Volt 510 Series User manual

VOLT®Low Voltage Landscape Lighting
Articulator
510 Series
INSTALLATION INSTRUCTIONS
Specications and product details subject to change without notice.
© Copyright 2015, VOLT® Lighting, Lutz FL USA 33549 • All rights reserved.
[email protected] • 813.978.3700
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)

Articulator
510 Series
Important: Please Read Before Installation
Important Safety Instructions
INSTALLATION INSTRUCTIONS
This luminaire is intended for installation in accordance with local codes
and the National Electric Code (NEC). Failure to adhere to these codes and
instructions may result in serious injury, property damage and void the
warranty.
These instructions do not intend to cover all variations in installation,
operation maintenance or mounting situation.
1. Make sure that the power is turned OFF before installing or servicing this
luminaire.
2. WARNING: risk of electrical shock. Install all luminaires 10 feet (3.05M) or
more from pool, spa or fountain.
3. This luminaire is intended to be used only with a power supply
(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.
4. Wiring connections must be made with wire connectors that is suitable for
outdoor use.
5. Position the low voltage wire and wire connector so that it is located
within 6 inches (15.2 cm) from a building structure, a luminaire or tting.
6. The main low voltage cable is intended for shallow burial - less than 6
inches (152 mm)
7. If additional lengths of low voltage cable is required, please contact www.
voltlighting.com or call 1-813-978-3700.
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS
Lighted lamp is HOT!
WARNING – To reduce the risk of FIRE OR INJURY TO PERSONS.
1. Turn off/unplug and allow to cool before replacing lamp.
2. Lamp gets HOT quickly! Contact only switch/plug when turning on.
3. Do not touch the hot lens, guard or enclosure.
4. Keep lamp away from materials that may burn.
5. Do not touch lamp at any time. Use a soft cloth. Oil from skin may
damage lamp.
6. Do not operate the luminaire tting with a missing or damage shield.
SAVE THESE INSTRUCTIONS
!
!
www.voltlighting.com

Package Contents
Product Dimensions
A. (1) Fixture
B. (1) PVC Tube
[e-mail] • 813.978.3700
5.53”
6.34”
3”
3”
3”
7.4”
Dig Hole
1
Dig hole on the ground. Make sure
there are approximately 3” spaces
surrounding the PVC tube for pea
gravel or sand.
PVC Tube
Hole
Soil

INSTALLATION INSTRUCTIONS
www.voltlighting.com
Articulator
510 Series
Place xture onto PVC tube. Pass
luminaire pigtail through PVC tube.
Strip two leads from luminaire
pigtail. Using two wire connectors
(not provided), connect leads from
luminaire to main supply cable
leads.
Wire Connection
Install/Replace Lamp
2
Pigtail
Fixture
PVC Tube
Wire Connector
Main Supply Cable
Install the PVC tube with xture in
hole and ll hole with pea gravel or
sand.
Loosen lock nuts and slip down the
housing to the end of the bars.
Unlock glare guard and remove it
from the housing.
Fill Pea Gravel or Sand
Remove Glare Guard
3
4
Pea Gravel
or Sand
PVC Tube
with Fixture
Bar
Lock Nut
Glare Guard
Housing
Soil

[e-mail] • 813.978.3700
Remove broken lamp and insert
replacement lamp with correct
wattage and type marked on
xture label.
CAUTION: Do not exceed maximum
wattage marked on luminaire
label.
NOTE: DO NOT touch lamp with
bare hands. Use soft cloth to
handle lamp.
Replace Lamp
5
Lamp
Socket
Bar
Lock Nut
Glare Guard
Housing
Install glare guard back onto
housing and hand tighten until
snug. Adjust housing to your
desired height and secure with lock
nuts.
Reinstall Glare Guard
6

is-510-ver1.pdf
