Vislink Quantum User manual

Vislink, Waterside House, Earls Colne Business Park, Colchester, Essex, CO6 2NS, UK
Telephone: [phone] ●Facsimile: [phone] ●Email: [e-mail] ●Website: www.vislink.com
Company Registered in England & Wales no. 10523708 ●VAT registration no. GB 260 012 169
Registered Office: Waterside House, Earls Colne Business Park, Colchester, Essex, CO6 2NS, UK
Quantum Receiver
User Manual

Issue No: A Page: ii
Ref: ?-Insert_Document_Part_No._Here-? Copyright © 2021 Vislink is a Vislink Technologies Inc. companies
Document Disclaimer
The information contained in this manual remains the property of Vislink and
may not be used, disclosed or reproduced in any other form whatsoever
without the prior written permission of Vislink.
Vislink reserves the right to alter the equipment and specification appertaining
to the equipment described in this manual without notification.
This document is supplied on the express terms that it is to be treated as
confidential and that it may not be copied, used or disclosed to others for any
purpose except as authorized by Vislink.
Trademark Information
Add any additional Trademark content from external companies from their
websites trademark pages etc.
Conventions
NOTE: Notes show to convey additional information.
CAUTION: Cautions show where potential equipment damage could occur.
WARNING:Warnings show where there is potential for personal danger or risk
of death. Read all warnings and understand them before carrying
out work on any equipment. This includes peripherals and any
related equipment in use. The danger is real and not reading and
understanding the warning could lead to injury, harm or potential
death.
Service/Support Contacts:
Register for support:
Worldwide: https://vislink.com/support-beyond-expectation/
Call for support:
Worldwide: [phone]
USA: [phone]
When contacting Technical Support, please include the model and serial
number of the unit (located on a label on the bottom of each unit) and the
approximate date of purchase.

Issue No: A Page: iii
Ref: ?-Insert_Document_Part_No._Here-? Copyright © 2021 Vislink is a Vislink Technologies Inc. companies
Document History
Version
Date
Modification
Firmware Version
1.00
30/09/2021
First release of document.
QANT-0100-00-06

Issue No: A Page: iv
Ref: ?-Insert_Document_Part_No._Here-? Copyright © 2021 Vislink is a Vislink Technologies Inc. companies
Table of Contents
1. General Information ........................................................................................... 9
1.1. General Safety Information ........................................................................................... 9
1.2. Disposal Instructions....................................................................................................... 9
1.3. Environmental ................................................................................................................. 9
1.4. Health & Safety ............................................................................................................. 10
1.5. Maximum RF Power Density Limits........................................................................... 11
2. Introduction........................................................................................................ 13
2.1. IP-Native Wireless Camera Receiver ......................................................................... 13
2.2. Firmware Version .......................................................................................................... 13
2.3. Functional Description ................................................................................................. 14
2.4. Key Features.................................................................................................................. 14
2.5. Licensed Options........................................................................................................... 15
3. Specification....................................................................................................... 16
3.1. Physical & Environmental............................................................................................ 16
3.2. RF Parameters ............................................................................................................... 16
3.3. IP Transport Stream Processing .................................................................................. 16
3.4. Video & Audio Parameters........................................................................................... 17
4. Rear Panel Connectors..................................................................................... 18
4.1. RF Input Connectors (Demod Cards).......................................................................... 18
4.2. ASI/Genlock Connectors .............................................................................................. 18
4.3. Video/Monitoring Output Connectors........................................................................ 19
4.4. Audio Output Connectors ............................................................................................ 20
4.5. EXP Connectors ............................................................................................................. 20
4.6. Focal Point Connector.................................................................................................. 21
4.7. Return Data Connector................................................................................................. 22
4.8. Ethernet Transport Stream & Control Connectors ................................................... 22
4.9. USB Port Connectors .................................................................................................... 23
4.10. AC Power Connector .................................................................................................... 24
5. Front Panel Display .......................................................................................... 25
5.1. Front Panel Controls..................................................................................................... 25
5.1.1. Rotary Control................................................................................... 25
5.1.2. Headphones Socket............................................................................ 25
5.1.3. USB Port .......................................................................................... 25
5.1.4. Touch-screen Display.......................................................................... 25
5.2. Home .............................................................................................................................. 26
5.3. Setup............................................................................................................................... 26
5.4. Info .................................................................................................................................. 26
5.5. Status.............................................................................................................................. 27
6. Web GUI Screens............................................................................................... 28
6.1. Overview ........................................................................................................................ 28
6.1.1. Menus ............................................................................................. 28
6.1.2. Options............................................................................................ 29
6.2. Status.............................................................................................................................. 29
6.2.1. Streaming Video (LH Sidebar)............................................................... 29
6.2.2. Antenna Status (LH Sidebar) ................................................................ 30
6.2.3. Antenna Status Graphs ........................................................................31

Issue No: A Page: v
Ref: ?-Insert_Document_Part_No._Here-? Copyright © 2021 Vislink is a Vislink Technologies Inc. companies
6.2.4. Active Preset –Selection..................................................................... 34
6.2.5. Active Preset –Configuration Settings (RH Sidebar) .................................. 34
6.2.5.1. Modulation ....................................................................................... 35
6.2.5.2. Receivers ......................................................................................... 36
6.2.5.3. Decoder ........................................................................................... 37
6.2.5.4. Stream Out ...................................................................................... 38
6.2.5.5. Network .......................................................................................... 39
6.2.5.6.Global ............................................................................................. 40
6.3. Settings........................................................................................................................... 41
6.3.1. RF ...................................................................................................41
6.3.1.1. Modulation ........................................................................................41
6.3.1.2. Channel Plan .................................................................................... 43
6.3.1.3. BDC ................................................................................................ 43
6.3.2. Decoder ........................................................................................... 44
6.3.2.1. Low Latency ..................................................................................... 44
6.3.2.2. Service ............................................................................................ 46
6.3.2.3. Genlock ........................................................................................... 48
6.3.2.4. Analog............................................................................................. 48
6.3.3. Stream ............................................................................................ 49
6.3.3.1. RTP................................................................................................. 49
6.3.3.2. RTSP ................................................................................................51
6.3.3.3. UDP ................................................................................................ 52
6.3.3.4. SRT................................................................................................. 53
6.3.4. eLinks ............................................................................................. 54
6.3.5. Presets ............................................................................................ 55
6.3.6. Network .......................................................................................... 56
6.3.6.1. Network 1/2 ..................................................................................... 56
6.3.6.2. Active Directory................................................................................. 57
6.3.6.3. Tools............................................................................................... 59
6.3.7. Global ............................................................................................. 60
6.3.7.1. ASI ..................................................................................................61
6.3.7.2. Decryption.........................................................................................61
6.3.7.3. User Data......................................................................................... 62
6.3.8. Admin ............................................................................................. 63
6.4. Info .................................................................................................................................. 63
6.4.1. Unit Information................................................................................ 63
6.4.2. License Information............................................................................ 65
6.5. Accounts......................................................................................................................... 67
6.5.1. Users............................................................................................... 67
6.5.2. Add New Account .............................................................................. 67
7. Receiver Installation & Setup ......................................................................... 69
7.1. Before You Connect...................................................................................................... 69
7.2. Connecting the Receiver.............................................................................................. 69
7.3. Powering Up the Receiver........................................................................................... 69
7.4. Setting the Unit IP Address......................................................................................... 69
7.5. Accessing the Web GUI ................................................................................................ 70
7.6. Configuring BDC (Down-conversion) ......................................................................... 70
7.7. Configuring Demodulation........................................................................................... 71
7.7.1. DVB-T Operation ................................................................................71
7.8. Configuring Diversity .................................................................................................... 72
7.9. Configuring Video Decoding........................................................................................ 73
7.10. Deinterleaving ............................................................................................................... 73

Issue No: A Page: vi
Ref: ?-Insert_Document_Part_No._Here-? Copyright © 2021 Vislink is a Vislink Technologies Inc. companies
7.11. Configuring Decryption ................................................................................................ 73
7.12. Configuring & Saving a Preset .................................................................................... 74
8. Licenses & Upgrades......................................................................................... 75
8.1. About Licensing............................................................................................................. 75
8.2. Obtaining New Licenses .............................................................................................. 75
8.3. Firmware Upgrades....................................................................................................... 75
Table of Figures
Figure 2-1 Quantum Receiver Overview ............................................................................. 13
Figure 2-2 Functional Block Diagram................................................................................... 14
Figure 4-1 Quantum Receiver Rear Panel........................................................................... 18
Figure 4-2 RF Input Connectors ............................................................................................ 18
Figure 4-3 ASI/Genlock Connectors...................................................................................... 19
Figure 4-4 Video/Monitoring Output Connectors ............................................................... 19
Figure 4-5 Audio Connectors................................................................................................. 20
Figure 4-6 EXP Connectors .................................................................................................... 21
Figure 4-7 Focal Point Connector ......................................................................................... 21
Figure 4-8 Return Data Connectors ...................................................................................... 22
Figure 4-9 Ethernet LAN/WAN Connectors......................................................................... 22
Figure 4-10 USB Port Connectors ........................................................................................... 23
Figure 4-11 AC Power Connector............................................................................................ 24
Figure 5-1 Quantum Receiver Front Panel ......................................................................... 25
Figure 5-2 Touch-screen Display .......................................................................................... 25
Figure 5-3 Front Panel Home Screen................................................................................... 26
Figure 5-4 Front Panel Setup Screen ................................................................................... 26
Figure 5-5 Front Panel Info Screen....................................................................................... 27
Figure 5-6 Front Panel Status Screen .................................................................................. 27
Figure 6-1 Web GUI Overview .............................................................................................. 28
Figure 6-2 Main Menus........................................................................................................... 28
Figure 6-3 Options Menu ....................................................................................................... 29
Figure 6-4 Streaming Video................................................................................................... 29
Figure 6-5 Streaming Video –Options................................................................................. 30
Figure 6-6 Streaming Video Panel –Control/Status.......................................................... 30
Figure 6-7 Antenna Status (Radar View)............................................................................. 31
Figure 6-8 Antenna Status –Options................................................................................... 31
Figure 6-9 Antenna Status (Graph View)............................................................................. 31
Figure 6-10 Status>Antenna Status Graphs .......................................................................... 32
Figure 6-11 Status>Antenna Status Graphs - Options ........................................................ 32
Figure 6-12 Status>Antenna Status Graphs –Quality/MER and RSL................................ 33
Figure 6-13 Status>Antenna Status Graphs –Historical Graph ......................................... 33
Figure 6-14 Status>Active Preset - Selection....................................................................... 34
Figure 6-15 Status>Active Preset –Configuration Settings ............................................... 34
Figure 6-16 Status>Modulation............................................................................................... 35
Figure 6-17 Status>Modulation –More Information............................................................ 35
Figure 6-18 Status>Receivers.................................................................................................. 36
Figure 6-19 Status>Receivers –More Information............................................................... 36

Issue No: A Page: vii
Ref: ?-Insert_Document_Part_No._Here-? Copyright © 2021 Vislink is a Vislink Technologies Inc. companies
Figure 6-20 Status>Decoder .................................................................................................... 37
Figure 6-21 Status>Decoder –More Information ................................................................. 38
Figure 6-22 Status>Stream Out .............................................................................................. 38
Figure 6-23 Status>Stream Out –More Information ........................................................... 39
Figure 6-24 Status>Network ................................................................................................... 39
Figure 6-25 Status>Network –More Information ................................................................ 40
Figure 6-26 Status>Global ....................................................................................................... 40
Figure 6-27 Status>Global –More Information .................................................................... 41
Figure 6-28 Settings>RF>Modulation..................................................................................... 42
Figure 6-29 Settings>RF>Channel Plan................................................................................. 43
Figure 6-30 Settings>RF>Channel Plan................................................................................. 44
Figure 6-31 Settings>Decoder>Low Latency ........................................................................ 45
Figure 6-32 Settings>Decoder>Service.................................................................................. 47
Figure 6-33 Settings>Decoder>Genlock ................................................................................ 48
Figure 6-34 Settings>Decoder>Analog .................................................................................. 49
Figure 6-35 Settings>Stream>RTP ......................................................................................... 50
Figure 6-36 Settings>Stream>RTSP ....................................................................................... 51
Figure 6-37 Settings>Stream>UDP......................................................................................... 52
Figure 6-38 Settings>Stream>SRT.......................................................................................... 53
Figure 6-39 Settings>Stream>SRT - Change Pass Phrase .................................................. 54
Figure 6-40 Settings>eLinks .................................................................................................... 54
Figure 6-41 Settings>Presets................................................................................................... 55
Figure 6-42 Settings>Presets - Create New Preset ............................................................. 55
Figure 6-43 Settings>Presets - Import New Preset ............................................................. 56
Figure 6-44 Settings>Network>Network 1/2........................................................................ 56
Figure 6-45 Settings>Network>ActiveDirectory................................................................... 58
Figure 6-46 Settings>Network>Tools .................................................................................... 60
Figure 6-47 Settings>Global>ASI............................................................................................ 61
Figure 6-48 Settings>Global>Decryption............................................................................... 61
Figure 6-49 Settings>Global>User Data ................................................................................ 62
Figure 6-50 Settings>Admin.................................................................................................... 63
Figure 6-51 Info –Unit Information ....................................................................................... 63
Figure 6-52 Info>Mac Address –More Information.............................................................. 64
Figure 6-53 Info>Serial Number –More Information .......................................................... 64
Figure 6-54 Info>Software Version –More Information...................................................... 65
Figure 6-55 Info –License Information.................................................................................. 66
Figure 6-56 Accounts –Users.................................................................................................. 67
Figure 6-57 Accounts –Add New Account............................................................................ 67
Table of Tables
Table 1-1 Minimum Safe Distance Overview Table ......................................................... 10
Table 3-1 Physical & Environmental Specification ........................................................... 16
Table 3-2 RF Parameters Specification............................................................................... 16
Table 3-3 IP Transport Stream Processing Specification.................................................. 16
Table 3-4 Video & Audio Parameters Specification .......................................................... 17
Table 4-1 RF Input Pinout .................................................................................................... 18

Issue No: A Page: viii
Ref: ?-Insert_Document_Part_No._Here-? Copyright © 2021 Vislink is a Vislink Technologies Inc. companies
Table 4-2 ASI/Genlock Pinout.............................................................................................. 19
Table 4-3 Video/Monitoring Output Pinout ....................................................................... 20
Table 4-4 Audio Pinout ......................................................................................................... 20
Table 4-5 EXP Pinout ............................................................................................................ 21
Table 4-6 Focal Point Pinout ............................................................................................... 21
Table 4-7 Return Data Pinout .............................................................................................. 22
Table 4-8 Ethernet Pinout .................................................................................................... 23
Table 4-9 USB Pinout............................................................................................................ 24
Table 4-10 AC Power Pinout .................................................................................................. 24
Table 6-1 Role Type Restrictions......................................................................................... 59
Table 7-1 DVB-T Bitrates...................................................................................................... 72
Table 7-2 LMS-T Bitrates...................................................................................................... 72

Quantum Receiver User Manual
General Information
Issue No: A Page: 9
Ref: ?-Insert_Document_Part_No._Here-? Copyright © 2021 Vislink is a Vislink Technologies Inc. companies
1. General Information
1.1. General Safety Information
To ensure awareness of potential hazards, all personnel concerned with the
operation or maintenance of the equipment must study the information that
follows, together with local site regulations.
WARNING:RF Power Hazard: High levels of RF power are present in the unit.
Exposure to RF or microwave power can cause burns and may be
harmful to health. Switch off supplies before removing covers or
disconnecting any RF cables, and before inspecting damaged cables
or antennas.
WARNING:Avoid standing in front of high gain antennas (such as a dish) and
never look into the open end of a waveguide or cable where RF
power may be present.
CAUTION: We strongly recommended that you return any equipment requiring
RF servicing to Vislink.
WARNING:GaAs / BeO Hazard: Certain components inside the equipment
contain Gallium Arsenide and Beryllium Oxide that are toxic
substances. Whilst safe to handle under normal circumstances,
individual components must not be cut, broken apart, incinerated or
chemically processed. In the case of Beryllium Oxide, a white
ceramic material, the principal hazard is from the dust or fumes,
which are carcinogenic if ingested, inhaled or entering damaged
skin.
Please consult your local authority before disposing of these components.
CAUTION: Tantalum Capacitors: When subjected to reverse or excess forward
voltage, ripple current or temperature these components may
rupture and could potentially cause personal injury.
CAUTION: This system contains MOS devices. Electro-Static Discharge (ESD)
precautions should be employed to prevent accidental damage.
1.2. Disposal Instructions
WARNING:DO NOT incinerate batteries. Exposing batteries to naked flames or
extreme heat sources can cause them to rupture or explode.
DO NOT dispose of any of the supplied equipment as household waste. The
supplied equipment is not biodegradable in landfill sites. For safe disposal of
the supplied equipment, take it to your local (council/authority) environmental
waste site. For details, contact your local authority/recycling center.
NOTE: In Europe dispose of all equipment in accordance with the European
Environmental directive.
1.3. Environmental
CAUTION: The unit is IPxx rated and must be protected from dripping or
splashing water/fluids. When used outdoors, protect the unit using a
rain cover.

Quantum Receiver User Manual
General Information
Issue No: A Page: 10
Ref: ?-Insert_Document_Part_No._Here-? Copyright © 2021 Vislink is a Vislink Technologies Inc. companies
1.4. Health & Safety
Exposure to Non-Ionizing (RF) Radiation/Safe Working Distances
The safe working distance from a transmitting antenna may be calculated from
the relationship:
D =
in which D = safe working distance (meters)
PT = transmitter or combiner power output (watts)
GR = antenna gain ratio = anti log (gain dBi ÷10)
w = Maximum allowed power density (watts/square meter)
The RF power density value is determined by reference to safety guidelines for
exposure of the human body to non-ionizing radiation. It is important to note
that the guidelines adopted differ throughout the world and are from time-to-
time re-issued with revised guidelines. For Vislink use, when calculating
minimum safe working distances, apply a maximum power density limit (w) of
1w/m². Appendix A refers.
WARNING: Any transmitting equipment, radiating power at frequencies of 100
kHz and higher, has the potential to produce thermal and athermal
effects upon the human body.
To be safe:
a. Operators should not stand or walk in front of any antenna, nor should they allow
anyone else to do so.
b. Operators should not operate any RF transmitter or power amplifier with any of
its covers removed, nor should they allow anyone else to do so.
Worked examples:
Antenna
Transmitter Power
Type
Gain (dBi)
Gain Ratio
2W
4W
10W
30W
OMNI
4
2.5
1
1
1.5
2.5
HELIX
20
100
4
5.6
9
15.5
PARABOLIC
DISH
35
3,162
22.5
32
50
87
MINIMUM SAFE DISTANCE (METERS)
Table 1-1 Minimum Safe Distance Overview Table
PT. GR
4.w

Quantum Receiver User Manual
General Information
Issue No: A Page: 11
Ref: ?-Insert_Document_Part_No._Here-? Copyright © 2021 Vislink is a Vislink Technologies Inc. companies
1.5. Maximum RF Power Density Limits
The RF Radiation Power Density limit figure recommended by Vislink is based
upon guideline levels published in:
a. IEEE standard C95.1 1999 - IEEE Standard for Safety Levels with respect to
Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300
GHz.
b. Guidelines for Limiting Exposure to Time-varying Electric, Magnetic &
Electromagnetic Fields (up to 300 GHz) published in 1998 by the Secretariat of
the International Commission on Non-Ionising Radiation Protection (ICNIRP).
Both documents define guideline RF power density limits for "Controlled" and
"Uncontrolled" environments. An uncontrolled environment is defined as one
in which the person subjected to the RF radiation may be unaware of and has
no control over the radiation energy received. The uncontrolled environment
conditions can arise, even in the best regulated operations and for this reason
the limits defined for the uncontrolled environment have been assumed for the
Vislink recommended limit.
Documents a) and b) also show the RF power density guidelines to be
frequency dependent. Different power density / frequency characteristics are
presented in the two documents. To avoid complexity and to avoid areas of
uncertainty, Vislink recommends the use of a single power density limit across
the frequency range 100 kHz to 300 GHz. The 1w/m² power density limit we
recommend satisfies the most stringent of the guidelines published to date.
NOTE: The IICNIRP document is freely available for download from the
internet at www.icnirp.de/emfgdl (PDF file) the IEEE standard is
available on loan from Essex County Library on payment of a search
fee.

Quantum Receiver User Manual
General Information
Issue No: A Page: 12
Ref: ?-Insert_Document_Part_No._Here-? Copyright © 2021 Vislink is a Vislink Technologies Inc. companies
This page is intentionally unused.

Quantum Receiver User Manual
Introduction
Issue No: A Page: 13
Ref: ?-Insert_Document_Part_No._Here-? Copyright © 2021 Vislink is a Vislink Technologies Inc. companies
2. Introduction
2.1. IP-Native Wireless Camera Receiver
The Vislink Quantum Receiver is designed to receive one wireless camera
transmitter output using up to 16 RF inputs employing Maximum Ratio
Combining (MRC) and packet switching diversity technology. It then
demodulates the received signals using LMS-T or DVB-T, providing low-latency
HEVC and MPEG-4 video decoding that supports all major video formats (4K
UHD and HD) including High Frame Rate (HFR) and High Dynamic Range (HDR).
The Quantum Receiver delivers content directly over IP fiber networks cutting
out the requirement for additional video compression stages. IP connectivity
enables production teams to work wirelessly and remotely over IP fiber
networks or the unmanaged internet, facilitating efficient live video production
workflows.
Figure 2-1 Quantum Receiver Overview
The Quantum Receiver incorporates a touch-screen interface, APIs and a web
browser application to allow integration into system control and orchestration
tools.
2.2. Firmware Version
This user manual describes the features and functions relating to the firmware
version at the time of writing: QANT-0100-00-06.
To verify the installed version, see either:
Front Panel: see Section 5.4 Info
Web Browser: see Section 6.4 Info
See the Vislink Support website for more details about the Quantum Receiver
and the latest firmware revision.
https://www.vislink.com/support-beyond-expectation/

Quantum Receiver User Manual
Introduction
Issue No: A Page: 14
Ref: ?-Insert_Document_Part_No._Here-? Copyright © 2021 Vislink is a Vislink Technologies Inc. companies
2.3. Functional Description
The relationship between the functions of the receiver and the connectors is
shown in the block diagram below.
Figure 2-2 Functional Block Diagram
The receiver connectors are detailed in Section 4 Rear Panel Connectors.
Multiple units can be cascaded using ASI input and outputs. The use of both
MRC (Maximum Ratio Combining) of the received COFDM signals and the ASI
packet diversity, the combining of two ASI streams to produce a stream with
fewer errors than either input; provides a flexible and extendable receiver
system.
When ‘External ASI & Diversity’ is configured as the unit input, Demod 4 is
switched to external ASI, so the 16-way RF input is reduced to 12-way plus
external ASI and the external ASI cannot be packet switched. Packet switching
is only possible if the external ASI is supplied from a separate Quantum with a
single Demod only.
2.4. Key Features
The following key features are available for this unit:
Up to 16-way diversity LMS-T or DVB-T demodulation
Low-latency HEVC and MPEG-4 video decode compression technology
4K UHD and HD decoding with HDR support
Dual service HEVC HD Decode
IP-native Transport Stream connectivity
SRT support
SMPTE2110-ready

Quantum Receiver User Manual
Introduction
Issue No: A Page: 15
Ref: ?-Insert_Document_Part_No._Here-? Copyright © 2021 Vislink is a Vislink Technologies Inc. companies
2.5. Licensed Options
Various licenses are available to add functionality to the base configuration.
Licensed options are:
QANT-LICE-0001 H.264
QANT-LICE-0002 HEVC
QANT-LICE-0003 4K UHD
QANT-LICE-0004 Dual HEVC
For further information about licenses and how they can be purchased,
delivered, installed and enabled; see Section 8 Licenses & Upgrades.

Quantum Receiver User Manual
Specification
Issue No: A Page: 16
Ref: ?-Insert_Document_Part_No._Here-? Copyright © 2021 Vislink is a Vislink Technologies Inc. companies
3. Specification
3.1. Physical & Environmental
Feature
Description
Dimensions
44mm (H) x 430mm (W) x 368mm (L)
(1.7” (H) x 17” (W) x 14.5” (L))
Weight
4.3kg with 2 Demod Cards fitted (build
dependent)
Temperature
0oC to 50oC (32oF to 122oF)
Humidity
95% long term
Power Connector
3-pin IEC
Power Supply
100 –240VAC
Power Consumption
230W (approx., depending on
configuration)
Table 3-1 Physical & Environmental Specification
3.2. RF Parameters
Feature
Description
RF Inputs
4x RF inputs implementing MRC
Diversity reception per demod card
Up to 4x demod cards per unit
Packet switching diversity between
demod cards
Frequency Band
100MHz -1000MHz** Use in conjunction
with the L3025-series down converters.
FEC
1/2, 2/3, 3/4, 5/6, 7/8
Guard Interval
1/32, 1/16, 1/8, 1/4
Frequency Selection
Up to 64 pre-set channels, or tuning in
1MHz steps via front panel control
Demodulation
DVB-T
LMS-T
Demodulation Modes
QPSK, 16QAM, 64QAM
Bandwidth
DVB-T bandwidths of 6/7/8 MHz
LMS-T bandwidths of 3/4/5/6/7/8/10/
12/14/16/20 or 24 MHz with dual
pedestal
Receiver Threshold
Receiver threshold: -92dBm to
BER 10-5 (nom. QPSK)
Table 3-2 RF Parameters Specification
3.3. IP Transport Stream Processing
Feature
Description
IP Inputs
RTP/UDP IP input
Up to 100Mbit/s
SMPTE2022-2 ProMPEG FEC
SRT
IP Outputs
RTP/UDP IP input
Up to 100Mbit/s
SMPTE2022-2 ProMPEG FEC
SRT
Table 3-3 IP Transport Stream Processing Specification

Quantum Receiver User Manual
Specification
Issue No: A Page: 17
Ref: ?-Insert_Document_Part_No._Here-? Copyright © 2021 Vislink is a Vislink Technologies Inc. companies
3.4. Video & Audio Parameters
Feature
Description
Video Encoder Profiles
HEVC (H.265) UHD & HD:
Profile: Main 4:2:2 10 @ L5.1
Sampling: 8bit & 10bit
Video rate: 1.0-40Mbps
Video format: up to 2160p 60
MPEG-4 AVC (H.264) HD:
Profile: 422HP @ L4.2
Sampling: 8bit & 10bit
Video rate: 1.0-40Mbps
Video format: up to 1080p 60
Video Outputs
3G-SDI SMPTE-424M (UHD)
HD-SDI SMPTE-424M (HD)
6G-SDI SMPTE-2081
12G-SDI SMPTE-2082
Video Formats
480i @ 29.97
576i @ 25
720p @ 50, 59.94 & 60
1080i @ 50, 59.94 & 60
1080p @ 23.98, 24, 25,
29.97, 30, 50, 59.94 & 60
2160p @ 23.98, 24, 25, 29.97, 30, 50,
59.94 & 60
Audio Decoder Profiles
AAC** (AAC-LC & HE-AAC)
MPEG-1 (Layer 1 & Layer 2)
Linear PCM Passthrough
Audio Outputs
Digital: Up to 8x stereo pair Embedded
audio over SDI
Analogue: 2x stereo pair
Genlock
CVBS Black & Burst
Tri-level sync
Latency
Single frame latency*
De-scrambling
Biss-1, Biss-E, AES-128, AES-256,
Bcrypt-128, Bcrypt-256
Dual Decode
HEVC Only
Table 3-4 Video & Audio Parameters Specification
* In combination with Vislink HCAM transmitter in HEVC mode and in
combination with Vislink L1700 and Clip On-4 transmitters
** Check availability

Quantum Receiver User Manual
Rear Panel Connectors
Issue No: A Page: 18
Ref: ?-Insert_Document_Part_No._Here-? Copyright © 2021 Vislink is a Vislink Technologies Inc. companies
4. Rear Panel Connectors
The unit is designed for rack-mounted use and provides input, output,
monitoring, control and power connectors at the rear panel for connection to
other equipment via cable looms.
Figure 4-1 Quantum Receiver Rear Panel
4.1. RF Input Connectors (Demod Cards)
Up to four RF Demod plug-in cards may be fitted to the unit. Each of the cards
provides four RF input coaxial connectors for receiving UHF input 70MHz to
860MHz.
NOTE: These inputs can have up to +24VDC output (enabled in Unit/LNB
Power) to power the external down converter; limited to 400mA per
connector, short circuit protected.
Figure 4-2 RF Input Connectors
Connector
Legend
Description
4x Plug-in Cards, each with
4x RF Connectors:
RF1 –RF4
75 ΩBNC (F)
Table 4-1 RF Input Pinout
4.2. ASI/Genlock Connectors
The Asynchronous Serial Interface (ASI) input and output use copper coaxial
connectors to carry MPEG Transport Streams from/to end equipment. Complies
with ISO/IEC 13818-2 –188-byte mode. ASI input to the Decoder or packet
diversity function for packet switching (Link Research algorithm).
Demod 1
Demod 2
Demod 3
Demod 4

Quantum Receiver User Manual
Rear Panel Connectors
Issue No: A Page: 19
Ref: ?-Insert_Document_Part_No._Here-? Copyright © 2021 Vislink is a Vislink Technologies Inc. companies
The ASI IN connector routes the received stream to either the video decoder,
packet diversity block or ASI OUT connector.
The ASI OUT connector delivers the output stream from the demodulator,
packet diversity block or ASI input for decoding by an external decoder.
The Generator Locking (Genlock) pulse uses a coaxial connector to synchronize
camera frame capture, accurately aligning video and audio sources.
Figure 4-3 ASI/Genlock Connectors
Connector
Legend
Description
1x ASI Input Connector:
ASI IN
75 ΩBNC (F)
1x ASI Output Connector:
ASI OUT
75 ΩBNC (F)
1x Genlock Connector:
GENLOCK
75 ΩBNC (F)
Table 4-2 ASI/Genlock Pinout
4.3. Video/Monitoring Output Connectors
The unit provides four, small form-factor pluggable (SFP) transceiver modules
used for transmitting Serial Data Interface (SDI) signals up to 2.97Gbps over
75Ωcoaxial cables via HD-BNC connectors.
12G SFP option available.
All connectors are outputs (no RX)
Video & Monitor SFPs are non-MSA.
Figure 4-4 Video/Monitoring Output Connectors

Quantum Receiver User Manual
Rear Panel Connectors
Issue No: A Page: 20
Ref: ?-Insert_Document_Part_No._Here-? Copyright © 2021 Vislink is a Vislink Technologies Inc. companies
Connector
Legend
Description
2x SFP cages:
VIDEO 1 & 2
VIDEO 3 & 4
4x 3G SDI out
2x 6G SDI out
1x 12G SDI out
2x SFP cages:
MON 1 & 2
MON 3 & 4
4x 3G SDI out
2x 6G SDI out
1x 12G SDI out
Table 4-3 Video/Monitoring Output Pinout
4.4. Audio Output Connectors
Two, 5-pin Lemo connectors with a audio pair per connector (2 x pairs, 4 x
channels).
48kHz sampling
Clip level: 18dB
THD: < 0.1%
20Hz to 18kHz ±0.25dB
Crosstalk: >60dB minimum
Signal to noise ratio: >66dB RMS
Standard cable assembly part number: L0079
Figure 4-5 Audio Connectors
Connector
Legend
Description
2x 5-Pin Lemo
Socket:
AUDIO1
AUDIO2
Pin 1
Left Line + (Line)
Pin 2
Left Line - (Return)
Pin 3
GND
Pin 4
Right Line + (Line)
Pin 5
Right Line - (Return)
Table 4-4 Audio Pinout
4.5. EXP Connectors
Two, small form-factor pluggable (SFP) expansion sockets (MSA SFP 25GbE)
are provided for future expansion of the unit.
