1. Overview
2. Package Checklist
4. Location
5. Cabling RJ-45
3. Hardware Installation Procedure
STEP 1:
Take out the device from its packing.
STEP 2:
Attach the DIN Rail Kit as picture.
The HNS-8415P is an Unmanaged Hardened PoE switch
perfectly suited for extreme industrial environments and
an ideal solution to deploy in surveillance systems. The
switch is designed to meet the requirements of both
power and data transmission over single Ethernet cable to
PoE appliances and devices without the need for power
outlets, eliminating additional cost of electrical cabling
and circuits. The switch’s rugged case and hardened
components withstand high degree of vibration, shock
and wide operating temperatures from -10oC~60oC. The
HNS-8415P features 5 10/100/1000Base-T ports and 1
Gigabit SFP slot to satisfy new and evolving network
demands. With 4 IEEE 802.3af/at compliant ports, the
switch provides up to 30W per port to meet the growing
demand of higher power consuming network devices
such as wireless access points, IP cameras, and other
powered devices (PDs).
Before installing HNS-8415P, verify that the package
contains the following items:
 HNS-8415P Switch x 1
 DIN Rail Kit x 1
Quick Installation Guide x 1
STEP 3:
Connect Power Adapter to DC-Jack or connect 48~57VDC
power to terminal block.
STEP 4:
Connect the Ethernet (RJ-45) port to the networking
device. See the LNK/ACT LED to conrm that the
connection is established.
The HSN-8415P can be DIN-Rail-mounted in cabinet or
enclosure.
DIN-Rail-mounted with HNS-8415P
Mounting the Switch Removing the Switch
The RJ-45 ports on the HNS-8415P support auto negotia-
tion and auto MDI/MDI-X. This feature eliminates the
worry of using specic cable types.
Category 5e cable or above should be used
6. Redundant Power Inputs
Turn the power o before connecting modules
or wires. The correct power supply voltage is listed on
the product label. Check the voltage of your power
source to make sure that you are using the correct
voltage. Do NOT use a voltage greater than what is
specied on the product label.
Calculate the maximum possible current in each
Safety rst
!
power wire and common wire. Observe all electrical
codes dictating the maximum current allowable for
each wire size. If current go above the maximum
ratings, the wiring could overheat, causing serious
damage to your equipment.
Quick Installation Guide
HNS-8415P
Top View
DIP Switches
Power Input
DC-Jack
Power Input
Terminal Block
Grounding
Screw
Front View
PWR
1000Mbps
(Green)
1 2 3 4
RPS
LNK/ACT
(Green)
PoE+
PoE+
5
1
2
3
4
6SFP
(1000Mbps)
SFP
ALM

-4- -5- -6-
v1.0
6400-000138
PWR
RPS
7. LED Indicators
ON: Master power alarm reporting is enabled
OFF: Master power alarm reporting is disabled
ON: Redundant power alarm reporting is enabled
OFF: Redundant power alarm reporting is disabled
PWR
(Green)
Illuminated Terminal block PWR / DC-Jack
power is connected
Terminal block RPS is
connected
O Terminal block PWR / DC-Jack
power fails or is not available
10/100/
1000
Mbps
(Green)
Illuminated Copper ports speed at 1000Mbps
O Copper ports speed at
10/100Mbps
PoE
1st~4th
port
(Green)
Illuminated PoE device is connected
No PoE power output or no
PoE connected PoE devices
LNK/
ACT
(Green)
Illuminated Copper port link-up
Blinking Data is transmitting / receiving
O
O
Port disconnected or link failed
Port disconnected or link failed
Data is transmitting / receiving
SFP
(Green)
Illuminated SFP port link-up at 1000Mbps
Blinking
O
RPS
(Green)
Illuminated
O or is not available
Terminal block RPS fails
PWR/RPS fails or is not available
ALM
(Red)
Illuminated
O No alarm to report
You can use either “DC-Jack” or “Terminal Block (PWR)”
for primary power and “Terminal Block (RPS)” for secondary
power source, to be a Redundant Power Input. Top views
of DC-Jack and Terminal Block are shown as picture.
Redundant Power Input: Choose either “DC-Jack”
or “Terminal Block (PWR)” as primary power. If you
choose “Terminal Block (PWR)”, please refer to
option 1, unless follow option 2.
Insert the “DC-Jack” connector into “DC-Jack”
receiver and “Terminal Block (RPS)” into terminal
block receptor.
6.1. Wiring the Redundant Power Inputs
Option 2:
Insert the terminal block connector which includes
“PWR” and “RPS” into the terminal block receptor.
DC-Jack Terminal Block
Option 1:
Notice: Connect power cables to terminal block
Use your nger to press the orange plug on top of
terminal block connector to insert power cables.
