Vivitek D5000 User manual

— i —
Copyright
This publication, including all photographs, illustrations and software, is protected under international copy-
right laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be
reproduced without written consent of the author.
© Copyright 2010
Disclaimer
The information in this document is subject to change without notice. The manufacturer makes no repre-
sentations or warranties with respect to the contents hereof and specifically disclaims any implied
warranties of merchantability or fitness for any particular purpose. The manufacturer reserves the right to
revise this publication and to make changes from time to time in the content hereof without obligation of
the manufacturer to notify any person of such revision or changes.
Trademark Recognition
Kensington is a U.S. registered trademark of ACCO Brand Corporation with issued registrations and pend-
ing applications in other countries throughout the world.
All other product names used in this manual are the properties of their respective owners and are ac-
knowledged.

DLP Projector—User’s Manual
— ii —
Important Safety Information
Important:
It is strongly recommended that you read this section carefully before using the projector. These
safety and usage instructions will ensure that you enjoy many years of safe use of the projector.
Keep this manual for future reference.
Symbols Used
Warning symbols are used on the unit and in this manual to alert you of hazardous situations.
The following styles are used in this manual to alert you to important information.
Note:
Provides additional information on the topic at hand.
Important:
Provides additional information that should not be overlooked.
Caution:
Alerts you to situations that may damage the unit.
Warning:
Alerts you to situations that may damage the unit, create a hazardous environment, or cause per-
sonal injury.
Throughout this manual, component parts and items in the OSD menus are denoted in bold font as in this
example:
“Push the Menu button on the remote control to open the Main menu.”
General Safety Information
Do not open the unit case. Aside from the projection lamp, there are no user-serviceable parts in
the unit. For servicing, contact qualified service personnel.
Follow all warnings and cautions in this manual and on the unit case.
The projection lamp is extremely bright by design. To avoid damage to eyes, do not look into the
lens when the lamp is on.
Do not place the unit on an unstable surface, cart, or stand.
Avoid using the system near water, in direct sunlight, or near a heating device.
Do not place heavy objects such as books or bags on the unit.

Preface
–iii –
Projector Installation Notice
Place the projector in a horizontal position
The tilt angle of the projector should not exceed 15 degrees, nor should the projector be installed in
any way other than the desktop and ceiling mount, otherwise lamp life could decrease dramatically.
Allow at least 50 cm clearance around the exhaust vent.
Ensure that the intake vents do not recycle hot air from the exhaust vent.
When operating the projector in an enclosed space, ensure that the surrounding air temperature
within the enclosure does not exceed 5 – 40°C while the projector is running, and the air intake and
exhaust vents are unobstructed.
All enclosures should pass a certified thermal evaluation to ensure that the projector does not
recycle exhaust air, as this may cause the device to shutdown even if the enclosure temperature is
with the acceptable 5 – 40°C range.

DLP Projector—User’s Manual
— iv —
Power Safety
Only use the supplied power cord.
Do not place anything on the power cord. Place the power cord where it will not be in the way of
foot traffic.
Remove the batteries from the remote control when storing or not in use for a prolonged period.
Replacing the Lamp
Replacing the lamp can be hazardous if done incorrectly. See Replacing the Projection Lamp on page 46
for clear and safe instructions for this procedure. Before replacing the lamp:
Unplug the power cord.
Allow the lamp to cool for about one hour.
Cleaning the Projector
Unplug the power cord before cleaning. See Cleaning the Projector page 49.
Allow the lamp to cool for about one hour.
Regulatory Warnings
Before installing and using the projector, read the regulatory notices in the Regulatory Compliance on
page 61.
Important Recycle Instructions:
Lamp(s) inside this product contain mercury. This product may contain other electronic waste that
can be hazardous if not disposed of properly. Recycle or dispose in accordance with local, state, or federal
Laws. For more information, contact the Electronic Industries Alliance at WWW.EIAE.ORG. For lamp
specific disposal information check WWW.LAMPRECYCLE.ORG.
Symbol Explanations
DISPOSAL: Do not use household or municipal waste collection services for
disposal of electrical and electronic equipment. EU countries require the use
of separate recycling collection services.

Preface
–v –
Main Features
 Lightweight unit, easy to pack away and transport.
 Compatible with all major video standards including NTSC, PAL, and SECAM.
 A high brightness rating allows for presentations in daylight or in lit rooms.
 Supports resolutions up to UXGA at 16.7 million colors to deliver crisp, clear images.
 Flexible setup allows for front, rear projections.
 Line-of-vision projections remain square, with advanced keystone correction for angled
projections.
 Input source automatically detected.
About this Manual
This manual is intended for end users and describes how to install and operate the DLP projector. Wher-
ever possible, relevant information—such as an illustration and its description—has been kept on one
page. This printer-friendly format is both for your convenience and to help save paper, thereby protecting
the environment. It is suggested that you only print sections that are relevant to your needs.

DLP Projector—User’s Manual
— vi —
Table of Contents
GETTING STARTED...............................................................................................................................................................1
PACKING CHECKLIST................................................................................................................................................................1
VIEWS OF PROJECTOR PARTS ...................................................................................................................................................2
Front-right View ..................................................................................................................................................................2
Top view—On-screen Display (OSD) buttons and LEDs...................................................................................................3
Rear view .............................................................................................................................................................................4
Bottom view .........................................................................................................................................................................6
REMOTE CONTROL PARTS........................................................................................................................................................7
REMOTE CONTROL OPERATING RANGE...................................................................................................................................9
PROJECTOR AND REMOTE CONTROL BUTTONS .......................................................................................................................9
SETUP AND OPERATION .................................................................................................................................................. 10
INSERTING THE REMOTE CONTROL BATTERIES.................................................................................................................... 10
CONNECTING INPUT DEVICES ............................................................................................................................................... 11
INSTALLING OR REMOVING THE OPTIONAL LENS................................................................................................................. 13
Removing the Existing Lens From the Projector............................................................................................................. 13
Installing the New Lens .................................................................................................................................................... 14
STARTING AND SHUTTING DOWN THE PROJECTOR ............................................................................................................... 15
SETTING AN ACCESS PASSWORD (SECURITY LOCK) ............................................................................................................ 17
ADJUSTING THE PROJECTOR LEVEL ...................................................................................................................................... 19
ADJUSTING PROJECTED IMAGE POSITION USING SHIFT ....................................................................................................... 20
Adjusting the vertical image position............................................................................................................................... 20
Adjusting the horizontal image position .......................................................................................................................... 21
Shift Range Diagram ........................................................................................................................................................ 21
ADJUSTING THE ZOOM, FOCUS AND KEYSTONE................................................................................................................... 22
ADJUSTING THE VOLUME...................................................................................................................................................... 23
ON-SCREEN DISPLAY (OSD) MENU SETTINGS ......................................................................................................... 24
OSD MENU CONTROLS......................................................................................................................................................... 24
Navigating the OSD.......................................................................................................................................................... 24
SETTING THE OSD LANGUAGE ............................................................................................................................................. 25
OSD MENU OVERVIEW ........................................................................................................................................................ 26
OSD SUB-MENU OVERVIEW ................................................................................................................................................ 27
IMAGE MENU......................................................................................................................................................................... 28
Advanced Feature............................................................................................................................................................. 29
Color Manager ................................................................................................................................................................. 30
COMPUTER MENU ................................................................................................................................................................. 31
VIDEO/AUDIO MENU............................................................................................................................................................. 32
Audio................................................................................................................................................................................. 33
INSTALLATION I MENU ......................................................................................................................................................... 34
Advanced........................................................................................................................................................................... 35
Presentation Timer ........................................................................................................................................................... 36
INSTALLATION II MENU ........................................................................................................................................................ 37
Advanced Feature............................................................................................................................................................. 38
Factory Reset.................................................................................................................................................................... 45
Status................................................................................................................................................................................. 45
MAINTENANCE AND SECURITY.................................................................................................................................... 46
REPLACING THE PROJECTION LAMP...................................................................................................................................... 46
Resetting the Lamp ........................................................................................................................................................... 48
CLEANING THE PROJECTOR ................................................................................................................................................... 49
Cleaning the Lens ............................................................................................................................................................. 49
Cleaning the Case............................................................................................................................................................. 49
USING THE PHYSICAL LOCK.................................................................................................................................................. 50
Using the Kensington®Lock ............................................................................................................................................ 50
Using the Security Chain Lock......................................................................................................................................... 50
TROUBLESHOOTING......................................................................................................................................................... 51

Preface
–vii –
COMMON PROBLEMS AND SOLUTIONS .................................................................................................................................. 51
TIPS FOR TROUBLESHOOTING ............................................................................................................................................... 51
LED ERROR MESSAGES ........................................................................................................................................................ 52
IMAGE PROBLEMS ................................................................................................................................................................. 52
LAMP PROBLEMS................................................................................................................................................................... 53
REMOTE CONTROL PROBLEMS.............................................................................................................................................. 53
AUDIO PROBLEMS ................................................................................................................................................................. 53
HAVING THE PROJECTOR SERVICED ..................................................................................................................................... 53
HDMI Q & A ........................................................................................................................................................................ 54
SPECIFICATIONS ................................................................................................................................................................ 55
SPECIFICATIONS .................................................................................................................................................................... 55
PROJECTION DISTANCE VS. PROJECTION SIZE ...................................................................................................................... 56
Projection Distance and Size Table ................................................................................................................................. 56
TIMING MODE TABLE............................................................................................................................................................ 58
PROJECTOR DIMENSIONS....................................................................................................................................................... 60
REGULATORY COMPLIANCE ........................................................................................................................................ 61
FCC WARNING...................................................................................................................................................................... 61
CANADA ................................................................................................................................................................................ 61
SAFETY CERTIFICATIONS ...................................................................................................................................................... 61

DLP Projector – User’s Manual
–1 –
GETTING STARTED
Packing Checklist
Carefully unpack the projector and check that the following items are included:
PROJECTOR WITH LENS CAP
REMOTE CONTROL
(WITH ONE AAA BATTERY)
RGB CABLE POWER CORD CD-ROM
(THIS USER’S MANUAL)
WARRANTY CARD QUICK START CARD
Contact your dealer immediately if any items are missing, appear damaged, or if the unit does not work. It
is recommend that you keep the original packing material should you ever need to return the equipment
for warranty service.
Caution:
Avoid using the projector in dusty environments.

DLP Projector—User’s Manual
– 2 –
Views of Projector Parts
Front-right View
ITEM LABEL DESCRIPTION SEE PAGE:
1. IR receiver Receives IR signal from remote control 7
2. Lens Projection Lens
3. Focus ring Focuses the projected image
4. Zoom ring Enlarges the projected image
22
5. Height adjuster Adjusts level of projector 19
6. Function keys See Top view—On-screen Display (OSD) buttons
and LEDs. 3
7. Lamp cover Removes cover to replace lamp or color wheel 46
8. Vertical lens shift Adjusts the image position vertically 20
9. Horizontal lens shift Adjusts the image position horizontally 21
10. Lens release button Press the release button before removing the lens 13
Important:
Ventilation openings on the projector allow for good air circulation, which keeps the projector lamp
cool. Do not obstruct any of the ventilation openings.

DLP Projector – User’s Manual
–3 –
Top view—On-screen Display (OSD) buttons and LEDs
ITEM LABEL DESCRIPTION SEE
PAGE:
1. MENU Opens and exits OSD menus
2. ▲(Up cursor) /
Keystone+
Navigates and changes settings in the OSD
Quick Menu – For Keystone
3. ENTER Enter or confirm highlighted OSD menu item
24
4. BLANK Displays a blank screen and mutes audio
5. (Volume -) Quick Menu – For Volume - 24
6. AUTO Optimizes image size, position, and resolution
7. (Volume +) Quick Menu – For Volume +
8. ▼(Down cursor) /
Keystone-
Navigates and changes settings in the OSD
Quick Menu – For Keystone
24
9. SOURCE Enter the Source menu 11

DLP Projector—User’s Manual
– 4 –
Rear view
ITEM LABEL DESCRIPTION SEE PAGE:
1. VGA2 IN/ YPbPr Connect an RGB cable from a computer or a video enabled
device
2. VGA1 IN/SCART/
YPbPr
Connect an RGB cable from a computer or a video enabled
device
3. AUDIO IN
(VGA1) Connect an audio cable from the input device
11
4. POWER
Turns the projector on or off (main power switch must be
turned on first).
Press to place the projector in standby mode.
15
Orange Standby
Green In normal operation
5. PWR LED
Flashing Powering on/ cooling
6. TEMP LED Red Error code
Red Error code
7. READY LED
Flashing Lamp is not ready (warming up/shutting
down/cooling)
52
8. DVI-D Connect the DVI cable (not supplied) from a computer
9. AUDIO IN
(VGA2/ DVI-D) Connect an AUDIO cable from the input device
10. HDMI Connect the HDMI cable from a HDMI device
11. USB Connect the USB cable from a computer
12. RJ-45 Connect a LAN cable from Ethernet
11

DLP Projector – User’s Manual
–5 –
ITEM LABEL DESCRIPTION SEE PAGE:
13. VGA OUT Connect the RGB cable to a display
(Pass through by VGA1 only)
14. AUDIO OUT Connect an AUDIO cable for audio loop through
15. AUDIO IN (BNC) Connect an AUDIO cable from the input device
11
16. IR receiver Receive IR signal from remote control 7
17. RS-232C Connects RS-232 serial port cable for remote control
18. AUDIO IN L/R
RCA (YPbPr) Connect the audio cables from a audio device
19. 12V OUT
When connected to the screen through a commercially avail-
able cable, the screen deploys automatically on start up of
the projector. The screen retracts when the projector is pow-
ered off (see notes below).
20.
AUDIO IN L/R
RCA (Video/ S-
Video)
Connect the audio cables from a audio device
21. VIDEO Connect the composite cable from a video device
22. S-VIDEO Connect the S-video cable from a video device
23. YPbPr Connect a component video enabled device
24. BNC Connect an BNC cable from a computer or a video enabled
device
11
25. AC IN Connects the power cable 13
26. Power switch Turns on/off the projector 15
27. Security chain lock Helps protect the projector from unauthorized use
28. Kensington Lock Secures to permanent object with a Kensington® Lock sys-
tem
50
Note:

To use this feature, you must plug in the connector before turn on/off the projector.

Screen controllers are supplied and supported by screen manufacturers.

Do not use this jack for anything other than intended use.
Note:
If your video equipment has both S-VIDEO and RCA jacks (composite video) connect to the
S-VIDEO connector. S-VIDEO provides a better quality signal.

DLP Projector—User’s Manual
– 6 –
Bottom view
ITEM LABEL DESCRIPTION SEE PAGE:
1. Tilt adjustor Rotate adjuster lever to adjust angle position. 19
2. Ceiling support holes Contact your dealer for information on mounting the projector on a ceiling
Note:
When installing, ensure that you use only UL Listed ceiling mounts.
For ceiling installations, use approved mounting hardware and M4 screws with a maximum screw
depth of 6 mm (0.23 inch).
The construction of the ceiling mount must be of a suitable shape and strength. The ceiling mount
load capacity must exceed the weight of the installed equipment, and as an additional precaution
be capable of withstanding three times the weight of the equipment (not less than 5.15 kg) over a
period of 60 seconds.

DLP Projector – User’s Manual
–7 –
Remote Control Parts
Important:
1. Avoid using the projector with bright fluorescent lighting turned on. Certain high-frequency fluo-
rescent lights can disrupt remote control operation.
2. Be sure nothing obstructs the path between the remote control and the projector. If the path be-
tween the remote control and the projector is obstructed, you can bounce the signal off certain
reflective surfaces such as projector screens.
3. The buttons and keys on the projector have the same functions as the corresponding buttons on
the remote control. This user’s manual describes the functions based on the remote control.

DLP Projector—User’s Manual
– 8 –
ITEM LABEL DESCRIPTION SEE PAGE:
1. IR transmitter Transmits signals to projector
2. Status LED Lights when the remote control is used
3. Laser Press to operate the on-screen pointer
4. Up Up arrow when connected through USB to a PC
5. Right Right arrow when connected through USB to a PC
6. Down Down arrow when connected through USB to a PC
7. Page Down Page down when connected through USB to a PC
8. Up cursor
9. Right cursor
10. Down cursor
Navigates and changes settings in the OSD 24
11. Volume +/- Adjusts volume 23
12. Mute Mutes the built-in speaker
13. Zoom+ Zoom in
14. Zoom- Zoom out
15. Freeze Freeze/unfreezes the on-screen picture
16. Blank Makes the screen blank
17. Source Detects the input device
18. Auto Auto adjustment for phase, tracking, size, position
19. Menu Opens the OSD 24
20. Status Opens the OSD Status menu (the menu only opens when an
input device is detected) 37
21. Keystone top/bottom Corrects image-trapezoid (wider top/bottom) effect 22
22. Left cursor Navigates and changes settings in the OSD
23. Enter Changes settings in the OSD
24. Page Up Page up when connected through USB to a PC
25. Left Left arrow when connected through USB to a PC
26. Enter Enter key when connected through USB to a PC
24
27. Power Turns the projector on or off 13
28. Laser Use as on-screen pointer. DO NOT POINT IN EYES.

DLP Projector – User’s Manual
–9 –
Remote Control Operating Range
The remote control uses infrared transmission to control the projector. It is not necessary to point the
remote directly at the projector. Provided you are not holding the remote perpendicular to the sides or
the rear of the projector, the remote will function well within a radius of about 7 meters (23 feet) and
15 degrees above or below the projector level. If the projector does not respond to the remote control,
move a little closer.
Projector and Remote Control Buttons
The projector can be operated using the remote control or the buttons on the top of the projector. All
operations can be carried out with the remote control; however, the buttons on the projector are lim-
ited in use.

DLP Projector—User’s Manual
– 10 –
SETUP AND OPERATION
Inserting the Remote Control Batteries
1.
Remove the battery compartment cover
by sliding the cover in the direction of
the arrow.
2.
Insert the battery with the positive side
facing up.
3.
Replace the cover.
Caution:
1. Only use AAA batteries (Alkaline batteries are recommended).
2. Dispose of used batteries according to local ordinance regulations.
3. Remove the batteries when not using the projector for prolonged periods.

DLP Projector – User’s Manual
–11 –
Connecting Input Devices
A PC or notebook computer and video devices can be connected to the projector at the same time. Video
devices include DVD, VCD, and VHS players, as well as movie camcorders and digital still cameras.
Check the user manual of the connecting device to confirm it has the appropriate output connector.
ITEM LABEL DESCRIPTION
VGA1 IN/SCART/
YPbPr Connect an RGB cable from a computer or a video enabled device
AUDIO IN (VGA1) Connect an audio cable from the input device
VGA2 IN/ YPbPr Connect an RGB cable from a computer or a video enabled device
DVI-D Connect the DVI cable (not supplied) from a computer
AUDIO IN (VGA2) Connect an AUDIO cable from the input device
HDMI Connect the HDMI cable from a HDMI device
USB Connect the USB cable from a computer
RJ-45 Connect a LAN cable from Ethernet
VGA OUT Connect the RGB cable to a display

DLP Projector—User’s Manual
– 12 –
ITEM LABEL DESCRIPTION
AUDIO OUT Connect an AUDIO cable for audio loop through
AUDIO IN (BNC) Connect an AUDIO cable from the input device
RS-232C Connects RS-232 serial port cable for remote control
AUDIO IN L/R RCA
(YPbPr) Connect the audio cables from a audio device
12V OUT
When connected to the screen through a commercially available cable, the
screen deploys automatically on start up of the projector. The screen retracts
when the projector is powered off (see notes below).
AUDIO IN L/R RCA
(Video/ S-Video) Connect the audio cables from a audio device
VIDEO Connect the composite cable from a video device
S-VIDEO Connect the S-video cable from a video device
YPbPr Connect a component video enabled device
BNC Connect an BNC cable from a computer or a video enabled device
Warning:
As a safety precaution, disconnect all power to the projector and connecting devices before making
connections.

DLP Projector – User’s Manual
–13 –
Installing or Removing the Optional Lens
Caution:
 Do not shake or place excessive pressure on the projector or the lens components as the projec-
tor and lens components contain precision parts.
 Before removing or installing the lens, be sure to turn off the projector, wait until the cooling fans
stop, and turn off the main power switch.
 Do not touch the lens surface when removing or installing the lens.
 Keep fingerprints, dust or oil off the lens surface.
 Do not scratch the lens surface.
 Work on a level surface with a soft cloth under it to avoid scratching.
 If you remove and store the lens, attach the lens cap to the projector to keep off dust and dirt.
Removing the Existing Lens From the Projector
1.
Pull and release the top cover to open as
shown.
2.
Push the LENSE RELEASE button to
the unlock position.
3.
Grasp the lens.
4.
Rotate the lens counterclockwise.
The existing lens will be disengaged.
5.
Pull out the existing lens slowly.
