Viper MAMBA Series User manual

MAMBASERIESVACUUM
OWNER SMANUAL
IMPORTANT READOWNERSMANUALCAREFULLY
Pleasefill out& returnyourwarrantycard!
MODEL #MB53CV
SERIAL#
VIPERNORTHAMERICA
P.O.BOX 104 VIPER…exceptional
HAMILTON.MI49419 value
[866]418-4737 REV.00[08-06]
[866]41-VIPER
VA
6
1
40
6
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com
All manuals and user guides at all-guides.com
all-guides.com

CONGRATULATIONSonyour purchaseofaViperproduct,
and welcometotheV.I.P. family. Weappreciateyour
businessand will do everythinginourpowertokeepyou
happywithyour purchaseformanyyearstocome.
Aspart oftheV.I.P. family,youareentitledtothebest
protectionbyoneofthemostcomprehensivewarrantiesinthe
industry.
Thank-youforpurchasingViper products!
TomVanderBie,CEO
TABLE OFCONTENTS
SafetyPrecautions3
MachineOperation4
MachineMaintenance &Storage4
PartsLists5-8
WiringDiagram9
All manuals and user guides at all-guides.com

SAFETYPRECAUTIONS
!!!Thismachinemustbe grounded!
Groundingprovidesapathofleast
resistanceforelectricalcurrent.To
reducetheriskofelectricalshock
should themachinemalfunction,the
machinehasaspecialgroundingplug.
Donotremovethegroundpin underany
circumstances!
Thismachineisintendedfor
Commercialuse.Itis constructedforusein an
indoorenvironmentandisnotintendedforany
otheruse. Useonlyrecommendedaccessories.
All operatorsshall read,understandand
exercisethefollowingsafetyprecautions:
1]Donotoperatemachine:
-Unless trainedandauthorized.
-Unless youhavereadandunderstand
operatorsmanual.
-Inflammableorexplosiveareas.
-Withadamagedcordorplug.
-Ifnotin properoperatingcondition.
-Inoutdoorareas.
-Instandingwater.
-Withoutbag/filtersin place
-Withtheuseofextensioncords.
2]Beforeoperatingmachine:
-Makesureall safetydevicesare
in placeandoperateproperly.
3]Whenusingmachine:
-Donotrunmachineovercord.
-Donotpull machinebycord
orplug.
-Donotpull cordaroundsharp
edgesorcorners.
-Donotunplug bypullingonthe
cord.
-Donotstretch cord.
-Donothandleplug withwet
hands.
-Keepcordawayfrom heated
surfaces.
-Donotpickupburningorsmoking
debrissuch ascigarettes,
matchesorhotashes.
-Report machinedamageoffaulty
operationimmediately.
4]Beforeleavingorservicingmachine:
-Turnoffmachine.
-Unplug cordfrom outlet.
5]Whenservicingmachine:
-Unplug cordfrom outlet.
-Usemanufacturersuppliedor
approvedreplacementsparts.
Toavoidelectricalshock,please
replacethepowercordimmediately
if anydamageisbeingdetected,
Thereplacementmustbeperformed
onlybyanauthorizedpersonorby
ourcustomerservicecentor.
All manuals and user guides at all-guides.com

OperationoftheCanisterVacuum
*Read operatorsmanualthoroughly
priortooperatingorservicingthis
machine. DRYPICKUP
1] RemoveThe vachead ofmachine and
confirmthatthereiseitheraclothof
paperfilterinplace.
2] Replace&thelatchvachead.
*Besurethemachineisnotplugged
intoanoutlet.
3]Connectvacuumhosetoinletonthe
machine body.
4]Chooseappropriatetool,andattachit
tothefree end ofthe hose.
5] Plugpowercordintogrounded
outlet.
*Donot useanextensioncordin
conjunction withthe standardpower
cord.
6] Tostart themachine pushonthered
rockerswitchturnon .
7]Check the filterbagperiodicallytosee
ifitisfull.Foroptimalperformance,
replacethe bagwhen it is3/4full.
8]Thismachine isdesignedtobepulled
aroundbythevacuumhose,sopull the
hose, and the vacuumwillfollow.
10] Tostopthe machine atanytime,
simplyturnoffthe rockerswitch.
MAINTENANCE
Tokeepthe machine performingwellfor
manyyears,pleasefollowthe following
maintenanceprocedures.
*Always confirmthatthemachineis
unpluggedpriortoperforming any
maintenance orrepairs.
1]Unplugmachine assoonasyou are
done usingit.
2]Check powercordforanydamage.If
anydamageisdetected,replacethe
cordimmediately.
3] Lubricatecasterswithawaterresistant
lubricant everymonth.
4]Check machine forlooseormissing
nutsandbolts,andreplaceas
necessary.
5]Checkthefilter,and cleanitaftereach
use.
6] Removethe vacuumhoseandcheck it
foranyholesandclogs.
7]Clean the outsideofthe machine with
amildcleaner.
STORAGE
1] Unplugmachine frompowersource.
2] Storeinupright position inadryarea.
All manuals and user guides at all-guides.com

All manuals and user guides at all-guides.com

DIA
NO PART NUMBER NO REQ'D
1VA60115Logo1
2VA60103Handle1
3VA60102Housing,VacHead1
4VA60107Pin1
5VA60118Switch1
6VA60105Catch1
7VA60106Basement,Catch1
8VF14116Screw,ST4X168
9VA60114Screen,Housing,VacHead1
10VA61104MountingCover,Motor1
11VA61105TopGasket,Motor1
12VA41038VacMotor,110V1
13VA61103BottomGasket,Mortor1
14VA61108Screen,MountingBase1
15VA61101MountingBase,Motor1
16VA61106Sealer1
17VA61201FilterFrame1
18VA61202Filter1
19VA61301Tank1
20VA61302Gasket,Intake1
21VA61303Intake1
22VA61304MountingBase,Tank1
23VA60303Caster, 502
24GT13001Screw, ST5 X122
25GT13010Axle2
26GT13011Whell2
27VA60302Holder,CombinationTool1
28VA13482Washer,Plain, 5X 11X14
29VF14117Screw, ST5 X168
30VA60108Valve,By-Pass1
31VA61107Filter,Motor1
32VA65002PowerCord1
33VA41019Grommet1
34VA21518ClampBlock1
35GT13047Screw,ST3X162
36VA60109Spring1
37VA61109Sreen,MountingCover4
DESCRIPTION
PARTSLIST
All manuals and user guides at all-guides.com
all-guides.com

ACCESSORIES
All manuals and user guides at all-guides.com

DIA
NO PART NUMBER NO REQ'D
1VA41130HOSEASSY1
2VA61309PAPERBAG1
3VA20205TUBE,SST 322
4VA61308VACUUMBAG,CLOTH1
5VA60400COMBINATIONTOOL1
6VA20804DUSTING TOOL1
7VA20805CREVICETOOL1
8VA20802-1UPHOLSTERYTOOL1
DESCRIPTION
PARTS LIST
All manuals and user guides at all-guides.com

SINGLE
120V
60HZ
PHASE
SUPPLY
SJTW16/3C
Power
Supply
Cord
Power
Supply
Cord
Motor
SWITCH
G/Y
BLACK
WHITE
G/Y
BLACK
BLACK
Wiring Diagram
MB53CV
