Viper MB39CV Mamba Series User manual

MODEL#MB39CV
SERIAL#
VA41128
HAMILTON,MI49419
VIPERNORTHAMERICA
[866]41-VIPER
[866]418-4737
P.O. BOX 104
Rev.00(08-08)
VIPER...exceptional
value
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

CONGRATULATIONS on yourpurchaseofaViperproduct,
and welcome totheV.I.P. family.Weappreciateyour
business and will doeverythinginourpowertokeepyou
happywithyourpurchaseformanyyearstocome.
AspartoftheV.I.P. family,you areentitledtothebest
protectionbyoneofthemostcomprehensivewarrantiesinthe
industry.
Thank-you forpurchasingViperproducts!
TomVanderBie,CEO
TABLE OF CONTENTS
SafetyPrecautions3
MachineOperation4
MachineMaintenance &Storage4
PartsLists5-9
WiringDiagram 10

SAFETYPRECAUTIONS
!!!Thismachinemustbe grounded!
Groundingprovidesapathofleast
resistanceforelectricalcurrent.To
reducetheriskofelectricalshock
should themachinemalfunction,the
machinehasaspecialgroundingplug.
Donotremovethegroundpin underany
circumstances!
Thismachineisintendedfor
Commercialuse.Itis constructedforusein an
indoorenvironmentandisnotintendedforany
otheruse. Useonlyrecommendedaccessories.
All operatorsshall read,understandand
exercisethefollowingsafetyprecautions:
1]Donotoperatemachine:
-Unless trainedandauthorized.
-Unless youhavereadandunderstand
operatorsmanual.
-Inflammableorexplosiveareas.
-Withadamagedcordorplug.
-Ifnotin properoperatingcondition.
-Inoutdoorareas.
-Instandingwater.
-Withoutbag/filtersin place
-Withtheuseofextensioncords.
2]Beforeoperatingmachine:
-Makesureall safetydevicesare
in placeandoperateproperly.
3]Whenusingmachine:
-Donotrunmachineovercord.
-Donotpull machinebycord
orplug.
-Donotpull cordaroundsharp
edgesorcorners.
-Donotunplug bypullingonthe
cord.
-Donotstretch cord.
-Donothandleplug withwet
hands.
-Keepcordawayfrom heated
surfaces.
-Donotpickupburningorsmoking
debrissuch ascigarettes,
matchesorhotashes.
-Report machinedamageoffaulty
operationimmediately.
4]Beforeleavingorservicingmachine:
-Turnoffmachine.
-Unplug cordfrom outlet.
5]Whenservicingmachine:
-Unplug cordfrom outlet.
-Usemanufacturersuppliedor
approvedreplacementsparts.
Toavoidelectricalshock,please
replacethepowercordimmediately
if anydamageisbeingdetected,
Thereplacementmustbeperformed
onlybyanauthorizedpersonorby
ourcustomerservicecentor.

OperationoftheCanisterVacuum
*Read operatorsmanualthoroughly
priortooperatingorservicingthis
machine. DRYPICKUP
1] RemoveThe vachead ofmachine and
confirmthatthereiseitheraclothof
paperfilterinplace.
2] Replace&thelatchvachead.
*Besurethemachineisnotplugged
intoanoutlet.
3]Connectvacuumhosetoinletonthe
machine body.
4]Removetoolstoragelidontopof
machine and unwind powercord..
5]Chooseappropriatetool,andattachit
tothefree end ofthe hose.
6] Plugpowercordintogrounded
outlet.
*Donot useanextensioncordin
conjunction withthe standardpower
cord.
7]Tostartthe machine,pushonthe
red powerbutton located abovethe
left rearwheel.
8]Check the filterbagperiodicallytosee
ifitisfull.Foroptimalperformance,
replacethe bagwhen it is3/4full.
9]Thismachine isdesignedtobepulled
aroundbythevacuumhose,sopull the
hose, and the vacuumwillfollow.
10]Tostopthe machine atanytime,
simplypress the red powerswitch&
the machine will stopautomatically.
MAINTENANCE
Tokeepthe machine performingwellfor
manyyears,pleasefollowthe following
maintenanceprocedures.
*Always confirmthatthemachineis
unpluggedpriortoperforming any
maintenance orrepairs.
1]Unplugmachine assoonasyou are
done usingit.
2]Rewind the powercordintothe tool
storagearea..
3]Replacethe toolintothetoolstorage
area.
4]Check powercordforanydamage.If
anydamageisdetected,replacethe
cordimmediately.
5] Lubricatewheels&casterswitha
waterresistant lubricant everymonth.
6]Check machine forlooseormissing
nutsandbolts,andreplaceas
necessary.
7]Checkthemotorcover/filter,and
clean it aftereachuse.
8] Removethe vacuumhoseandcheck it
foranyholesandclogs.
9]Clean the outsideofthe machine with
amildcleaner.
STORAGE
1] Unplugmachine frompowersource.
2]Properlystorepowercordand toolsin
the on-boardstoragecompartment.
3] Storeinupright position inadryarea.

PARTSLIST

DIA
NO PART NUMBER DESCRIPTION NO REQ'D
1VF47035ALOGO1
2VA41012ATOP COVER1
3VA41048BUTTON1
4VA41045LATCH1
5VA41047SPRING1
6VA14216PIN 3X301
7VA41044HOUSING,LATCH1
8VA13469SELF-TAPPINGSCREW,ST3X124
9VA13487SELF-TAPPINGSCREW,ST3X124
10VA41043SHIELD1
11VA41046BLOCK,LATCH1
12VA14007PIN 4X122
13VA41010ABASE,TOP COVER1
14VA41021SPRING2
15VA41009PUSH BUTTON1
16VA41008COVER,UPPERHANDLE1
17VA14487SELF-TAPPING,SCREW,ST3X166
18VA41011GASKET,BASE,TOP COVER2
19VA41013FOAMFILTER,TOP COVER1
20VA41026FILTER,TOP COVER1
21VA41006AFILTERHOLDER1
22GT13001SELF-TAPPING,SCREW,ST5X126
23VA13492SCREW,M5X126
24VA41041HOLDER1
25VA41029INTAKE1
26VA14006ASCREW,M3X68
27VA41007COVER,LOWERHANDLE1
28VA41004-3STRIKE,PUSH BUTTOM1
29VA41004LOWERHANDLE1
30VA41005TANK1
31VV20509SCREW M5X103
32VV13662WASHER,PLAIN 5X 12X12
33VA65002CORD1
34VA41034GASKET,BASE,TOP COVER1
35VA41019GROMMET1
36VA13488AWASHER,LOCK2
37VA41042SEAL1
38VF14004LOCK2
39VA41014AXEL1
40VA13474SCREW,M5X168
PARTSLIST

DIA
NO PART NUMBER DESCRIPTION NO REQ'D
PARTSLIST
41VA41003ATANKSEAT1
42VA41036VACMOTOR, 110V1
43VA41032GASKET1
44VA41015AMOTORSEAT1
45GT13004SELF-TAPPING,ST5X168
46VA41031FOAMFILTER,MOTOR1
47VA21544ASERIALTAG1
48VF40994READMANUAL1
49VF47027WASHER,LOCK2
50VF47055REARWHEEL2
51VA96851CAP,AXEL2
52VA41017PUSH SWITCHBUTTON1
53VA20209-16SPRING,SWITCHBUTTON1
54VA41018ASEAT,SWITCH1
55VA41024ASWITCH(HP12AS2HOOO)1
56VA41030ABRACKET,SWITCH1
57VV13640SELF-TAPPINGSCREW ST4X162
58VA21517CLAMP BLOCK,CABLE1
59VA13470SELF-TAPPING,ST3X162
60VA41016FOAMFILTER,STRIP1
61VA41001BOTTOMCOVER1
62VA41002BUMPER1
63VA91345CASTER1
64GT13002SELF-TAPPING,ST5X246

ACCESSORIES

DIA
NO PART NUMBER DESCRIPTION NO REQ'D
1VA41130HOSEASSY1
2VA41023PAPERBAG1
3VA20205TUBE2
4VA41027VACUUMBAG,CLOTCH1
5GT0012BCOMBINATIONTOOL1
6VA20804DUSTINGTOOL1
7VA20805CREVICETOOL1
8VA20802-1UPHOLSTERYTOOL1
PARTSLIST

Motor
Cord
Supply
Power
SJTW16/3C
Supply
Cord
Power
MB39CV
WiringDiagram
120V
SINGLE
SUPPLY
PHASE
60HZ
SWITCH
BLACK
WHITE
G/Y
BLACK
G/Y
BLACK
