Vitek SAGA VT-ST440H User manual

blackyellowmagentacyan
(888) VITEK-70 | WWW.VITEKCCTV.COM
28492 Constellation Road Valencia, CA 91355
SAGA “ST-H” Series 4, 8, and 16 Channel Digital Video
Recorders with H.264 Compression
• Efficient H.264 Compression Algorithm
• 240 IPS Recording per Channel (VT-STH84 0 / VT-STH16
40) & 120 IPS Recording (VT-STH440 at HD1 Resolution)
• Up to 4 HDDs Internal Storage (4x - 2TB HDD) and Up to
80 Terabytes External Storage (4x - 10 HDD Expansion bay
units) for a total of 88 Terabytes of Storage
• Smooth, Continuous Reverse Playback
• 4 Channel Audio
• Remote Viewing with 2-way Audio Communication over the
internet
• Multi-site remote client
• Built-in DVD/RW drive
• Accepts 4 External (VT-XHD10) HDD Bays for an Additional
40 Hard Drives
• Block Search Function Retrieves Lost Files, Even from
Damaged Hard Drives
• USB Mouse Compatible
• Embedded Linux OS
• Dynamic IP support (DDNS)
• Average File Size of 1~3KB(CIF), 3~7KB(HD1),
6~15KB(D1)
• Continuous, Motion, Alarm, V-Loss, Scheduled recording
modes
• Numerous search modes: Calendar, Search & Copy, Time,
Event, Block, File, Bookmark & Log
• Notification e-mail to up to 10 accounts on Motion, Alarm,
V-Loss, HDD Fail
• Pentaplex Plus: Record, Playback, Network Transmission,
Mirror, Backup and Live Viewing
• Backup to External HDD, CD-R, DVD-RW, DVD+RW, USB
Memory Stick
• Control up to 16 DVRs via Keyboard or IR Remote control
FEATURES
VT-XHD10U
SAGA Series USB 2.0 HDD
Expansion Bay
• Capable of supporting up to 10 IDE
hard drives
• Hard drives can be setup in a
Mirrored Array for redundancy,
Striped into a massive disk array up
to a 80TB, or in any combination of
each
• Up to 4 Bays can be connected via
USB 2.0
H.264
Compression
blackyellowmagentacyan
(888) VITEK-70 | WWW.VITEKCCTV.COM
28492 Constellation Road Valencia, CA 91355
SAGA “ST-H” Series 4, 8, and 16 Channel Digital Video
Recorders with H.264 Compression
Video Standard NTSC & PAL Standards, automatic configuration
Video Input 4 Channels BNC 8 Channels BNC 16 Channels BNC
Input Level 1.0 Vp-p ± 10% Composite, 75 Ohm Balanced.
Loop Through Output 4 Channels BNC 75 Ohm Balanced w/ Automatic
Signal Boost 8 Channels BNC 75 Ohm Balanced w/ Automatic Signal Boost 16 Channels BNC 75 Ohm Balanced w/ Automatic
Signal Boost
Main Video Output 1.0 Vp-p Composite, 75 Ohm Balanced
Spot Video Output 1.0 Vp-p Composite, 75 Ohm Balanced
S-Video Output 4-pins mini DIN
VGA Output 15 pins female DSUB
Channel Title 8 Alphanumeric Characters / Bitmap Picture or Characters
Live Display 1 & 4 w/ Customizable 4 Channel View Mode 1, 4, 6, 7 & 8 w/ Customizable 4, 6 & 7 Channel View Modes 1, 4, 6, 7, 9, 10, 13 & 16 w/ Customizable 4, 6, 7, 9,
10 & 13 Channel View Mode
Spot Display Single Channel View
Live Display Resolution NTSC: 720 x 480 PAL: 720 x 576
Playback Display 1 & 4 w/ Customizable 4 Channel View Mode 1, 4, 6, 7 & 8 w/ Customizable 4, 6 & 7 Channel View Modes 1, 4, 6, 7, 9, 10, 13 & 16 w/ Customizable 4, 6, 7, 9,
10 & 13 Channel View Mode
Automatic Sequence Interval 0 ~ 60 seconds
Codec ADPCM
Audio In 4 Channels
Audio Out 1 Channel
Input Level 0.5 ~ 1.4 Vp-p @ 20KOhm
Codec H.264
Recording Resolution NTSC: D1 (720 X 480), Half-D1 (720 X 240), CIF (360 X 240) / PAL: D1 (720 X 576), Half-D1 (720 X 288), CIF (360 X 288)
Recording Speed
NTSC - Max 120ips (120ips @ CIF / 120ips @ HD1
/ 60ips @ D1) / PAL - Max 100ips (100ips @ CIF /
100ips @ HD1 / 50ips @ D1)
NTSC - Max 240ips (240ips @ CIF / 120ips @ HD1 / 60ips @ D1) / PAL - Max 200ips (200ips @ CIF / 100ips @
HD1 / 50ips @ D1)
Recording Quality Low / Fine / Superfine
Maximum Average File Size CIF:3K HD1: 7K D1: 15K
Recording Modes Normal (Continuous),Event ( Motion detection, Sensor, Video loss), Schedule, Holiday
Search Modes Calendar, Search & Copy, Time, Event, Block, File, Bookmark & Log
Playback Modes Forward & Reverse, Pause, Picture by Picture, Normal, Slow up to 128th of normal speed, Fast up to 128X normal speed
Motion Recording 300 Selectable Grids & Multi-Level Detection per Channel
Alarm Recording 4 Channel Terminal Blocks, Normally Open or Normally Closed Circuit
Alarm Output 4 Relay output 2 pins Terminal Block (NO, Common) x 4=8P (Total)
Pre / Post Event Buffer 5 Seconds Pre-Event / Up to 60 Seconds Post-Event Buffer
Network LAN, WAN, Internet
DDNS/Dynamic IP support Dynamic IP address and DDNS lookup
Monitoring Environment Dedicated Central Monitoring System
Multisite Monitoring No limit on Registration of DVRs, up to 64 multi-camera view (DMCC) AND up to 16 DVR or 256 cameras view (client viewer)
Audio Transmission 2-Way Audio Communication
Internal Storage 4 Hard Drives, 8 Terabytes Maximum
External Storage 40 Hard Drives, 80 Terabytes Maximum
Speed 5400 RPM Minimum, 7200 RPM Maximum
DMA 45Mhz DMA
Hard Drive Type SATA
Seek Time Faster than 9.0ms average
Expansion Bay Interface USB 2.0
Data Redundancy Event Backup / Individual Hard Drive Mirroring
Security 5 separate user access and passwords monitor menu access, record / playback / network / backup
Watchdog Software Watchdog
System Log Power Failure Check
Recovery Auto-Reboot by watchdog and resumes previous operating mode &
Event Notification Notification e-mail to up to 10 accounts on Motion, Alarm, V-Loss, HDD Fail
Log File List 20,000 Logs
Operating System Modified Embedded Linux
Simultaneous Functions Pentaplex Plus: Record, Playback, Mirror, Backup, Network Transmission and Live Monitoring
Control Devices Front buttons, IR Remote Controller, Mouse, Remote Client Software and Keyboard
Multiple DVR Support Control up to 255 DVRs via Keyboard Controller; 16 with IR Remote Controller
Matrix & Cascade support Up to 16 DVRs per Matrix, up to 15 Matrix systems
File Compatibility Compatible with Windows based operating systems
USB Interface 3 USB 2.0 slots, 1 in Front, 2 in Rear
Backup Backup to External HDD, CD-R, DVD-RW, DVD+RW, USB Memory Stick
Serial Interface RS-232C for External Control & Debugging
Terminal Block RS-485 Interface for PTZ control
Ethernet RJ45 @ 10/100Mbps
Power Source DC 12V, 10A
Power Consumption Approx. 60 Watt ( Including 1 HDD)
Operating Temperature 0º ~ +40º (32º ~ 104º Fahrenheit)
Storage Temperature -10º ~ +60º (12º ~ 140º Fahrenheit)
Humidity 30% ~ 90% Non-Condensing
Dimensions (W x H x D) 16.93” x 2. 68” x 15.35”(430mm x 68mm x 390mm)
Detailed Specifications VT-ST440H VT-ST840H VT-ST1640H

This manual suits for next models

3
