Vislink InCam-HG User manual

Vislink, Waterside House, Earls Colne Business Park, Colchester, Essex, CO6 2NS, UK
Telephone: [phone] ●Facsimile: [phone] ●Email: [e-mail] ●Website: www.vislink.com
Company Registered in England & Wales no. 10523708 ●VAT registration no. GB 260 012 169
Registered Office: Waterside House, Earls Colne Business Park, Colchester, Essex, CO6 2NS, UK
InCam-HG
User Manual

Issue No: 1 Page: ii
Ref: INHG-ASUM-70XX Copyright © 2020 IMT and Vislink are Vislink Technologies Inc. companies
Document Disclaimer
The information contained in this manual remains the property of Vislink
and may not be used, disclosed or reproduced in any other form
whatsoever without the prior written permission of Vislink.
Vislink reserves the right to alter the equipment and specification
appertaining to the equipment described in this manual without
notification.
This document is supplied on the express terms that it is to be treated as
confidential and that it may not be copied, used or disclosed to others for
any purpose except as authorized by Vislink.
Trademark Information
Add any additional Trademark content from external companies from their
websites trademark pages etc.
Conventions
NOTE: Notes show to convey additional information.
CAUTION: Cautions show where potential equipment damage could occur.
WARNING: Warnings show where there is potential for personal danger or
risk of death. Read all warnings and understand them before
carrying out work on any equipment. This includes peripherals
and any related equipment in use. The danger is real and not
reading and understanding the warning could lead to injury,
harm or potential death.
Service/Support Contacts:
Register for support:
Worldwide: https://support.imt-solutions.com
Call for support:
Worldwide: [phone]
USA: [phone]
When contacting Technical Support, please include the model and serial
number of the unit (located on a label on the bottom of each unit) and the
approximate date of purchase.

Issue No: 1 Page: iii
Ref: INHG-ASUM-70XX Copyright © 2020 IMT and Vislink are Vislink Technologies Inc. companies
Document History
Version
Date
Modification
Firmware Version
1
29/05/2020
First release of document.
V6.00

Issue No: 1 Page: iv
Ref: INHG-ASUM-70XX Copyright © 2020 IMT and Vislink are Vislink Technologies Inc. companies
Table of Contents
1. General Information.............................................................................................. 7
1.1. General Safety Information ..................................................................................................7
1.2. Disposal Instructions...............................................................................................................7
1.3. Environmental .........................................................................................................................8
1.4. Health & Safety .......................................................................................................................9
1.5. Maximum RF Power Density Limits...................................................................................10
2. InCam-HG Encoder Transmitter Introduction ................................................... 12
2.1. InCam Matrix.........................................................................................................................12
2.2. InCam Optional Items..........................................................................................................13
2.3. Control Panel Operation .....................................................................................................13
2.4. InCam Display .......................................................................................................................14
2.4.1. Main Display..................................................................................................................... 14
2.4.2. Summary Pages .............................................................................................................. 14
3. Specifications....................................................................................................... 15
3.1. Physical...................................................................................................................................15
3.2. Inputs.......................................................................................................................................15
3.3. Output.....................................................................................................................................15
3.4. Video .......................................................................................................................................16
3.5. Audio .......................................................................................................................................16
4. InCam Transmitter Connector Descriptions.................................................... 17
4.1. Camera Connection..............................................................................................................17
4.2. Modulator Input / Output Connectors...............................................................................18
4.2.1. COFDM TX RF................................................................................................................... 18
4.2.2. UHF RX RF....................................................................................................................... 18
4.3. Modulation Options...............................................................................................................18
4.3.1. DVB-T Operation ........................................................................................................... 19
4.3.2. LMS-T Operation........................................................................................................... 20
4.4. InCam Connections...............................................................................................................20
4.4.1. External DC Input ......................................................................................................... 20
4.4.2. MON OUT ........................................................................................................................ 20
4.4.3. VF VIDEO ........................................................................................................................ 20
4.4.4. STEADY CAM TALLY...................................................................................................... 21
4.4.5. EXTERNAL AUDIO 2 IN.................................................................................................. 21
5. Software Menus................................................................................................... 22
5.1. Icons ........................................................................................................................................22
5.2. SDI Input Type .......................................................................................................................22
5.3. Audio Settings .......................................................................................................................22
5.4. Wi-Fi Settings ........................................................................................................................23
5.5. Recall Default Settings.........................................................................................................23
5.6. Advanced Menu.....................................................................................................................23
5.7. InCam Menus .........................................................................................................................23
6. Mechanics ............................................................................................................. 34
6.1. Docking to Camera ...............................................................................................................34
6.2. Docking Modulator module .................................................................................................36

Issue No: 1 Page: v
Ref: INHG-ASUM-70XX Copyright © 2020 IMT and Vislink are Vislink Technologies Inc. companies
7. InCam Setup ......................................................................................................... 37
7.1. Camera Hardware.................................................................................................................37
7.2. Turning on..............................................................................................................................37
7.3. Video Format Configuration ...............................................................................................38
7.3.1. Video Combinations ......................................................................................................38
7.4. Audio Combinations .............................................................................................................38
7.4.1. SuperSlot .........................................................................................................................38
7.4.2. External Audio 2 ............................................................................................................39
7.5. InCam Back Indications........................................................................................................39
8. FocalPoint Camera Control................................................................................ 40
8.1. Introduction............................................................................................................................40
8.2. FocalPoint Camera Control Overview...............................................................................40
8.2.1. Camera Configuration ................................................................................................. 40
8.2.2. Grass Valley VS Generic/Transparent mode........................................................... 40
8.2.2.1. Grass Valley mode..................................................................................................... 40
8.2.2.2. Generic/Transparent mode....................................................................................... 41
8.2.3. Menu descriptions ......................................................................................................... 41
9. Firmware Upgrades............................................................................................. 43
Table of Figures
Figure 2-1 Keypad .......................................................................................................................13
Figure 4-1 Camera Connection .................................................................................................17
Figure 6-1 Camera Docking #1.................................................................................................. 34
Figure 6-2 Camera Docking #2 ................................................................................................. 34
Figure 6-3 Camera Docking #3 .................................................................................................35
Figure 6-4 Modulator Docking...................................................................................................36
Figure 7-1 On/Off Switch........................................................................................................... 37
Figure 7-2 Camera Control Indication LED’s........................................................................... 39
Table of Tables
Table 1-1 Minimum Safe Distance Overview Table............................................................... 9
Table 2-1 InCam Matrix Table.................................................................................................. 12
Table 2-2 Licenses Table .......................................................................................................... 13
Table 2-3 UHF Antennas........................................................................................................... 13
Table 2-4 Keypad Overview..................................................................................................... 14
Table 3-1 Physical Spec ............................................................................................................ 15
Table 3-2 Inputs Table............................................................................................................... 15
Table 3-3 Outputs Table ........................................................................................................... 16
Table 3-4 Video Table................................................................................................................16
Table 3-5 Audio Encoding Table.............................................................................................. 16
Table 4-1 OFDM Antennas........................................................................................................18
Table 4-2 DVBT Bitrate Table .................................................................................................. 19
Table 4-3 LMS-T Bitrate Table................................................................................................. 20
Table 4-4 DC Input Connection................................................................................................20

Issue No: 1 Page: vi
Ref: INHG-ASUM-70XX Copyright © 2020 IMT and Vislink are Vislink Technologies Inc. companies
Table 4-5 SteadyCam Tally Connection.................................................................................21
Table 4-6 Ext Audio Connection..............................................................................................21
Table 5-1 Icons Table ................................................................................................................22
Table 5-2 SDI Input Type .......................................................................................................... 22
Table 7-1 On/Off Switch Position ...........................................................................................37
Table 7-2 Video Combinations................................................................................................. 38

Template Operators Manual
General Information
Issue No: 1 Page: 7
Ref: INHG-ASUM-70XX Copyright © 2020 IMT and Vislink are Vislink Technologies Inc. companies
1. General Information
1.1. General Safety Information
To ensure awareness of potential hazards, all personnel concerned with
the operation or maintenance of the equipment must study the
information that follows, together with local site regulations.
WARNING: RF Power Hazard: High levels of RF power are present in the
unit. Exposure to RF or microwave power can cause burns and
may be harmful to health. Switch off supplies before removing
covers or disconnecting any RF cables, and before inspecting
damaged cables or antennas.
WARNING: Avoid standing in front of high gain antennas (such as a dish)
and never look into the open end of a waveguide or cable where
RF power may be present.
CAUTION: We strongly recommended that you return any equipment
requiring RF servicing to Vislink.
WARNING- GaAs / BeO Hazard: Certain components inside the equipment
contain Gallium Arsenide and Beryllium Oxide that are toxic
substances. Whilst safe to handle under normal circumstances,
individual components must not be cut, broken apart,
incinerated or chemically processed. In the case of Beryllium
Oxide, a white ceramic material, the principal hazard is from the
dust or fumes, which are carcinogenic if ingested, inhaled or
entering damaged skin.
Please consult your local authority before disposing of these components.
CAUTION: Tantalum Capacitors: When subjected to reverse or excess
forward voltage, ripple current or temperature these
components may rupture and could potentially cause personal
injury.
CAUTION: This system contains MOS devices. Electro-Static Discharge
(ESD) precautions should be employed to prevent accidental
damage.
1.2. Disposal Instructions
WARNING: DO NOT incinerate batteries. Exposing batteries to naked
flames or extreme heat sources can cause them to rupture or
explode.
DO NOT dispose of any of the supplied equipment as household waste.
The supplied equipment is not biodegradable in landfill sites. For safe
disposal of the supplied equipment, take it to your local (council/authority)
environmental waste site. For details, contact your local
authority/recycling center.
NOTE: In Europe dispose of all equipment in accordance with the
European Environmental directive.

Template Operators Manual
General Information
Issue No: 1 Page: 8
Ref: INHG-ASUM-70XX Copyright © 2020 IMT and Vislink are Vislink Technologies Inc. companies
1.3. Environmental
CAUTION: The unit is IPxx rated and must be protected from dripping or
splashing water/fluids. When used outdoors, protect the unit
using a rain cover.

Template Operators Manual
General Information
Issue No: 1 Page: 9
Ref: INHG-ASUM-70XX Copyright © 2020 IMT and Vislink are Vislink Technologies Inc. companies
1.4. Health & Safety
Exposure to Non-Ionizing (RF) Radiation/Safe Working Distances
The safe working distance from a transmitting antenna may be calculated
from the relationship:
D =
in which D = safe working distance (meters)
PT = transmitter or combiner power output (watts)
GR = antenna gain ratio = anti log (gain dBi ÷10)
w = Maximum allowed power density (watts/square meter)
The RF power density value is determined by reference to safety
guidelines for exposure of the human body to non-ionizing radiation. It is
important to note that the guidelines adopted differ throughout the world
and are from time-to-time re-issued with revised guidelines. For Vislink
use, when calculating minimum safe working distances, apply a maximum
power density limit (w) of 1w/m². Appendix A refers.
WARNING: Any transmitting equipment, radiating power at frequencies of
100 kHz and higher, has the potential to produce thermal and
athermal effects upon the human body.
To be safe:
a. Operators should not stand or walk in front of any antenna, nor should they
allow anyone else to do so.
b. Operators should not operate any RF transmitter or power amplifier with any of
its covers removed, nor should they allow anyone else to do so.
Worked examples:
Antenna
Transmitter Power
Type
Gain (dBi)
Gain Ratio
2W
4W
10W
30W
OMNI
4
2.5
1
1
1.5
2.5
HELIX
20
100
4
5.6
9
15.5
PARABOLIC
DISH
35
3,162
22.5
32
50
87
MINIMUM SAFE DISTANCE (METERS)
Table 1-1 Minimum Safe Distance Overview Table
PT. GR
4.w

Template Operators Manual
General Information
Issue No: 1 Page: 10
Ref: INHG-ASUM-70XX Copyright © 2020 IMT and Vislink are Vislink Technologies Inc. companies
1.5. Maximum RF Power Density Limits
The RF Radiation Power Density limit figure recommended by Vislink is
based upon guideline levels published in:
a. IEEE standard C95.1 1999 - IEEE Standard for Safety Levels with respect to
Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz.
b. Guidelines for Limiting Exposure to Time-varying Electric, Magnetic &
Electromagnetic Fields (up to 300 GHz) published in 1998 by the Secretariat of
the International Commission on Non-Ionising Radiation Protection (ICNIRP).
Both documents define guideline RF power density limits for "Controlled"
and "Uncontrolled" environments. An uncontrolled environment is defined
as one in which the person subjected to the RF radiation may be unaware
of and has no control over the radiation energy received. The
uncontrolled environment conditions can arise, even in the best regulated
operations and for this reason the limits defined for the uncontrolled
environment have been assumed for the Vislink recommended limit.
Documents a) and b) also show the RF power density guidelines to be
frequency dependent. Different power density / frequency characteristics
are presented in the two documents. To avoid complexity and to avoid
areas of uncertainty, Vislink recommends the use of a single power
density limit across the frequency range 100 kHz to 300 GHz. The 1w/m²
power density limit we recommend satisfies the most stringent of the
guidelines published to date.
NOTE: The IICNIRP document is freely available for download from the
internet at www.icnirp.de/emfgdl (PDF file) the IEEE standard is
available on loan from Essex County Library on payment of a search
fee.

Template Operators Manual
General Information
Issue No: 1 Page: 11
Ref: INHG-ASUM-70XX Copyright © 2020 IMT and Vislink are Vislink Technologies Inc. companies
This page is intentionally unused.

Template Operators Manual
InCam-HG Encoder Transmitter Introduction
Issue No: 1 Page: 12
Ref: INHG-ASUM-70XX Copyright © 2020 IMT and Vislink are Vislink Technologies Inc. companies
2. InCam-HG Encoder Transmitter Introduction
The Vislink INCAM-HG is a fully integrated HEVC 4K UHD, HDR-ready
wireless system, designed for the Grass Valley LDX 86N 4k-RF 4K UHD
camera.
The INCAM-HG offers full broadcast quality encoding at 4K UHD, 1080p,
1080i and 720p with camera control.
The unit utilizes user-changeable RF modules for rapid, in-field, swap
outs.
2.1. InCam Matrix
The InCam-HG unit comprises of two parts with the main chassis and
interchangeable RF unit, meaning the unit is flexible to changing needs.
Unit Number
Max
O/P
Power
(mW)
Freq
RF/UHF
Module
View-
Back
Battery
Plate
INHG-ASSY-7002
250
1.95-2.7 GHz
HCAM-ASSY-5501
✓
IDX
INHG-ASSY-7003
100
5.6-6.0 GHz
HCAM-ASSY-5506
✓
IDX
INHG-ASSY-7004
100
6.8-7.5 GHz
HCAM-ASSY-5505
✓
IDX
INHG-ASSY-7005
100
6.425-7.125 GHz
HCAM-ASSY-5504
✓
IDX
INHG-ASSY-7006
250
1.95-2.7 GHz
HCAM-ASSY-5501
✓
A/B
INHG-ASSY-7007
100
5.6-6.0 GHz
HCAM-ASSY-5506
✓
A/B
INHG-ASSY-7008
100
6.8-7.5 GHz
HCAM-ASSY-5505
✓
A/B
INHG-ASSY-7009
100
6.425-7.125 GHz
HCAM-ASSY-5504
✓
A/B
INHG-ASSY-7010
250
1.95-2.7 GHz
HCAM-ASSY-5501
X
IDX
INHG-ASSY-7011
100
5.6-6.0 GHz
HCAM-ASSY-5506
X
IDX
INHG-ASSY-7012
100
6.8-7.5 GHz
HCAM-ASSY-5505
X
IDX
INHG-ASSY-7013
100
6.425-7.125 GHz
HCAM-ASSY-5504
X
IDX
INHG-ASSY-7014
250
1.95-2.7 GHz
HCAM-ASSY-5501
X
A/B
INHG-ASSY-7015
100
5.6-6.0 GHz
HCAM-ASSY-5506
X
A/B
INHG-ASSY-7016
100
6.8-7.5 GHz
HCAM-ASSY-5505
X
A/B
INHG-ASSY-7017
100
6.425-7.125 GHz
HCAM-ASSY-5504
X
A/B
INHG-ASSY-7018
250
3.2-3.9 GHz
HCAM-ASSY-5502
✓
IDX
INHG-ASSY-7019
250
3.2-3.9 GHz
HCAM-ASSY-5502
✓
A/B
INHG-ASSY-7020
250
3.2-3.9 GHz
HCAM-ASSY-5502
X
IDX
INHG-ASSY-7021
250
3.2-3.9 GHz
HCAM-ASSY-5502
X
A/B
INHG-ASSY-7022
100
4.45-5.0 GHz
HCAM-ASSY-5503
✓
IDX
INHG-ASSY-7023
100
4.45-5.0 GHz
HCAM-ASSY-5503
X
IDX
Table 2-1 InCam Matrix Table

Template Operators Manual
InCam-HG Encoder Transmitter Introduction
Issue No: 1 Page: 13
Ref: INHG-ASUM-70XX Copyright © 2020 IMT and Vislink are Vislink Technologies Inc. companies
2.2.InCam Optional Items
The following table outlines the currently available InCam license and
Antenna options.
INCAM Licenses
HCAM-LICE-0001
HCAM/INCAM LICENSE SERVICE 1 4K UHD ENCODE + HD 1080P
HCAM-LICE-0007
HCAM/INCAM LICENSE H.264 ENCODING
HCAM-LICE-0008
HCAM/INCAM LICENSE DEEP INTERLEAVING
HCAM-LICE-0009
HCAM/INCAM LICENSE VARIABLE BANDWIDTH LMS-T
HCAM-LICE-0010
HCAM/INCAM LICENSE UHF RX CAMERA CONTROL
HCAM-LICE-0011
HCAM/INCAM LICENSE BISS SCRAMBLING
Table 2-2 Licenses Table
Antenna Options
L0018-4145
ANTENNA UHF 410-450MHz SMA(M) RED CAP
L0018-4549
ANTENNA UHF 450-490MHz SMA(M) BLUE CAP
Table 2-3 UHF Antennas
2.3.Control Panel Operation
Use the InCam control panel to configure and make in-field changes to the
unit’s configuration.
Figure 2-1 Keypad
Use the directional pads to navigate through the menu structure,
displayed on the OLED screen.
Press OK to accept and save changes.

Template Operators Manual
InCam-HG Encoder Transmitter Introduction
Issue No: 1 Page: 14
Ref: INHG-ASUM-70XX Copyright © 2020 IMT and Vislink are Vislink Technologies Inc. companies
Press ESC to cancel, exit and back out of menus.
Action
Function
Up and
down
Modifies alphanumeric values
Left and
right
Changes the alphanumeric character being
edited / Navigates
OK
Accepts the newly edited value (or enters
menus)
ESC
Cancels the edit (or exits menus)
Table 2-4 Keypad Overview
When you power on the INCAM, it reverts to the last known condition.
2.4.InCam Display
2.4.1. Main Display
The InCam encoder has an integrated OLED display. The brightness of
OLED displays reduces with usage. To increase the life of the OLED
display, we advise that you enable the display time-out where possible.
Operating the directional keys reactivates the display after a time-out.
The default for the timeout comes enabled and set to 30 seconds.
2.4.2. Summary Pages
The InCam display provides a tree like menu structure of control
parameters and status indicators. In addition, at the top level of the menu
structure, there are summary pages, accessed using the Esc keypad. The
summary pages, along with the display icons, give quick access to
important parameters. Press OK to access menus.

Template Operators Manual
Specifications
Issue No: 1 Page: 15
Ref: INHG-ASUM-70XX Copyright © 2020 IMT and Vislink are Vislink Technologies Inc. companies
3. Specifications
3.1. Physical
Feature
Description
Dimensions
212 x 213 x 141 mm
Weight
2.8kG
Temperature
-20oC to 45oC (-4oF to 113oF)
Power Connector
4-pin XLR or Battery
Power Consumption
Nominally 30W in standard
configuration (with L1750-1927)
Table 3-1 Physical Spec
3.2.Inputs
Feature
Description
Audio
Camera XLR - Analogue
WisyCom, Super Slot - AES
External XLR - Analogue
UHF Receiver
410 to 490MHz range
FocalPoint camera control
compatibility
View-Back Receiver
H.264 Diversity Receiver
with switchable Viewfinder
Table 3-2 Inputs Table
3.3.Output
Feature
Description
Frequency Band
See the InCam Matrix table.
Transmit Power
10 to 250mW (or add barrel booster option)
RF Module specific
Transmit Antenna
Omni-directional 3 dBi gain (nominal)
Frequency Selection
Up to 32 preset channels for tuning
Modulation
COFDM DVB-T or LMS-T
Modulation Modes
DVB-T:
-QPSK, 16QAM, 64QAM
-FEC: 1/2, 2/3, 3/4, 5/6, 7/8
-Guard Interval: 1/32, 1/16, 1/8, 1/4
LMS-T:
-QPSK, 16QAM
-FEC: 1/2, 2/3, 3/4, 5/6, 7/8, 9/10, 14/15
-Guard Interval: 1/16, 1/8
Data Rate
DVB-T 4.98 to 31.7 Mbit/s
LMS-T up to 43 Mbit/s bandwidth dependent
(licensed option)

Template Operators Manual
Specifications
Issue No: 1 Page: 16
Ref: INHG-ASUM-70XX Copyright © 2020 IMT and Vislink are Vislink Technologies Inc. companies
Bandwidth
DVB-T: 6/7/8MHz
LMS-T: 3/4/5/6/7/8/10/12/14/16/20MHz or
24MHz with two carrier density options
Optional pre-distortion for enhanced
adjacent channel performance (frequency
permitting)
Monitor SDI
View-Back loop through of camera output,
Can be set to View-Back image
VF SDI
Viewfinder monitor output
Table 3-3 Outputs Table
3.4.Video
Feature
Description
Video Formats
480i/29.97
576i/25
720p/50, 59.94, 60
1080i/50, 59.94, 60
1080p/23.98, 24, 25, 29.97, 30, 50, 59.94, 60
2160p/23.98, 24, 25, 29.97, 30, 50, 59.94, 60
Video Encoder Profiles
H.265 HEVC Main, Main-10:
- H.265 HEVC 8/10 Bit to 4K 60p
H.264 AVC Main, High, Baseline up to Level 5.2:
- H.264 AVC High 10/4:2:2
- H.264 AVC 4:2:0/4:2:2
- 8/10 Bit to HD 60p
4K Native and UHD (1 Service)
- 4.2.0 Main
- 4.2.2 Main
Encoding
HEVC (H.265)
AVC (H.264)
MPEG-2 (H.262)
Table 3-4 Video Table
3.5.Audio
Feature
Description
Encoding
AAC
MPEG-1
AES/Dolby Pass through
Table 3-5 Audio Encoding Table

Template Operators Manual
InCam Transmitter Connector Descriptions
Issue No: 1 Page: 17
Ref: INHG-ASUM-70XX Copyright © 2020 IMT and Vislink are Vislink Technologies Inc. companies
4. InCam Transmitter Connector Descriptions
The InCam Side Panel unit consists of two assemblies. The main chassis
housing encoder hardware and the interchangeable transmitter module.
4.1. Camera Connection
Figure 4-1 Camera Connection
The InCam uses the same docking method as the Grass Valley Triax/Fiber
camera back.

Template Operators Manual
InCam Transmitter Connector Descriptions
Issue No: 1 Page: 18
Ref: INHG-ASUM-70XX Copyright © 2020 IMT and Vislink are Vislink Technologies Inc. companies
4.2.Modulator Input / Output Connectors
4.2.1. COFDM TX RF
100mW into 50Ω–switchable. 10, 50, 100 and 250mW fixed power
settings, and a user-adjustable mode between zero and 24dBm.
NOTE: 250mW is for use in FCC regulatory regions only.
50Ωchassis mounted ‘N’type bulkhead socket.
Antenna:
L3421 TX Omni Spring 3 dBi 1.95-2.7GHZ
L3423 TX Omni Spring 3 dBi 1.95-2.7GHZ
(Extra Long)
L3424 TX Omni Spring 3 dBi 3.0-3.7GHZ
Table 4-1 OFDM Antennas
WARNING: There should always be an antenna connected to the N-type
connector when the unit is powered.
4.2.2. UHF RX RF
SMA connector for UHF receive antenna: 410-490MHz.
Antenna: L0018-4145 410-450MHz SMA (M) Red Cap
Antenna: L0018-4549 450-490MHz SMA (M) Blue Cap
4.3.Modulation Options
The modulator operates as one of three main types:
1. Single Pedestal LMST(S)
2. Dual Pedestal LMST(D)
3. DVB-T
Modulation options are selected in the MODULATOR > Modulation menu.
Here, you select either LMST or DVB-T.
Select the Bandwidth from MODULATOR > Bandwidth menu.
NOTE: In LMST(D) mode, the bandwidth shown is the combined width of
the two pedestals.

Template Operators Manual
InCam Transmitter Connector Descriptions
Issue No: 1 Page: 19
Ref: INHG-ASUM-70XX Copyright © 2020 IMT and Vislink are Vislink Technologies Inc. companies
The LMST bandwidths:
•Single Pedestal:
−3, 4, 5, 6, 7, 8, 10, 12 MHz
NOTE: Without a variable bandwidth license, only 10MHz is available.
•Dual Pedestal:
−6, 8, 10, 12, 14, 16, 20 & 24 MHz
NOTE: Without a variable bandwidth license, only 20MHz is available.
The DVB-T bandwidths:
•6, 7 & 8 MHz
4.3.1. DVB-T Operation
The table below defines the corresponding gross bit rates for DVB-T
operation. This includes video, audio, data and other transport stream data
tables.
Bitrates (Mbit/s) for a DVB-T system in 8 MHz channels
Modulation
Code
Rate
Guard Interval
1/4
1/8
1/16
1/32
QPSK
1/2
4.976
5.529
5.855
6.032
2/3
6.635
7.373
7.806
8.043
3/4
7.465
8.294
8.782
9.048
5/6
8.294
9.216
9.758
10.053
7/8
8.709
9.676
10.246
10.556
16-QAM
1/2
9.953
11.059
11.709
12.064
2/3
13.271
14.745
15.612
16.086
3/4
14.929
16.588
17.564
18.096
5/6
16.588
18.431
19.516
20.107
7/8
17.418
19.353
20.491
21.112
64-QAM
1/2
14.929
16.588
17.564
18.096
2/3
19.906
22.118
23.419
24.128
3/4
22.394
24.882
26.346
27.144
5/6
24.882
27.647
29.273
30.16
7/8
26.126
29.029
30.737
31.668
Table 4-2 DVBT Bitrate Table

Template Operators Manual
InCam Transmitter Connector Descriptions
Issue No: 1 Page: 20
Ref: INHG-ASUM-70XX Copyright © 2020 IMT and Vislink are Vislink Technologies Inc. companies
4.3.2. LMS-T Operation
The table below defines the corresponding gross bit rates for LMS-T
operation at the most common bandwidths (Single or Dual pedestal):
Bitrates (Mbit/s) for a LMS-T system
Channels
Guard Interval
Modulation
Code Rate
10MHz
20MHz
24 MHz
1/8
1/16
1/8
1/16
1/8
1/16
QPSK
2/3
9.2
9.7
18.4
19.5
22.1
23.4
16QAM
2/3
18.4
19.5
36.8
39
44.2
46.8
Table 4-3 LMS-T Bitrate Table
4.4.InCam Connections
4.4.1. External DC Input
EXT. DC IN 11-17V
Connection
1
GnD
2
N/C
3
N/C
4
+12 Volts
Table 4-4 DC Input Connection
WARNING: Battery input has priority over External DC Input
4.4.2. MON OUT
75ΩBNC chassis mounted socket,
SDI monitor output from View-Back receiver.
Output options:
•Camera loop through –2SI Output 1 in 4K
•View-Back decoder
4.4.3. VF VIDEO
75ΩBNC chassis mounted socket,
SDI Viewfinder output.
NOTE: Viewfinder output menu not available in 4K formats
