VOX® POWER DRAWER & EDGE BUILD UP
INSTALLATION GUIDE
SUGGESTED MINIMUM CREW: 2
APPROXIMATE INSTALL TIME: 30 Min
TOOLS REQUIRED:
Ratchet
1/2” Socket
1/4” Socket / Wrench
5/16” Socket / Wrench
4mm Hex Key
Philips Screwdriver / Driver
HARDWARE:
5/16”-18 X 2 1/2”
Hex bolt
6-32 Nut
6-32 x 3/8”
Pan Head
Mach. Screw
#8 x 1/2”
Pan Head
Wood Screw
#8 x 5/8”
Pan Head
Wood Screw
1/4”-20 x 7/8”
Joiner Bolt
With table upside down on a protective surface place
edge build up in place and secure using 5/16”-18 x 2
1/2” hex head bolt & washer. Repeat for all build ups.
Attach slides by clipping slide into back of drawer and
securing with #8 x 1/2” black pan head, phillips drive
wood screws.
For Power Drawers with typical plug in power cords,
mount starting link of power chain horizontally to
drawer using 6-32 x 3/8” pan head machine screws
and 6-32 nuts.
For Power Drawers with hardwire cabling, mount
starting link of power chain vertically to drawer using
6-32 x 3/8” pan head machine screws and 6-32 nuts.
1/4”-20 x 7/8”
Joiner Bolt

Customer Support: 1.800.668.9318
Email: [e-mail]
Web: www.nienkamper.com
VOX® POWER DRAWER
INSTALLATION GUIDE
Power chain orientation for standard cable and plug
power drawers.
Power chain orientation for hardwired power drawers.
Using 1/4-20” x 7/8” joiner bolts, mount assembled
drawer unit in place.
Caution- the drawer can slide open during installation.
Take care of this when handling.
For standard cable and plug installations, the power
chain is fixed to the bottom of the table with #8 x 5/8”
pan head, phillips drive wood screws.
Snap either hardwire or standard wire into first
link of power chain that has been mounted to
the drawer. Push cable into top of full length
of power chain. Snap length of chain into the
mounted starter link .
end mounts to drawer
end mounts to table
end mounts to table
note: additional bracket and
hardware will be added to this
assembly- see steps to follow
for details
end mounts to drawer

Customer Support: 1.800.668.9318
Email: [e-mail]
Web: www.nienkamper.com
VOX® POWER DRAWER
INSTALLATION GUIDE
For power drawers that are hardwired, an additional 90 degree bracket and hardware will be supplied. Simply, mount the bracket
to the end of the power chain using 6-32 x 3/8” pan head, phillips drive machine screws and nuts. Allow wire to take a natural “U”
shape bend and attach the bracket to the underside of the top approximately 6” - 10” from the closed drawer using #8 x 5/8” pan
head phillips drive wood screws.
power drawer
power chain
hardwire cable
90 degree bracket
THIS IS A GENERAL ASSEMBLY GUIDE, NOT ALL CONDITIONS MAY APPLY TO YOUR
PARTICULAR INSTALLATION.
