Vision ZM 1602 US User manual

Federal Communications Commission Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try and correct the interferene by one of the following measures:
Reorient or relocate the receiving antenna,
Increase the separation between the equipment and receiver,
Connect the equipment into and outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undersired
operation.
FCC Caution:Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
Limited Warranty
Vision Guarantees that every wireless siren & strobe alarm is free from physical defects
in material and workmanship under normal usage for one year from the date of purchase.
If the product proves defective during this one-year warranty period, Vision will replace it
free of charge. Vision does not issue any refunds. This warranty is extended to the
original end user purchase only and is not transferable. This warranty does not apply to :
(1) damage to units caused by accident, dropping or abuse in handling, or any negligent
usage; (2) units which have been repaired, taken apart, or modified by a unauthorized
personnel; (3) units not used in accordance with instruction; (4) damages exceeding the
cost of the product; (5) transit damage, initial installation costs, removal cost, or
reinstallation cost.
For information on addional devices, plesae visit us at www.visionsecurity.com.tw
-3-
Installation & Operation Manual
ZM 1602 US
ZM 1602 EU
ZM 1602 BR
ZM 1602 JP
DC/AC Power Siren
ZM 1602
V2
1010201
6B1Z-16003

Introduction
Thanks for choosing the Vision’s wireless siren & strobe alarm of the home security device.
This sensor is a Z-Wave™enabled device (interoperable, two-way RF mesh networking
technology) and is fully compatible with any Z-Wave™ enabled network. Every main
powered Z-Wave™ enabled device acts as a signal repeater and multiple devices result in
more possible transmission routes which helps eliminate “RF dead-sports”.
Z-Wave™ enabled devices displaying the Z-Wave™ logo can also be used with it
regardless of the manufacturer, and ours can also be used in other manufacturer’s
Z-Wave™ enabled networks. This product will sound a loud siren and flash a strobe light
when an alarm message or alert is received on any Z-Wave™enabled network. When ZM
1602 main power has dropped out, the backup batteries will automatically install.
Product Description and Specification
*** For indoor use only ***
Specification:
Package Content:
Protocol: Z-Wave™(ZM3102N/ZM4102AH)
Frequency Range:
868.42MHz (ZM1602EU)
908.42MHz (ZM1602US)
921.42MHz (ZM1602BR)
920-928MHz (ZM1602JP)
Operating Range: Up to 100 feet line of sight
Loud Audible Alarm: > 105dB@1meter
LED Strobe Lighting
Operating Temp.: -15°C~ 60°C(5°F~140°F)
Z-Wave Command Class:
COMMAND_CLASS_BASIC
COMMAND_CLASS_CONFIGURATION
COMMAND_CLASS_MANUFACTURER_SPECIFIC
COMMAND_CLASS_SWITCH_BINARY
COMMAND_CLASS_VERSION
Note: COMMAND_CLASS_BASIC Mapping
1pc
1pc
2pcs
1pc
Note:
ZM 1602 Siren
Adhesive tape
Screw
Installation & Operation
Manual
Power adapter excluded
Installation
Notice: If you are installing the entire Z-Wave™ system for the first time, please refer to
the installation guide of Z-Wave™ Interface Controller before installing ZM1602.
1. Remove the bracket from the siren by press the locking tab, and then gently slide
up the siren.
2. Remove two screws and pull out the plastic case as below. Pull out the short head
& put back into the position where two pin heads are covered.
3. Knock out the thin wall on the bracket. Power line goes through the hole on
bracket and connects to screw terminal on ZM1602.
4. Using the screws or adhesive tape to affix the bracket on the chosen location.
5. S lide back the cover and screw fastening with the front cover.
6. For “Inclusion” in (adding to) a network: Put the Z-Wave™Interface Controller
into “inclusion” mode, and following its instruction to add the ZM 1602 to your
controller. To get in the “inclusion” mode, the distance between siren and
controller is suggested to be in one meter. Open the bracket and press the tamper
switch of ZM 1602 for 1 second at least & release to be included. After setting, the
LED Setting Lighting should go off, if not, please try again.
For “Exclusion” from (removing from) a network:Set up the Z-Wave™Interface
Controller into “exclusion” mode, and following its instruction to delete the ZM 1602
from your controller. Press the tamper switch of ZM 1602 for 1 second at least &
release to be excluded.
Please note: 1. LED setting light will flash continuously in Exclusion condition.
2. ZM 1602 can only connect to DC 12~39V,AC 9~28V Power adapter
3. ZM 1602 is extremely LOUD, please don’t near your ear when you test!
7. Configuration Command Class:
Parameter 0: Siren/ Strobe Mode, 1 Byte Value: 0=siren and Strobe enable (default),
1=siren only, 2= Strobe only.
Parameter 1:Alarm auto stop time command, 0=30 seconds (default), 1= 60 secs, 2=
120 secs, 3= siren will not automatically stop.
Operation
1. Normal operation, the LED light will not on.
2. Alarm mode (It is status of alarm triggered): It is based on the user’s configuration
setting of LED flash ON/OFF and Siren ON/OFF. ZM 1602 will sound a loud, when
Basic set/Binary Swtich On signal is received
3. Self-Protection Mode: After put back the bracket over 5 seconds, ZM 1602 will enter
Self-Protection mode. If the back cover is opened will triggered the Self-Protection
