Vislink Live Gear NewStream User manual

 
RD001414 NewStream Quick Start Guide Revision 2 

NewStreamQuickStartGuide
Overview
TheintentofthisdocumentistoassisttheuserwiththeinitialsetupoftheNewStreamsystemasquicklyaspossibleusingthedefaultsettings.
TheNewStreamshipswiththreedefaultpresets,oneforeachmodeofoperation(ENG,CNG,andSNG)whichcanbeusedimmediatelytotransmit
orstreamvideo/audioaccordingtothelicensedfeaturesordered.TheNewStreamsystem,dependingonthemode,utilizesaRFoutdoorunit
(RFODU)formicrowavetransmission,aCellularoutdoorunit(CODU)forCellulartransmission,andL‐bandoutputsforSatellitetransmission.
QuickStartProcess(ENG)
1. ConnecttheNewStreamoralegacyODUtotheIDU(refertotheIDURearPanelConnectionssectionofthisdocumentforcableconnections)
andsettheODUswitchonrearpaneltomatchtheODUtype.
WARNING:If the ODU switch is placed in the wrong position or if you change the ODU type without changing the switch position
and restarting the IDU, this may result in damage to the ODU and inability to communicate with the ODU.
2. ApplypowertotheIDU.Afterboot‐upverifyODUisdetectedbypushingtheODUtouchscreentabtoseetheODUstatus.
3. ToaccesstheWebUI(thedefaultIPaddressis192.168.1.10,loginusingadmin/admin.
4. SelectPreset1(defaultENG)whichissetforSD‐SDIandembeddedaudio.
5. SelecttheRFchannelyouwanttouseandpressthetransmit/standbybuttontostartRFtransmission.
6. Tocreate,saveorcopycustompresets,RFchannelsorotheradvancedsettingrefertheusermanual.
7. PleasenotethattheusermanualcanbeaccessedfromtheWebUISupporttab.

Note:ForCellular(CNG)andSatellite(SNG)moderefertotheusermanualforinstructionsonhowtogetthesemodes
configured.

Ifyouhaveanyquestions,pleasecall978.671.5995
IDU Front Panel Operating Controls




 
RD001414 NewStream Quick Start Guide Revision 2 
IDU Rear Panel Connections

IDU Control Data Serial Port DB9 Connector Pinouts [Wayside Data]

ControlDataSerialPortDB15ConnectorSignal
2DataIn
5GND

ODU Antenna Control & Power Pinouts

AntennaControl8PinConnectorSignalPower12PinConnectorSignal
ALCJ+VDC
BHK+VDC
CVLGND
DANTMGND
EBAND
F28V
GGND
HNC
 
