Vpc 9025 User manual

9025/ 9025TR USER MANUAL

07/11/2022

INDEX (CLICK TO NAVIGATE TO PAGE)

PAGE

PRECAUTIONARY NOTES

INSTALLING  RACK MOUNT RECEIVER

INSTALLING  WITH VERTICAL HINGED MOUNTING FRAME

 INSTALLING TR WITH SLIDE KIT

INSTALLING  WITH SLIDE KIT

SLIDE MOUNT NOTATION REGARDING U HEIGHT

INSTALLING INSTRUMENT BRACKET

 INSTALLING KEYBOARD TRAY

 INSTALLING CABLE TRAY

 MOUNTING TR TABLETOP RECEIVER

 REMOVING TR PLATFORM

 REINSTALLING TR PLATFORM

 TR HANDLE ROTATION & SIDE CHANGE

 MICROSWITCH REMOVAL & INSTALLATION

 ITA ENCLOSURES

 ITA & RECEIVER ENGAGEMENT

 TROUBLESHOOTING

Please note that any printed or downloaded User Manual may not reflect the most current revisions.

The information contained herein is subject to change.

For the most current information available, visit vpc.com.

 USER MANUAL VPC

07/11/2022

For more information visit vpc.com

RETURN TO INDEX

The following is a listing of precautionary notes that should be noted and followed for optimal equipment operation.

• Never probe a contact without using a mating patchcord as a test lead.

• Never forcefully engage a system if there is an excessive amount of resistance.

• Never allow an ITA to drop as this may cause misaligned engagement and/or irreparable damage.

• Always insert and extract a contact insertion/extraction tool in line with the contact. Never apply pressure to the side as this may break either contact or

tool. This also applies to forming and enlarging tools.

• It is advisable that power to the interface system be disconnected prior to handling and maintenance.

• Caution should always be used when engaging, making sure that all foreign objects are removed from the system.

• To prevent equipment damage caused by inadvertent contact being made with the system when not in use; such as bumping into the receiver/ITA

assembly with a box, chair or electronic equipment; for example, using ITA and receiver protective covers is highly recommended.

PRECAUTIONARY NOTES

FORCEFUL ENGAGEMENT OF THE ITA AND RECEIVER MAY RESULT IN

SERIOUS DAMAGE TO MULTIPLE PARTS OF THE SYSTEM (MODULES,

RECEIVER, ITA AND CONTACTS).

IN THE EVENT OF OPERATIONAL DIFFICULTIES, A TRAINED VPC

TECHNICIAN SHOULD BE NOTIFIED TO AVOID ANY POTENTIAL

DAMAGE TO THE SYSTEM FROM IMPROPER HANDLING.

 USER MANUAL VPC

07/11/2022

For more information visit vpc.com

RETURN TO INDEX

INSTALLING  RACK MOUNT RECEIVER

PART #   ,   ,   

TOOLS REQUIRED

Phillips Head Screwdriver

INSTALLATION INSTRUCTIONS

1. Install clip/cage nuts on rack, to correlate with mounting holes and

captive screws on receiver.

2. Place receiver up to clip/cage nuts on rack, making sure they are

aligned (Figure A).

3. Tighten captive screws in a cross pattern to ensure even torque is

applied.

Figure A. Mounting 9025 Receiver.

 USER MANUAL VPC

07/11/2022

For more information visit vpc.com

RETURN TO INDEX

INSTALLING  WITH VERTICAL HINGED MOUNTING FRAME

PART #   ,   ,   ,   

TOOLS REQUIRED

Phillips Head Screwdriver

/32 Allen Wrench

INSTALLATION

1. Using the 4 receiver mounting holes, attach the receiver to the Vertical

Hinged Mounting Frame (VHMF) with the 10-32 x 1” captive screws, lock

washers, and hex nuts included with the VHMF (Figures A and B).

2. Determine an appropriate location in the rack to mount the VHMF and

receiver. Keep in mind that the cables connecting to the receiver need to

be long enough to allow the VHMF to hinge down.

3. Attach the VHMF to the rack in the desired location using the four 10-32 x

1” mounting screws (Figure C). Tighten screws in a cross pattern to ensure

even torque is applied.

4. When not in use, ensure that the receiver handle is closed and the VHMF is

in the closed position, secured with the two 8-32 screws (Figure D).

Figure A. Receiver assembled with VHMF.

Figure B. Attach receiver to VHMF using provided hardware.

Figure C. Attach the VHMF to the rack.

RECEIVER

VERTICAL HINGED

MOUNTING FRAME

1/4 TURN LATCHES

MOUNTING HOLE

TYP. 4 PLCS.

4 PLACES EACH

MOUNTING HARDWARE

VERTICAL HINGED

MOUNTING FRAM

10-32 X 1" MOUNTING SCREWS

TYP. 4 PLCS.

(CLOSED POSITION)

RECEIVER HANDLE

8-32 SECURING SCREWS

Figure D. Screws secure receiver to rack when not in use.

 USER MANUAL VPC

07/11/2022

For more information visit vpc.com

RETURN TO INDEX

TOOLS REQUIRED

Phillips Head Screwdriver

/32 Allen Wrench

DETERMINE SLIDE KIT LENGTH

1. The slide kit should be chosen based on the distance from rail to rail inside the

rack. Measure dimension A to determine the proper slide kit length, ensuring

the slide length does not exceed dimensions A + B (Figure A).

SLIDE INSTALLATION

1. Determine rack location to mount slides and receiver. Cables will need to be

long enough to connect to instrumentation and allow for the slides to fully

extend without putting tension on the cables.

2. Install slides using manufacturer’s instructions (included with slide packaging

or online at accuride.com). Make sure to use mounting holes in matching

locations on each side. Do not fully tighten down the 4 front and 4 rear

mounting screws at this time (Figure B).

4. Remove the innermost section of each slide by extending the slides fully,

depressing the blue tab, and continuing to extend the inner sections of each

slide until it is free from the slide assembly (Figure C).

5. If applicable, install the instrument bracket or cable tray onto the inner

sections of the slide kit. Following the instrument bracket and/or cable tray

Installation instructions also in this manual.

Figure A. Dimensions for measurement.

SLIDE

RELEASE TAB

INNER SLIDE

Figure C. Remove inner section of slide from assembly.

Figure B.

INSTALLING TR WITH SLIDE KIT

PART #   ,   ,   ,   

Dimensions shown: [millimeters]

inches

10-32 X 1" MOUNTING

SCREW

2 TYP. EACH SIDE

TR INSTALLATION

1. Replace each inner slide back into the slide assemblies in the rack.

2. Attach the platform mounting flanges to the inner slide rails using the (6)

8-32 button head screws provided with the receiver (Figure D). Do not fully

tighten down the screws.

3. Install the 9025TR platform/receiver onto the platform mounting flanges

with the (6) 8-32 screws (Figure E). Do not fully tighten down the screws.

4. Pull the receiver out as far as possible. The slides will lock in position. Push

the blue tabs located on the middle section of the slides. Apply pressure to

push the receiver back in toward the rack. The smaller inner slides move

into the middle section, which should not move. Push receiver until it

backs against the rack.

NOTE: The receiver platform is estimated to hold 180 lbs. of weight.

However, the platform leg kit, is recommended to provide greater

stability and balance. The leg kit will allow for weight support of up to

350 lbs. The leg kit may be purchased via p/n 310113566.

 USER MANUAL VPC

07/11/2022

For more information visit vpc.com

RETURN TO INDEX

ALWAYS SUPPORT THE RECEIVER AND PLATFORM

WITH THE MOST ROBUST (MIDDLE) SECTION OF THE

SLIDES.

9025TR RECEIVER 9025TR PLATFORM

8-32 X .62"

FLAT HEAD SOCKET SCREW

TYP. 6 PLCS.

CAPTIVE 10-32

PANHEAD SCREWS

TYP. EACH SIDE

Figure E. Install 9025TR onto platform mounting flanges.

Figure D. Attach platform mounting flanges to the inner slide rails.

Figure F. Secure the receiver to the rack with the captive 10-32 screws,

taking care to li up on the platform slightly to ensure even engagement.

INSTALLING TR WITH SLIDE KIT (CONT’D)

PART #   ,   ,   ,   

5. During regular use of the 9025TR, when not extended away from the

rack on the slides, the user should secure the receiver to the rack.

This prevents the unit from uncontrolled slide motion. To ensure the

receiver is correctly aligned with mounting hole locations on the test

rack, temporarily fasten the receiver to the rack using its captive 10-

32 screws. Be sure to provide support beneath the platform, liing it

slightly to ensure an even screw engagement (Figure F).

6. Now, complete installation by fully tightening the previously

installed screws in this order:

1. 8-32 platform mounting screws ( Figure D).

2. 8-32 button head platform mounting flange screws (Figure C).

3. Front slide mounting screws (from slide mounting procedures).

4. Rear slide mounting screws (from slide mounting procedures).

7. With the remaining installation screws now secure, you may release

the receiver and platform from the rack by unscrewing the 10-32

captive screws. Slowly slide the receiver out.

8. To ensure proper support when extending the receiver and platform

away from the rack, stop the receiver and platform at approximately

6” from the rack.

9. Reach around to the rear of the receiver to the slides underneath on

both sides. Manually extend the middle section of the slides forward

until fully underneath the platform. The receiver and platform

may then be extended while holding this middle slide in place. If

completed properly, the middle section of the slides will remain

underneath the platform and oer the strongest support.

 USER MANUAL VPC

07/11/2022

For more information visit vpc.com

RETURN TO INDEX

Figure A.

INSTALLING  WITH SLIDE KIT

PART #   ,   ,   ,   ,   

Dimensions shown: [millimeters]

inches

SLIDE

RELEASE TAB

INNER SLIDE

Figure C. Remove inner section of slide from assembly.

Figure B. Slides installed into rack.

10-32 X 1" MOUNTING

SCREW

2 TYP. EACH SIDE

TOOLS REQUIRED

Phillips Head Screwdriver

/32 Allen Wrench

DETERMINE SLIDE KIT LENGTH

1. The slide kit should be chosen based on the distance from rail to rail inside the

rack. Measure dimension A to determine the proper slide kit length, ensuring

the slide length does not exceed dimensions A + B (Figure A).

SLIDE INSTALLATION

1. Determine rack location to mount slides and receiver. Cables will need to be

long enough to connect to instrumentation and allow for the slides to fully

extend without putting tension on the cables.

2. Install slides using manufacturer’s instructions (included with slide packaging

or online accuride.com).Make sure to use mounting holes in matching

locations on each side. Do not fully tighten down the 4 front and 4 rear

mounting screws at this time (Figure B).

4. Remove the innermost section of each slide by extending the slides fully,

depressing the blue tab, and continuing to extend the inner sections of each

slide until it is free from the slide assembly (Figure C).

5. If applicable, install the instrument bracket and/or cable tray onto the inner

sections of the slide kit. Following the instrument bracket and/or cable tray

Installation instructions also in this manual.

 USER MANUAL VPC

07/11/2022

For more information visit vpc.com

RETURN TO INDEX

Figure D. Be sure the mounting surface of the flange is facing out.

Figure E. Seen here with optional instrument bracket installed.

Figure F. Seen here with optional instrument bracket installed.

8-32

FLAT HEAD SOCKET SCREW

TYP. 8 PLCS.

9025 RECEIVER

INSTALLING  WITH SLIDE KIT (CONT’D)

PART #   ,   ,   ,   

 INSTALLATION

1. Attach each receiver mounting flange to the appropriate slide using the

provided (3) 8-32 button head screws, per side. Ensure that the mounting

surface portion of the flange is directed toward the outside of the overall

assembly (Figure D).

2. Re-install the inner slide assembly into the rack by aligning each inner slide

with the slide assembly in the rack (Figure E). With the inner section inserted

into the center section of the slide assembly, push the mounting flanges

toward the rack, collapsing the slides. It may be necessary to depress the

locking tabs, if the slides are locked in the extended position.

3. Slide the assembly out to enable access to the mounting flanges.

4. Using the provided (8) 8-32 flat head screws, attach the receiver to the

mounting flanges (Figure F).

NOTE: When moving the rack or attaching an ITA, ensure the slides are fully

collapsed and receiver is secured to rack with .190-32 UNF screws.

 USER MANUAL VPC

07/11/2022

For more information visit vpc.com

RETURN TO INDEX

SLIDE MOUNT NOTATION REGARDING U HEIGHT

PART #   ,   ,   

With certain receivers including the 9025/ 9025TR, the slide mechanism protrudes downward slightly into the next U height on

both sides of the receiver. Please make any necessary adjustments to U height when planning your test rack layout.

Measurements can vary per receiver, see table.

 USER MANUAL VPC

07/11/2022

For more information visit vpc.com

RETURN TO INDEX

INSTALLING INSTRUMENT BRACKET

PART #   

NOTE: This instrument bracket is only compatible with slide kits 28” and longer.

TOOLS REQUIRED

5/32 Allen Wrench

Phillips Head Screwdriver

INSTALLATION

1. Depress the blue tab on one of the inner slides and remove from outer

slide.

2. Attach it to the instrument bracket using (2) 8-32 button head screws

in the front two holes. The front two holes on the instrument bracket

will align with the front two holes on any length slide kit.

3. Install the third 8-32 button head screw in the rear hole of the inner

slide and instrument bracket. (Figure A) The third hole alignment may

dier depending on which slide kit you are using.

4. Attach the remaining inner slide to the other side of the instrument

bracket.

5. Reinstall the inner slides to the rack installed slides.

• Slide the le mid-section of the slide all the way out, you will feel it

lock into position.

• Feed the matching inner slide into position and ensure the inner

section slides into place with the roller bearings seated in the

groove.

• Push the inner slide in about 6-8 inches and then pull out the right

side. Slide the track of the mid-section over the right side of the

inner slide.

• Pull the slide out until the position matches the le side.

• Reach to the back of the middle slides and release the spring

locking mechanism (Figure B).

6. At this time, both sides should be partially installed. This is indicated

when neither side is able to proceed into the rack because the support

tab on the instrument brackets is hitting the slide mounting bracket.

7. Rotate both instrument brackets inward so the support tabs can pass

the mounting brackets. Push and install both slides simultaneously

into position. Be sure to push in the blue tabs to allow the inner tabs to

travel into the middle slide section.

NOTE: The middle section will not go into the outer section until the

inner section has been fully installed into the middle section.

8. Tighten the slide mounting screws.

FRONT TWO HOLES

ALIGN UNIVERSALLY

ON ALL SLIDE LENGTHS

Figure A. Shown here, 30” slide kit (Part # 310 113 411).

The slots on the instrument bracket are designed to accept a strap for

securing a test chassis, if desired.

Figure B. Spring-locking mechanism.

MAKE SURE ALL MOUNTING SCREWS HAVE

BEEN SECURELY TIGHTENED. ONLY USE

- BUTTON HEAD SCREWS.

 USER MANUAL VPC

07/11/2022

For more information visit vpc.com

RETURN TO INDEX

INSTALLING KEYBOARD TRAY

PART #   

NOTE: The Keyboard Tray Kit mounts below the platform on the

slide-mounted 9025TR receiver. The kit includes a keyboard with

touch pad and 72" long USB connector, keyboard tray, and 12"

slides.

MOVEMENT

12 INCH SLIDE

1.2

[30.48]

KEYBOARD WITH TOUCHPAD

KEYBOARD TRAY

12 INCH SLIDES

MOUNTING BRACKET, RIGHTMOUNTING BRACKET, LEFT

USB KEYBOARD

CONNECTOR.

RUBBER GROMMET

13.0

[330.2]

13.3

[337.82]

28.4

[721.36]

Figure A.

TOOLS REQUIRED

3/32 Allen Wrench

Dimensions shown: [millimeters]

inches

 USER MANUAL VPC

07/11/2022

For more information visit vpc.com

RETURN TO INDEX

INSTALLING KEYBOARD TRAY (CONT’D)

PART #   

Figure A.

INSTRUCTIONS

1. Attach the keyboard mounting brackets to the existing platform

mounting brackets using with the supplied 8-32 flat head

screws, nuts, and lock washers. Align the keyboard mounting

brackets with the 3 screws that extend beyond the platform

mounting bracket (Figure A).

2. Use 6 of the 8-32 x .38 button head screws to attach the 12"

keyboard kit slides to the inner side of the keyboard brackets.

The manufacturer stamped identification on the slides should

be placed toward the rack. Fully extend the keyboard slides to

access the hole locations (Figure B).

3. Insert the keyboard into the keyboard tray. Wrap the plastic

strain relief around the cable near the back of the keyboard and

press into the hole provided on the keyboard tray.

4. Fully extend the 12” slides and mount the keyboard tray (Figure

C). Floating, self-locking fasteners in the keyboard mounting

brackets prevent the screws from backing out. This creates a

noticeably snug fit when tightening the screws.

Figure B. Fully extend the keyboard slides to access the mounting holes for the self-

locking fasteners.

Figure C. The dierent hole patterns allow for variations in the overall position of the

keyboard.

PLATFORM MOUNTING BRACKE

MOUNTING BRACKET, LEFT

SUPPLIED 8-32 SCRE

LOCKING WASHER, AND NU

BOTTOM VIEW

SELF-LOCKING FASTENERS

BOTTOM VIEW

 USER MANUAL VPC

07/11/2022

For more information visit vpc.com

RETURN TO INDEX

INSTALLING CABLE TRAY

PART #   

NOTE: The cable tray only works with slide kits 28” and longer. Cable trays cannot be

used in conjunction with instrument brackets.

INSTRUCTIONS

1. Loosen the slide mounting screws by one turn.

2. Depress the blue tabs and remove the inner slides.

3. Attach the cable tray to the inner slides with the provided 8-32 screws (Figure A).

The angled side of the cable tray should face the receiver.

4. Reinstall the inner slides and cable tray assembly into the rack.

5. Retighten the slide mounting screws.

Figure A.

TOOLS REQUIRED

3/32 Allen Wrench

 USER MANUAL VPC

07/11/2022

For more information visit vpc.com

RETURN TO INDEX

MOUNTING TR TABLETOP RECEIVER

PART #   

NOTE: The 9025TR Tabletop Receiver includes a rear cover to protect receiver side wiring and a

“skirt” to allow for suicient rotation of the handle.

PERMANENT MOUNTING

1. Prepare the mounting surface using the following dimensions:

• Receiver without rear cover installed- drill 0.257” [6.53 mm] minimum thru holes

(Figure A).

• Receiver with rear cover installed- drill 0.196” [4.98 mm] minimum thru holes

(Figure B).

2. Secure the receiver skirt to the mounting surface with the provided ¼-20 x 1.00 screws,

washers and nuts.

3. Use the /32 Allen wrench with the provided #8-32 screws and washers to attach the included

rear cover to the receiver.

4. Secure the rear cover to the mounting surface with the provided 10-32 x .375 screws,

washers and nuts (Figure B).

Figure A. Receiver without Rear Cover Installed.

184.15

7.25

368.30

14.50

492.76

19.40

Dimensions shown: [millimeters]

inches

Figure B. Receiver with Rear Cover Installed.

11.43

.45

123.83

4.88

219.08

8.63

314.33

12.38

37.19

1.46

197.76

7.79

197.76

7.79

37.19

1.46

 USER MANUAL VPC

07/11/2022

For more information visit vpc.com

RETURN TO INDEX

8-32 x .625" PLATFORM

MOUNTING SCREWS

REMOVING TR PLATFORM

PART #   

TOOLS REQUIRED

5/32 Ball End Allen Wrench or Ball Driver

Phillips Head Screwdriver

Zip Ties

REMOVAL INSTRUCTIONS

1. Secure receiver to rack using the captive 10-32 mounting screws

(Figure A). The platform should only be removed from the receiver

aer the receiver has been secured to the rack.

2. Remove any optional accessories including keyboard tray, leg kit and

instrument bracket.

3. Remove the torsion sha cover by removing the two flat head Phillips

screws on each end and the three pan head Phillips screws in the

center of the cover.

4. With the receiver secured to the rack, remove the (6) 8-32 mounting

screws from the bottom of the 9025TR to remove the platform

(Figure B).

5. Remove the 8-32 screws that attach the platform brackets to the

slides. The platform will now be free from the receiver and slides. The

platform brackets do not need to be removed from the platform for

transportation.

6. To secure the slides for transport, return the slides to the closed

position and use zip ties to secure the 3 sections of each slide.

KEYBOARD

TRAY KIT

INSTRUMENT BRACKET

TYP. EACH SIDE

10-32 X 1" MOUNTING SCREW

Figure A.

Figure B. The 6 mounting screws must be removed from the receiver before

the platform can be removed.

 USER MANUAL VPC

07/11/2022

For more information visit vpc.com

RETURN TO INDEX

REINSTALLING TR PLATFORM

PART #   

REINSTALLATION

1. Remove zip ties used to secure the slides.

2. Pull the slides out from the closed position.

3. Attach platform with brackets to the slides using the (6) 8-32

mounting screws (Figure C).

4. Attach the torsion sha cover by inserting the two flat head Phillips

screws on each end and the three pan head Phillips screws in the

center of the cover.

5. Slide the platform to the slide’s closed position and install the six 8-32

mounting screws to attach the platform to the 9025TR receiver.

6. Re-install any optional accessories.

7. Once the platform has been re-attached to the 9025TR and the slides,

remove the receiver from the rack by releasing the captive 10-32

mounting screws.

PLATFORM BRACKET

8-32 X .50" BRACKET MOUNTING

SCREWS TYP.

9025TR PLATFORM

Figure C. The brackets will be securely reinstalled to the slides aer the mounting

screws are installed.

 USER MANUAL VPC

07/11/2022

For more information visit vpc.com

RETURN TO INDEX

TR HANDLE ROTATION AND SIDE CHANGE

PART#   

NOTE: The 9025TR receiver handle requires approximately 90° of counter-

clockwise movement space for engagement and 90° of clockwise movement

space for disengagement of the ITA. The handle is removable and adjustable

to accommodate dierent mounting configurations and for transportation

purposes.

TOOLS REQUIRED

3/32 Allen Wrench

ROTATION

1. Remove the handle screw with a 3/32 Allen wrench.

2. Remove the handle and reposition in 90˚ increments (Figure A).

3. Replace the screw and tighten until the handle is secured tightly.

SWITCHING HANDLE SIDES

1. Using the 3/32 Allen wrench, remove the handle screw and handle (Figure B).

2. Using the 3/32 Allen wrench, remove the screw and handle washer on the le side

of the receiver (Figure B).

3. Install the handle into the le side hole at the preferred 90°position (Figure C).

4. Replace the screw and handle washer into the cavity on right side of the

receiver.

HANDLE CAN BE LOOSENED AND

ROTATED IN 90 DEGREE INCREMENTS

489.97

19.29

553.47

21.79

Dimensions shown: [millimeters]

inches

Figure A.

Figure B. Remove handle from standard right side.

Figure C. Install handle on le side.

OFFSET LINK

HANDLE WASHER

SCREW

 USER MANUAL VPC

07/11/2022

For more information visit vpc.com

RETURN TO INDEX

TOOLS REQUIRED

Phillips Head Screwdriver

REMOVAL

1. Disengage and completely remove the ITA from the receiver.

2. With the receiver handle in the open position (handle down), unscrew the

two plate retaining screws (using a Phillips screwdriver) that are located

immediately below the top right engaging mechanism/slot - this will expose the

microswitch.

3. Remove any modules necessary to access the microswitch retaining screws.

4. Using a Phillips screwdriver, unscrew the retaining screws. Caution should be

taken to ensure that no screws fall into the system.

5. The microswitch may now be removed for continuity testing or replacement.

INSTALLATION

Repeat above steps in reverse order.

AS WITH ALL ELECTRICAL SYSTEMS - DISCONNECT ALL

ELECTRICAL SUPPLIES TO THE SYSTEM PRIOR TO REMOVAL

OF THE MICROSWITCH.

MICROSWITCH REMOVAL AND INSTALLATION

PART #   

NOTE: A microswitch may be used in VPC receivers to determine the presence (or

absence) of an engaged ITA in the system. It is typically configured so that power to

the interface is turned o when there is no ITA present.

MICROSWTICH COLOR CODE:

Wires- 24 AWG

Red - Normally Closed

White - Normally Open

Black - Common

 USER MANUAL VPC

07/11/2022

For more information visit vpc.com

RETURN TO INDEX

ITA ENCLOSURES

PART #   ,   ,   ,   ,   

TOOLS REQUIRED

Front mount: 3/32” Allen Wrench for 4-40 screws

Rear mount: 7/64” Allen Wrench for 6-32 screws

Phillips Head Screwdriver

164.85

6.49

1.00

25.40

Dimensions shown: [millimeters]

inches

Parts of ITA enclosure contain ABS plastic.

Operating temperature

1. Enclosure: -55º C to 85º C

2. Handles: -50º C to 60º C

STANDARD ENCLOSURES

1. To mount ITA frame, align frame with enclosure.

2. Insert screws and tighten with Allen Wrench (Figure A).

• Torque 6-8 in. - lbs. for 4-40 screws (front mount)

• Torque 10 in. - lbs. for 6-32 screws (rear mount)

Figure A. Example shown -p/n 410112823

Front mount option

shown.

CUSTOMIZED 9025TR ENCLOSURES

1. When building a customized ITA enclosure, these guidelines

should be followed to ensure proper function of the 9025TR

Receiver:

• When mounting, the ITA frame must be flush with the

bottom of the enclosure

• The width of the enclosure may longer than the ITA frame,

as long as the extended width is oset to the opposite side

of the receiver’s engagement handle

• There is no limit to the height of the enclosure.

9025TR with Standard ITA Enclosure

 USER MANUAL VPC

07/11/2022

For more information visit vpc.com

RETURN TO INDEX

251

D D

Prior to engaging an ITA with the receiver for the first time, ensure all modules (ITA and receiver) are properly installed. This includes inspection of modules to

ensure proper mounting and to verify module positioning. Modules must be installed so that Pin 1 of each respective mating receiver and ITA module pair are

adjacent. VPC recommends that Pin 1 be positioned to the le in the receiver and ITA frames. All ITA modules must match the respective receiver modules. It is

crucial for all modules to be installed properly.

ENGAGEMENT

1. The receiver should be checked for any foreign objects that may interfere with engagement.

2. Aer inspection, the ITA is ready for engagement with the receiver. The ITA may be placed onto the receiver platform and properly positioned relative to the

receiver guide pins. Ensure that the ITA roller bearings are aligned with the receiver slide openings when the receiver handle is in the open position.

3. Carefully rotate the handle forward to actuate the receiver slide engagement mechanisms, which will draw the ITA into engagement position with the

receiver. Once the handle reaches a positive stop at the end of its travel and latches into place, the modules are engaged.

4. Upon completing use of the ITA, rotate the receiver handle to the open position, remove the ITA, reinstall the receiver protective cover and rotate the handle

to the closed position.

5. Always protect the contacts when the system is not in use. The receiver contacts are protected when either the ITA or receiver protective cover is engaged.
