Vollrath Insta Cut 3.5 User manual

Operator's Manual
Part 2350022-1 10/5/2023
I C® 3.5 S, D, W,  C
Thank you for purchasing this Vollrath® product! Save this
manual for reference and the packaging in case shipping is
necessary.
SAFETY PRECAUTIONS
To help ensure safe use, please read and fully understand
this manual and all safety messages before operation!
WARNING
Warning indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION
Caution indicates a hazardous situation which, if not
avoided, could result in minor or moderate injury.
NOTICE:addresses practices not related to physical injury.
To reduce risk of injury or damage to the unit
•Check unit before each use to ensure it is clean.
•Inspect for broken, nicked, or dull blades; replace as needed.
•Ensure Pusher Block and Blade Assemblies align and match.
•Only use unit if bumpers are in place and the lowered
Pusher Head rests completely on them.
•Use tabletop models on a level, smooth surface,
•Mount wall unit securely to studs using proper hardware.
•Lubricate Guide Rods lightly with mineral oil, Petro-Gel, or
food-grade lubricant; cooking oil becomes sticky and could
permanently damage the unit.
•Operate in non-public areas, away from children—and attend
the unit during use.
•Only operate if functioning properly and undamaged.
FUNCTION AND PURPOSE
Vollrath® Insta Cut® 3.5 manual food processor is intended
for slicing, dicing, wedging, and coring soft vegetables and
fruits. It is not intended for hard root vegetables such as
carrots and sweet potatoes.
Tabletop Wall-
Mount
Pusher
Block &
Blade
Tabletop
Pusher
Block &
Blade
Wall-
Mount
Blade
Only
Description
15000 15016 15059 15081 15062 ¼" (6.4) Dice
15001 15017 15060 15082 15063 ⅜" (9.5) Dice
15002 15018 15061 15083 15064 ½" (12.7) Dice
— — 15085 15084 15086 ¼ x ½(6.4 x 12.7) Dice
15003 15019 15050 15073 15065 4-Section Wedge
15005 15021 15052 15075 15067 6-Section Wedge
15006 15022 15053 15076 15068 8-Section Wedge
15007 15023 15054 15077 15069 10-Section Wedge
15008 15024 15055 15078 15070 12-Section Wedge
15009 —15087 15079 15071 6-Section Core
15010 15026 15058 15080 15072 8-Section Core
Accessories Description
4425 Food Processor Blade-Cleaning Brush
UNPACKING THE UNIT
1. Remove all packing material, tape, and protective plastic.
2. Clean any left over glue residue.
BEFORE FIRST USE
•Clean the unit per the Cleaning and Maintenance section.
INSTALLING THE WALL-MOUNTED MODEL
1. Secure base to studs with four (4) ¼" screws of proper length; if
not possible, proper anchors and screws must be used.

Insta Cut® Operator's Manual
2
FEATURES AND CONTROLS
A. Handle—used to safely raise and lower the Pusher Head.
B. Guide Rods—keep Pusher Head aligned with Blades.
C. Pusher Head Assembly—includes Bushings, Pusher Head,
and Pusher Block.
D. Bumpers—cushion the pusher head when it stops.
E. Thumbscrews—secure Pusher Head or Blade Assembly.
F. Base Assembly—holds Guide Rods and Blade Assembly.
G. Blade Assembly—holds the blades; sized to match the
corresponding Pusher Head Block.
H. Pusher Head Block—pushes food through Blade Assembly;
must be matched with corresponding Blade Assembly.
I. Locking Pin—secures the Pusher Head to the Handle.
A
C
D
E
F
G
H
B
C
B
G
H
I
D
F
E
A
OPERATION
WARNING
Sharp Blade Hazard.
To avoid injury, handle with caution.
Prepare the Food
Maximum Size:
• 3½" (8.9 cm) wide
Prepare the Unit
1. Verify blade assembly and pusher block match and align.
Each must be for the same size slice, dice, core, or wedge.
2. Before each use, ensure unit and blades are clean and
undamaged; replace as necessary.
3. Place the unit on a clean, flat work surface.
4. Verify bumpers are in place on the guide rods.
NOTICE:DO NOT USE WITHOUT BUMPERS.
5. Verify Blade Assembly is properly installed in the base;
thumbscrew must be fully tightened and the Blade
Assembly fully tight against the side of the frame opposite
the Thumbscrew.
6. Before each use, check blade alignment by slowly lowering
the Pusher Head onto the Blade Assembly; they should
slide smoothly together. If there is resistance, ensure Blade
Assembly and Pusher Head match and carefully remove
obstructions as necessary.
NOTICE: Do Not operate if unit or blades are misaligned
or damaged.
7. Lift handle and place food on the blades, flat side down.
8. Remove hand from Blade Assembly area and place that
hand on the leg of the base for a tabletop unit or on the wall
for a wall-mounted model.
9. Use a strong, quick, downward motion to press food
through the blades; repeat until you have enough for a day.
10. Clean and lubricate the unit immediately after every use per
the following Cleaning and Maintenance section.

Part 2350022-1 10/05/23© 2023 The Vollrath Company L.L.C.
CLEANING & MAINTENANCE
WARNING
Sharp Blade Hazard.
To avoid injury, handle with caution.
NOTICE:Food acids dull and corrode blades over time. Cleaning
immediately after use prolongs unit life and appearance.
NOTICE:Alkaline cleaners (e.g. dishwasher detergent) cause
damage and corrosion. Handwashing is required.
NOTICE:Use only non-abrasive cloths and cleansers.
Disassembly
1. Slide Pusher Head Assembly o Guide Rods.
2. Loosen the two captive (not removable) thumbscrews.
3. Separate the Pusher Block from the Pusher Head.
4. Raise the bumpers approximately 2" (5.0 cm).
5. Loosen thumbscrew and carefully remove Blade Assembly by
pressing up on the bottom/dull side of the blade holder.
Cleaning
6. For best results, spray unsharpened side of blades with hot, clean
water; if needed, carefully remove food with a nylon brush.
7. Wash other parts in soapy water, rinse well, and air dry.
Reassembly
8. Slide the Blade Assembly onto the base; tighten thumbscrew to
push Blade Assembly securely against the other side.
9. Lubricate Guide Rods with mineral oil or Petro Gel.
NOTICE:Cooking oil becomes sticky and could cause damage.
10. Slide bumpers onto rods; reattach Pusher Head to Pusher Block.
11. Install Pusher Head Assembly. Wall-Mount units: Remove Locking
Pin. Lift Handle; slide Pusher Head onto rods. Push Locking Pin
into hole, through Handle Assembly and Pusher Head.
Preventative Maintenance
1. Clean unit after every use.
2. Use for intended purposes only.
3. Check blades often and change if dull, nicked, or damaged.
Replacing Blade Assembly
WARNING
Sharp Blade Hazard.
To avoid injury, handle with caution.
1. Wash new blades with warm, soapy water, then rinse thoroughly.
2. Follow steps 1–5 under Disassembly; discard the old blades.
3. Insert the tab on the blade holder into the groove in the base,
then lower so it is flush; tighten the Thumbscrew.
4. Slide Bumpers down rods to Base Assembly. Place, then slowly
lower Pusher Head Assembly on rods to check blade alignment.
5. Lubricate Guide Rods per previous Reassembly section.
TROUBLESHOOTING
Problem Potential Cause Course of Action
Blade(s) broke. Blades were dull.
Replace Blade
Assembly and
Pusher Block if
damaged.
Pusher Head does
not slide easily.
Guide Rods are not
properly lubricated.
Clean and lubricate
the Guide Rods
per the Cleaning
section.
Food is damaged
when cutting.
Blades are broken,
bent, nicked, or dull.
Replace Blade
Assembly.
Food cannot be
pushed through.
Blades are
misaligned or Blade
Assembly and
Pusher Head do not
match.
Confirm the Pusher
Block is for the
same size and
type of cut as the
Blade Assembly
and that it glides
smoothly through
when cutting. Install
correct Pusher
Block if it does not.
If Pusher Block is
correct, tighten
Thumbscrew and
ensure blades are
against frame.
SERVICE AND REPAIR
Serviceable parts are available on vollrathfoodservice.com.
To avoid serious injury or damage, never attempt to repair the
unit or replace a damaged power cord yourself. Do not send
units directly to The Vollrath Company LLC. Please contact
Vollrath Technical Services for instructions.
When contacting Vollrath Technical Services, please be ready
with item number, model number (if applicable), serial number,
and proof of purchase showing date the unit was purchased.
WARRANTY STATEMENT FOR THE VOLLRATH
CO. L.L.C.
This warranty does not apply to products purchased for
personal, family or household use; The Vollrath Company LLC
does not oer a written warranty to purchasers for such uses.
The Vollrath Company LLC warrants the products it
manufactures or distributes against defects in materials and
workmanship as specifically described in our full warranty
statement. In all cases, the warranty runs from the date of the
end user’s original purchase date found on the receipt. Any
damages from improper use, abuse, modification, or damage
resulting from improper packaging during return shipment for
warranty repair will not be covered under warranty.
For complete warranty information, product registration, and
new product announcements, visit vollrathfoodservice.com.
