTSLIST
HANDLEGROUPFORDR1500H
3

DIA
NO PART NUMBER DESCRIPTION NO REQ'D
1VF14105 SCREW, M8x12 2
2VF13515 WASHER, PLAIN 2
3VF52112 SPRING, RIGHT 1
4VF52113 AXLE 1
5VF47009 FRONTCOVER,SEAT,GEAR 1
6 VF47029 SEAT,GEAR 1
7 VF52016 GEAR 1
8GV40227 WASHER,NYLON 2
9 GV40228 "O"RING,GEARSEAT 2
10 VF52111 SPRING, LEFT 1
11 VF50120 GROMMET 2
12 VF47015 REARCOVER,SEAT,GEAR 1
13 VF14080 SELF-TAPPING SCREW,M4x25 2
14 VF14087 SELF-TAPPING SCREW,M4x35 2
15 VF47046 SEALRING 1
16 VF47045 HOOK,CABLE 1
17 VF13616 HEX SCREW,M10x55 1
18 GT13019 HEX SCREW,M6x45 4
19 VF52015 INSERT,LEVELING 1
20 GT13013 NUT,M4 4
21 VF52117 RODLEVELING 1
22 VF47007 SPRING,LEVELING 1
23 VF47033 RETAINER 1
24 VF47008 SEAL,TUBE 1
25 VF52116 TUBE 1
26 VA13474 SCREW,M5x16,PH 1
27 VA13476 SCREW,M5x40,PH 1
28 VF40994 SERIALTAG 1
29 VF14212 SCREW,M3x25,PH 2
30 VF13511 WASHER,LOCK,INTERNALTOOTH 2
31 VF99023 SWITCH ASSY,20A,250V 1
32 VF45124 JUMPWIRE 1
33 VV13650 SCREW, M4x10, PH 2
34 VF48309 BLOCK, HANDLECABLE 1
35 VF46703 LEVELING HANDLE, SWITCH, LEFT 1
HANDLEGROUPFORDR1500H
4

DIA
NO PART NUMBER DESCRIPTION NO REQ'D
HANDLEGROUPFORDR1500H
36 VF45121A CORD,POWERSUPPLY,H05 RR-F1.5mm2/3C 1
37 VF44005 STRAINRELIEF,CORD 1
38 VF52019 COVER, SOLUTIONLEVER 1
39 VF14226 SCREW, FH, M6X35 2
40 VF52118 REARCOVER 1
41 VF40994 READMANUALLABEL 1
42 VF14218 SCREW,PH, M6x40 2
43 VF46705 SAFETYBLOCK 1
44 GV40218 SPRING,SAFETYBLOCK 1
45 VF99010 CIRCUITBREAKER 1
46 VF13527 EXTERNALTOOTH,WASHER, 41
47 VF13526 HEX SOCKETSCREW,M4x30 1
48 VF46704 LEVELING HANDLE, RIGHT, SWITCH 1
49 VF48306 PIN, LEVER 3
50 GT13014 NUT, M4, NYLONINSERT 1
51 VF46707 LEVELING HANDLE,ROD 1
52 GT13017 BIG WASHER, PLAIN, 4x 16 1
53 VF46706 HANDLEGRIP 2
54 VF46701 FRONTCOVER,HANDLEHOUSING 1
55 VF47035A "VIPER"LOGO 1
56 VF13600 WASHER,PLAIN, 64
57 VF13502 NUT,M6,NYLONINSERT 4
58 VF45120 CABLE,HANDLE, SJTW14/3C 1
5

BASEGROUPFORDR1500H
PARTSLIST
6

DIA
NO PART NUMBER DESCRIPTION NO REQ'D
1VF52102A UPPERCOVER 1
2 VF47035A "VIPER"LOGO 1
3VA13484 SELF-TAPPING SCREW,M4x12 7
4VF52114 PLASTICSTAND,RIGHT 1
5VF52115 PLASTICSTAND,LEFT 1
6VF52101A LOWERCOVER 1
7 VV20509 SCREW,M5x10,PH 8
8 VF13503 NUT,M8,NYLONINSERT 3
9VF13524 WASHER,PLAIN 7
10 VF52104A RIGHT,ARM 1
11 VF52103A LEFT,ARM 1
12 VF47026 SEAL,UPPERCOVER 2
13 GT13016 SCREW,M8x60,HEX SOCKET 3
14 VF14088 SCREW,M8x25,HEX SOCKET 4
15 VF13519 WASHER,LOCK, 810
16 VF52105 RISER,ARM 2
17 VF13607 SCREW,M8x25 4
18 VF52011 AXLE,TRANSPORTATION 1
19 VF13520 RETAINING RING,EXTERNAL, 12 2
20 VF52017 WHEEL,5" 2
21 VF13666 WASHER,PLAIN, 12 2
22 VF44012 SCREW,M5x12.7 2
23 VF50119 WAVING WASHER, 12 2
24 GV40235 CLAMPBLOCK,AXLE 2
25 VV13621 SELF-TAPPING SCREW,ST5x20 8
26 VF52010 FRONTAXLE 1
27 VF47038 CLAMPBLOCK,AXLE 2
28 VA13474 SCREW,M5x16,PH 4
29 VF13474A WASHER,PLAIN, 5x 16 2
30 VF13517 WASHER,PLAIN, 10 8
31 VF13518 WASHER,LOCK, 10 8
32 VF13608 SCREW, M10 x25 4
33 GT13004 SELF-TAPPING SCREW,M5x20 7
34 VF52003 FRAME 1
35 VF14009 HEX SCREW,M10x65 1
BASE GROUP FORDR1500H
7

DIA
NO PART NUMBER DESCRIPTION NO REQ'D
36 VF14005 NUT,M10 1
37 VF52008 SPACER 1
38 VF52009D DRIVING PULLEY 1
39 VF14004 RETAINING RING,EXTERNAL, 19 2
40 VF50123 WASHER, 19 2
41 VF47027 WAVING WASHER, 19 2
42 VF47055 WHEEL,160mm 2
43 VA96851 CAP,AXLE 2
44 VF52021 WASHER,PLAIN 2
45 GT13018 HEX SCREW,M8x30 2
46 VF99003A BIG MOUTH 1
47 VF99024D PADHOLDER 1
48 VF14079 BELT, 43" 1
49 VF52004D DRIVENPULLEY 1
50 VF52001 KEY 1
51 VF52005 DRIVENSHAFT 1
52 VF14075 BEARING, 60042RS 2
53 VF52006 SPACER 1
54 VF14003 LOCK 2
55 VF14007 HEX SCREW,M10x32 4
56 VF52007 MOUNTING PLATE,DRIVENSHAFT 1
57 VF52002 BUMPER 1
58 VF52106 MOUNTING PLATE 2
59 VF999846 RUNNING CAPACITOR 1
60 VF52110 CLAMP, CAPACITOR 2
61 VF99920-1 KEY 1
62 VF99920 MOTOR,220V1500R.P.M 1
BASE GROUP FORDR1500H
8

Motor
WiringDiagram
DR1500H
9
