voran EBP580 User manual

Single belt press EBP580
Version: 166000000, M0017267B_EN208-240-60D
Date: 28.11.2017 - 1 / 52 -
Translation
Operating manual –part 1
Single belt press EBP580
3 x 208-240V 60Hz

Single belt press EBP580
Version: 166000000, M0017267B_EN208-240-60D
Date: 28.11.2017 - 2 / 52 -
1BASIC SAFETY PRINCIPLES............................................................................................................................. 4
1.1 KEY TO THE SYMBOLS..................................................................................................................................... 4
1.2 GENERAL SAFETY REGULATIONS ..................................................................................................................... 5
1.3 SELECTION,QUALIFICATION AND RESPONSIBILITY OF OPERATING STAFF ............................................................ 6
1.4 ORGANIZATIONAL MEASURES .......................................................................................................................... 6
1.5 SAFETY REQUIREMENTS FOR THE OPERATING STATE........................................................................................ 8
1.5.1 Servicing/repair operation ........................................................................................................................ 8
1.5.2 Normal Operation..................................................................................................................................... 9
1.6 SAFETY DEVICES .......................................................................................................................................... 10
1.7 REMNANT RISKS ........................................................................................................................................... 12
1.8 CORRECT USE.............................................................................................................................................. 13
1.9 INAPPROPRIATE USE..................................................................................................................................... 13
1.10 TRAINING RECORD........................................................................................................................................ 14
2TECHNICAL DATA ............................................................................................................................................ 15
2.1 TECHNICAL DATA -OVERALL MACHINE/LINE .................................................................................................... 15
3TRANSPORTATION AND SETTING UP OF THE MACHINE/LINE ................................................................. 16
3.1 NOTES ON TRANSPORTATION ........................................................................................................................ 16
3.2 NOTES ON ASSEMBLY ................................................................................................................................... 17
4STARTING UP / RE-STARTING OF THE MACHINE/LINE .............................................................................. 19
4.1 GENERAL..................................................................................................................................................... 19
4.2 MOUNTING BELT LUG .................................................................................................................................... 19
4.3 CONTROLS AND SETTINGS WORK BEFORE FIRST STARTING UP/RE-STARTING OF LINE........................................ 20
4.3.1 Setting the pressure regulator................................................................................................................ 21
4.3.2 Testing of the screen belt....................................................................................................................... 21
4.3.3 Water supply for belt cleaning................................................................................................................ 21
5FUNCTIONAL DESCRIPTION........................................................................................................................... 22
5.1 FUNCTIONAL DESCRIPTION –SINGLE BELT PRESS EBP 580............................................................................ 22
6OPERATION....................................................................................................................................................... 23
6.1 GENERAL..................................................................................................................................................... 23
6.2 OPERATION -MACHINE/LINE COMPONENTS..................................................................................................... 23
6.2.1 Screen belt tension................................................................................................................................. 23
6.2.2 Switch on and off the Belt press............................................................................................................. 24
6.2.3 Setting belt speed................................................................................................................................... 26
6.2.4 Setting the cleaning interval................................................................................................................... 27
6.2.5 Belt cleaning........................................................................................................................................... 27
6.2.6 Charging of the press............................................................................................................................. 28
7ELECTRICALS................................................................................................................................................... 29
7.1 ELECTRICAL CIRCUIT DIAGRAM –EBP580 ..................................................................................................... 29
7.2 MATERIAL LIST ............................................................................................................................................. 37
8PNEUMATIC....................................................................................................................................................... 38
8.1 PNEUMATIC DIAGRAM –EBP580................................................................................................................... 38
9FAULT AND ERROR ANALYSIS...................................................................................................................... 39
9.1 GENERAL..................................................................................................................................................... 39
9.2 FAULT AND ERROR ANALYSIS -MACHINE/LINE COMPONENTS............................................................................ 39
9.2.1 Error message on the display ................................................................................................................ 39

Single belt press EBP580
Version: 166000000, M0017267B_EN208-240-60D
Date: 28.11.2017 - 3 / 52 -
10 SERVICING AND REPAIRS.......................................................................................................................... 41
10.1 GENERAL..................................................................................................................................................... 41
10.2 SERVICING AND REPAIRS REPORTING............................................................................................................. 44
10.3 SERVICING INTERVALS .................................................................................................................................. 45
10.4 LUBRICANTS OVERVIEW................................................................................................................................ 46
10.5 SERVICING AND REPAIRS -MACHINE/LINE COMPONENTS................................................................................. 47
10.5.1 Cleaning ............................................................................................................................................. 47
10.5.2 Reading off operating hours............................................................................................................... 49
10.5.3 Setting the pressure regulator............................................................................................................ 49
10.5.4 Setting of the screen belt ................................................................................................................... 49
10.5.5 Adjusting the regulating valve ............................................................................................................ 50
10.5.6 The setting of the ind. proximity switch.............................................................................................. 50
10.6 SCREEN BELT CHANGE.................................................................................................................................. 51

Single belt press EBP580
Version: 166000000, M0017267B_EN208-240-60D
Date: 28.11.2017 - 4 / 52 -
1 Basic safety principles
1.1 Key to the symbols
Listing of the symbols used and their significance
BEFORE FIRST START INSTRUCTIONS READ
Not observing this requirement can lead to serious injury or to death!
WARNING AGAINST GENERAL DANGERS
The instructions for these signs must be used without fail!
Not observing this requirement can lead to serious injury or to death!
WARNING OF DANGEROUS LIVE ELECTRICAL POWER SUPPLY
Before any servicing or checking work is undertaken, all parts or supply lines on the machine that
are marked with this sign must be switched free from live current.
Not observing this requirement can lead to serious injury or to death!
BEFORE OPENING UNPLUG!
Interrupting your work on the machine power supply and secure against accidental before
reconnecting it and turning.
Non compliance can mean severe personal injury.
PROTECTIVE GLOVES and WEAR EYE PROTECTION!
Always wear protective gloves and goggles when using cleaning agents.
Non-observance could be serious burns and eye injuries and even loss of sight!

Single belt press EBP580
Version: 166000000, M0017267B_EN208-240-60D
Date: 28.11.2017 - 5 / 52 -
WEAR EAR MUFFS!
Ear muffs must be worn when there is a high noise level!
Not observing this can lead to serious personal injury!
INFORMATION!
Helps you to make optimal use of the functionality of your machine.
NOTE!
Technical requirements for simplifying the operation of the machine!
1.2 General safety regulations
NOTE!
Ensure that the machine/line is only operated under perfect technical operational conditions and
giving full account to the proper use.
WARNING AGAINST GENERAL DANGERS
Ensure that all possible faulty functions and risk situations are eliminated immediately and without
delay before starting up!
Faulty functions and risk situations are e.g.:
uncontrolled lifting/sinking and turning/ swiveling movements
loose parts on the machine/line
INFORMATION!
Apart from the instructions and standards which are listed on the CE marking, the accident
prevention regulations of the national laws and regulations, for example, VDE to IEC note.

Single belt press EBP580
Version: 166000000, M0017267B_EN208-240-60D
Date: 28.11.2017 - 6 / 52 -
1.3 Selection, qualification and responsibility of operating staff
NOTE!
Please note each operator of the unit must be trained, instructed and older than 15 years.
Please observe your national law and regulations for industrial safety.
Operating staff who are in training or under instruction may only work under the constant
observation of an experienced person who is thoroughly familiar with this machine/line!
All work on the electrical systems for this machine/line may only be carried out by a qualified
electrician / electrical engineer. All work of this kind may only be carried out under the direction of a
qualified electrician / electrical engineer taking full account of the relevant electro-technical
guidelines.
The operating personnel must ensure that no other people are in the working area.
Before you leave the unit, you have to stop it and to ensure that no unauthorized person (especially
children) is able to restart it. Therefore lock the main switch in position <0> with a padlock and / or
disconnect the main plug!
1.4 Organizational measures
NOTE!
Before starting up the machine/line the operating personnel must without fail be familiar with the
Operating Manual, in particular with the safety regulations and notes.
It is too late to make a start on familiarization with these procedures when work is already being
done on the machine/line.
This applies in particular to persons who work constantly on the machine/line.
Ensure that a copy of the Operating Manual is kept constantly at the machine/line!
The Operating Manual must be read by every person whose task is operation or maintenance
(servicing, inspection and maintenance).
Only line-specific trained personnel who are thoroughly familiar with it may be employed on the
machine/line.
If the machine/line must be transported only trained staff who are permitted to do so may operate
the lifting gear (crane, stacker).
Training and instruction must be recorded and entered in this documentation machine/line
Operating Manual (instructor, content, participant and date).
Safety and danger notes and all notices must be maintained in a perfect and legible state.
In the event of warning and notice signs on the machine being illegible the manufacturer must be
informed at once!

Single belt press EBP580
Version: 166000000, M0017267B_EN208-240-60D
Date: 28.11.2017 - 7 / 52 -
NOTE!
Use protective equipment if necessary, but without fail if this is required by the protection
regulations! (gloves, masks, ear muffs, protective helmets etc.)
Observe all the safety requirements and notices that are place on the machine/line !
In the event of damage to a part or a component group that may a detrimental effect on operating
personnel on the line, the line must be shut down immediately and the responsible person or the
Customer Service Department must be informed!
All changes, additions or subsequent constructions to the machine/line that may have a negative
effect on its safety and functionality, may only be made when these are tested, agreed to and
released in writing by the machine/line suppliers!
This also applies to the installation and setting of the safety devices and safety equipment This also
includes the welded constructions of the bearing and support structures .
All spare parts must comply with the technical requirements of the machine/line supplier. This is
also the case where original spare parts are used
NOTE!
Ensure that the fixed intervals, or the inspection intervals specified in the Operating Manual are
adhered to! (see the chapter "Servicing and Repairs")
Ensure that the tools and equipment required for each kind of servicing work is available as
required!
Ensure that both fire-fighting equipment and instructions for the fire alarms and for fire fighting are
available.
Observe the instructions given for the fire alarms and for fire fighting.
NOTE!
The machine should be taken from company Voran in operation!
When commissioning an enrollment (operation, maintenance) is performed.

Single belt press EBP580
Version: 166000000, M0017267B_EN208-240-60D
Date: 28.11.2017 - 8 / 52 -
1.5 Safety requirements for the operating state
WARNING AGAINST GENERAL DANGERS
The machine/line may only be operated after all statutory safety requirements have been
fulfilled.
1.5.1 Servicing/repair operation
WARNING AGAINST GENERAL DANGERS
Servicing and repair work may only be carried out when the machine/line is switched off and
secured against being switched on again (e.g. by pulling out the device mains plugs, locking the
mains switches; the key must be in the safe keeping of the maintenance staff!)
WARNING AGAINST GENERAL DANGERS
The machine may only be operated when the safety covers are assembled!
The machine/line area that is to be serviced must be switched off and locked before the start of the
work. It must be assured that the machine/line is not switched on again by appropriate measures or
the posting of a second person.
When carrying out work in an unsecured area it must be possible for the second person must be
outside of the danger area and must be able to take appropriate rescue measures in the event of
an emergency.
Servicing, repair and maintenance work may only be carried out from a safe working position.
Before starting up again and renewing normal operation a functional test of all functional groups
and safety equipment must be made without fail.
WARNING OF DANGEROUS LIVE ELECTRICAL POWER SUPPLY
Before servicing and maintenance work on electrical components (e.g. clamping box) it must be
assured that no parts are live and they must be secured against the power being switched on
again!
Before loosening the electrical connections the clamps must be tested with a voltage tester to
ensure that they are not live.

Single belt press EBP580
Version: 166000000, M0017267B_EN208-240-60D
Date: 28.11.2017 - 9 / 52 -
1.5.2 Normal Operation
NOTE!
Avoid working methods that are not clear from a safety aspect!
Make all required settings to the machine/line so that can work under reliable and safe operating
conditions!
The machine/line may only be operated when all safety devices and safety equipment is available
and functional, such as e.g.:
- emergency stop button - safety switches
- two hand operation (dead man's switch) - personal safety equipment
- protective covers
WARNING AGAINST GENERAL DANGERS
Check the machine/line before each start up for externally visible damage or defects! All changes
(including any changes made to the Operator's Manual) must be reported without delay to the
responsible person or the Customer Service Dept.
The machine/line is to be stopped immediately and secured against being started up again!
In the event of malfunctions the line/machine must be shut down immediately and locked!
Ensure that immediate and professional trouble shooting of the malfunctions is carried out!
Observe the switching on and off procedures and compare the controls indicators with the data
provided in the documentation/Operating Manual!
Observe the notices on the machine/line!
Before starting up the machine/line it must be ensured that no person will be endangered!
Do not remove any safety covers while the machine/line is in operation!
Moving mechanical parts must never be touched!
Use no fuses that do not comply with the required fuse protection! In the event of a fault in the
power supply machine/line must be switched off immediately!
In order to assure an operation free from interruptions the machine/line and the area around it must
be kept clean and tidy
and adequate lighting must be provided.
Before starting normal operation a safety test of all functional groups and safety equipment must be
carried out!

Single belt press EBP580
Version: 166000000, M0017267B_EN208-240-60D
Date: 28.11.2017 - 10 / 52 -
1.6 Safety devices
The machine/line may only be used either in the course of normal operation or in servicing/repair operation when all
required safety devices are used and are effective.
the following safety regulations have been introduced in order to reduce the remnant risk from the machine/line to an
absolute minimum:
-The Operating Manual describes the sources of risk and the orderly behavior of the
operating, servicing and repair personnel.
-Notices on the machine/line marking sources of risk!
e.g.:
Picture 1.6-1) Caution live voltage!
HINWEIS!
The safety devices must not be left aside nor made in effectual.
Where this is not assured no liability can be accepted.
safety devices must be checked monthly.
Notices must be easy to recognize.
Electrical safety devices
WARNING AGAINST GENERAL DANGERS
All electrical safety devices must be connected and functional at all times.
they must not be electrically bridged!
Before quitting any activated safety devices it must be ensured that no persons are in the danger
areas.
The electrical safety devices include for example:
- main switch
- emergency stop-switch and button
- energy supply cables
- any operator controls and control stands if these are provided

Single belt press EBP580
Version: 166000000, M0017267B_EN208-240-60D
Date: 28.11.2017 - 11 / 52 -
Mechanical safety devices
WARNING AGAINST GENERAL DANGERS
All safety devices must be firmly fixed!
It must only be possible to remove them with the use of tools!
The possibility of loosening them manually is not permitted!
Protective devices may only be removed for the period of maintenance and servicing! The
machine/line must be secured against a starting up in unsecured condition!
The mechanical safety devices include for example:
- safety clothing
- railings and barriers
- protective grids
- covers on moving parts

Single belt press EBP580
Version: 166000000, M0017267B_EN208-240-60D
Date: 28.11.2017 - 12 / 52 -
1.7 Remnant risks
Reasonably foreseeable, incorrect
use/risk
Remnant risk
Measures
Not maintaining of the safety
regulations, as described in the
documentation or the Operating
Manual
Any failure of safety
devices, all forms of risk
possible
Additional note on the machine/line about the
observation of specified safety regulations
Servicing and maintenance work on
the machine/line, while it is not in a
safe condition, e.g. the mains
electricity has not been switched off,
etc.
All forms of risk possible!
For operator training see Operating Manual
Not observing the safety measures in
setting up the machine/line
All forms of risk possible,
e.g. loose mechanical
parts
For operator training see Operating Manual
Catching of clothing in moving
mechanical parts during servicing or
repair work
All forms of risk possible!
Starting up of the machine/line only with
assembled safety covers;
Regulation clothing, operator training
Standing beneath hanging loads
The endangering of the
ground personnel is
possible from falling
loads
Wear safety helmets; observe safety notes for
servicing and repair work; staff training
Neglect of personal protection
equipment in normal operation and
servicing and maintenance work
All forms of danger to
staff are possible!
For operator training see Operating Manual;
use personal protection equipment if required,
but without fail if this is required by the
protection regulations! (gloves, facial protection
and earmuffs, protective helmet etc.)
Straining the body through incorrect
manual lifting
Permanent damage to
the spine and joints of
the hand
Use of suitable permitted lifts
Risk areas
Risk areas must be constantly marked by means of warning plates, coloured markings or other clear indicators.
WARNING AGAINST GENERAL DANGERS
- The presence of persons during operation in risk areas
is prohibited!
-A functional test of all
safety devices must be carried out before re-starting of line!
-It must be assured before switching the main switch and the control power,
that there are no persons in the risk areas.

Single belt press EBP580
Version: 166000000, M0017267B_EN208-240-60D
Date: 28.11.2017 - 13 / 52 -
1.8 Correct use
This machine/line is intended and constructed for the following use in full compliance with the contractual terms:
INFORMATION!
The press may only be used for the pressing of fruit, vegetables and herbs that contain juices.
The stones must be removed from all stone fruit, unless the stones are no bigger than cherry pits
and do not have sharp edges (danger of breaking screen belt).
Any other use of this machine/line represents an improper use of the machine/line.
The correct use of this machine/plant to terms of the contract requires further that the documentation/Operating
Manual as also the specified inspection and servicing intervals are strictly adhered to.
Although this machine/plant has been constructed to the highest technical standards and the recognised standards of
safety and has been accepted by the client, danger of injury or of loss of life may none-the-less arise for the user or
third persons as a result of its use, or the machine/line may itself be damaged.
The machine/line may only be operated when in a technically perfect condition, in a professional manner and when
the operator is fully aware of the safety and danger aspects.
Recognized weaknesses or faults that may reduce the safety of operation, must be dealt with in a professional
manner immediately or must be reported to customer service in a manner that can be proven!
Changes must not be made to the machine/line settings values.
WARNING AGAINST GENERAL DANGERS
This machine/line was constructed to the current standards of engineering and the currently
applicable Safety of Machinery Directive (MSV) .
Non-observation of the safety regulations contained in the Operating Manual during operation
of the line/machine can endanger the operating staff or third persons or have a detrimental
effect on the line/machine or its properties.
1.9 Inappropriate use
WARNING AGAINST GENERAL DANGERS
Any use of this machine/line other than that as defined in the chapter "Correct Use", represents an
inappropriate use of the machine/line and can result in serious injuries of the operating staff or third
persons or to the damage or destruction of the line/machine.
The manufacturer/supplier cannot be held liable for any damage resulting from an inappropriate use of
the machine/line.
In such cases the user assumes full liability.

Single belt press EBP580
Version: 166000000, M0017267B_EN208-240-60D
Date: 28.11.2017 - 14 / 52 -
1.10 Training record
Line/machine:
Trainer:
Date of training:
Place of training:
Training content:
Participant confirmation
Name of participant
Signature of participant (you confirm with your signature that you
have understood the training in special safety measures)

Single belt press EBP580
Version: 166000000, M0017267B_EN208-240-60D
Date: 28.11.2017 - 15 / 52 -
2 Technical data
2.1 Technical data - overall machine/line
Picture 2.1-1) Full view of the single belt press EBP580
rated power
up to 1000 kg
speed of belt
2,1 –5,5 m/min
processing time
0,6 –1,6 min
application width
240 –460 mm
application height
10 –50 mm
width of belt
580 mm
weight
665 kg
Sound power level EN ISO 3746
LWA < 80dB
Drive motor
Drive type
Helical-bevel geared motor
Voltage
230/400V 50HZ IP56
Capacity
0,75 kW
Rotary speed
1400
Transmission
i=151
Pneumatic system
The press is provided with a manometric switch that switches the press off when the working pressure
of the press is too low, or that makes it possible to first switch on the machine when a minimum
operational pressure has been reached.
This serves to protect the machine against damage.
When the pressure is too low the belt tenser and the diagonal run regulation no longer work.
NOTE!
You will find further information on the setting of the pressure regulator in the chapter
"Controls and settings work before first starting up/re-starting of line"!

Single belt press EBP580
Version: 166000000, M0017267B_EN208-240-60D
Date: 28.11.2017 - 16 / 52 -
3 Transportation and setting up of the machine/line
3.1 Notes on transportation
NOTE!
- Before transporting the machine/line the motor is to be switched off and the
mains connector plug must be pulled out!
- The machine/line must not be tipped!
- In order to avoid transportation damage assemble any available
transport securing devices.
- Secure the machine/line in an orderly manner on the means of transport!
- Observe the statutory requirements (StVO) for legally specified dimensions or mark the load!
A forklift with a lifting capacity in compliance with the table given below is required for the unloading of
the machine.
Before unloading the machine must be checked for any transportation damage, this is to be recorded
in the delivery certificate and reported to the Customer Service Department.
Ensure that the machine is not damaged by knocking it or setting it down too quickly in the course of
the manipulation.
Picture 3.1-1) Transport single belt press EBP 580
F1 load on the means of attachment
6650 N oder 665 kg
F2 foundation load
3400 N/m² oder 340 kg/m²
1
Foundation fixture
2
Transport pallet
3
Reception point on the forklift
WARNING AGAINST GENERAL DANGERS
A crane or forklift stacker with a lifting capacity in compliance with the table given
below is required for the unloading of the machine.
Means of attachment (rope, chain, belt) should be fixed only to the lifting points
provided!
The lifting accessories used must be adequate for dealing with the load as given
(See table above and nameplate on notice)!
The machine must be secured during transportation by belts or on a pallet bolted.

Single belt press EBP580
Version: 166000000, M0017267B_EN208-240-60D
Date: 28.11.2017 - 17 / 52 -
3.2 Notes on assembly
WARNING OF DANGEROUS LIVE ELECTRICAL POWER SUPPLY
The Power connection must not come into contact with water!
Not observing this requirement can lead to serious injury or to death!
NOTE!
- A 4-pole connection must be available as a minimum (3 phase and grounding)!
- Only use connection pipes of at least 4 x 2,5 mm².
- Mobile devices that are used in the open air must be connected with minimum
operational current switch protection (FI). If this not possible, the machine must be
separately earth.
The centrifugal crusher may only be connected to 208-240V cables that are secured with a
capacity protection switch 16 A.
- The water pipes must be permanently protected against frost!
Electricity supply
Three-phase current 208 - 240 V (3 phases + earthing)
Fuse protection 16 A neutral
Water supply for belt cleaning
a) For high-pressure cleaners supplied by Voran (Kärcher type HD 7/18 C):
Water supply pipe 3/4" with a reduced connection to 1/2" external thread
b) For high-pressure cleaners supplied by the customer:
a continuously sustained high-pressure cleaner with a working highest pressure of at least 180 bar and a
supply performance of 500 l.
The water supply pipe dimensions must be compliant with the high pressure cleaner operating manual.
The water supply pipe must without fail be provided with a to prevent a blocking of the cleaning jet with
sand or sediment.
The press is provided with a standard high-pressure connection M22 x 1.5 mm external thread.
NOTE!
The water pipes must be permanently protected against frost!
NOTE!
There’s no separate light mounted on the unit.
The licensee is responsible for adequate light based on national requirements for workplace layout!

Single belt press EBP580
Version: 166000000, M0017267B_EN208-240-60D
Date: 28.11.2017 - 18 / 52 -
The following measures must be undertaken before starting up:
Picture 3.3-1) Assembly of connections [single belt press EBP 580]
➢Polokal pipes D = 70 mm nominal value (Fig. Pos.2) for belt cleaning waste water.
NOTE!
- Before you connect the unit to the sewer, you have to talk with your regional sewer contractor!.
➢Connect the washing machine to the safety switch (Fig. Pos.3).
Compressed air supply
The compressor must have a maximum pressure of 10 bar and a supply capacity of 100 l/min.
The compressor is set to a cutting-off pressure of maximal 8.5 bar and this must on no account be
increased by the customer.
NOTE!
The membrane switch responsible for the dosing settings in the dosing box may be
connected either to the Voran Washing Machine with fully automatic dosing or to an
own line.

Single belt press EBP580
Version: 166000000, M0017267B_EN208-240-60D
Date: 28.11.2017 - 19 / 52 -
4 Starting up / re-starting of the machine/line
4.1 General
NOTE!
−Before starting up and before each restart, the complete unit and all devices must be
efficient cleaned.
−For cleaning just use the specified and preferred agents (chapter 9.5.1)
−If you should use other cleaning agents the responsibility, suitability and right usage of them
belongs to the licensee.
WARNING AGAINST GENERAL DANGERS
The operator must ensure, just to handle materials which aren’t capable, also especially during the
milling process, to create ignitable substances (fluids, aerosol, steam, explosive dust atmosphere,
etc.)!
NOTE!
The machine/line and all machine/line components must be checked by a specialist
−before starting up and before re-starting after significant changes.
4.2 Mounting belt lug
For transport, the belt lug of the belt regulation is disassembled and is in the control cabinet of the machine.
For mounting the belt lug look at picture Picture 4.1-1.
Piece
Name
Part nr.
2
Belt lug 3x61x181
10035699
Picture 4.1-1) Mounting belt lug

Single belt press EBP580
Version: 166000000, M0017267B_EN208-240-60D
Date: 28.11.2017 - 20 / 52 -
4.3 Controls and settings work before first starting up/re-starting of line
Check the machine/line for loose parts (e.g. forgotten tool)!
Check all cable connections (clamp and plug connections) as also all pneumatic pipelines of the
machine/line. Pay particular attention to damaged and loose cable and connections (see illustration)
Check that the required safety devices have been placed in an orderly manner and are intact!
(see the chapter "Safety devices")
WARNING AGAINST GENERAL DANGERS
Before cleaning the device or checking the connection cable, to see if this has been
twisted or damaged, switch the machine off
without fail and pull out the mains connector plug!
Picture 4.2-1) Symbol image, control cable and connector point
Changes in comparison with normal operation such as
- higher capacity feeding
- higher noise development
- higher acceleration or delay, higher vibration amplitudes
- unusual noises or unusual smells
- response of the safety devices without a motivational cause
are grounds for recognizing that the function of the line/machine is impaired.
Detrimental effects such as this or similar are to be immediately reported by the operator to the person
responsible.
Optische_Kontrolle_Kabel_Leitungen_1PSM
