Installation Guide

Table of Contents
Important Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
System Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Required Installation Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Recommended Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installation Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Control Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Valet Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
LED Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Siren . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Ultrasonic Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Ultrasonic Sensitivity Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Pin Connector Charts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
18-Pin Connector (P1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
10-Pin Connector (P2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4-Pin Pigtail Connector (P3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Final Wiring Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
System Status/Diagnostic Charts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
LED System Status Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Specific Zone Intrusion Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Chirp/Indicator Light Flash Interpretation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Door Lock Diagrams. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Personal Identification Number (PIN) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Entering Your PIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Programmable Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Programming Table for System Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Programming Table for Remote Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Final Testing Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Certificate of Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
©2002 Directed Electronics, Inc.
2

Important Information
IMPORTANT! The Avital Maxx3system is designed to be installed in any petrol powered vehicle with
a 12 volt battery.
One Avital Maxx3Control Unit with Metal Enclosure Voltmeter
One Prewired 18-Pin Connector Harness Wire Strippers/cutters
One Prewired 10-Pin Connector Harness Electric Drill & Bits
One Prewired 4-Pin Pigtail Connector Harness Phillips Screwdriver
One Prewired Valet Switch Convoluted Tubing *
One Prewired Status LED Soldering Iron
One 4-Button 10-Channel Remote Control Wire Crimpers
One 2-Button 3-Channel Remote Control Shrink Tube or Electrical Tape
Two Ultrasonic Transducers
One Battery Back-up Siren with Mounting Bracket
One Hardware Pack
One Owner’s Guide
One Certificate of Installation
Two Avital Window Decals * Optional
1. Test all circuits with a voltmeter.
2. Make all wiring connections using solder and heatshrink using the procedure below. Do NOT twist wires or
use scotch-lock connectors.
• Strip half an inch of insulation from the wires you are going to solder and slide a piece of shrink tubing
over one of them.
• Join the wires together, then heat the wires with a soldering iron whilst touching solder to the wires
until the solder melts.
• Pull the wires to test the solder joint, then position the loose shrink tube over the solder joint and gently
heat with a hot air gun so that it tightly seals and insulates.
3. Keep extensions as short as possible. Use the same gauge wires for short extensions and larger gauge wires
for longer extensions.
4. Before installing, discuss the placement of the LED indicator and Valet switch with the vehicle’s owner.
5. Turn off interior light(s) or remove interior light fuse to prevent battery drain.
recommended procedures
required installation toolssystem components
©2002 Directed Electronics, Inc. 3

©2002 Directed Electronics, Inc.
4
Installation Procedures
CAUTION: The Avital Maxx3control unit must be installed inside the vehicle. Under no circum-
stances should the unit be installed under the bonnet or other similarly hostile environment.
1. Select a location under the dash that will allow you to use the screws to securely fasten the control unit.
2. Mount the control unit as high as possible to ensure maximum range.
3. Do not mount the control unit near moving parts.
4. Avoid areas that are in the direct path of air blowing from the heater vents.
5. Route wires from this point, leaving slack for ease of service.
1. Do not shorten or lengthen the antenna.
2. Route the antenna away from the control unit.
3. Keep the antenna as far away from metal and wire harnesses as possible to optimise range.
1. Discuss placement with the vehicle’s owner.
2. Choose a location for the Valet switch that is convenient for the owner to access.
3. Drill a 7mm hole and mount the switch.
1. Discuss placement with the vehicle’s owner.
2. Choose a location that is visible from both sides of the vehicle.
3. Drill a 7mm hole.
4. Insert the LED into the black mounting collar.
5. Push the LED and collar into the 7mm hole.
1. Choose a location in the engine compartment away from high temperature engine components, moving parts
and direct exposure to water.
2. Make sure the siren and siren wires cannot be seen or reached from below the vehicle.
3. Mount the siren with the two self-tapping screws to a solid metal surface.
4. Route the siren cable through the firewall into the passenger compartment.
5. Make the wire connection as per the diagram on page 23.
Siren
LED Indicator
Valet Switch
Antenna
Control Unit

©2002 Directed Electronics, Inc. 5
1. Choose a location at the top of the A-pillar on both driver and passenger sides.
2. Mount the sensors using the screws provided or by inserting the mounting tabs between the dashboard and
windscreen pillar.
3. Angle the sensors towards the top centre of the rear window. If mounted at the top of the A-pillars make
sure the ultrasonic position does not affect use of the sunvisor.
4. Route the sensor cables to the control module and plug-in.
1. Follow the instructions for entering program mode on page 19. Enter program branch number 19 on page 20
listed as "Ultrasonic Sensor Test and Adjustment Mode."
2. Once in this mode the system LED will flash ON and the siren will chirp if movement is detected inside the
vehicle.
3. The sensitivity adjuster is found on the side of the main Alarm/Immobiliser Control Unit. Insert a small screw-
driver into the adjustment hole and turn the screw clockwise to increase sensitivity or anti-clockwise to
decrease sensitivity.
4. Move your arm through an open window on the vehicle as if attempting to remove an item from the seat.
The LED should illuminate and the siren should chirp to detect the movement. If it does not, then increase
the sensitivity in small increments until the optimum position is reached and the sensors do pick up the
movement. Do not over adjust the sensors as the system will false alarm. The sensitivity level should be left
at the minimum setting where the sensors pick up movement in the rear seating position.
5. When satisfied with the final sensitivity setting, you may exit Installer Ultrasonic setup mode by either
turning off the ignition or by pressing any remote control button. Program mode exit will be confirmed by
two siren chirps (one short and one long chirp).
Ultrasonic Sensitivity Adjustment
Ultrasonic Sensors

©2002 Directed Electronics, Inc.
6
Pin Connector Charts
Pin Number Wire Colour Description
1WHITE/BLUE Channel 4 Accessory (-) Pulsed or Timed Output
2PINK/BLACK Second Stage Unlock (-) Output
3VIOLET/WHITE Arm/Disarm (-) Output (300mA maximum)
4GREY/BLACK Channel 5 Accessory (-) Pulsed or Latched Output
5BROWN Coded Link for Siren
6RED/WHITE Channel 2 Accessory (-) Pulsed for Boot Release
7
8 Pre-Wired to Ultrasonic Sensors
9
10 WHITE Indicator Light Output
11 BLACK with WHITE TAG Indicator Light Polarity (+) or (-) Input Select
12 WHITE Indicator Light Output
13 BLUE/BLACK Unlock Common
14 VIOLET Unlock Normally Open
15 BROWN/BLACK Unlock Normally Closed
16 WHITE/BLACK Lock Normally Closed
17 VIOLET/BLACK Lock Normally Open
18 GREEN/BLACK Lock Common
WHITE/BLUE Channel 4 Accessory (-) Output (P1/1)
CAUTION: Do not use this output to roll-up windows on vehicles not equipped with "Total-close."
The WHITE/BLUE wire can be programmed to provide a (-) output from one second to two minutes. The wire can
also be programmed to automatically activate when the alarm system is armed. This output can be used to acti-
vate headlights, roll-up/down windows and close sunroofs on vehicles equipped with factory "Total-close."
PINK/BLACK Second Stage Unlock (-) Output (P1/2)
The alarm has onboard relays to lock and unlock the doors. It also incorporates a PINK/BLACK (-) output wire
that will allow the customer to operate a Two-Stage Unlock feature. The second stage unlock wire provides a 400
mA, 0.75 second (-) output when activated.
CAUTION: Ask the customer at the time of installation whether they require this feature. Verify the
type of central locking system the vehicle has. Carefully follow the door lock/unlock diagrams on
pages 13-17.
18-Pin Connector (P1)

©2002 Directed Electronics, Inc. 7
1. Press the button once and the driver’s door only will unlock.
2. Press the button again within three seconds and the passenger doors will unlock.
VIOLET/WHITE Arm/Disarm (-) Output (300 mA maximum) (P1/3)
The VIOLET/WHITE wire can be connected to a pager or used to drive a relay when adding extra sirens. This wire
pulses to ground (-) when the siren chirps and will stay at ground for as long as the siren is sounding.
GREY/BLACK Channel 5 Accessory (-) Output (P1/4)
The GREY/BLACK wire can be programmed to provide a PULSED 0.75 second ground (-) or LATCHED output. If the
remote control button is continuously pressed when programmed for a PULSED output, the signal will stay at
ground for as long as the button is held. If the remote control button is pressed when programmed for a LATCHED
output, the signal will stay at ground until such time as the button is pressed a second time.
BROWN Coded Link for Siren (P1/5)
The BROWN wire is the siren's data connection. This wire controls whether the siren should chirp or sound, etc.
Connect the BROWN wire to the BROWN siren wire.
NOTE: Do not connect anything other than the system siren to this wire or damage may occur.
RED/WHITE (P1/6)
The RED/WHITE wire provides a 0.75 second ground (-) output when the alarm is disarmed only. This is ideal for
boot release. If the remote control button is continuously pressed, the signal will stay at ground for as long as
the button is held.
NOTE: Most boot releases are switched positive and require an additional relay.
2 BLACK Screened Wires Pre-Wired to Ultrasonic Sensors (P1/7, 8, & 9)
These wires are to be plugged into the two ultrasonic sensors.
2 WHITE & BLACK with WHITE TAG Indicator Lights (P1/10, 11, & 12)
1. If the indicator lights are positive trigger, connect the BLACK wire with WHITE tag to the constant positive
(+) battery terminal through the 20 amp fuse provided.
NOTE: Do not connect the BLACK wire with WHITE tag to the control unit BLACK wire with RED tag.
2. If the indicator lights are negative (-) trigger, connect the BLACK wire with WHITE tag to the control unit
BLACK wire with GREEN tag.
3. Connect the WHITE wires to the left and right indicator light wires on the vehicle.
On-Board Door Lock Relays (P1/13-P1/18)
For installation instructions, see Door Lock Diagrams beginning on page 13.

©2002 Directed Electronics, Inc.
8
Pin Number Wire Colour Description
1 NOT USED Not Used
2BLUE/WHITE Boot Trigger (-) Input
3BLACK with ORANGE TAG Ignition Sense (+) Input
4BLACK/WHITE Normally Closed (-) Trigger Input
5GREY Prewired To Valet Switch
6ORANGE Armed (-) Output
7BLUE Bonnet Trigger (-) Input
8GREEN (-) Door Trigger Input, Interior Light
Illumination (-) Output
9BLACK with GREEN TAG 12 volt (-) Input x2
10 BLACK with RED TAG 12 volt (+) Input
BLUE/WHITE Boot Trigger (-) Input (P2/2)
1. Locate the vehicle boot pin switch that shows ground when the boot is opened.
2. Connect the BLUE/WHITE wire to the vehicle boot switch wire.
3. If the vehicle does not have a boot switch, install a pin switch and connect it to the BLUE/WHITE wire.
BLACK with ORANGE TAG Ignition Sense (+) Input (P2/3)
1. Use a voltmeter to locate the one wire that shows 12 volts when the ignition key is in the ON, CRANK and
RUN positions, and 0 volts when the ignition key is in the OFF position.
2. Connect the BLACK wire with the ORANGE tag to the vehicle ignition wire.
NOTE: Remove tag from wire after connection.
BLACK/WHITE Normally Closed (-) Trigger Input (P2/4)
The BLACK/WHITE wire is a normally closed input as opposed to the systems sensor, door, & boot/bonnet inputs which
are normally open. Some vehicles are factory fitted with normally closed bonnet pin switches which can be connected to
this wire. Or alternatively, it can be connected to ground after being looped through external ancillary equipment such
as mountain bikes, spot lamps, spare wheels, in-dash CD players, etc. The input can also be used for connection to a
heated rear window switched wire. This last option is especially useful as if the rear windscreen was removed whilst the
alarm was armed the alarm would trigger.
NOTE: If you are not going to use this Input then it must be grounded or the system will report a mal-
function.
10-Pin Connector (P2)

©2002 Directed Electronics, Inc. 9
GREY Prewired to Valet Switch (P2/5)
The GREY wire is switched to ground whenever the valet switch is pressed.
ORANGE Armed (-) Output (P2/6)
The ORANGE wire will provide a ground (-) output for as long as the alarm is Armed. It does not provide a ground
when the system is Passive Immobilised or Disarmed.
BLUE Bonnet Trigger Input (P2/7)
1. Locate the vehicle bonnet pin switch that shows ground when the bonnet is opened.
2. Connect the BLUE wire to the BLUE siren wire. Connect the bonnet switch to the BLUE wire exiting the siren
harness at the siren.
3. If the vehicle does not have a bonnet switch, install a pin switch and connect it to the BLUE wire exiting
the siren harness at the siren.
GREEN Door Trigger/Interior Light Illumination (P2/8)
The system has a negative door trigger input. If the vehicle door trigger is negative (-) switching, connect the
alarm GREEN wire to the vehicle door trigger wire. For vehicles that have a positive door trigger, a relay will need
to be added to provide the GREEN wire with a negative when the door is open.
NOTE: When the alarm is remote disarmed, the GREEN wire will provide a negative output to turn
the interior lights on.
BLACK with GREEN TAG, BLACK with RED TAG Power and Ground Connections (P2/9 & 10)
CAUTION: Do not plug in the system fuses until the final step below.
1. Connect the BLACK wire with RED tag to one of the supplied fuse assemblies.
2. Connect the BLACK wires with GREEN tags to separate chassis ground locations.
3 Connect the empty fuse assembly(s) to the positive battery post.
NOTE: This wire must be a minimum of 14 gauge.

Pin Number Wire Colour Description
1 BLACK with WHITE TAG No. 1 Immobiliser Circuit No.1
2 BLACK with WHITE TAG No. 2 Immobiliser Circuit No.1
3 BLACK with WHITE TAG No. 3 Immobiliser Circuit No.2
4 BLACK with WHITE TAG No. 4 Immobiliser Circuit No.2
NOTE: The current rating for each of the two onboard immobilisation circuits is 20 amps continu-
ous/30 amps peak.
Immobilisation Connections
Make sure the four black pigtail connector wires are solidly connected. The ignition and starter circuit may draw
very high current.
Ignition Disable
1. Locate the ignition switch loom under the dashboard.
2. Use a voltmeter to locate the one wire that shows 12 volts when the ignition key is in the ON, CRANK, and
RUN positions and 0 volts when the ignition key is in the OFF position.
3. Cut this wire in half. Test by attempting to start the engine with the ignition key. The starter should crank
but the engine should not start.
4. Connect the control unit BLACK wire marked 1 to the vehicle ignition switch side.
5. Connect the control unit BLACK wire marked 2 to the vehicle coil side.
NOTE: Remove all tags from wires after connection.
Starter Disable
1. Locate the ignition switch wireloom under the dashboard.
2. Use a voltmeter to find the one wire that will show 12 volts while the ignition key is in the CRANK position
only. This should be the starter solenoid wire.
3. Cut the starter solenoid wire. Test by trying to crank the starter with the ignition key. If it does not crank,
you have the correct wire.
4. Connect the control unit BLACK wire marked 3 to the key side.
5. Connect the control unit BLACK wire marked 4 to the starter side.
NOTE: Remove all tags from wires after connection.
4-Pin Pigtail Connector (P3)
©2002 Directed Electronics, Inc.
10

1. Inspect all alarm wiring. Make sure all wires are connected.
2. Install the 5 amp fuse in the BLACK wire with RED tag fuse assembly.
3. Install the 20 amp fuse in the BLACK wire with WHITE tag fuse assembly (if the vehicle indicator lights are
positive).
NOTE: Remove tags from wires after connection.
Final Wiring Connections
©2002 Directed Electronics, Inc. 11
System Status/Diagnostic Charts
LED Status
Off System is disarmed.
On In Valet mode.
Slow Flash Passive Immobilised only.
Double Flash System is armed and Immobilised.
Triple Flash More than three consecutive incorrect Valet
codes have been entered (system ignores
Valet switch for two minutes).
Flashing in Cycles See "Specific Zone Intrusion Identification"
chart below.
Rapid Flash Passive arming countdown.
If the alarm has been triggered, the siren will chirp three times upon remote disarm. Turn the ignition ON and
count the LED flashes. Each flash cycle is repeated two more times giving three cycles in total.
LED Zone Input Description
Three Flashes Optional Sensor 2 Dual Zone 4-pin
Four Flashes Door Trigger Input (-) P2 Pin 8 GREEN
Five Flashes Boot/Bonnet Trigger P2 Pin 2 BLUE/WHITE or Pin 7 BLUE
Six Flashes Normally Closed Trigger Input (-) P2 Pin 4 BLACK/WHITE
Seven Flashes Ultrasonic Sensor P1 Pin7/8/9 Ultrasonic sensors
Eight Flashes Ignition Trigger P2 Pin 3 BLACK with ORANGE Tab
Specific Zone Intrusion Identification
LED System Status Indicator

©2002 Directed Electronics, Inc.
12
When you press the remote buttons, the system will respond with chirps and indicator light flashes. This is to
indicate the system status and to alert you to any active trigger or sensor input.
Number of chirps and flashes Explanation
1 chirp, 1 flash Disarming of the alarm.
2 chirps, 2 flashes Arming of the alarm.
3 chirps, 3 flashes Disarmed and there was an intrusion attempt.
2 chirps and flashes, Armed and a door is ajar.
then 3 more chirps and flashes
2 chirps and flashes, Armed and there is a sensor input active
then 4 more chirps and flashes (automatically bypassed).
2 chirps and flashes, then 5 more chirps and flashes Armed and there is a boot, bonnet, or normally closed
trigger input active (automatically bypassed).
Chirp/Indicator Light Flash Interpretation

©2002 Directed Electronics, Inc. 13

©2002 Directed Electronics, Inc.
14

©2002 Directed Electronics, Inc. 15

©2002 Directed Electronics, Inc.
16

©2002 Directed Electronics, Inc. 17

©2002 Directed Electronics, Inc.
18
Personal Identification Number (PIN)
Each system has an individual four-digit PIN. In order to access Valet mode or any of the programmable features,
you must first enter the PIN, one number at a time.
NOTE: To enter a zero, simply turn the ignition on and then off without pressing the Valet switch.
1. Turn the ignition key to the ON position.
2. Enter the first number in your PIN. Press and release the Valet switch the same number of times as the first
digit in your PIN. Example: If your PIN is 2345, press the Valet switch two times.
3. Turn the ignition key OFF.
4. Turn the ignition key to the ON position.
5. Enter the second number in your PIN. Press and release the Valet switch the same number of times as the
second digit in your PIN. Example: If your PIN is 2345, press the Valet switch three times.
6. Turn the ignition key OFF.
7. Turn the ignition key to the ON position.
8. Enter the third number in your PIN. Press and release the Valet switch the same number of times as the third
digit in your PIN. Example: If your PIN is 2345, press the Valet switch four times.
9. Turn the ignition key OFF.
10. Turn the ignition key to the ON position.
11. Enter the last number in your PIN. Press and release the Valet switch the same number of times as the last
digit in your PIN. Example: If your PIN is 2345, press the Valet switch five times.
12. Turn the ignition key OFF. If you have entered the correct code you will hear two chirps (one short and one
long). Should you hear five rapid chirps, the correct code has not been entered. Begin entering your PIN from
the beginning.
13. To enter Valet mode, now turn the ignition on and press and hold the Valet switch for three seconds until
the LED illuminates constantly. The system will automatically exit Valet mode the next time the ignition is
switched ON.
Entering Your PIN

©2002 Directed Electronics, Inc. 19
Programmable Features
All system features and remote control features are accomplished by entering your Personal Identification Number
(PIN) by following steps 1-12 on page 18, then pressing the Valet switch a preset number of times to access the
feature you wish to program.
The system also allows you to add new remote controls in one step and delete lost or stolen remote controls.
1. Programming cannot be accessed while the system is in Valet mode indicated by the LED permanently lit.
Remove the system from Valet mode by turning on the ignition. The LED should turn off automatically.
2. Select the feature you wish to program from the Programming Table for System Features or the Programming
Table for Remote Controls sections of this guide. Note the number of chirps associated with that feature.
3. Follow steps 1-12 in the Entering Your Pin section of this guide.
4. Begin to press and release the Valet switch. The siren will chirp once each time you press and release the
Valet switch.
5. Continue pressing and releasing the Valet switch, counting the siren chirps.
NOTE: Stop when you reach the number of chirps associated with your chosen feature. The system
LED will give confirmation of the feature status. If the LED is ON, the feature is ON. If the LED is
OFF, the feature is OFF.
6. Follow the "Secondary Action" listed in the programming table. You will hear one or two chips and the system
LED will give you confirmation that you have changed the feature.
7. After you have programmed the feature you have chosen, you can exit programming by turning the ignition
key OFF. You will hear two chirps to confirm exit of program mode. If you wish to program additional fea-
tures, leave the ignition ON and press the Valet switch again. The system will advance to the next feature.
Continue pressing and releasing the Valet switch until you have reached your next chosen feature.

©2002 Directed Electronics, Inc.
20
Feature Factory Setting No. of Chirps Secondary Action
Passive Arming ON 2 Press button. The siren will chirp
once for OFF, twice for ON.
Passive Arm with Door Lock OFF 3 Press button. The siren will chirp
once for OFF, twice for ON.
Auto Rearm and Door Lock ON 4 Press button. The siren will chirp
once for OFF, twice for ON.
Ignition Controlled ON 5 Press button. The siren will chirp
Lock/Unlock once for OFF, twice for ON.
Programmable 0 or 2.5 2.5 Seconds 6 Press button. The siren will chirp
Second Delay for Ignition once for 0 seconds, twice for 2.5 seconds.
Controlled Door Lock/Unlock
Door Lock/Unlock 1 Second 7 Press button. The siren will chirp
Duration (1-3 second) once for 3 seconds, twice for 1 second.
Arm/Disarm Siren Chirps ON 8 Press button.The siren will chirp
once for OFF, twice for ON.
Channel 4 Accessory 1 Second 9 Press button to start timer.
Output Duration Press button to stop the timer.
Channel 4 Auto OFF 10 Press button. The siren will chirp
Activation Upon once for OFF and twice for ON.
Remote Arming
Channel 5 Accessory Pulsed 11 Press button. The siren will chirp
Output once for Latched, twice for Pulsed.
Indicator Light Flash ON 12 Press button. The siren will chirp
Confirmation once for OFF, twice for ON.
Door Ajar Indication ON 13 Press button.The siren will chirp
once for OFF, twice for ON.
Dual Sensor trigger Mode Single 14 Press button. The siren will chirp
once for Single, twice for Dual.
Double Lock Pulse Single Pulse 15 Press button. The siren will chirp
once for Single Pulse, twice for Double
Pulse.
Double Unlock Pulse Single Pulse 16 Press button. The siren will chirp
once for Single Pulse, twice for Double
Pulse.
Pin Code Digits 1 and 2 Factory Selected 17 Press button, 1 to 9 times to set
first digit of PIN code. Press button, 1 to
9 times to set the second digit of PIN code.
If you require a 00 (zero, zero) in the PIN
code, press + buttons at the same
time.
Pin Code Digits 3 and 4 Factory Selected 18 Press button, 1 to 9 times to set
third digit of PIN code. Press button, 1
to 9 times to set fourth digit of PIN code.
If you require a 00 (zero, zero) in the PIN
code, press + buttons at the same
time.
Ultrasonic Sensor Test — 19 See Explanation on Page 5.
and Adjustment Mode
Programming Table for System Features
