Vollrath 1694 Quick setup guide

Assembly and Use Instructions
Flatbed Utility Dolly
©2020 The Vollrath Company L.L.C. Part No. 352387-1 9/3/20
ASSEMBLY
Attach Casters or Pneumatic Wheels
NOTICE: Use a wrench or torque wrench to tighten the hardware.
NOTICE: Inflate pneumatic tires to 50 psi.
NOTICE: Attach the casters/wheels with brakes in the back position
of the dolly (handle mounting end)
Attach Handle
The handle is included with item 1695 and is an optional accessory for
items 1694 and 1695-1.
1. Insert the handle into the back side of the base in the upright
position. To secure the handle:
a.Place a screw through the hole in the small rectangle end of the
tethered cable.
b.Insert the screw into the top hole located on the left side of the
base, above the back wheel. It should pass through the upper hole
in the handle and be secured underneath the base with the pro-
vided lock nut. Repeat on the other side.
2. Insert the pin end of the tethered cable into the bottom hole to keep
the handle in an upright position. Repeat on the other side.
1695-1
1694
1695
Item No. Description
1694 Flatbed Utility Dolly, gray with 5” casters and
straps
1695 Flatbed Utility Dolly, gray with 6” pneumatic
wheels and straps
1695-1 Flatbed Utility Dolly, gray with 6” pneumatic
wheels, straps, and handle
Fixed casters in
the front
Swivel casters in the
back by the handle
mount
NOTICE: Weight capacity 350 lbs.

©2020 The Vollrath Company L.L.C. Part No. 352387-1 9/3/20
www.vollrathfoodservice.com
The Vollrath Company, L.L.C.
1236 North 18th Street
Sheboygan, WI 53081-3201 U.S.A.
Main Tel: [phone] or 920.457.4851
Main Fax: [phone] or 920.459.6573
Customer Service: 800.628.0830
Canada Customer Service: 800.695.8560
Technical Services
[email protected]
Induction Products: 800.825.6036
Countertop Warming Products: 800.354.1970
Toasters: 800-309-2250
All Other Products: 800.628.0832
Attach Strap Collapse Handle
1. Remove the pins from the bottom holes on both sides of the base.
2. Lower the handle into the slots located in the base.
3. Re-insert the pins into the bottom holes to secure the handle in the
collapsed position.
Strap storage pockets
