Vitek VTC-C750WDR User manual

blackyellowmagentacyan
(888) VITEK-70 | WWW.VITEKCCTV.COM
28492 Constellation Road Valencia, CA 91355
VTC-C750/WDR Pixim Powered WDR Color CCD
Camera w/550TVL
• Wide Dynamic Range 1/3” Color DPS Pixim Image Sensor
• 550 TV Lines of Resolution
• OSD (On Screen Display) for Camera Function Setup
• True (ICR) Day/Night Function
• 0.0002 Lux Sensitivity (F1.2 @40IRE Sense-Up)
• Dual Voltage Operation 12VDC/24VAC
• Over 50dB S/N Ratio
FEATURES

blackyellowmagentacyan
(888) VITEK-70 | WWW.VITEKCCTV.COM
28492 Constellation Road Valencia, CA 91355
VTC-C750/WDR Pixim Powered WDR Color CCD
Camera w/550TVL
Detailed Specifications
Image Device
Effective Pixels
TV System
Scan Frequency
Synchronization
H. Resolution
Sensitivity
S/N Ratio
White Balance
S/N Ratio
Electronic Iris
White Balance
WDR Mode
Auto Iris Control
Slow Shutter
BLC Zone
Presets
Flicker Reduction
OSD
Video Output
Lens Mount
Power
Operation Temperature
Dimensions (W x H x L)
Weight
1/3” RGB Color DPS SENSOR (Pixim Orca D1500series)
720(H) x 540(V)
NTSC, 525lines / 2:1interlace
59.94Hz(V), 15.734Khz(H)
Internal/Line lock (Default: Internal)
550 TV Lines
0.0002Lux(F1.2,@40IRE, DN(DSS mode + ICR mode)
50dB with AGC OFF at 50IRE
2000~11000ºK Automatic tracking
More than 52dB with AGC OFF at 50IRE
1/60 ~ 1/100,000sec
2000~8000ºK Automatic tracking
4 presets (Low / Middle / High / Custom )
DC drive iris control. Level control is fixed internally
2X, 4X, 8X, 16X, 32X ESS
4 areas (CTR SPOT, UPPER 1/3, MIDDLE 1/3, LOWER 1/3)
NORMAL, INDOOR, OUTDOOR, FL-LIGHT, LOBBY, WAREHOUSE
Yes (NTSC Version only)
Yes (Setup menu only)
VBS 1Vpp +/-10%, 75ohm
CS Mount
24VAC(12V-28.8Vac) or 12VDC(10.5-30Vdc), 5Watts max
14°F~122°F / -10°C ~ + 50°C, 85% RH. Max. non-condensing
2.56” x 2.17” x 4.17” (65mm x 55mm x 106mm)
9.52 Oz. (270g)
